Maytag MEP5775BAF - 30in Electric Range Manual

Repair

Parts

List

MODEL NUMBER

MEP5775BAF

When requesting service or ordering parts, always

provide the following information:

- Product Type - Part Number

- Model Number - Part Description

RANGE

Section: CONTROL PANEL/TOP ASY

C10-684

Model: MEP5775BAF

CONTROL PANEL/TOP ASY

No. Part No. Description

Section:

Series Qty

1 74011076 PANEL, CONTROL (WHT) 10 1

2 7403P238-60 SWITCH, INFINITE (SML ELEMENT) Note: (LR) 10 1

3 74010824 SWITCH, ELEMENT (LRG) Note: (RF) 10 1

4 74007845 SUPPORT, ELEMENT 10 12

5 74004153 LIGHT, INDICATOR 10 2

6 7730P011-60 LENS, INDICATOR LIGHT 10 2

7 74010826 SUPPORT, CONTROL PANEL 10 1

8 74004821 CAP, END (WHT-RT) 10 1

8 74004822 CAP, END (WHT-LT) 10 1

9 74010663 TOP ASSEMBLY (FROST WHT) 10 1

10 74010676 CLOCK/OVERLAY (WHT) 10 1

11 74010846 SHIELD, CONTROL 10 1

12 74008897 ELEMENT, DUAL (2400W) Note: (RF) 10 1

13 74008568 ELEMENT (1200W) Note: (LR/RR) 10 2

14 74008950 KNOB (WHT/CHR) 10 6

15 74003357 SCREW (6ABX.25-ZN) 10 24

16 74005759 TUBE, VENT (UPR) 10 1

17 Y706125 LIGHT, INDICATOR 10 1

18 74010825 SWITCH, ELEMENT (WARM ZONE) Note: (CTR) 10 1

19 74008898 ELEMENT, WARMING Note: (CTR) 10 1

20 74002929 SWITCH, SELECTOR 10 1

21 74008940 SWITCH, INFINITE (FLEX) Note: (RR) 10 1

22 74011070 SWITCH, INFINITE Note: (RF) 10 1

23 74011093 ELEMENT (TRIPLE) Note: (RF) 10 1

*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: BODY

C14-925

Model: MEP5775BAF

BODY

No. Part No. Description

Section:

Series Qty

1 74011203 RETAINER, REAR 10 1

2 74010813 INSULATION, WRAPPER 10 1

3 74010815 EXTENSION, MAIN BACK 10 1

4 74011142 HINGE, OVEN DOOR 10 2

5 74010816 TUBE, VENT 10 1

- 74010817 HOLDER, VENT TUBE 10 1

6 74010818 SWITCH, HI-LIMIT 10 1

7 74008263 SWITCH, DOOR LOCK 10 1

8 74001632 BRACKET, SWITCH ACTUATOR 10 1

9 22002368 SCREW----NA 10 2

10 74001629 SPRING, DOOR SWITCH 10 1

11 74003562 ROD, DOOR LIGHT SWITCH 10 1

12 74001631 BUMPER, ROD 10 1

13 74008264 INSULATOR 10 1

14 74010819 LATCH ASY 10 1

15 74010820 EXTENSION, HEAT SHEILD 10 2

16 74010822 PANEL, SHIELD (RT) 10 1

16 74010821 PANEL, SHIELD (LT) 10 1

17 74010823 FAN, COOLING 10 1

18 74011206 FLEX CABLE ASSEMBLY 10 1

19 74004180 BRACKET, POWER SUPPLY 10 1

20 74001338 SHIELD, VENT (WHT) 10 1

- 74011202 TRIM, SIDE (LT-WHT) 10 1

21 74011200 TRIM, SIDE (RT-WHT) 10 1

22 74006096 COVER, WIRE (REAR) 10 1

23 74005264 COVER, TERMINAL BLOCK 10 1

24 7101P112-60 SCREW 10 4

25 74003976 SCREW, SHOULDER 10 4

26 7401P039-60 BLOCK, TERMINAL 10 1

- 7103P027-60 NUT, TERMINAL BLOCK 10 3

*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: OVEN/BASE

C12-553

Model: MEP5775BAF

OVEN/BASE

No. Part No. Description

Section:

Series Qty

1 74002373 LEG, LEVELING 10 4

2 74011204 BASE, DROP-IN 10 1

3 74010808 TUBE, VENT (LWR) 10 1

4 74010810 BAFFLE, BROIL 10 1

5 74003040 ELEMENT, BROIL (6 PASS) 10 1

6 74003563 SUPPORT, BROIL ELEMENT 10 1

7 74010883 ELEMENT, BAKE 10 1

8 74004943 SENSOR, OVEN (LONG) 10 1

9 74010885 LAMP ASSEMBLY 10 1

10 74001757 RACK, OVEN 10 1

11 74009589 RACK, CREATE A SPACE HALF 30" 10 1

- 7101P352-60 SCREW 10 2

12 74005564 BRACKET, ANTI-TIP 10 1

13 74010505 SCREW, 3/4" HEX HEAD 10 6

14 74009587 INSERT, HALF RACK 30" 10 1

*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: DOOR

C11-882

Model: MEP5775BAF

DOOR

No. Part No. Description

Section:

Series Qty

1 74003642 LINING, DOOR 10 1

2 74004224 TAPE, SINGLE SIDED (WHT) 10 2

3 74001574 NUT, SNAP (ROUND-BLK) 10 4

4 7201P046-60 GASKET, DOOR 10 1

5 74005546 SPACER, RUBBER 10 2

6 74003644 FRAME, GLASS 10 1

7 74003645 GLASS, INNER 10 2

8 74003647 INSULATION, OVEN DOOR 10 2

9 74009502 BAFFLE, OVEN DOOR 10 1

10 74004857 GLASS W/TAPE ASSY 10 1

11 74003650 RETAINER, GLASS 10 2

12 74009690 TRIM, DOOR TOP (WHT) 10 1

13 74009699 BRACKET, DOOR HANDLE (LT) 10 1

13 74009698 BRACKET, DOOR HANDLE (RT) 10 1

14 74010972 HANDLE, DOOR (WHT) 10 1

15 74006635 SCREW W/WASHER (HANDLE MTG) 10 2

16 12002358 KIT, DOOR TRIM (WHT) 10 1

17 74009687 SUPPORT, GLASS (WHT) 10 1

18 74009540 SCREW (WHT) 10 9

19 12002396 KIT, DOOR GLASS (WHT) 10 1

*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

SUPPLEMENTAL INFORMATION

No. Part No. Description

Section:

Series Qty

- 8113P500-60 MANUAL, USE & CARE 10 1

- 8113P561-60 MANUAL, USE & CARE 11 1

- 74011205 HARNESS, MAIN 10 1

- 74011090 HARNESS, SWITCH (RT) 10 1

- 74010849 HARNESS, SENSOR/LATCH 10 1

- 74010851 HARNESS, SWITCH (LT) 10 1

- 74011092 HARNESS, TOP 10 1

- 74006500 SCRAPER, RAZOR (METAL) 10 1

- 20000001 COOKTOP CLEANING CREME 10 1

- K71FILLW KIT, EXTRUSION FILLER (WHT) 10 1

*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
