Mercury VesselView Mobile Manual de usuario
VesselView Mobile
Page: 1
Back to Main Page
8M0127340 eng December 2017 © 2017 Mercury Marine
VesselView Mobile FAQ
What is VesselView Mobile?
Module
How Can I Get the VesselView Mobile Module?
How Do I Install the VesselView Mobile Module?
How Do I Get the VesselView Mobile App?
Can I Use the Module/App and Stream Music?
Application
What Engine Configurations are Supported?
What Are the Requirements to Use the App?
Why Do I Need a VesselView Mobile Log–in?
Why Do I Need a Profile Log–in?
How Do I Connect to the VesselView Mobile Module?
How Do I Get Started After Installation?
How Do I Connect to My VesselView Mobile App?
What Are the Features in the VesselView Mobile App?
How Do I Customize the View in the Engine Data Details?
Why is My Speed Not Working?
How Does Fuel Management Work?
How Does the Fault Code Information Work?
How Do the Maintenance Reminders and Logs Work?
Why Do My Maintenance Numbers Look Wrong?
Why is My Map Not Working?
What is Capture a Moment?
What is Add Catch?
What is the Calendar Function?
Why Am I Not Getting Notifications?
Why is My Mobile Device Losing Battery Power?
Where is My Data Saved?
Why Do Only Certain Things Work On My App?
How Do I Connect to More Than One Boat?
Companion Account
How Do I Access My Account From Any Computer?
How Do I Select My Preferred Dealers?
Page: 2
Back to Main Page
VesselView Mobile
8M0127340 eng December 2017 © 2017 Mercury Marine
About VesselView Mobile
What Is VesselView Mobile?
VesselView Mobile delivers your boat’s SmartCraft®digital data to the
palm of your hand. VesselView Mobile is an onboard module, linking to
your mobile device app and mobile account via Bluetooth®technology.
The application is compatible with both iOS and Android™ mobile
devices and is available for use with smartphones and tablets.
About VesselView Mobile
Module
How Can I Get the VesselView Mobile Module?
Purchase the VesselView Module at your
local Mercury®dealer, part number 8M0115080.
Purchase online by using your VesselView
Mobile app, via the Purchase Module link, or by visiting:
VesselViewMobile.com.
How Do I Install the VesselView Mobile Module?
• If you already have existing SmartCraft gauges, modules can be
installed by simply installing it as instructed.
VesselView Mobile: How to Install On Single Engine
VesselView Mobile: How to Install with Junction Box
• For more advanced setup, please see your local Mercury Marine
dealer. You can find a dealer by using the Dealer Locator feature in
the app.
How Do I Get the VesselView Mobile App?
You can download the app for free at the following locations:
• Apple mobile device:
Apple App Store
• Android mobile device:
Google Play Store
Can I Use the Module/App and Stream Music?
Yes, you can stream music while using VesselView Mobile.
VesselView Mobile
Page: 3
Back to Main Page
8M0127340 eng December 2017 © 2017 Mercury Marine
Application
What Engine Configurations are Supported?
The VesselView Module will work in any of the
following configurations:
• For single engine applications that do not have SmartCraft
architecture (an available junction box at
the helm), you can install the module directly
on the engine. This setup does require the
ten-pin termination resistor, typically yellow and
on the engine.
• For multi-engine applications that do not have SmartCraft
architecture (available junction box
under the helm), see your Mercury Marine dealer
for assistance with architecture configuration
and installation.
• For boats with SmartCraft architecture in place, use an open port
(remove weather cap) in a junction box or replace your junction box
with a higher capacity unit if all ports are already used.
Page: 4
Back to Main Page
VesselView Mobile
8M0127340 eng December 2017 © 2017 Mercury Marine
What Engine Configurations are Supported?
(Continued)
Outboard Engine Compatibility
Model Serial Range
30-40 hp (3 cyl) EFI FourStroke 0T409000 and above
40-60 hp (4 cyl) EFI FourStroke All
75-115 hp EFI FourStroke 1B366823 and above
75-125 hp OptiMax All
150 hp FourStroke All
V6 OptiMax 0T178500 and above
V6 EFI TwoStroke 0T409000 and above
Verado All
NOTE: Some 2001 model year engines may require an ECM update.
MerCruiser Engine Compatibility
Model Serial Range
3.0L MPI All
4.3L MPI All
4.5L/6.2L - Mercury Built All
5.0L/350 MAG/5.7L/377 MAG/6.2L MPI - GM 0M300000 and above
496/8.1L All
8.2L All
NOTE: 6.2L Black Scorpion SmartCraft compatible, 0M391777 and above.
