DASHBOARD

DISASSEMBLY INSTRUCTIONS

for Polaris®RZR®Vehicles

Instruction Manual

MBQR-RAD-2

THANK YOU!

Congratulations for choosing the MBQR-RAD-2, an AM/FM/WB, USB and Bluetooth

Multimedia Controller by MB Quart. The unit and housing are engineered to t 2013 and

newer Polaris®RZR®vehicles. For more detailed information about the product, the

operator/install manual* and a video tutorial, please visit MBQuart.com.

*Wiring information, installation steps and operation of the MBQR-RAD-2 source unit are in the

Operator's Guide and Installation Instructions pictured at right.

INSTALLATION TIME

About 1.5 hours are required to complete this installation, not including other system

components. These instructions are for dashboard disassembly only.

TOOLS AND SUPPLIES NEEDED

● Wire Strippers and Crimpers ● Flush Cut Wire Cutters (for trimming zip-ties)

● Bojo Tools (Pry Tools) ● T40 Torx Driver

● Ratchet w/ 10mm Socket ● T25 Torx Driver

● (Optional) Soldering iron, solder and heat shrink tubing or high-quality electrical tape

SAFETY PRECAUTIONS

Safely prepare your machine for the MBQR-RAD-2 installation before proceeding.

● Turn the ignition off and remove the key

● Use a packing blanket other soft material to protect your machine

● Safety Glasses - always wear eye protection

PREPARATION FOR INSTALLATION

Before dismantling your vehicle, we suggest you prepare your tools, the MBQR-RAD-2 and its wiring as

increases efciency to have everything ready when each component is installed.

STEP 1 – REMOVE SEATS

Remove driver and passenger seats by pulling on the

lock clip shown in Figure 1-1 This lock clip is located

between the bottom and upright portion of the seat.

Removing both seats will give you the room to work in

the kick panel areas, in addition to getting access to the

battery for Step 2.

STEP 2 – REMOVE NEGATIVE BATTERY CABLE

Using a 10mm socket and ratchet, remove the negative

battery terminal and set aside as shown in Figure 1-2.

This safety measure ensures you do not have any

accessories powered during the installation, as well as

keeps the battery from unnecessarily draining.

Figure 1-1

Figure 1-2

PRE-INSTALLATION

Operator’s Guide and

Installation Instructions

MBQR-RAD-2

AM/FM/USB/Bluetooth®

Multimedia Controller and

for Polaris®RZR®Vehicles

MBQR-RAD-2

Operator's Guide and

Installation Instructions

DISASSEMBLY

DASH AREA DISASSEMBLY 2013-2018 (Non-Turbo S) RZR

Please note, separate disassembly instructions for the 2018.5 Turbo S and 2019+ RZR models are found on

pages 5-8 in this manual.

STEP 1 – REMOVE CENTER HOOD

Start with removing the hood as shown in Figure 5-1.

Twist the tabs at the upper left and right corners. Pull

up to remove. This is where you will access the bus

bar to make power connections for your source unit.

Conrm that your machine has the bus bar harness

installed. If your bus bar harness has not been installed,

you can purchase from your dealer or Polaris online.

The part numbers are 2881551 or 2881646 depending

on which specic RZR model you own.

STEP 2 - REMOVE TOP OF DASH

Remove (2) T40 screws as shown in Figure 5-2. Slide

dash forward to access back of dash and unplug gauges and switches one at a time. Set dash aside in a

safe location. This will provide wiring access.

STEP 3 – REMOVE THE GRAB BAR

Remove the grab bar as shown in Figure 5-3 by removing the retaining clip and pin and rmly pulling the

grip toward the rear of the vehicle.

STEP 4 - REMOVING DASH POCKET & REAR MOUNT

To remove the DIN dash pocket from the dash, locate the rear support bracket at the rear of the pocket and

remove the T40 Torx head screw as in Figure 5-4. Next, remove the clip shown on the right from the back

and pull out the plastic pocket. Set aside the retaining clip shown in Figure 5-5 for re-use when mounting the

MBQR-RAD-2 source unit.

Figure 5-1

Figure 5-2

Figure 5-3

Figure 5-4

T40 Torx Screw

Set aside OEM dash clip for source unit mounting

later in the installation as its reused when you are

installing an MB Quart MBQR-RAD-2.

Figure 5-5

DASH AREA DISASSEMBLY 2013-2018 (Non-Turbo S) RZR - Continued

STEP 5 – REMOVE DASH FASCIA CENTER HARDWARE

Remove (4) Torx screws from the front of the dash through the openings shown in Figure 5-6. The rst set of

Torx screws will come out allowing access to the second (upper) set further back in the dash. Next, pull the

only the center of the dash loose as shown in Figure 5-7.

STEP 6 – REMOVE DASH FASCIA HARDWARE

Using a large panel removal tool, release the side clips from the passenger’s side front dash assembly as

shown in Figures 5-8 and 5-9. Slowly ensure you account for all clips removed.

