MBM FUNK URBAN 20 Manual de usuario
FUNK URBAN 20”
USER MANUAL
FUNK URBAN
FUNK URBAN USER MANUAL
1. FOREWORD 4
1.1 General 4
1.2 Assistance 4
1. 3Graphic form of security warnings 4
2. SECURITY WARNINGS 5
2.1 General safety rules 5
2.2 Responsabilities 5
2.3 Warning for users 6
2.4 Maintenance warnings 6
2.5 Other provisions 7
2.6 Unpacking and tuning 7
2.6.1 Saddle adjustment
7
2.6.2 Handlebar adjustment
8
2.6.3 Pedal mounting
9
3. BICYCLE DESCRIPTION 10
3.1 General description 10
3.2 Data sheet 11
3.3 Brake levers 12
3.4 Speed change 12
3.5 Assistance system management 13
3.5.1 Commands
13
3.5.2 Turning the system on/off
13
3.5.3 Assistance attivation
14
3.5.4 Support levels
14
3.5.5 Single distance reset
15
3.5.6 Walking assistance mode
15
3.5.7 Turning the lights on/off
15
3.5.8 Battery indicators
16
3.5.9 Error codes
16
3.5.10 Problem solving
17
3.6 Battery 18
3.6.1 Battery charge status
18
3.6.2 Battery removal/installation
18
3.6.3 Battery charging
20
3.6.4 Problem solving
20
3.7 Front and rear light 21
3.8 Front suspension 21
INDEX
4. CONDITION OF USE AND INTENDED ENVIRONMENT 22
4.1 Intended use 22
4.2 Environment of use 22
4.3 Improper uses and contraindications 23
5. LIFTING AND TRANSPORT 24
5.1 Lifting 24
5.2 Transport 24
6. COMMISSIONING 25
6.1 Battery charge 25
6.2 Preliminary functional settings 26
6.2.1 Control devices
26
6.2.2 Wheels
26
6.2.3 Braking
26
6.2.4 Frame, handlebar and seat position
27
6.2.5 Brake adjustment
28
6.2.6 Suspension adjustment
28
6.2.7 Headlight operation
29
7. USE OF THE BICYCLE 29
7.1 Driving the bicycle 30
7.2 Braking 30
7.3 Bicycle parking 30
8. MANTEINANCE 31
8.1 General 31
8.2 Daily maintenance and checks 31
8.2.1 Tags and pictograms check
31
8.2.2 Wheel check
31
8.2.3 Brake functional sitting
32
8.3 Weekly maintenance and checks 32
8.3.1 Washing and cleaning
32
8.3.2 Lubrication and chain tension control
32
8.3.3 Frame and bolt control
32
8.4 Monthly maintenance and checks 33
8.4.1 Control of electrical circuits and components
33
8.4.2 Rear derailleur control and adjustment
33
FUNK URBAN USER MANUAL
p.3
9. TECHNICAL ASSISTANCE AND SPARE PARTS 34
10. WAREHOUSE 34
11. DISPOSAL OF COMPONENTS AND MATERIALS 35
12. WARRANTY RULES 36
13. CONFORMITY 37
FUNK URBAN USER MANUAL
p.4
1.FOREWORD
1.1 Generalities
This manual is an integral and essential part of the FUNK URBAN 20” pedal-assisted bicycle. Before commissioning , it
is essential that users read, understand and scrupulously follow the following provisions. The manufacturer is not liable
for damage caused to persons and / or things or to the pedal-assisted bicycle if it is used incorrectly with respect to
the requirements Indicated.
With a view to continuous technological development, the manufacturer reserves the right to modify the components,
including the frame, without notice and without this manual being automatically updated.
1.2 Assistance
For any inconvenience or request for clarification contact the authorized dealer, who has competent and specialized per-
sonnel, as well as specific equipment and original spare parts.
1.3 Graphic form of security warnings
To identify security messages, the following graphical signal symbols will be used in this manual. They have the function
of attracting the attention of the reader / user for the correct and safe use of the assisted bicycle.
