Metel 2G 2S.0.3.F Instrucciones de funcionamiento y mantenimiento

www.metel.eu 1/23

www.iplog.eu

REV-202204

Industrial PoE+ Managed witches 2G

2 .0.3.F

2 .0.3.F PoE NMPMODBU VLAN R TPONVIF 802.1X

Typical connection

2G-2 .0.3.F-BOX-PoE

LAN-RING 20G

LAN-RING 2G

For Available FP Modules Visit www.metel.eu

2G-2 .0.3.F-BOX-PoE 2 0 3 2 1 2

AVAILABLE PORT : FP GE FE D/AI RELAY R 485

upply without PoE 10-60VDC/10-30VAC, with PoE 48-57VDC

upply with PoE+ 52-57VDC (15…25W), with PoE++ 53-57VDC (>25W)

2G-2 .0.3.F-BOX-PoE 1-988-220 10-60VDC/10-30VAC

Holder for Mounting to DIN35 and Flat urface is Included.

PRODUCT NAME CODE NOTE

Vertical Mounting to DIN35 Mounting to a Flat urfaceMounting to DIN35

v 2x FP lot with upport of 100/1000BA E-X

v 3x Fast Ethernet Port with PoE IEEE 802.3af/at

max. 30W per Port

v Total PoE Power Over All Ports is 90W

v 2x R 485/Modbus-RTU Buses

v 2x Digital/Alarm Inputs

v 1x Programmable Relay Output

v 2 Independent Power Inputs

v Redundant Topology LAN-RING, R TP

v Event Management with upport:

HTTP/ONVIF Client, E-mail, IP Watchdogs, ETH

Events, TCP, Modbus, DIO, Balanced Loops…

v Visualization oftware upport

v Encrypted Management via LAN/Local U B

v urge Protectors up to 150A (8/20µs)

v VLAN, Qo , NMP, MTP, NTP, IGMP, R TP,

LLDP, 802.1X, Mirror, Remote Acces IP Table

v Maximum tart Time 15s

v Operating Range −40°C to + 70°C

v Operating Range of Components -40°C to + 85°C

LAN-RING 2G

1x MM / M Fiber Fast Ethernet erial Buses Other IO

Gigabit Ethernet Fast Ethernet with PoE

I&HAS

& ACS

REDO AO

AI DI

Modbus RTU

RE DOAOAIDI

AI DI RE

AI DI

I&HAS

& ACS

Modbus RTU

Typical Connection of LAN-RING ystem Versatility

www.metel.eu 2/23

www.iplog.eu

REV-202204

Industrial PoE+ Managed witches 2G

2 .0.3.F

2 .0.3.F PoE NMPMODBU VLAN R TPONVIF 802.1X

Further

info

pages

12 - 13

16 - 18

Further

info

pages

15,

21 - 22

BX-100-20-W4-L 4-101-020 C / PC 20 / 5 km

BX-100-20-W5-L 4-101-010 C / PC 20 / 5 km

BX-1000-20-W4-L 4-101-120 C / PC 20 / 2 km

BX-1000-20-W5-L 4-101-110 C / PC 20 / 2 km

BX-1000-60-W4-L 4-101-122 C / PC 60 / - km

BX-1000-60-W5-L 4-101-112 C / PC 60 / - km

PRODUCT NAME CODE CONNECTOR RANGE(1)

2x FP lots with 100/1000BA E-X upport

Switches 2G-2S.0.3.F have 2 SFP slots universally usable

both for SFP modules ME EL (tab on the right) and for SFP

modules of other manufacturers. he main advantages of

ME EL SFP modules are:

- bidirectional CWDM data transmission over one fiber

- used components with a range from −40 to +85°C

- SM / MM universal (all versions -20-)

- minimum warranty period 5 years (1) singlemode (9/125µm) / multimode (50/125µm)

3x Fast Ethernet Port with PoE up to 30W per Port

Fast Ethernet ports support 10BASE- , 100BASE- standards including Auto negotiation,

MDI/MDI-X and PoE standards 802.3af/at up to 30W per port. he distri-bution of power to

individual ports is set in the Simuland.v4 application. he ports due to increased reliability

are protected by surge protection up to 150A in a floating connection.

& The maximum total power consumption of PoE over all ports is 90W.

2x R 485/Modbus-RTU Buses

he switches are equipped with two RS485 buses enabling the connection of Modbus R U IO

modules and sensors, selected types of I&HAS systems and other devices.

