MICRO-EPSILON FSC1/7 Manual de usuario

Operating Instructions

FSC1/7, FSC1000

MICRO-EPSILON

MESSTECHNIK

GmbH & Co. KG

Koenigbacher Str. 15

94496 Ortenburg/Germany

Phone +49 (0) 8542/168-0

Fax +49 (0) 8542/168-90

email [email protected]

www.micro-epsilon.com

Layer thickness measuring device for insulators on metal and

carbon fiber-reinforced plastics (CFRP)

FSC1/7, FSC1000

Contents

1. Safety ................................................................................................ 5

1.1 Symbols Used ................................................................................................... 5

1.2 Warnings............................................................................................................ 5

1.3 Notes on CE Marking ........................................................................................ 6

1.4 Notes regarding FCC Approval ......................................................................... 6

1.5 Intended Use ..................................................................................................... 7

1.6 Proper Environment........................................................................................... 7

2. Overview ........................................................................................... 8

2.1 Structure, Functional Principle .......................................................................... 8

2.2 FSC1/7 and FSC1000 Technical Data............................................................... 9

3. Delivery ........................................................................................... 10

3.1 Unpacking, Included in Delivery...................................................................... 10

3.2 Storage ............................................................................................................ 10

4. Initial Operation.............................................................................. 11

4.1 Dimensional Drawings..................................................................................... 11

4.2 Insert and Replace Battery Pack ..................................................................... 12

4.3 Connecting the Sensor.................................................................................... 13

5. FSC1/7 and FSC1000 Operation.................................................... 14

5.1 Switch-on Phase, Warm-up............................................................................. 14

5.2 General Controller Operation .......................................................................... 14

5.3 Measuring Program Start ................................................................................ 15

5.4 Setup, Parameters ........................................................................................... 16

5.5 Adjustment of the Measuring System ............................................................. 18

5.5.1 General ........................................................................................... 18

5.5.2 Load Adjustment Table................................................................... 19

5.5.3 Managing Adjustment Tables......................................................... 19

5.5.4 Performing an Adjustment.............................................................. 20

5.5.5 Removing a Calibration Point......................................................... 25

5.5.6 Checking Calibration Points........................................................... 26

5.5.7 Number of Calibration Points Exceeded........................................ 27

5.5.8 Checking Calibration Point Temperature ....................................... 28

5.5.9 Incorrect Distance Between Calibration Points.............................. 28

FSC1/7, FSC1000

5.6 Performing a Measurement, Single Value....................................................... 29

5.7 Performing a Series of Measurements, Statistics ........................................... 32

5.8 Measurement Data .......................................................................................... 34

5.8.1 General Info .................................................................................... 34

5.8.2 Displaying Measurement Data ....................................................... 34

5.8.3 Managing Measurement Data........................................................ 35

5.8.4 Saving/Exporting Measurement Data ............................................ 36

5.9 Ending the Measuring Program, Switching off the Controller ........................ 37

6. Liability for Material Defects.......................................................... 38

7. Cleaning, Service, Repair .............................................................. 38

8. Decommissioning, Disposal .......................................................... 39

9. License agreement, software ........................................................ 40

Appendix......................................................................................... 41

Page 5

Safety

FSC1/7, FSC1000

1. Safety

System operation assumes knowledge of the operating instructions.

1.1 Symbols Used

The following symbols are used in these operating instructions.

Indicates a hazardous situation which, if not avoided, may result in minor or moderate injuries.

Indicates a situation that may result in property damage if not avoided.

Indicates a user action.

iIndicates a tip for users.

Measurement Indicates hardware or a software button/menu.

1.2 Warnings

This product contains nickel metal hydride (NiMh) accumulators. Rechargeable accumulators are not ordinary

waste. Dispose of used accumulators in accordance with national laws and regulations.

Damaged accumulators may leak, contact with skin can cause burns.

> Use suitable protective gloves if necessary.

Improper charging or replacement of the accumulator may cause the battery to explode.

> Use the charger supplied by Micro-Epsilon for charging.

Only replace the accumulators with accumulators of the same type.

Avoid shocks and impacts to the sensor.

> Damage to or destruction of the sensor

Avoid exposure of sensor and controller to splashes of water.

> Damage to or destruction of the sensor/controller

Page 6

Safety

FSC1/7, FSC1000

Avoid exposure of sensor to aggressive media (detergents, cooling emulsions).

> Damage to or destruction of the sensor

Avoid bending, clamping and tensile stress of the sensor cable.

> Damage or destruction of the sensor cable

Avoid grinding the measuring area.

> Damage of the sensor

1.3 Notes on CE Marking

The following apply to the FSC1/7 and FSC1000:

EU Directive 2014/30/EU | EU Directive 2014/35/EU | EU Directive 2011/65/EU

Products which carry the CE mark satisfy the requirements of the EU directives cited and the European harmonized standards (EN)

listed therein. The measuring system is designed for use in industrial environments and meets the requirements. The EU Declaration

of Conformity is available to the responsible authorities according to EU Directive, article 10.

1.4 Notes regarding FCC Approval

The FSC1/7 and FSC1000 are registered under the FCC identifier: 2AMBGMEMW02, equipment class

- Part 15 Class B Computing Device Peripherals and

- Part 15 Class C Low Power Communication Device Transmitter

with the US Federal Communications Commission (FCC).

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference

that may cause undesired operation.

If sensor and/or controller are modified, the FCC approval becomes void.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installa-

tion.