Highlights the presence of hazards that cause
residual risks to which the user must pay at-
tention in order to avoid accidents or materi-
al damage.
DANGER
Highlights behavioral rules to be kept in order
to avoid damage to the pedal-assisted bicycle
and / or the onset of dangerous situations.
ATTENTION
FUNK URBAN USER MANUAL
p.5
2. SECURITY WARNINGS
2.1 General safety rules
Even if you are already practical in the use of pedal-assisted bicycles , you must follow the instructions given here, in
addition to the general precautions to be observed during the driving a motor vehicle . In particular:
• Acquire full knowledge of the pedal-assisted bicycle;
• Read the manual carefully to know the operation, the safety devices and all the precautions necessary for the safe use
of the vehicle. All this to allow safe use;
• Carefully maintain the pedal-assisted bicycle in perfect condition;
For any inconvenience or request for clarification contact without hesitation the authorized dealer, who has competent
and specialized personnel, specific equipment and original spare parts.
2.2 Responsabilities
Failure to comply with the operating instructions and safety requirements contained in this manual exempts the man-
ufacturer from any liability.
If the maintenance of the pedal-assisted bicycle is carried out in a manner that does not comply with the instructions
provided, with non-original spare parts or in any case in such a way as to compromise its integrity and modify its charac-
teristics, the manufacturer shall will be relieved of any responsibility inherent in the safety of persons and the defective
operation of the pedal-assisted bicycle.
ATTENTION
USE OF THE PEDAL-ASSISTED BICYCLE
Each user must first have read the instruction manual, in particular the chapter on safety claims.
ATTENTION
RISK ASSOCIATED WITH THE USE OF THE PEDAL-ASSISTED BICYCLE
• Notwithstanding the application of safety devices, for the safe use of the pedal-assisted bicycle , all the requirements re-
lating to the prevention of accidents reported in this manual.
• Always stay focused while driving and DO NOT underestimate the residual risks associated with the use of the assisted
bicycle.
FUNK URBAN USER MANUAL
p.6
For any data not included or not deductible from this manual, it is recommended to consult the authorized dealer directly.
2.3 Warnings for users
1. It can only be used by experienced adults and children;
2. Do not take alcohol or drugs before riding the pedal-assisted bicycle;
3. These models of pedal-assisted bicycles are designed and built to be used outdoors, on roads and private and public
environments;
4. Do not ask the pedal-assisted bicycle for performance higher than that for which it was designed;
5. Never ride the pedal-assisted bicycle with disassembled parts;
6. Avoid uneven surfaces and obstacles;
7. Ride with both hands on the handlebars;
8. Replace worn and/or damaged parts and check that the guards are working properly before use.
2.4 Maintenance warnings
1. Any maintenance must take place with the battery disconnected;
2. During each maintenance phase , operators must be equipped with the necessary accident prevention equipment;
3. The tools used for maintenance must be suitable and of good quality;
4. Do not use gasoline or flammable solvents as detergents, but always resort to non-flammable and non-toxic solvents;
5. Limit as much as possible the use of compressed air for cleaning (max 2 bar) and protect yourself with glasses with
side guards;
6. Never resort to the use of open flames as a means of illumination when carrying out verification or maintenance op-
erations;
7. After any maintenance or adjustment, make sure that no tools or foreign bodies remain between the moving parts of
the pedal-assisted bicycle.
ATTENTION
UNAUTHORIZED CHANGES
If you hear unusual noises or feel something strange, stop the pedal-assisted bicycle immediately. Carry out a check after-
wards and, if necessary, contact the authorized dealer.
ATTENTION
ORIGINAL SPARE PARTS
Use only original spare parts supplied by M.B.M. S.r.l. Unipersonal. Any liability of the Manufacturer for damage or loss of
functionality caused as a result of the use of non-original accessories and parts is excluded.