& The transmission of system buses of I&HA systems is certified according to EN50131-1.

Further

info

page

8-9

2x Digital/Alarm Inputs

Digital/alarm inputs are mainly used for connecting button tampers, PIR sensors and others.

SIMUland management software allows them to be used to set up a range of automatic

actions. In addition, the inputs are monitorable via the SNMP protocol.

Further

info

page

1x Programmable Relay Output

Programmable relay output is used to signal faults (eg open circuit), control el. locks,

contactors and signaling elements. In addition, the relay can be controlled from software

superstructures, IPLOG PLC SNMP or MODBUS protocol, or EVEN MANAGEN switches.

Further

info

page

2 Independent Power Inputs

he switches have 2 independent power inputs 10 to 60VDC and one 10-30VAC input.

ypical applications with backup power supply are systems where the switch is part of the IP

CC V system and at the same time transmits the system bus of the PZ S system. he inputs

are protected against overvoltage.

Further

info

page

LAN / U B Management

In addition to secure LAN management, each LAN-RING switch has a USB-A connector for

local management via the SIMULand application. he USB connector also allows you to reset

the switch to factory settings. he inputs are protected against overvoltage.

www.metel.eu 3/23

www.iplog.eu

REV-202204

Industrial PoE+ Managed witches 2G

2 .0.3.F

2 .0.3.F PoE NMPMODBU VLAN R TPONVIF 802.1X

upported Formats 100/1000 BA E-LX, BA E-BX M A Compatibility

FP lots Number 2

LAN Number 3 FE

Overvoltage Protection FE ports: up to 150 A in the wave 8/20μs - more p. 22

upported Formats FE ports: 10BaseT, 100BaseTx

With PoE+ up to 30W 52 - 57 52 - 57 VDC

Power Consumption Max. 4 W without PoE supply to FE ports

Parameter Value Unit Note

Connector RJ45

Power upply Main Input Back-up Input

Max. Load 62,5VA (30W) / 1A / 60V Resistive Load

Overvoltage Protection 1500 W 10/1000µs

torage Range –40…+70 °C

Environment Operational Range –40...+70 °C Temperature of Environment

Humidity Max. 95 % Non-condensing

Management Application IMULand Windows Applications

Without PoE 10 - 60 / 10 - 30 10 - 60 VDC/AC

With PoE up to 15,4W 48 - 57 48 - 57 VDC

Weight 0,65 kg

Relay Output Type of Contact 1x Change-Over

Analog 0 - 30kΩ for Balanced Loops

Overvoltage Protection 30 A 8/20μs

peed Max. 57,6 kbps

R 485 Number 2

Digital inputs Number 2

Mode Digital - NC / NO

The producer retains the right to change any technical parameters without previous written or published notification.

Certification CE, TUV

Technical Parameters compatibility

Electromagnetic Compatibility compatibility

tandard Tested Level – Criteria Note

EN 55024 - Information technology equipment - Immunity characteristics - Limits and methods of measurement

EN 61000-4-2 – Contact Discharge Level 4 – Criteria B 8kV

EN 61000-4-2 – Air Discharge Level 4 – Criteria B 15kV

EN 61000-4-4 – Bursts Level 4 – Criteria B 4kV / 5kHz

EN 61000-4-5 – urge Immunity Level 4 – Criteria B 4kV, BU , GE and DI Level 3 (2kV)

EN 61000-4-8 – Magnetic Field 50 Hz Level 5 – Criteria A 100A

EN 61000-4-9 – Pulse Magnetic Field Level 5 – Criteria A 1000A

EN 55022 – Radiated Emission Class A

www.metel.eu 4/23

www.iplog.eu

REV-202204

Industrial PoE+ Managed witches 2G

2 .0.3.F

2 .0.3.F PoE NMPMODBU VLAN R TPONVIF 802.1X

Dimensions of 2G-2 .0.3.F universality

REV: 201406 – Default

201504 – Added Installation GBIC Modules

201904 – Design change, added 802.1X protocol, galvanically separated cover from the electronics

202204 – Change PoE circuit

www.metel.eu 5/23

www.iplog.eu

IMULand.v4 - Configuration oftware with GUI

SIMULand.v4 is a freeware software for configuring all LAN-RING devices. It

excels in intuitive GUI and advanced tools for efficient management of

even ver large s stems.