Mercury Diesel Engine Compatibility
Model Serial Range
2.0L/2.8L I4 All
3.0L V6 TDI All
4.2L I6 All
4.2L V8 TDI 0M300000 and above
QSB/QSC/QSM11/QSL Series Cummins All
Mercury Racing Sterndrive Engine Compatibility
Model Serial Range
520/525/540/565 EFI All
600/662/700 SCi All
850/1025/1075/1200 SCi All
QC4V Models All
Mercury Racing Outboard Engine Compatibility
Model Serial Range
2.5 XS All
200/225/250/300 XS All
225/300 X Pro Max All
350Sci and 400R Verado All
VesselView Mobile
Page: 5
Back to Main Page
8M0127340 eng December 2017 © 2017 Mercury Marine
What are the Requirements to Use the App?
To get the most from your app, you need the following:
1. Mercury Marine SmartCraft-capable engine.
Typically from 2003 and newer, 40 HP and above,
single to quad engine boat.
Please reference the chart above for compatibility.
Still unsure?
Your local Mercury Marine dealer is a great source for answers to all
your boating needs.
Provide your engine serial number to the dealer to help verify if your
boat is VesselView Mobile compatible.
2. The VesselView Mobile module.
3. A compatible Smart Device with the VesselView Mobile app installed.
Compatible devices are either iOS (Apple) or Android with BLE
(Bluetooth Low Energy), versions 4.0 or later. GPS and cellular–
enabled devices will provide the most capability.
Why Do I Need a VesselView Mobile Log–in?
The basic functionality of VesselView Mobile
does not require a valid log–in.
NOTE: Detailed fault information requires a valid log–in.
Why Do I Need a Profile to Log–in?
The profile created on the mobile device is used to keep track of engine
specific information (engine hours, maintenance history, engine software
ID, etc.). The profile determines how many engines will be displayed. A
profile name is required and is typically the name of your boat.
Page: 6
Back to Main Page
VesselView Mobile
8M0127340 eng December 2017 © 2017 Mercury Marine
How Do I Connect to the VesselView Mobile Module?
IMPORTANT: Bluetooth must be on. Do not select “Pair” from the
Settings/Bluetooth menu to connect to the device.
All Bluetooth Low Energy modules detected will appear on the scan
screen, sorted by signal strength.
NOTE: To confirm connectivity to the module, key off the engine. Data will
display as dashes on your mobile device. To connect, key back on; the data
should display promptly. You must reconnect to the module each time the
engine has been keyed off for more than ten minutes.
VesselView Mobile
Page: 7
Back to Main Page
8M0127340 eng December 2017 © 2017 Mercury Marine
How Do I Get Started After Installation?
Sign up – Create a free VesselView Mobile account and boat profile for
full access to the app.
Log–in – Once logged in, you will stay logged in until you log out, or
uninstall the app.
Skip – Allows limited access.
NOTE: All app content will be available for use except for Fault Details, which
requires a user account and internet access.
How Do I Connect to My VesselView Mobile App?
• First time users – Connect with or without a user profile. Access to
the app will be limited without logging in with a profile.
• Returning users – Must manually connect to VesselView Mobile each
day, or when the vessel has been keyed off for over ten minutes.
Page: 8
Back to Main Page
VesselView Mobile
8M0127340 eng December 2017 © 2017 Mercury Marine
What Are the Features in the VesselView Mobile App?
• View and customize up to five different screens of accurate
SmartCraft digital engine data such as RPM, engine temperature,
battery voltage, engine hours, fuel consumption, and more.
• View GPS Speed from the mobile device, which
also captures top speed, and holeshot
(0-20 mph) performance.
• View Fuel Management details such as Fuel Remaining (when you
record fuel added using your app). Information displayed includes
Fuel Used, and Distance to Empty.
Speed
Location
Calendar
Checklist
Add Feature
VesselView Mobile
Page: 9
Back to Main Page
8M0127340 eng December 2017 © 2017 Mercury Marine
What Are the Features in the VesselView Mobile App?
(Continued)
• Other features include: maintenance reminders, Engine Data Details,
and engine fault code information.
How Do I Customize the View of the Engine Data Details?
Users can now add additional SmartCraft data into the Engine Data Detail
screen. Select the RPM area to change the data and order seen . To customize
the view touch the menu in the upper right corner of the screen.
Note: Not all data will be available on all engines. Some data may require
optional sensors even if that engine is capable of providing the data.
Page: 10
Back to Main Page
VesselView Mobile
8M0127340 eng December 2017 © 2017 Mercury Marine
How Do I Customize the View of the Engine Data Details
(Continued)
Tap next to the data items to turn on or off. The checked data items will appear
on the Engine Data Detail screen.
To reposition how the data is displayed. Tap the item you wish to reposition and
swipe up or down to it's new location. Data Items will be displayed from top to
bottom as shown.
Users can uniquely name each page of data. To advance swipe from right to left
to view all data pages. The red dots at the bottom of the screen indicate how
many pages have been created. You can add up to three pages of data items.
The last page has all the details regarding the Engine hours, serial number,
software ID, calibration ID, and VVM module ID, useful if any troubleshooting is
required.
.