FIG. 1
FUNK URBAN USER MANUAL
p.7
2.5 Other provisions
The first thing to do when starting use is to check the presence and integrity of the protections and the operation of the
safety devices. If you find any defects, do not use the pedal-assisted bicycle!
2.6 Unpacking and tuning
The pedal-assisted bicycle is delivered fully assembled and working.
2.6.1 Saddle adjustment
The adjustment of the height of the saddle is an essential prerogative for the correct use of the pedal-assisted bicycle.
Incorrect adjustment can generate structural breaks to the frame.
Adjust the height of the saddle by operating the quick release mechanism (Ref. A – Figure 1). Check that the mechanism
is tightened before testing the seat and using the medium. Do not lift the saddle beyond the limit sign placed in the tube
(Ref. B – Figure 1
DANGER
IMPORTANT NOTICE:
For your safety, the reference mark of
the seatpost tube (B) should never be
outside the tube where the seatpost tube
is inserted.
ATTENTION
ASSEMBLY
In the event that you do not have the ap-
propriate instrumentation for adjust-
ment or do not have the capabilities, con-
tact the authorized dealer.
GUARDS
It is strictly forbidden, therefore, to modify or remove the guards, controls, labels and indication plates.
DANGER
FIG. 2
FIG. 3
FUNK URBAN USER MANUAL
p.8
2.6.2 Handlebar adjustment
For a comfortable posture on the bike, which does not cause neck or back pain, we recommend the handlebar column
height adjustment.
Adjust the height of the handlebar column by operating the quick release mechanism (Ref. C – Figure 2). Check that the
mechanism is tight before using the vehicle. Do not lift the handlebar column beyond the height allowed by the mechanism.
To facilitate the transport and storage of the pedal-assisted bicycle, it is possible to unhook and flex the steering column
by means of the centrally placed hinge (Ref. D – Figure 2).
Use the hinge of the handlebar column by lifting the safety
mechanism (Ref. E – Figure 3) and open the hinge.
Check that the release mechanisms are tightened before us-
ing The vehichle.
ATTENTION
ASSEMBLY
In the event that you do not have the appropri-
ate equipment for adjustment or do not have
the capabilities contact the authorized dealer .
ATTENTION
ATTENTION
Do not lift the handlebar column beyond the
maximum height allowed by the mechanism.
Do not use the pedal-assisted bicycle with the
zipper unhooked .
FIG. 4
FUNK URBAN USER MANUAL
p.9
ATTENTION
ASSEMBLY
In the event that you do not have the appropriate
equipment for adjustment or do not have the capa-
bilities, contact the authorized dealer.
2.6.3 Pedal mounting
Right pedal: IT is identified by the letter “R” marked on its
pin. For pedal mounting, screw by turning the pin clockwise.
(Figure 4).
Left pedal: it is identified by the letter “L” marked on its pin.
For pedal mounting, screw by turning the pin counterclock-
wise (Figure 4).
ATTENTION
ASSEMBLY
For a correct tightening of the pedals, it is neces-
sary to use a key of 15
FUNK URBAN USER MANUAL
p.10
3. BICYCLE DESCRIPTION
3.1 General description
The pedal-assisted bicycle is designed and built to be used outdoors, on roads and private or public environments. In
particular, the components and the type of pedal-assisted bicycle allow you to tackle routes with asphalt surfaces or
with similar characteristics without particular roughness.
The pedal-assisted bicycle is equipped with a rechargeable battery and an electric motor, whose intervention takes
place only in conjunction with the pedaling and gradually stops as the speed of the vehicle approaches 25 km / h, and then
stops completely at that speed.
For the management of the assistance system there is a special display located on the left side of the handlebar. On the
right side of the handlebar there is a control system for adjusting the gears.
INCORRECT AND UNINTENDED USE
The bicycle has been designed and manufactured for the specified use; a different use and failure to comply with the technical
parameters set by the manufacturer may constitute a dangerous condition for users.
DANGER