v Online / Offline configuration of all LAN-RING devices in the GUI

v Automatic search for available devices on the LAN

v Automatic detection and rendering of system topology

v U B console for local device management

v Download menu for bulk downloads of configurations from device to IMULand

v Upload menu for bulk uploads of the prepared configurations to the devices

v Encrypted communication protected by a hash algorithm

v IMULand includes firmware for upgrading all supported devices

v In the tatus menu, you can monitor the operating status of the device online

v Quick config for accelerated PoE configuration, IP address assignment ...

v Access to the device log

Y TEM REQUIREMENT

Operating system Windows 8, 10 – 32/64bit

Monitor Full HD

RAM 2GB or more, depending on the size of the project

Language versions CZ, EN PL, UA

The manufacturer reserves the right to change technical parameters without prior notice.

SIMULand.v4 is a Windows desktop software with a GUI for bulk configuration of LAN-RING

devices in Online, Offline or USB mode. It also includes a number of tools for network

communication analysis, including fully automatic detection of network topology with display

of optical and metallic connections, amount of transmitted data in Mbps in connections,

number of dropped packets on ports, PoE status, power status, input/outputs/ports status.

Processor Intel Core 2 DUO 2GHz / AMD X2 2GHz or faster

LI T OF UPPORTED DEVICE

BB-x.x.x-22

200M-1.0.4.E-W4

200M-1.0.4.E-W4-PoE+

200M-1.0.4.E-W5

200M-1.0.4.E-W5-PoE++

200M-2.0.1.E

200M-2.0.4.ECA

200M-2.0.4.ECB

200M-2.1.0

200M-2.1.0.E

200M-2.1.4

200M-RS.E4

200M-RS.E5

200M-EVA

200M-EVA8

200M-ADAM

200M-ADAM8

2G-0.1.4

2G-0.1.4.E

2G-0.1.8.E

2G-0.1.8.EC

2G-1.0.4.E-W4

2G-1.0.4.E-W4-PoE++

2G-1.0.4.E-W5

2G-1.0.4.E-W5-PoE++

2G-2.0.1.E

2G-2.0.4.ECA

2G-2.0.4.ECB

2G-2.1.0

2G-2.1.0.E

2G-2.1.0.EB

2G-2.1.4

2G-RS.E4

2G-RS.E5

2G-RS.E6

RING-IO

LAN-485

200M-2.1.4.E

200M-2.1.4.E ++

2G-2.1.4.E

2G-2.1.4.E ++ 2G-2.1.7.E

2G-2.3.0.E

2G-6S.1.16.E

2G-6S.1.16.F-UNI /1U,

2G-10S.F-UNI /1U

2G-2S.0.3.F-BOX-PoE

2G-2S.0.3.F-BOX PoE(M-PoE)

2G-2S.0.3.FC-BOX

2G-2S.3.0.F-BOX

2G-2S.0.2.F-BOX-PoE

2G-2S.0.2.F-BOX-PoE-PP

2G-2S.1.4.F-BOX

2G-2S.1.4.F-BOX-PoE-PP

2G-2.7.1.0.F-BOX

2G-2C.0.8.F-BOX-PoE-PP

2G-1C.0.8.FC-BOX-PoE-PP

2G-2C.8S.0.0.F-BOX

20G-2X.8.0.F-BOX

miniLAN-232

miniLAN-485

IPLOG-DEL A-1

IPLOG-DEL A-2

IPLOG-DEL A-3

IPLOG-DEL A-1-Geuteb.

IPLOG-DEL A-1-Eza

IPLOG-DEL A-1-Redwall

IPLOG-DEL A-1-Elfar

IPLOG-DEL A-1-R62

IPLOG-DEL A-1-Peridect

IPLOG-DEL A-3-Peridect

IPLOG-DEL A-3-Valert

IPLOG-DEL A-VoIP

IPLOG-DEL A-2-GSM

IPSEN-D6

IPSEN-D16

IPSEN-H2O

IPSEN- 1

IPSEN- H1

IPSEN-BL8I

IPSEN-BL8O

www.metel.eu 6/23

www.iplog.eu

LAN-RING for Ring Topology

One of the fundamental elements of the security system LAN-RING is fast data forwarding to a back-up

line. Since 2008, this function has been performed by LAN-RING.v1 protocol with a switchover time of

30ms from the failure. Each ring in the system has a unique ID and one switch with the MAS ER function

(controls the ring). he higher port of the MAS ER switch is normally set to a BLOCKING mode, hence

preventing a loop. A port in BLOCKING mode receives only LAN-RING frames and blocks the other data

(back-up line). If a failure occurs, the state of the blocked port changes to FORWARDING and starts to

transmit all data.

