Memorex 8564 Manual de usuario

User’s Guide

256MB MP3/WMA

Digital Audio Player

MMP8564

Before operating this product,

please read these instructions completely.

• Distributing copies of MP3, WMA with DRM or WAV tracks without permission is a

violation of international copyright laws.

SAFETY:

• Vibration experienced during walking or exercising will not affect the player. However,

dropping the player or dropping a heavy object on the player may result in damage or

sound distortion.

• Avoid spilling any liquid onto or into the player.

• Do not leave the player in a location near heat sources; in a location subject to direct

sunlight, excessive dust, sand, moisture, rain or mechanical shock; on an unlevel

surface; or in a car with the windows closed during periods of excessive heat.

ROAD SAFETY:

• Do not use headphones while driving, cycling or operating any motorized vehicle. It

may create a traffic hazard and it is illegal in some areas. It can be potentially

dangerous to play your headset at a high volume while walking, especially at pedestrian

crossings. You should exercise extreme caution or discontinue use in potentially

hazardous situations.

FCC WARNING:

• This equipment may generate or use radio frequency energy. Changes or

modiﬁcations to this equipment may cause harmful interference unless the

modiﬁcations are expressly approved in the instruction manual. The user could lose

the authority to operate this equipment if an unauthorized change or modiﬁcation is

made.

PRECAUTIONS

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

FCC DECLARATION

This device complies with Part 15 of the FCC rules. Operation is subject to the

following two conditions: 1) This device may not cause interference, and 2) This

device must accept any interference received, including interference that may cause

undesired operation.

Warning: Changes or modifications to this unit not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Shield cable must be used with this unit to ensure

compliance with class B FCC limits.

Dear Customer:

Selecting fine audio equipment such as the unit you’ve just purchased is only the start

of your musical enjoyment. Now it’s time to consider how you can maximize the fun

and excitement your equipment offers. This manufacturer and the Electronic Industries

Association’s Consumer Electronics Group want you to get the most out of your

equipment by playing it at a safe level. One that lets the sound come through loud and

clear without annoying blaring or distortion and, most importantly, without affecting

your sensitive hearing.

Sound can be deceiving. Over time your hearing “comfort level” adapts to higher

volumes of sound. So what sounds “normal” can actually be loud and harmful to your

hearing. Guard against this by setting your equipment at a safe level BEFORE your

hearing adapts.

To establish a safe level:

• Start your volume control at a low setting.

• Slowly increase the sound until you can hear it comfortably and clearly, and without

distortion.

Once you have established a comfortable sound level:

• Set the dial and leave it there.

Taking a minute to do this now will help to prevent hearing damage or loss in the future.

After all, we want you listening for a lifetime.

We Want You Listening For A Lifetime

Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment.

Since hearing damage from loud noise is often undetectable until it is too late, this

manufacturer and the Electronic Industries Association’s Consumer Electronics Group

recommend you avoid prolonged exposure to excessive noise. This list of sound levels

is included for your protection.

Decibel

Level Example

30 Quiet library, soft whispers

40 Living room, refrigerator, bedroom away from traffic

50 Light traffic, normal conversation, quiet office

60 Air conditioner at 20 feet, sewing machine

70 Vacuum cleaner, hair dryer, noisy restaurant

80 Average city traffic, garbage disposals, alarm clock at two feet

THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:

90 Subway, motorcycle, truck traffic, lawn mower

100 Garbage truck, chain saw, pneumatic drill

120 Rock band concert in front of speakers, thunderclap

140 Gunshot blast, jet engine

180 Rocket launching pad

Information courtesy of the Deafness Research Foundation.

EST. 1924

EIA

LISTENING

For A Lifetime

Want You

LOCATION OF CONTROLS

1. Headphone Jack

2. Battery Compartment

(Under Cover)

3. MENU/Lock Button

(Side of Unit)

4. Power On/Off/Stop Button

(Side of Unit)

5. Navigation Control*: (clockwise)

Navigation π

Navigation ®/Skip/Search n

Navigation †

Navigation √/Skip/Search o

6. USB Jack & SD/MMC Memory

Card Slot (Under Cover)

7. Display

8. Volume + Button

9. Volume - Button

10. Play/Pause ®p Button*

*Pressing the Navigation control also

acts as an Enter/Select/Play/Pause ®p

button.

BATTERY INSTALLATION

When the bars in the battery indicator (in the display) become low (see Figure 1),

replace the battery as follows.

1. Remove the top cover by pressing the

Open button, then lifting the top cover

up to remove it as shown in Figure 2.

2. Insert one (1) “AAA” battery (positive

side facing the bottom of the unit and negative side facing the top) as shown

in Figure 3, making sure to close the battery latch (press down the battery

latch and slide the latch until it locks in place). An alkaline battery is

recommended

for the longest

playing time.

3. Put the top

cover back on

until it snaps in

place.

BATTERY PRECAUTIONS

Follow these precautions when using a battery in this device:

1. Use only the size and type of battery speciﬁed.

2. Be sure to follow the correct polarity when installing the battery as indicated. Reversed

batteries may cause damage to the device.

3. If the device is not to be used for a long period of time, remove the battery to prevent damage

or injury from possible battery leakage.

4. Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.

(Follow battery manufacturer’s directions.)

Figure 3

Figure 1

Figure 2

NOTE: Each time after you have replaced the battery, when you turn on the unit again, it

will search the music files to update the index. It will take approx. several seconds to update

the index; this updating time depends on the number of music files in the SD/MMC card and

in the internal memory.

FULL 50% EMPTY

USING THE ARM STRAP

Insert the arm strap into the slot on

the rear of the unit and pull through.

Pull the arm strap and insert it into

the buckle.

Insert the arm strap into the slot on

the rear of the unit and pull through.

TO INSTALL THE "DIGITAL AUDIO PLAYER" CD SOFTWARE

For Windows ME, Windows2000 or Windows XP:

Windows will automatically detect the audio player without installing the CD software

when the USB cable is connected.

For Macintosh OSX:

Macintosh OSX will automatically detect the audio player without installing the CD

software. Do not install the software when using a Macintosh.

For Windows98SE:

The USB mass storage function will not be activated without driver installation. To

activate the USB mass storage function, please use the installation CD-Rom to install

the driver.

For Windows 98SE, if you are connecting your player to your computer for the first

time, please follow these instructions:

Procedure to Install Player Driver

1. Insert the Installation CD-Rom

into the CD Drive, then the

installation screen will appear. If

the installation screen doesn't

automatically appear, double-

click my computer then double-

click on the CD drive, then the

installation screen will appear.

Click on the Windows 98

firmware icon. Then click on the

MMP8564 icon.

INSTALL “DIGITAL AUDIO PLAYER” SOFTWARE

2. At the Welcome screen, click NEXT.

3. Read the License Agreement. If you accept

the terms of the license agreement, select

and dot the circle at the left of "I accept the

terms of the license agreement". Then click

NEXT.

4. At the Setup screen, click NEXT. It is

recommended to leave the destination folder

as it is.

WINDOWS 98 DRIVER INSTALLATION
