Maxxus MX 12.0Z Instrucciones de instalación
1
ENG
Massage Chair
MX 12.0Z
INSTALLATION & OPERATING MANUAL
2
Index
Index 2
Safety & Maintenance 3 – 5
Functions & Application Areas 6
Description of Parts 7
Remote Control 8
Use 9 – 12
Assembling the Side Parts 13 – 14
Assembling the Foot Rest 15
Setting up and Transporting the Device 16
Exploded Drawing 17
Spare Parts List 17
Warranty 18
Service Contract 19
© 2019 MAXXUS Group GmbH & Co. KG
All rights reserved / All rights reserved
This publication may not be reproduced, stored in a retrieval system, or transmitted in whole or in part, in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise without the prior written permission of Maxxus Group GmbH & Co. KG.
Errors, colour and technical modication subject to change, reproduction as well as electronic duplication only with written permission of MAXX-
US Group GmbH & Co. KG.
3
ENG
1. Important Safety Instructions
−Keep children away from all moving parts of the chair.
−Connect the device to an earthed electrical socket
−Remove the electrical plug from the socket after use and before cleaning to avoid
personal injury or damage to the device.
−Only use the chair as instructed in this operating instruction manual.
−Do not use any additional parts or components which are not included in this scope
of delivery.
−Never use this device outside or on a balcony or terrace.
−Please read the operating instructions carefully before using the device.
−All types of use which are not described in this manual are prohibited
− Es empehlt sich, das Gerät nicht länger als 20 Minuten pro Massage zu nutzen.
−Please do not use this device if:
−the leather is torn or damaged.
−any of the covers are broken or damaged
−the heating or ventilation vent is covered up or blocked.
−If you have consumed excessive alcohol or you are feeling sick or unwell
−Wait for at least an hour after a big meal before using the device.
−Do not fall asleep on the chair during a massage.
− To avoid injury, do not turn the massage function up too high.
2. Installation Location
−Please do not use the device:
−In rooms with high temperatures and/or in rooms with a high humidity.
−When the room temperature varies rapidly or quickly
−In very dusty rooms
−In any location where there is not enough space for the necessary ventilation.
Safety and Maintenance
4
Safety and Maintenance
3. Personal Conditions
− If you suer from any of the following ailments or illnesses, we advise against using this
device:
−Osteoporosis
−Heart problems or heart disease
−If you have a pacemaker or any other electronic medical device
−High temperature or fever
−Any open wounds
−Skin diseases
−During pregnancy or menstruation
−If your doctor has ordered you to rest, we also advise not to use this device.
−Children under the age of 14 years should not be allowed to use this chair without
supervision.
−Do not use this device if your body is wet or damp.
4. General Safety Instructions
− Check the electrical supply voltage before turning the device on for the rst time.
−Do not remove the electrical plug from the socket with wet hands
−Keep water or any other liquids away and avoid them getting into the device
−Do not damage any cables and do not exchange any circuits on this product.
−Do not use wet or damp cloths or similar to clean electrical components like switches or
electrical plugs.
− Keep away from the device during a power cut to avoid being injured when the electric-
ity goes back on.
−Please stop using the device immediately if any kind of malfunction occurs.
−Also stop using the device if you start to feel unwell.
−If the electrical cable is damaged, remove the plug from the socket and contact the sup-
plier or another qualied electrical technician for a replacement.
−Children must be supervised when they are near the unit.
−The device is not suitable for use by persons with diminished physical, sensory or
mental abilities. It is also not suitable to be used by inexperienced or unknowledgeable
persons (eg children) without supervision.
5
ENG
Safety and Maintenance
5. Service and Maintenance
− The maintenance of the device may only be carried out by qualied personnel.
Please do not disassemble or try to maintain the device yourself. Exceptions are
only small maintenance works or repairs under the instruction of a technician of the
supplier.
− Do not forget to turn o the power to the device at the mains after use.
−Do not use the device if the electrical plug is loose in the socket.
−If the chair is not to be used for a long period of time, roll up the cable and store it in
a dry and dust-free place.
−Do not expose the device to high temperatures or long periods of direct sunlight.
−If the electrical cable is damaged, remove the plug from the socket and contact the
supplier or another qualied electrical technician for a replacement
−Please clean the device with a dry cloth. Do not ever use thinner, mineral spirits, or
alcohol for cleaning.
−All mechanical components of the chair are designed so that no special mainte-
nance is required.
− Avoid contact with sharp objects with the chair.
−Please do not push or pull the chair over uneven ground. The chair must always be
lifted to be transported.
