MEITRACK TC68L/TC68SL Plug-and-Play Vehicle GPS Tracker User Guide

MEITRACK TC68L/TC68SL Plug-and-Play

Vehicle GPS Tracker User Guide

MEITRACK TC68L/TC68SL Plug-and-Play Vehicle GPS Tracker User Guide

Change History

File Name MEITRACK TC68L/TC68SL Plug-and-Play Vehicle GPS Tracker User Guide

Project TC68L/TC68SL Creation Date

Update Date

2019-05-06

2021-09-01

Subproject User Guide Total Pages 15

Version V1.3 Confidential External Documentation

MEITRACK TC68L/TC68SL Plug-and-Play Vehicle GPS Tracker User Guide

Contents

1 Copyright and Disclaimer........................................................................................................................................... - 4 -

2 Friendly Reminder ..................................................................................................................................................... - 4 -

2.1 Use Notice .................................................................................................................................................... - 4 -

2.2 Device and Accessories................................................................................................................................. - 4 -

3 Product Introduction ................................................................................................................................................. - 5 -

3.1 Product Overview ......................................................................................................................................... - 5 -

3.2 Product Specifications .................................................................................................................................. - 5 -

3.3 Product Functions......................................................................................................................................... - 6 -

3.3.1 Position Tracking .................................................................................................................................. - 6 -

3.3.2 Alerts.................................................................................................................................................... - 6 -

3.3.3 Other Functions ................................................................................................................................... - 7 -

4 Appearance................................................................................................................................................................ - 8 -

5 How to Use ................................................................................................................................................................ - 9 -

5.1 Installing a SIM Card ..................................................................................................................................... - 9 -

5.2 LED Indicator................................................................................................................................................. - 9 -

5.3 Tracking by Mobile Phone............................................................................................................................. - 9 -

5.3.1 Setting Authorized Phone Numbers – A71 ........................................................................................ - 11 -

5.3.2 Setting the Smart Sleep Mode – A73 ................................................................................................. - 11 -

5.3.3 Setting the SMS Time Zone – B35 ...................................................................................................... - 12 -

5.4 Configuring Device Parameters by Meitrack Manager ............................................................................... - 12 -

5.4.1 Setting the IP Address and Port ......................................................................................................... - 13 -

5.4.2 Setting the WiFi Network................................................................................................................... - 13 -

5.5 Logging In to MS03 Tracking System........................................................................................................... - 14 -

6 OBD Function........................................................................................................................................................... - 14 -

7 Device Installation ................................................................................................................................................... - 14 -

MEITRACK TC68L/TC68SL Plug-and-Play Vehicle GPS Tracker User Guide

1Copyright and Disclaimer

, and are trademarks that belong to Meitrack Group and its subsidiary.

The user manual may be changed without notice.

Without prior written consent of Meitrack Group, this user manual, or any part thereof, may not be reproduced for

any purpose whatsoever, or transmitted in any form, either electronically or mechanically, including photocopying

and recording.

Meitrack Group shall not be liable for direct, indirect, special, incidental, or consequential damages (including but

not limited to economic losses, personal injuries, and loss of assets and property) caused by the use, inability, or

illegality to use the product or documentation.

2Friendly Reminder

2.1 Use Notice

Power off the device before you go to a gas station, hazard zone, or a place where wireless products are

prohibited.

Do not expose the device to rain or extremely hot temperatures.

The device's tracking function may be unavailable due to force majeure (like bad weather and GPS blind spots).

To strength the device signal, keep away from a metal covered place when you use an extension cord.

The device's operating voltage is DC 11.5–36 V, and you can install it into a 12 V/24 V vehicle.

Ensure that the vehicle engine is cut off before installation.

The device's extension cord you purchase additionally can be used to strength the GPS signal.

2.2 Device and Accessories

Check whether the product and standard accessories are included according to the following table. You can

additionally purchase optional accessories as required.

Device and Standard Accessories

NO. Item Quantity

1 TC68L/TC68SL tracker 1

2 USB cable 1

3 Packing box 1

4 CD download card 1

Optional Accessories

NO. Item Quantity

1 OBD extension cord 1

2 Velcro 1

MEITRACK TC68L/TC68SL Plug-and-Play Vehicle GPS Tracker User Guide

3Product Introduction

3.1 Product Overview

The TC68L/TC68SL is a plug-and-play vehicle GPS tracker equipped with an OBD II plug, which supports vehicle

positioning, live tracking, and anti-theft functions.

