Miboxer TRI-C1WR Manual de usuario

Subordinate New Brand

AC Triac Dimmer (WiFi + 2.4G + Push)

Model No.: TR-C1WR

Feature

Parameter

Connecon Diagram

Breaker mode instrucon

Installaon Diagram

PUSH Dimming

Remote control instrucon

Link remote

Unlink with remote

Compable remote

Set up min brightness

Auto transming

Smartphone APP control instrucon

Alexa voice control instrucon

Google Home voice control instrucon

Aenon

................................................................................................. 2

............................................................................................ 3

........................................................................... 4

................................................................. 4

........................................................................... 5

................................................................................... 5

............................................................ 6-9

................................................................................... 6

...................................................................... 7

...................................................................... 8

.................................................................. 8

......................................................................... 9

....................................... 10-13

...................................................... 14

......................................... 15

........................................................................................... 16

Contents

1. Feature

Don’t need signal cable and change original wire layout, it’s very simple

to install it with low cost. Mini appearance can ﬁt for EU/USA standard

juncon box. Wide applicaon for single color triac LED lights, ﬁlament

lamps, Halogen lamps.

Various control soluon:

● Uses WiFi + Bluetooth + 2.4G wireless transmission technology

● Smartphone APP control

● 2.4G RF wireless remote control

● Push dimming funcon

● Trailing edge phase-cut technology

● 0~100% stepless dimming and ﬂicker free

● Lowest brightness seng funcon

● Built-in temperature detecng switch, over heart /loading protecon

● Auto transming funcon, unlimited control distance

● Screw connector is reliable and easy to do installaon

● An-ﬁre PC shell is more safety

Powered b

с Алисой

Paбoтaeт

⸺2⸺

2. Parameter

25mm 49mm

49mm

SET

Indicator light

⸺2⸺

⸺3⸺

Model No.: TRI-C1WR

Input Voltage: 100-240V~ 50/60Hz

Output Voltage: 100-240V~

Output Current: Max 1.36A

Output Power: 150W @110V; 300W @220V

Dim Method: WiFi + 2.4G + Push

Working Temperature: -10~40°C

2.4G RF Control Distance: 30m

3. Connecon Diagram

PUSH switch

Input: AC100~240V

Triac dimming led light

Filament lamps and Halogen lamps

Please check and ensure that all cable had done correct connecon

before turn on it, otherwise the dimmer is easy to be damaged.

Aenon

S1S2 N LS2

N L1

INPUT

OUTPUT

Aenon: It only support to turn on/oﬀ light, user can not dim

device once this mode is acvated

“Breaker mode” is acvated or shut down

Turn On: short press “SET” 5 mes quickly, mode had acvated once

indicator blink 3 mes quickly

Turn Oﬀ: short press “SET” 5 mes quickly, mode had shut down once

indicator ﬂash 3 mes slowly

APP ON/OFF, review page 13

⸺3⸺

⸺4⸺

4. Installaon Diagram

Support following standing juncon box

PUSH switch The depth of juncon box is over 50mm

5. PUSH Dimming

Short press PUSH switch:

Turn ON/OFF light

Stepless dimming brightness.

Long press PUSH switch:

Long press and release your ﬁnger, then repeat long pressing to increase or

decrease brightness

Please long press switch 20 seconds unl all lights have same brightness with

100% level if mul dimmers had connect with same self-return switch. The

quanty of dimmers which connect with same self-return switch can not be

over 25 pieces, the connecon cable of self-return switch can not be over 20m.

⸺4⸺

⸺5⸺

2). Press “ ” any “ ” buon in group zones

3 mes within 3 seconds, linking code is

done once the light ﬂashes 3 mes slowly

2). Press “SET” 3 mes within 3 seconds, linking

code is done once the light ﬂashes 3 mes slowly

1). Learning code

6. Remote control instrucon

6.1. Link remote

For K1 remote

For other remote

Way 1: short press “SET” one me, indicator is

bursng

Way 2: power oﬀ dimmer 10 seconds and

power on again

Way 3: short press Push switch to keep light ON

1). Learning code SET

SET

Turn ON light buon

Indicator light

⸺5⸺

⸺6⸺

For K1 remote

2). Press “SET” 5 mes within 3 seconds,

unlinking is done once the light ﬂashes

10 mes quickly

1). Learning code

SET

6.2. Unlink with remote

2). Press “ ” any “ ” buon in group zones

5 mes within 3 seconds, unlinking is done

once the light ﬂashes 10 mes quickly

1). Learning code

For other remote

Turn ON light buon

⸺6⸺

⸺7⸺

6.4. Set up min brightness with remote

This funcon should be paired with remote ﬁrstly before seng.

For K1 remote

1). Long press “SET” 3 seconds unl the light ﬂashes one me,

indicator is going into ﬂashing status

2). Short press “SET” to get 10 kinds of brightness: 3%, 5%, 7%, 9%,

12%, 17%, 22%, 28%, 34%, 40%

3). Short press rotang buon to conﬁrm seng or waing for 10

seconds to be conﬁrmed automacally, the light will recover

brightness to previous level.

6.3. Compable remote (purchase separately)

K1 / K1-B S1-B / S1-W / S1-GFUT087 / FUT087-B

B1 / B1-B / T1

⸺7⸺

⸺8⸺

For other remote

1). Long press the " " buon on the remote or " " buon on the

zone, unl the light ﬂashes one me, indicator is going into ﬂashing

status

2). Short press the " " buon on the remote or " " buon on the

zone to set up 10 diﬀerent brightness (3%, 5%, 7%, 9%, 12%, 17%,

22%, 28%, 34%, 40%)

Short press any buon except “OFF” to conﬁrm seng or waing for 10

seconds to be conﬁrmed automacally, the light will recover brightness

to previous level

Aenon: Master OFF buon can set up lowest brightness for all

connected dimmer

6.5. Auto transming

One light can transmit the signals from the remote control to another

light within 30m, as long as there is a light within 30m, the remote

control distance can be limitless.

Aenon: All dimmer must link with same remote

Distance 30mDistance 30m

Signal transming

Triac Dimmer Triac Dimmer

⸺8⸺

⸺9⸺

7.2. Pairing Network

7. Smartphone APP control instrucon

1). Connect with power supply

2). Pairing network (aenon: factory default is pairing network)

3). Connect phone with home WiFi network in the 2.4GHz

frequency.

Way 1: Long press “SET” about 3 seconds unl indicator ﬂashes

quickly

Way 2: Long press push switch 10 seconds while light is OFF status

(aenon: need to wire with Push switch)

Way 3: Disconnect power - Connect power *3 mes.

Network Conﬁguraon (Don’t support 5G router)

7.1. Download and install [Tuya Smart] app

Search for [Tuya Smart] in Apple or Google

store or scan following QR code to download

and install the app.

Please open the app click "Register" buon to

create account while using it in the ﬁrst me,

⸺9⸺
