Mesa/Boogie SINGLE RECTIFIER RECT-O-VERB 50 2 Series Guía de inicio rápido

Series 2

SINGLE RECTIFIER - RECT O VERB (Series 2)

FRONT PANEL

CHANNEL 1 CHANNEL 2

Control Function Type Mesa Part# Control Function Type Mesa Part#

Clean/Pushed Switch 607101 Raw/Vin/Mod Switch 607303

Gain Pot 593792 Gain Pot 592794

Knob 408110 Knob 408110

Treble Pot 593148 Treble Pot 592738

Knob 408110 Knob 408110

Middle Pot 592378 Middle Pot 593737

Knob 408110 Knob 408110

Bass Pot 593148 Bass Pot 593739

Knob 408110 Knob 408110

Presence Pot 593737 Presence Pot 593150

Knob 408110 Knob 408110

Reverb Pot 593151 Reverb Pot 593151

Knob 408110 Knob 408110

Master Pot 592738 Master Pot 593739

Knob 408110 Knob 408110

Green LED LED 395438 Red LED LED 395753

Lens 703300 Lens 703300

REAR PANEL

MISC PARTS MISC PARTS

Control Function Type Mesa Part# Control Function Type Mesa Part#

Input Jack 610120 Slave Jack 618112

Output Pot 593148 Speaker Outs (3) Jack 618112

Knob 408110 Bias Select Switch 602000

Solo Pot 593148 FX Loop

Knob 408110 Mix Level Pot 593736

Pilot Light Knob 408110

Light 703047 Return Jack 618112

Lens 703782 Send Jack 618112

Light Holder 703822 External Swtch

Standby Switch 600631 Reverb Jack 618112

Power Switch 600631 Solo Jack " "

Channel Jack " "

Footswitch Jack 613615

Channel Select Switch 600631

Fuse Holder

Domestic Cap/Holder 790347

Fuse 790250

Export Cap/Holder 790346

Fuse 795101

AC Receptacle Jack 613713

SINGLE RECTIFIER - SOLO 50 (Series 2)

FRONT PANEL

CHANNEL 1 CHANNEL 2

Control Function Type Mesa Part# Control Function Type Mesa Part#

Clean/Pushed Switch 607101 Raw/Vin/Mod Switch 607303

Gain Pot 593792 Gain Pot 592794

Knob 408110 Knob 408110

Treble Pot 593148 Treble Pot 592738

Knob 408110 Knob 408110

Middle Pot 592378 Middle Pot 593737

Knob 408110 Knob 408110

Bass Pot 593148 Bass Pot 593739

Knob 408110 Knob 408110

Presence Pot 593737 Presence Pot 593150

Knob 408110 Knob 408110

Master Pot 592738 Master Pot 593739

Knob 408110 Knob 408110

Green LED LED 395438 Red LED LED 395753

Lens 703300 Lens 703300

REAR PANEL

MISC PARTS MISC PARTS

Control Function Type Mesa Part# Control Function Type Mesa Part#

Input Jack 610120 Slave Jack 618112

Output Pot 593148 Speaker Outs (3) Jack 618112

Knob 408110 Bias Select Switch 602000

Solo Pot 593148 FX Loop

Knob 408110 Mix Level Pot 593736

Pilot Light Knob 408110

Light 703047 Return Jack 618112

Lens 703782 Send Jack 618112

Light Holder 703822 External Swtch

Standby Switch 600631 Solo Jack 618112

Power Switch 600631 Channel Jack 618112

Footswitch Jack 613615

Channel Select Switch 600631

Fuse Holder

Domestic Cap/Holder 790347

Fuse 790250

Export Cap/Holder 790346

Fuse 795101

AC Receptacle Jack 613713