With a standard OBD II plug, it can be easily installed. The device has an internal battery that supplies power to it for

a limited time period. When the device is removed, an instant alert will be received.

The TC68L/TC68SL tracker is a perfect choice for private cars and other motor vehicles equipped with an OBD II

connector.

The TC68L tracker supports the OBD function, while the TC68SL tracker does not support this function.

3.2 Product Specifications

Item Specifications

Dimension 67 mm x 51 mm x 23.5 mm

Weight 60g

Power supply DC 11.5–36 V / 1 A

Backup battery 200 mAh/3.7 V

Battery life Power-saving mode: 20 hours

Normal working mode: 2 hours

Power consumption Current in standby mode: 100 mA

Operating

temperature

-20°C to 55°C

Operating humidity 5%–95%

LED indicator 2 LED indicators showing GSM and GPS status

Button/Switch 1 SOS button

Memory 8 MB

Sensor 3-axis accelerometer

Frequency band No WiFi version band：

TC68L\TC68SL-E：

LTE FDD:B1/B3/B7/B8/B20/B28A

WCDMA: B1/B8

GSM/GPRS: B3/B8

TC68L\TC68SL-A：

LTE FDD:B2/B4/B12

WCDMA: B2/B4/B5

TC68L\TC68SL-AU：

LTE FDD:B1/B2/B3/B4/B5/B7/B8/B28

LTE TDD:B40

WCDMA: B1/B2/B5/B8

GSM/GPRS: B2/B3/B5/B8

TC68L\TC68SL-J：

LTE FDD: B1/B3/B8/B18/B19/26

WiFi version band：

TC68L\TC68SL-E：

LTE FDD:B1/B3/B5/B7/B8/B20/

WCDMA: B1/B5/B8

GSM/GPRS: B3/B8

TC68L\TC68SL-A：

LTE FDD:B2/B4/B12

WCDMA: B2/B4/B5

TC68L\TC68SL-AU：

LTE FDD:B1/B2/B3/B4/B5/B7/B8/B28

LTE TDD:B40

WCDMA: B1/B2/B5/B8

GSM/GPRS: B2/B3/B5/B8

TC68L\TC68SL-J：

LTE FDD: B1/B3/B8/B18/B19/26

WCDMA: B1/B6/B8/19

MEITRACK TC68L/TC68SL Plug-and-Play Vehicle GPS Tracker User Guide

TDD：B41

GPS sensitivity -161 dB

Positioning accuracy 2.5 meters

I/O port 1 USB port

WiFi function

(optional)

2.4 GHz WiFi hotspot

3.3 Product Functions

3.3.1 Position Tracking

Function Description

Real-time tracking After sending a command, you can query the current device location from the

platform or your mobile phone.

Tracking by time

interval

After you set the time interval, the device will report its location information to the

platform or mobile phone at the preset time interval.

Tracking by distance After you set the distance, the device will report its location information to the

platform based on the preset distance.

Cornering report Set the cornering angle. When the driving angle is greater than the preset value, the

device will report its location information. This report is used to make the driving

route smoother when no data is sent at the preset time interval or distance interval

while the vehicle corners.

3.3.2 Alerts

Function Description

External power supply

cut-off alert

When the device is removed from the OBD connector, an alert will be reported to

the platform or be notified to the user.

Speeding You can set the maximum speed threshold by using the platform, Meitrack

Manager software or SMS. When the driving speed exceeds the preset value, an

alert will be sent.

Geo-fence With a coordinate and radius, you can set a circular geo-fence.

When the vehicle enters or exits the preset geo-fence, an alert will be reported

to the platform or be notified to the user by SMS. A maximum of eight circular

geo-fences can be set.

SOS alert When the SOS button is pressed, an alert will be sent.

Low battery alert for the

external power supply

When the voltage of the external power supply is lower than 11.4 V, an alert will

be sent.

Device status alert When the device is powered on or powered off, a device status alert will be sent.

When the internal battery power is low, a low battery alert will be sent.