NEXT STEPS

Refer to the MBQR-RAD-2 Operator’s Guide and Installation Instructions for wiring and tting details. This is

available at MBQuart.com.

Figure 5-7Figure 5-6

Figure 5-9Figure 5-8

DISASSEMBLY

Operator’s Guide and

Installation Instructions

MBQR-RAD-2

AM/FM/USB/Bluetooth®

Multimedia Controller and

for Polaris®RZR®Vehicles

MBQR-RAD-2

Operator's Guide and

Installation Instructions

DASH AREA DISASSEMBLY 2018.5 Turbo S & 2019+ RZR (RIDE COMMAND)

Please note, separate disassembly instructions for the 2013-2018 RZR models are found on pages 3-4 in

this manual.

STEP 1 – REMOVE CENTER HOOD

Remove the center of the hood area as shown in Figure

7-1. Twist the recessed tabs at the upper left and right

corners. Pull up to remove. Next, pull passenger’s side

grab bar retaining clip and pin, then rmly pulling the

grip toward the rear of the vehicle. This is where you

will access the bus bar if you will also be installing

an amplier to power the kick panel speakers. This

access is also necessary for further disassembly.

STEP 2 - REMOVE CENTER SHROUD

Remove (2) plastic push clips behind the center shroud as shown in Figure 7-2a to remove the Ride

Command cover or pocket depending on your vehicle. Cover removed shown in Figure 7.2b.

STEP 3 - REMOVE FULL FRONT COVER DASH TOP ASSEMBLY

Remove (2) T40 screws located by the A-pillars as shown in Figure 7-3a. Next, remove the (2) T40 screws

holding the front of the dash in the inner fender near the water bottle and bus bar. Lift upwards to release the

top of the dash cover and remove as shown in Figure 7-3b. This allows easy access for running wires.

Figure 7-1

Figure 7-2a Figure 7-2b

Figure 7-3a Figure 7-3b

DISASSEMBLY

DASH AREA DISASSEMBLY 2018.5 Turbo S & 2019+ RZR - Continued

STEP 4 – REMOVE DYNAMIX®ECU BRACKET OR POCKET SCREW

If no Ride Command, Dynamix ECU or OEM installed amplier are present, proceed to removing lower

pocket. If you have the Dynamix ECU or OEM installed amplier, remove (4) 10mm bolts holding the bracket

as shown in Figure 7-4a. Move the ECU and/or OEM amplier to the side leaving wire connections intact.

Lower pocket removal is (1) T40 screw on the pocket support bracket as shown in Figure 7-4b.

STEP 5 – REMOVE LOWER POCKET AND PASSENGER SIDE CUBBY

Remove the lower pocket by pulling forward as shown in Figure 7-5a. If you have Ride Command you

will also have to disconnect the USB cable. If you don’t have Ride Command, the pocket area is where

the MBQR-RAD-2 source unit installs if you'll be installing one. Next, remove (2) plastic push clips in the

passenger side cubby as shown in Figure 7-5b. Then remove cubby and set aside.

STEP 6 – REMOVE CENTER SWITCH HARDWARE

Remove (4) T40 screws located above the center

switches as in Figure 7.6a. If you have a Ride

Command, (2) will be on each side of the screen and (2)

behind the screen as in Figure 7.6b.

Figure 7-4a Figure 7-4b

Figure 7-5a Figure 7-5b

Figure 7-6a Figure 7-6b

DISASSEMBLY

T40 Torx Screw

DISASSEMBLY

DASH AREA DISASSEMBLY 2018.5 Turbo S & 2019+ RZR - Continued

STEP 7 – PREPARE FINAL ELECTRONICS FOR DASH REMOVAL

Gently remove the plastic nut holding the ignition switch to the dash as shown in Figure 7-7a. Next,

disconnect wires from back of switches as shown in Figure 7-7b. Take note of plug color and switch location

for reassembly purposes.

STEP 8– REMOVE DASH FASCIA

Gently pull dash fascia toward seat to remove as shown

in Figure 7-8. Set aside in a safe location until it’s time

for reassembly. This allows further access for running

wires.

NEXT STEPS

Refer to the MBQR-RAD-2 Operator’s Guide and Installation Instructions for wiring and tting details. This is

available at MBQuart.com.

Figure 7-7a Figure 7-7b

Figure 7-8

Operator’s Guide and

Installation Instructions

MBQR-RAD-2

AM/FM/USB/Bluetooth®

Multimedia Controller and

for Polaris®RZR®Vehicles

MBQR-RAD-2

Operator's Guide and

Installation Instructions

WIRING LAYOUT

COMPLETE WIRING LAYOUT

This is a complete wiring harness layout diagram of a

RZR Stage 5 system. Your source unit is only one part

of the whole audio system package possible.

To view all the RZR-Tuned

Audio System Options, visit

MBQuart.com

NOTES

Use this section to record serial numbers of each product, nal settings of your MBQR-RAD-2 source unit

or any other wiring or installation-related details that will be helpful if you need to add on to the system or

troubleshoot any unforeseen issues.