Initial tate Failure Failure Resolution Final tate

During the failure creation and resolution, there are 2 short interruptions in the route. he second

interruption provides the switchover from the back-up line back to the MAS ER switch. Since, the end

of 2014, a new innovative version of LAN-RING.v2 is available. he switch which has the MAS ER function

which controls the ring. In the case of a failure, the MAS ER function moves to the switch next to the

failure. From the origin of the problem to the time of its removal, only one interruption occurs of up to

maximum of 30ms.

Initial tate Failure Failure Resolution = Final tate

& The switchover time to the back-up line is for LAN-RING protocols slightly dependent

on the number of switches connected in the ring. With each switch connected to the ring,

the reconfiguration time increases by only about 6μs!

MA TER

MA TER MA TER MA TER

Interruption

When a Failure

Occurs

Interruption

During Failure

Resolution

MA TER MA TER

Port in

BLOCKING

Mode

Port in

BLOCKING Mode Interruption

When a

Failure

Occurs

R TP and R TP-M for ME H Topology

he RS P-M protocol is a time-optimized version of

the general RS P protocol with which it is backward

compatible. In addition, it meets the requirements of

safety and automation systems to quickly secure a

backup route in the event of a fault and:

v is fully compatible with RS P according to IEEE

802.1D-2004

v supports MESH topology

v reduces reconfiguration times to a minimum

DP DP

DP RP

RP RP

RP RP – root port

DP – designated port

BP – blocked port

Redundant Topology

www.metel.eu 7/23

www.iplog.eu

NAME TYPE NOTE

The LAN-RING industrial switch software includes the Event Management

tool set in the Extension menu. The user can set up to 64 automatic

actions. The event management switch is also able to communicate

directl with the PLC IPLOG where the control program written in the FBD,

LD, ST or IL language described in IEC 61131-3 is running. Event

management has the potential to significantl increase the value of our

s stem and customize the s stem to the customer's requirements.

MODBU RTU/TCP INPUT and OUTPUT (DI, AI, BI, RE, AO, DO, BO) Up to 16 IO Modules and ensors on R 485 Bus

LOCAL IO INPUT and OUTPUT (BI, DI, RE) Local Inputs and Outputs LAN-RING witches

ETHERNET EVENT INPUT and OUTPUT Protocol for Transmission of tatuses Over LAN

NMPv2/v3 INPUT and OUTPUT Protocol for Transmission of tatuses Over LAN

TCP EVENT INPUT Receives TCP Messages From Cameras etc.

RE TART POE OUTPUT Restarts PoE with IP Watchdog

EMAIL OUTPUT ends E-mails

ONVIF OUTPUT Controls Cameras

HTTP OUTPUT ends HTTP Commands to CAM, NVR, PLC...

IP WATCHDOG INPUT Monitors IP devices

OPTICAL RING INPUT Monitors Optical RINGs tates

FE / GE / FO PORT INPUT and OUTPUT Monitors Port tates, Port Control

Nastavení

výstupu

Automatic Actions

LAN-RING witch

of the witch Input

Processing the

set Action

et the witch

Output

PLC IPLOG Control Program

of PLC

Inputs

et the

PLC

Outputs

Loading of

External Inputs

ettings of

External Outputs

Motion Detection witch … Activates Local RELAY

… ends an E-mail

… ends a NMP Trap

… ends a ONVIF command

Restart PoE at

Freezing Detection

Modbus T/RH ensor

Event Management - Overview

Examples of Automatic Actions

Available Inputs and Outputs

A unique set of tools in the EX ENSION menu of LAN-RING switches and monitoring units IPLOG allow

you to set a whole range of automated actions independent of external software. he table below

provides an overview of supported inputs and outputs that can be used to set automatic actions.

Connection to a PLC IPLOG

www.metel.eu 8/23

www.iplog.eu

ETH

E H events are used for status transmission over the LAN-RING network. Events differ from each other by

a so-called ID identifier in the range of 1 to 999. An E H event with the same identifier must be set on the

side that sends and receives the event.

Example The switch sends the status of input IN1 as an ETH event with ID#87.

Example The switch receives ETH events with ID#87, which control the relay.