−Please use the device with enough time intervals between each application. Do not
have the device in constant use.
6. Commonly Alleged Malfunctions
− It is normal for the electronic motors to make buzzing noises during operation.
− If the control unit does not operate, please check rst if the electrical plug is correct-
ly plugged into the socket and it is turned on at the mains.
− The device will switch o automatically when the set program has come to an end.
− If the device runs too long, the chair temperature protection system will switch o
automatically.
− If the device switches o automatically, it should be possible to switch it on again for
use after approximately 30 minutes
6
1. There are sensors in the shoulder area qhich automatically detect the contours of
the body and massage points. With this the necessary micro-adjustments of the
massage hands are made to achieve the best results.
2. The chair has many dierent massage programs to choose from.
3. The air pressure technology enables the hip-stretching and rotation exercises
4. You can select from the following functions by selecting the manual massage pro-
gram:
Massage Positions:
−Full body
−Partial body
−Fixed position
Massage Types:
−Shoulder massage
−Kneading massage
−Tap massage
−Knead and tap massage
−Shiatsu massage
Five dierent intensity levels can be selected for each type of massage. The distance
between the hands in tap and shiatsu massages can also be adjusted to ve levels.
There are many positive eects which can be gained from using the massage chair. In
addition to general relaxation, depending on the program selected, time and intensity it is
possible to achieve the following results:
−Vitalisation of the full body
−Improvement of blood circulation
−Relief of muscle tension
−Relaxation from nerve pain
−Reduction of muscle aching and soreness
Functions
Application Areas
7
ENG
Description of Parts
1. Head cushion
2. Loud Speaker / negative ions
3. Air cushion shoulder
4. Air cushion arm
5. Quick Selection Keys on Arm Rest
6. USB Charger
7. Remote Control
8. Seat Cushion
9. Leg Unit
10. Foot Rest
11. Rear Foot Plate
12. Back Rest Pad
13. Side Part
14. Decoration Element
15. Side Cover
16. Housing Cover
17. Remote Control Pocket
18. LED Circuit
20. Transport Rollers
21. Electrical Cable
22. Power Connection
23. Fuse
24. Power Switch
25. Connection (remote control)
8
The Remote Control
The remote control of your new massage chair al-
lows you to select from the many massage types
and massage programs the chair provides.
In the following, all the various functions and
associated control keys of the remote control are
explained.
Remote Control
12
12
9
ENG
1 Switching on the Device
Insert the mains adapter plug into socket (1) located on the back of the chair.
Push the electrical plug into the socket and switch on the device at the power switch (2).
2 Starting the Massage
a) Make sure the chair is switched on at the power switch.
b) Press the power button on the remote control. The chain will move automatically into a relaxing
position. (Before you press the power button please sit down comfortably in the chair. Sit right back
into the chair so that your back is leaning completely against the back cushion and gently lean back
your head in a relaxed position. This will ensure that the automatic measurement of your massage
points can be measured correctly).
c) The chair will automatically take a measurement of the most important massage points in the
shoulder and back areas.
d) If the automatic measurement is not as you require, you can manually adjust the position of the
massage rollers by pressing the key for „adjust shoulder“.
Use
To move the massage rollers for the shoulders either upwards or downwards
repeatedly press the „Adjust Shoulder“ key.
e) Select the massage you require (there is more information about this in the next section).
You can combine several of the massage types with each other. If you have found a massage
setting which you like and do not want always to have to program it to start, simply save your setting
with the save key. To do this press and hold down the double-assigned keys (see below) for 3 sec-
onds.
These two keys (Upper Body/M1 and Lower Body/M2) are double-assigned.
Press the key for a short time to select upper and lower body. If you press
these two buttons for a long time, your settings will be saved on M1 or M2.
Position too high
Position correct
Position too low
AUTO
F1
AUTO
F2
AUTO
F3
AUTO
F4
AUTO
F5
AUTO
F0
10
10
3: The Dierent Types of Massage
Here there are 6 automatic and numerous other manual programs to chose from. In the
following are detailed instructions about how to select the dierent programs.
Automatic Massage Types
To select the automatic massage types, press the appropriate key on the remote control.
The display on the remote control will show AUTO Fx.
Pain relieving: Deep massage to relax the areas of pain
Relaxing: Soothing full-body massage
Vitalising: Massage to improve blood circulation “RELAX”
Demo: Hold down the key for 2 seconds and try out all the massage functions the chair
has to oer.
Upper Body Massage: Focus on massaging the upper body
Leg and Torso Massage: Focus on massing the legs and hips area
Use
