Maxtor Maxtor OneTouch USB Manual de instalación

EXTERNAL HARD DRIVE

READ ME FIRST

FOR ADDITIONAL INFORMATION NOT INCLUDED IN THE USER’S GUIDE

FOR WINDOWS®USERS

(see other side for Macintosh)

Software installation: Do not press the Maxtor OneTouch™ button until instructed by the

User's Guide or installation software. Please quit all applications, including the application

icons on your taskbar (right side), before starting the installation process. Do not remove the

installation CD until after completing the Maxtor OneTouch setup.

Maxtor OneTouch Setup:

After completing the Retrospect®software registration described in

step 5 (page 12 for Windows 2000 & XP, page 19 for Windows 98SE

&Me):

•Exit Retrospect by going to the File menu and selecting Exit.

•Push the Maxtor OneTouch button again on the front of your

drive. Retrospect will open and the Maxtor OneTouch Setup

screen will appear. Continue the setup process as documented in

Step 6. Refer to Knowledge Base Article 1555 for more detail on

setting up the Maxtor OneTouch button.

If you own a Maxtor Personal Storage™5000 drive:

For proper installation of a Maxtor OneTouch drive on systems

with a Maxtor 5000(LE/DV/XT) drive already installed, follow the

installation notes provided in the Maxtor Knowledge base article

on the web.

•Go to www.maxtorkb.com

•In the box called Knowledge Base Quick Links,

click on the link External Storage answers.

The Product Support Knowledge Base window will appear. In the

field labeled Search Text (optional), enter the text OneTouch@5000,

and then click the Search button.

ADDITIONAL INFORMATION

Standby and hibernate settings: Windows 98SE / Me (USB interface)

You may experience problems with the standby or hibernate modes on Windows 98SE and Me systems

when using your drive on the USB interface. Possible problems include: the system hangs on returning

from standby or hibernate mode, the drive icon disappears from your desktop or you get an error message:

Failed drive needs format.

Note that this problem can result in lost or damaged files.

Solution: disable the standby and hibernate modes in your operating system

Maxtor OneTouch error message

If you get the following warning message on a Windows system, Use Maxtor OneTouch Settings to

associate Maxtor OneTouch button to an application, refer to the section titled: How to Reset the Maxtor

OneTouch button, User’s Guide—page 44, to reset your Maxtor OneTouch button.

Maxtor OneTouch

Maxtor OneTouch and

Maxtor Personal Storage 5000

EXTERNAL HARD DRIVE

READ ME FIRST

FOR ADDITIONAL INFORMATION NOT INCLUDED IN THE USER’S GUIDE

FOR MACINTOSH®USERS

(see other side for Windows)

Software installation: Do not press the Maxtor OneTouch™ button until instructed by the User's

Guide or installation software. Please quit all applications before starting the installation process.

Do not remove the installation CD until after completing the Maxtor OneTouch setup.

If you also own a Maxtor Personal Storage 5000 drive:

For proper installation of a Maxtor OneTouch drive on systems with

a Maxtor 5000(LE/DV/XT) drive already installed, follow the installation

notes provided in the Maxtor Knowledge base article on the web.

•Go to www.maxtorkb.com

•In the box called Knowledge Base Quick Links,

click on the link External Storage answers.

The Product Support Knowledge Base window will appear. In the

field labeled Search Text (optional), enter the text OneTouch@5000,

and then click the Search button.

For proper installation of multiple Maxtor drives (Maxtor OneTouch and 5000 models) on OS 9

follow the installation notes provided in the Maxtor Knowledge base article on the web.

• Go to www.maxtorkb.com

• In the box called Knowledge Base Quick Links, click on the link External Storage answers.

The Product Support Knowledge Base window will appear. In the field labeled Search Text

(optional), enter the text OneTouch@OS9, and then click the Search button.

ADDITIONAL INFORMATION

Disaster Recovery: Macintosh systems

Please note the following clarification for the Disaster Recovery chapter

Follow steps 1 – 7 as described (pages 62 – 63).

Step 7 In addition to the description provided in the User’s Guide …

The default location for the catalog file is the same drive used for your backup set. If you chose

another location for this file, look there instead.

Step 8 In addition to the description provided in the User’s Guide …

In the lower box of this screen, you should see a list containing snapshots named for each of the drives

on your system. Select the snapshot name that matches the name of the drive you wish to restore (for

example, your old system drive).

Follow all of the other steps as documented in the User’s Guide.

Copyright ©2003 Maxtor Corporation. All rights reserved. Maxtor is a registered trademark of Maxtor Corporation. Maxtor Personal Storage and Maxtor OneTouch are trademarks of Maxtor Corporation. Retrospect is a registered trademark

of Dantz Development Corporation. Mac and the Mac logo are trademarks of Apple Computer, Inc., registered in the U. S. and other countries. Microsoft, Windows and the Windows logo are either registered trademarks or trademarks of

Microsoft Corporation in the United States and/or other countries. Other trademarks are the property of their respective holders. Specifications subject to change without notice. Maxtor Corporation, 500 McCarthy Boulevard, Milpitas,

CA 95035 8/03 www.maxtor.com P/N: 20247100

OS9

Maxtor OneTouch and

Maxtor Personal Storage 5000