Harsh

acceleration/braking alert

When the driving speed exceeds the preset harsh acceleration/braking threshold,

an alert will be sent. The TC68L supports this function because it can obtain OBD

data. However, the TC68SL does not support this function.

MEITRACK TC68L/TC68SL Plug-and-Play Vehicle GPS Tracker User Guide

3.3.3 Other Functions

Function Description

Over-the-Air (OTA)

update

Update the device firmware by OTA.

GPS log When the GPS is valid, the device will record the driving routes at the preset time

interval. You can use Meitrack Manager software to read these records. A maximum

of 130,000 records can be stored.

GPS + LBS positioning When a valid GPS signal cannot be received, the GSM base station will be used for

assisted positioning to ensure that the vehicle can be located at any time.

GPS blind spot report When the vehicle enters or exits an area without GPS signal, the device will send a

report to the platform.

Auto data storage in a

GSM blind spot/Data

resending

When data fails to be sent to the platform in a GSM blind spot, the data will be

automatically stored. When the GSM becomes valid, the data will be automatically

sent to the platform. The built-in 8 MB flash memory can store 8,192 pieces of GPRS

data and 256 SMS messages.

Mileage report All the GPRS data contains the vehicle mileage. For the first use, you can modify the

default mileage.

Maintenance report You can set the maintenance mileage and time by using the platform. When the

vehicle maintenance mileage or time reaches the preset value, the device will send a

maintenance alert.

External power

protection

When the device detects that the voltage of the external power supply is lower than

the rated voltage and the device stops moving, it will automatically enter the deep

sleep mode.

WiFi function

(optional)

The device supports the 2.4 GHz WiFi hotspot function, and a maximum of eight WiFi

networks can be connected. You can use Meitrack Manager software to configure the

WiFi function.

MEITRACK TC68L/TC68SL Plug-and-Play Vehicle GPS Tracker User Guide

4Appearance

NO. Item Description

1 USB port The USB port is used to charge the device, configure device parameters, and

upgrade software.

2 GSM LED indicator

(green)

Indicates the GSM status. For details, see the section 5.2 "LED Indicator."

3 GPS LED indicator

(blue)

Indicates the GPS status. For details, see the section 5.2 "LED Indicator."

4 SOS button Press and hold down the button for two seconds in the case of emergency.

Then the device will beep once.

The device will also dial three authorized phone numbers 1, 2, and 3 in

sequence. It will stop dialing when a phone number responds. Meanwhile,

the device will send an SMS with positioning information to authorized phone

numbers. If the GPRS function is enabled, the device will send a GPRS

message to the server.

USB port

SOS button

Vehicle's OBD II connector

GSM LED indicator GPS LED Indicator

MEITRACK TC68L/TC68SL Plug-and-Play Vehicle GPS Tracker User Guide

In the sleep mode, short press the button to wake the device up.

5 Vehicle's OBD II

connector

After you plug the device into the vehicle's OBD II connector, the device will

be always powered on by the vehicle's battery.

5How to Use

5.1 Installing a SIM Card

To install a SIM card, open the SIM card cover, insert the card (card chip facing up), and close the card cover.

Note:

Ensure that the SIM card has sufficient balance.

Ensure that the phone card PIN lock has been closed properly.

Ensure that the SIM card in the device has subscribed the caller ID service if you want to use your authorized

phone number to call the device.

Power off the device before installing the SIM card.

5.2 LED Indicator

GPS LED Indicator (Blue)

Steady on A button or an input is triggered.

Blink fast (once every 0.1 seconds) The device is being initialized, or the battery power is low.

Blink fast (0.1 seconds on and 2.9

seconds off) A GPS signal is received.

Blink slowly (1 second on and 2

seconds off) No GPS signal is received.

GSM LED Indicator (Green)

Steady on There is an incoming call, or the subscriber you dialed is busy

now.

Blink fast (once every 0.1 seconds) The device is being initialized.

Blink fast (0.1 seconds on and 2.9

seconds off) A GSM signal is received.

Blink slowly (1 second on and 2

seconds off) No GSM signal is received.

Note: When the device is in the sleep mode, the GSM and GPS LED indicators are off.