Menu „Extension/ETH-IO“

he setting of the communication parameters for status transfer between

inputs and outputs is configured in the "Extension / E H-IO" menu. So-called

multicast packets are used for transmission, which enable the transmission of

information to multiple recipients.

Receive address - multicast address for receiving packets

Priority - QoS priority assigned to outgoing packets

VLAN ID - VLAN tag for sending and receiving packets

Transmit address 1 to 5 - multicast address for sending packets

Application note I O transfer between switches

Event Management - ETH, DIGITAL

DIGITAL

DIGI AL inputs allow you to set automatic actions with digital inputs of switches IN1 and IN2.

DIGITAL MODE - supported modes

Close - event is triggered by closing the input (connection of IN to GND)

Open - the event is triggered by opening the input

Direct - the input status is sent every 3 seconds. When there is a change, this change is sent immediately

Change - the event is triggered by closing or opening the input

Example Switch on input No. 2 calls up the setting of Preset No. 12 on camera No. 3 (Onvif command).

Menu „Extension/Input/Digital“

Label - input naming (stored in the SIMULandv4 project)

Negation - input negation

Minimal pulse duration (s) - minimum input on/off length

& The METEL-COMIO-DIO-MIB file, which also contains NMP TRAP

permissions, is available for monitoring NMP inputs.

www.metel.eu 9/23

www.iplog.eu

Event Management - ALARM

ALARM

ALARM inputs are digital inputs IN1 and IN2 switched to alarm mode in the "Extension / Input / Alarm"

menu. Once activated, they function as standard alarm inputs and support PIR connections with EOL

resistors (up to 8 states per input).

MODE - supported modes

tate is / tate is not - Balanced loop is/is not in state ...

Direct is / Direct is not - he loop status is sent every 3 seconds. When the entered input state

changes, this change is sent immediately.

Change is / Change is not - If there is/did not change from the state.

tate direct - he current state of the loop is sent every 3 seconds. When the loop state changes, this

information is sent immediately.

tate change –- Response to state change only.

Value direct - he current value of the balanced loop is sent every 3 seconds. When the value of the

balanced loop changes, the information is sent immediately.

Value change - he information is sent when the value of the balanced loop changes.

AC IVE - resistance ranges defined in "Extension / Input / Alarm". In total, 8 ranges up to a maximum of

30,000 Ohms are available for each input.

Example If the resistance of the alarm loop at input IN1 corresponds to Sabotage (short), an HTTP user

command URL1 ("Camera / User commands") with a value of 2 is sent to camera No. 4.

Examples of alarm loop balancing: Menu with alarm loop settings:

& The METEL-COMIO-EZ -MIB file is available for

monitoring alarm inputs via the NMP protocol,

which also contains NMP TRAP permissions.

1k0 3k0

1k0

ALARM TAMPER FAULT

1k0 12k

ALARM FAULT ANTIMA K. 1k0

3k0

ABOTAGE

www.metel.eu 10/23

www.iplog.eu

LAN-RING

Optical ring status monitoring with LAN-RING protocol.

MODE - supported modes

Close - the event is triggered when the ring closes

Open - the event is triggered if the ring opens

Direct - the status of the optical ring is sent every 3 seconds. When the status changes, the change is sent

immediately

Change - the event is triggered by closing or disconnecting the optical ring

Example The state of the ring is transmitted to the relay output, which is connected to the signaling LED

light. In case the ring is disconnected, the light is active.

& A METEL-RING-MIB file is available for monitoring the status of NMP rings, which also contains

NMP TRAP permissions.

Event Management – LAN-RING, TCP, MIO , EXP-C

TCP

he switch can listen on the specified CP port set in the "Extensions / CP" menu. If a device on the

network sends a notification to the switch's IP address and the specified CP port, the switch can respond

to it with the created automatic action.

MODE - supported modes

Matches - the pattern entered must match the text that came

Contains - the received text contains the specified pattern

tarts - the received text starts with the specified pattern

Ends - the received text ends with the specified pattern

Example In case the switch intercepts a TCP notification from the network with the entered text

(pattern), it will control the camera No. 2.

MIO , EXP-C

Modes for communication with discontinued IO modules. More information at support@metel.eu

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de Metel

Metel

Metel 200M-2.0.4.ECA Manual de usuario

Metel

Metel M-MDR-40-48 Manual de usuario

Metel

Metel 2G-2.1.4.E-BOX-PoE++ Manual de usuario

Metel

Metel 200M-RS.E4 Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