Page 7

Safety

FSC1/7, FSC1000

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna

- Increase the separation between the equipment and receiver

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected

- Consult the dealer or an experienced radio/TV technician for help

1.5 Intended Use

- The FSC1/7 and FSC1000 are designed for use in industrial and laboratory applications. They are used to measure the thickness

of paint and other electrically insulating layers on substrates such as carbon fiber-reinforced plastics (CFRP), CFRP with metallic

lightning protection and metals.

- The system must only be operated within the limits specified in the technical data, see Chap. 2.2

- The system must be used in such a way that no persons are endangered or machines and other material goods are damaged in

the event of malfunction or total failure of the measuring system.

- Take additional precautions for safety and damage prevention in case of safety-related applications.

- The system is designed for battery operation; operating with a charger connected is not permitted.

1.6 Proper Environment

- Protection class: IP 40

- Temperature range

Operation: +10 ... +40 °C (+50 ... +104 °F)

Storage: 0 ... +45 °C (+32 ... +113 °F)

- Humidity: 20 ... 80 % (non-condensing)

- Ambient pressure: Atmospheric pressure

Page 8

Overview

FSC1/7, FSC1000

2. Overview

2.1 Structure, Functional Principle

The FSC1/7 and the FSC1000 are suitable for thickness measurements of insulating layers on

- CFRP,

- CFRP with lightning protection,

- metals

- and conductive or weakly conducting materials.

The device includes a sensor (handheld module) and a controller (control and display module).

The system operates

- based on microwaves, no coupling medium is required,

- on a non-destructive basis, without affecting coating or substrate.

One measurement takes less than 1 second.

Fig. 1 Sensor Fig. 2 Controller

Page 9

Overview

FSC1/7, FSC1000

2.2 FSC1/7 and FSC1000 Technical Data

Model FSC1/7 FSC1000

Measuring range 500 µm 1000 µm

Resolution Static 1 µm 1 µm

Display 1 µm or 0.01 mils 1 µm or 0.01 mils

Repeatability £2 µm £4 µm

Linearity 1 £±3 µm £±5 µm 2

Duration single measurement < 1 sec.

Frequency range 24 … 24.25 GHz (ISM band)

Supply voltage NiMh battery 6 V, 4500 mAh

Battery life approx. 8 hours 3

Min. target thickness Coating none

Substrate depending on material and its conductivity 4, > 1 µm

Min. target size 20 mm diameter

Target material (substrate) electrically conductive and poorly conductive materials such as CFRP 4,

CFRP with lightning protection, metals

Coupling medium not required

Active measuring area approx. 15 mm diameter

Interface USB

Temperature Storage -0 ... +45 °C (+32 ... +113 °F)

Operation +10 ... +40 °C (+50 ... +104 °F)

1) Adjustment based on calibration points, distance max. 150 µm; not taking into account the film tolerance

2) From 500 µm: also depends on the dielectric constant, typically <±3 %.

3) With approx. 1,000 measurements, new and charged battery

4) With CFRP woven materials at least one layer; with CFRP laid materials at least two layers with different angles

Page 10

Delivery

FSC1/7, FSC1000

Model FSC1/7 FSC1000

Humidity 20 … 80 % r.H. (non-condensing)

Protection class (DIN EN 60529) IP40 (sensor and controller)

Control and display elements

3.2” resistive LCD touch display, membrane keypad

statistical functions with recording and data export : Min., Max., counter, mean value

and standard deviation

dynamic tilt prevention (can be activated, configurable)

3. Delivery

3.1 Unpacking, Included in Delivery

1 Sensor including hand strap

1 Controller including shoulder strap

1 Exchangeable battery

1 Charger

1 Sensor cable with push-pull latching mechanism

1 Box with calibration foils

1 Operating instructions and test certificate

1 Carry case

Carefully remove the components of the measuring system from the packaging and ensure that the goods are forwarded in such

a way that no damage can occur.

Check the delivery for completeness and shipping damage immediately after unpacking.

If there is damage or parts are missing, immediately contact the manufacturer or supplier.

3.2 Storage

Temperature range storage: 0 ... 45 °C (+32 ... +113 °F)

Otros manuales para FSC1/7

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Instrumento de medición de MICRO-EPSILON

MICRO-EPSILON

MICRO-EPSILON eddyNCDT 3060 Guía de instalación

MICRO-EPSILON

MICRO-EPSILON optoCONTROL 2600 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON gapCONTROL 2711 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON surfaceCONTROL 3D 35 Series Manual de usuario

MICRO-EPSILON

MICRO-EPSILON optoNCDT ILR 1183 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON CS02 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON eddyNCDT 3010 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON confocalDT IFD2410 Series Manual de usuario

MICRO-EPSILON

MICRO-EPSILON thicknessCONTROL MTS 8202.LLT Manual de usuario

MICRO-EPSILON

MICRO-EPSILON ILD1402-5 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON combiSensor KSH5 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON capaNCDT 6200 Guía de instalación

MICRO-EPSILON

MICRO-EPSILON thermoMETER CS Manual de usuario

MICRO-EPSILON

MICRO-EPSILON capaNCDT CST6110 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON optoControl 1200 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON eddyNCDT 3060 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON optoControl 1200 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON capaNCDT 6222 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON scanCONTROL 3000/BL Manual de usuario

MICRO-EPSILON

MICRO-EPSILON optoCONTROL 2520 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON gapCONTROL 2711 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON confocalDT 2451 Manual de usuario

MICRO-EPSILON

MICRO-EPSILON surfaceCONTROL 3D 35 Series Manual de usuario

MICRO-EPSILON

MICRO-EPSILON capaNCDT 6630 Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