5.3 Tracking by Mobile Phone

Call the device's SIM card number, and hang up after the dial tone rings 2–3 times. The device will reply to an SMS

MEITRACK TC68L/TC68SL Plug-and-Play Vehicle GPS Tracker User Guide

with a map link.

Click the SMS link. The device's location will be displayed on Google Maps on your mobile phone.

SMS example:

Now,110721 16:40,V,10,0Km/h,97%,http://maps.meigps.com/?lat=22.513015&lng=114.057235

The following table describes the SMS format:

Parameter Description Remarks

Now Indicates the current location. SMS header: indicates the current location or

the alert type.

For details about the SMS header, see the

MEITRACK SMS Protocol and MEITRACK GPRS

Protocol.

110721 16:40 Indicates the date and time in

MMDDYY hh:mm format.

Time format: MMDDYY hh:mm

V The GPS is invalid. A = Valid

V = Invalid

10 Indicates the GSM signal strength. Value range: 1–32

The larger the value is, the stronger the signal

is. If the parameter value is greater than 12,

GPRS reaches the normal level.

0Km/h Indicates the speed. Unit: km/h. The speed is 0.

97% Indicates the remaining battery

capacity.

The remaining battery capacity is 97%.

http://maps.meigps.c

om/?lat=22.513015&

l ng=114.057235

This is a map link with a latitude and

longitude.

lat indicates the latitude. Latitude:

22.513015.

lng indicates the longitude.

Longitude: 114.057235.

You can visit the map through a mobile phone.

If your mobile phone does not support HTTP, enter the latitude and longitude on Google Maps to query a location.

Otros manuales para TC68L

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de GPS de MeiTrack

MeiTrack

MeiTrack iButton T333 Manual de usuario

MeiTrack

MeiTrack Mobileye T622 Manual de usuario

MeiTrack

MeiTrack MT90G Manual de usuario

MeiTrack

MeiTrack MVT100 Manual de usuario

MeiTrack

MeiTrack MVT380 Manual de usuario

MeiTrack

MeiTrack TC68 Manual de usuario

MeiTrack

MeiTrack GT30i Manual de usuario

MeiTrack

MeiTrack MT80i Manual de usuario

MeiTrack

MeiTrack iButton MVT600 Manual de usuario

MeiTrack

MeiTrack Mobileye T622 Manual de usuario

MeiTrack

MeiTrack MT90 Manual de usuario

MeiTrack

MeiTrack T633G Manual de usuario

MeiTrack

MeiTrack T711L Manual de usuario

MeiTrack

MeiTrack iButton T1 Manual de usuario

MeiTrack

MeiTrack T399G-GFB5 Manual de usuario

MeiTrack

MeiTrack MT88 Manual de usuario

MeiTrack

MeiTrack TC68L Manual de usuario

MeiTrack

MeiTrack MT90G Manual de usuario

MeiTrack

MeiTrack GT60 Manual de usuario

MeiTrack

MeiTrack T622 Series Manual de usuario

MeiTrack

MeiTrack TA255 Series Manual de usuario

MeiTrack

MeiTrack MVT380 Manual de usuario

MeiTrack

MeiTrack MT80 Manual de usuario

MeiTrack

MeiTrack MT90 Manual de usuario

Manuales populares de GPS de otras marcas

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Manual de usuario

Garmin

Garmin SOUNDER 125 Manual de usuario

Garmin

Garmin DEZL 580 Manual de usuario

Jigabot

Jigabot EX Manual de usuario

Pointer

Pointer Cellocator CelloTrack XT LTE Guía de instalación

Queclink

Queclink GV55LITE Manual de usuario

Voxson

Voxson Voxtrack GPS500 Manual de instrucciones

Garmin

Garmin ECHOMAP PLUS Manual de usuario

Starcom Systems

Starcom Systems Kylos Compact Manual de usuario

Garmin

Garmin 15 H Series Manual de usuario

Cobra

Cobra Marine MC 600Ci Manual de usuario

Cellocator

Cellocator CelloTrack T Manual de usuario

Enfora

Enfora Mini-MT GSM2228UG001 Manual de usuario

Magellan

Magellan eXplorist 100 Manual de usuario

LTE

LTE G50B Manual de usuario

Garmin

Garmin DEZL OTR500 Manual de usuario

SkyGolf

SkyGolf SkyCaddie SG1 Manual de usuario
