USER GUIDE
DAB Alarm Clock Radio
MODEL NUMBER: 68819
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Ver. 2.0
Contents
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
1.
2.
3.
4.
5.
6.
7.
8.
9.
10 - 11.
12.
13.
14.
15.
16.
17.
18.
Welcome Section
Contents & Features
Controls
Setup
Selecting DAB Station
Saving a Preset
Selecting a Preset
Auto tuning DAB
Manually tuning DAB
Auto tuning FM
Manually tuning FM
DAB / FM Information
Reset
Manually Setting Time/Date
Setting the Alarm
Stopping the Alarm
Snooze Function
Backlight
Setting the Language
Prune Function
DRC Function
Inactive Standby (Sleep)
Control Method
Menu Map
FAQ
Welcome Section
Congratulations!
You have made an excellent choice with the purchase of this quality
MAXTEK®product.
By doing so you now have the assurance and peace of mind which
comes from purchasing a product that has been manufactured to
the highest standards of performance and safety, supported by the
high quality standards of Quesh Ltd.
We want you to be completely satised with your purchase so this
MAXTEK®product is backed by a comprehensive manufacturer’s
3 year warranty and outstanding after sales service through our
dedicated helpline.
We hope you enjoy using this product for many years to come.
If you require technical support or in the unlikely event that your
purchase is faulty, please telephone our helpline for immediate
assistance. Faulty product claims made within the 3 year warranty
period will be repaired or replaced free of charge provided that you
have a satisfactory proof of purchase (keep your receipt safe).
This does not affect your statutory rights. However be aware that the
warranty will become null and void if the product is found to have
been deliberately damaged, misused and/or disassembled.
1
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
2
Contents & Features
Contents
1 x DAB & FM alarm clock radio
1 x 5V mains adaptor
Features
•DABreceiver(174MHz-240MHz)
•FMreceiver(87.5MHz-108.00MHz)
•Stores10FMpresets
•Stores10DABpresets
•5vmainsadaptor(included)
•Autoadjustingclock
•BlueLEDbacklightdisplay
•Monosound(1x1Wspeaker)
•Cableaerial
3
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Controls
Mode
Scan Volume -
Volume +
Info/Menu
Preset
Tune -
Tune +
On/Off
Select/Snooze
LCD Screen
4
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Setup
First time use
After removing the radio from the packaging, fully extend the
cable aerial and connect the mains adaptor to the mains outlet and
the power lead to the ‘DC in’ socket located on the back of the radio.
Press the button to take it out of standby mode, the radio will turn
on. The radio will perform a full scan of the DAB frequencies
available. The scan progress and the number of DAB stations found
will be shown on the display.
The date and time will automatically be set by the DAB signal the
radio is receiving. If your radio is in a poor signal area, the date and
time will not be set and you will see a message on the display.
You can set the time manually through the ‘System’ menu.
This will also mean you can only use the radio in FM mode as the
DAB signal is not strong enough for the radio to receive stations.
After the date and time has been set the radio will be ready to use.
5
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Instructions
Selecting a DAB station
Press the ‘Tune +’ Or ‘Tune -’ buttons to cycle through the available
stations. All the stations are displayed in alphabetical order.
Once you have found the required DAB/FM station to listen to, press
the ‘Select/Snooze’ button to select it. The station will only change
once it has been selected, so you can browse the available stations
without disturbing the current selected station.
Please Note:
All button actions unless stated are a quick press.
Saving a DAB/FM station
Press and hold the ‘Preset’ button for 3 seconds once you have
tuned the radio on to a required station in DAB or FM mode. The
display will show the ‘Preset Store’ message.
Press the ‘Tune +’ Or ‘Tune -’ buttons to select a slot (1 to 10) and
press the ‘Select/Snooze’ button to save the preset. You will see the
saved message on the screen conrming the preset has been stored.
.
6
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Selecting a preset DAB/FM station
Press the ‘Preset’ button and use the Press the ‘Tune +’ Or ‘Tune -’
buttons cycle through the saved presets. To select a preset press
the ‘Select/Snooze’ button.
Auto Tune DAB
To fully retune all of the available stations on DAB press and hold the
‘Info/Menu’ button. This will show you the scan option on the dis-
play. Press the ‘Select/Snooze’ button select the ‘Full Scan’ option.
The radio will now scan through all the available channels.
All the channels found will be shown in alphabetical order.
Manually Tune DAB
To manually tune the radio, press ‘Info/Menu’ button and ‘Tune +’ Or
‘Tune -’ buttons untill ‘Manual Tune’ is displayed. Press the ‘Select/
Snooze’ button to select.
Use the ‘Tune +’ Or ‘Tune -’ buttons to tune the radio in. This helps
in poor signal areas to get a clear signal. Repeat the storing a preset
procedure to save the current tuning.
Instructions
7
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Instructions
Auto Tune FM
To auto tune to the next available radio station press and hold the
‘Tune +’ Or ‘Tune -’ button for 3 seconds. This will start the radio to
auto scan.
The scan will always stop at the next signal received.
Repeat the storing preset procedure to save the current station.
You can change between all stations and strong station for the FM
scan by pressing and holding the ‘Info/Menu’ button and selecting
‘Scan Setting’ with the ‘Tune +’ Or ‘Tune -’ buttons.
Use the ‘Tune +’ Or ‘Tune -’ buttons to select either ‘Strong Stations’
or ‘All Stations’ and press the ‘Select/Snooze’ button to conrm the
required selection. The asterisk in the top right corner indicates
current selection.
You will be sent to the previous menu once a selection has been
made. Press the ‘Info/Menu’ button to return to the main screen.
Manually Tune FM
Use the ‘Tune +’ Or ‘Tune -’ buttons in either direction to tune the
radio in FM mode.
This helps in poor signal areas to get a clear signal.
Repeat the storing preset procedure to save the current station.
8
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
Reset
To reset the unit press and hold the ‘Info/Menu’ button until the screen
changes, cycle through the options with the ‘Tune +’ Or ‘Tune -’ but-
tons and select ‘System’ by pressing the ‘Select/Snooze’ button.
Cycle through the menu options as before and select
‘Factory Reset’.
Select ‘Yes’ and conrm by pressing the ‘Select/Snooze’ button.
The radio will restore itself to the original factory settings.
This will clear any presets saved.
DAB
•NowPlaying
•SignalStrength
•Musicgenre
•National/Localdesignation
•MHzFrequency
•SignalErrors
•Kbpsdatatransferrate
•Time
•Date
FM
•NowPlaying
•StationName
•Musicgenre
•Mono/Stereo
•Time
•Date
Instructions
DAB/FM information
When listening in DAB or FM mode you can cycle through the
available information from the broadcasting service by pressing the
‘Info’ button.
The information cycle:
