METREL test and measurement accessories:
3-Phase Active Switch
A 1507
Instruction manual
Version 1.1.1, Code no. 20 752 862
2
Distributor:
Manufacturer:
METREL d.d.
Ljubljanska cesta 77
1354 Horjul
Slovenia
web site: http://www.metrel.si
Mark on your equipment certifies that it meets requirements of all subjected EU
regulations
.
© 2018 METREL
No part of this publication may be reproduced or utilized in any form or by any means
without permission in writing from METREL.
A 1507 3-Phase Active Switch Table of contents
3
Table of contents
1Preface ........................................................................................................................4
2Safety and operational considerations.....................................................................5
2.1 Warnings and notes ..............................................................................................5
2.2 Standards applied .................................................................................................6
3Battery and charging..................................................................................................7
3.1 New battery cells or cells unused for a longer period............................................7
4A 1507 Description .....................................................................................................9
4.1 Connection panel ..................................................................................................9
4.2 Bottom side .........................................................................................................10
4.3 A 1507 set and accessories ................................................................................12
4.3.1 Standard set.................................................................................................12
4.3.2 Optional accessories....................................................................................12
5A 1507 Operation......................................................................................................13
5.1 Measuring with A1507.........................................................................................13
5.2 Supported instruments ........................................................................................14
5.3Supported measurements...................................................................................14
6Maintenance..............................................................................................................15
6.1 Cleaning..............................................................................................................15
6.2 Service ................................................................................................................15
7Technical specifications..........................................................................................16
7.1 General data........................................................................................................16
A 1507 3-Phase Active Switch Preface
4
1 Preface
Congratulations for purchasing and using METREL A 1507 3-Phase Active Switch
accessory with METREL test and measuring instruments. The A 1507 simplifies testing
of 3-phase installations with single phase installation testers. It is especially applicable
to the instruments containing the Auto Sequence™option.
A 1507 3-Phase Active Switch Safety and operational considerations
5
2 Safety and operational considerations
2.1 Warnings and notes
In order to reach high level of operator’s safety while carrying out various tests and
measurements using A 1507 as well as to keep the test accessory and equipment
undamaged, it is necessary to consider the following general warnings:
Warning on the A 1507 means »Read the Instruction manual with special
care to safety operation«. The symbol requires an action!
If the A 1507 is used in a manner not specified in this Instruction manual or the
manual of target test equipment, the protection provided by the A 1507 and
equipment may be impaired!
Read this Instruction manual carefully, otherwise use of the A 1507 may be
dangerous for the operator, for test equipment or for the tested object!
Do not use the A 1507 if any damage is noticed!
Consider all generally known precautions in order to avoid risk of electric shock
while dealing with hazardous voltages!
Service intervention is allowed to be carried out only by a competent authorized
person!
All normal safety precautions have to be taken in order to avoid risk of electric
shock when working on electrical installations!
A 1507 3-Phase Active Switch Safety and operational considerations
6
2.2 Standards applied
The A 1507 is manufactured and tested according to the following regulations, listed
below.
Safety (LVD)
EN 61010-1
Safety requirements for electrical equipment for measurement,
control, and laboratory use –Part 1: General requirements
EN 61010-2-
030
Safety requirements for electrical equipment for measurement,
control, and laboratory use –Part 2-030: Particular requirements for
equipment having testing or measuring circuits
EN 61010-031
Safety requirements for electrical equipment for measurement, control
and laboratory use –Part 031: Safety requirements for hand-held
probe assemblies for electrical measurement and test
Electromagnetic compatibility (EMC)
EN 61326-1
Electrical equipment for measurement, control and laboratory use –
EMC requirements –Part 1: General requirements
EN 61326-2-2
Electrical equipment for measurement, control and laboratory use –
EMC requirements –Part 2-2: Particular requirements –Test
configurations, operational conditions and performance criteria for
portable test, measuring and monitoring equipment used in low-
voltage distribution systems
A 1507 3-Phase Active Switch Battery and charging
7
3 Battery and charging
The instrument uses three AA size alkaline or rechargeable Ni-MH battery cells.
Nominal operating time is declared for cells with nominal capacity of 2000 mAh. Battery
condition is present by LED indicator when the A 1507 is turned on.
The battery is charged whenever the power supply adapter is connected to the A 1507.
Internal circuit controls charging assuring maximum battery lifetime.
The A 1507 automatically recognizes connected power supply adapter and controls
charging. Operation of the A 1507 is disabled during charging. Charging is indicated by
blinking blue LED.
Before opening battery compartment cover disconnect all measuring
accessories connected to the A 1507 and power off the instrument.
Insert cells correctly, otherwise the A 1507 will not operate and the battery could
be discharged.
Remove all battery cells from the battery compartment if the A 1507 is not used
for longer period.
Do not charge alkaline battery cells!
Take into account handling, maintenance and recycling requirements that are
defined by related regulative and manufacturer of alkaline or rechargeable
batteries!
Use only power supply adapter delivered from manufacturer or distributor of the
test equipment to avoid possible fire or electric shock!
3.1 New battery cells or cells unused for a longer period
Unpredictable chemical processes can occur during charging of new battery cells or
cells that were unused for a longer period (more than 3 months). Ni-MH battery cells are
affected to capacity degradation (sometimes called as memory effect). As a result, the
instrument operation time can be significantly reduced.
Recommended procedure for recovering battery cells:
Procedure
Notes
Completely charge the battery.
At least 14h with in-built charger.
Completely discharge the battery.
Can be performed with normal work with
the adapter.
Repeat the charge / discharge cycle for at
least two times.
Four cycles are recommended.
Complete discharge / charge cycle can be performed automatically for each cell using
external intelligent battery charger.
A 1507 3-Phase Active Switch Battery and charging
8
Notes:
The charger in the instrument is a pack cell charger. This means that the battery
cells are connected in series during the charging. The battery cells have to be
equivalent (same charge condition, same type and age).
One different battery cell can cause an improper charging and incorrect
discharging during normal usage of the entire battery pack (it results in heating of
the battery pack, significantly decreased operation time, reversed polarity of
defective cell …).
If no improvement is achieved after several charge / discharge cycles, then each
battery cell should be checked (by comparing battery voltages, testing them in a
cell charger, etc.). It is very likely that only some of the battery cells are
deteriorated.
The effects described above should not be mixed with normal decrease of
battery capacity over time. Battery also loses some capacity when it is repeatedly
charged / discharged. Actual decreasing of capacity, versus number of charging
cycles, depends on battery type. It is provided in the technical specification from
battery manufacturer.
A 1507 3-Phase Active Switch A 1507 Description
9
4 A 1507 Description
4.1 Connection panel
Figure 4.1: Connection panel
Legend:
1
Connection for METREL installation tester.
2
Charger socket
3
Banana safety sockets for connection to tested 3-phase electrical installation.
4
Supply and operational state indicator.
LED status
Charging
Blue blinking
Battery in good condition
Green
Battery low
Red
Battery voltage too low
Red blinking alternately
(Adapter will automatically turn off
after 5 s).
Battery fault or absent
(Charger connected)
Blue-Red blinking alternately
A 1507 3-Phase Active Switch A 1507 Description
10
4.2 Bottom side
Figure 4.2: Back panel
Legend:
1
Serial number label
2
Battery compartment cover
3
Back panel information label
4
Fixing screws for battery compartment cover
