Maxon MX-7930 Manual de usuario
Entry
1
Table of contents
Subject: Page:
Phonebook
Look-up and add contacts 37
Phonebook settings 39
Organizer
Calendar 43
Tasks 45
Alarm 45
Calculator 46
PC-Synchronization (Optional) 47
MaxFun
Games (1-3) 51
My Phone
Personalizing sounds 53
MelodyMaker 55
Graphics 57
Caller Groups 58
LED 58
Subject: Page:
Entry
Read me first Cover
Legal statement Cover
Table of contents 1
Welcome 3
Getting started
What’s in the package 5
Setting language, time & date 6
Get acquainted 13
Messaging
T9 editor 21
SMS/EMS 23
Cell Broadcast 27
E-mail (Optional) 28
WAP
WAP Home & Bookmarks 31
WAP settings 33
02207155_1.2 11/18/02 3:35 PM Side 1
Entry
2
Table of contents
Subject: Page:
Settings
Language 8
Time & date 9
PIN code (Security) 9
Data 59
Network 60
Call forward & waiting 61
Call barring 63
Billing 64
Miscellaneous
Cellular phones in brief 65
Abbreviations & acronyms 68
Cell phone care 69
Questions & Answers (FAQ) 73
Technical data 76
EU Certificate of compliance 77
Index 79
02207155_1.2 11/18/02 3:35 PM Side 2
Entry
3
Welcome
Uplink to the Mobile Internis facilitated
with WAP 1.2 and a fast GPRS data con-
nection.
Size has always been a Maxon
focuspoint, and the 7930-series
have very modest exterior
dimensions and will fit into
any shirt pocket or purse.
50 different ring signals,
SMS alert signals, wallpa-
pers along with renameable
profiles and caller groups
facilitates a high degree of
personalization.
You have acquired a phone and
a communications companion
that will enable you to stay tuned
wherever you choose to go.
Thank you for choosing a cel-
lular phone from Maxon Telecom, Koreas
second-largest IT industrial complex
and a manufacturer with more
that two decades of experi-
ence within the electronic
communications industry.
Your new communica-
tions device represents
the cutting edge tech-
nology of the 21st cen-
tury, featuring 64k
brilliant color display,
enhanced messaging
service (EMS), polyphon-
ic ring tones. PC-syn-
chronisation and stunning
games along with extensive
Organizer and Phonebook prop-
erties.
02207155_1.2 11/18/02 3:35 PM Side 3
Entry
4
About this user guide
This user guide is written for the Maxon
MX7930/31-series cellular handsets and
for these models only.
The layout of the user guide follows the
same order as the phone menu system.
Please note that optional functions may
not be shared by all models. The text is
printed in grey color if optional.
The user guide is accompanied by a Mini
Guide describing the most commonly
used functions.
Symbols used in the text:
>Indicates a user action
< indicates system response
-indicates a listing
Grey text indicates optional functions
indicates direction of joy-
stick presses
OK indicates a downwards joystick press
Indicates a network ressource
Queries regarding the user guide or
phone handling can be addressed to:
Maxon Technical Marketing
User guide order no.: 02207155
Mini Guide order no.: 02207159
02207155_1.2 11/18/02 3:35 PM Side 4
Get started
5
What’s in the package
When you open your MX7930/31 sales
package you should find the phone
itself, the battery, the charger, the
MaxSoft CD (Optional), the Mini Guide
and this user guide. Depending of your
place of purchase, various accessories
may also be included. Contact your
retailer if any of the above is missing.
The battery
Your phone comes with a high-perform-
ance rechargeable battery. The battery
must be fully charged before you use
your phone. Failure to do so may impair
the service life of the battery. Use only
the charger supplied with the phone.
To install the battery, align the pins at
the bottom with the guides in the cover
and click in place. To remove the bat-
tery, pull the button on the back of the
phone upwards and lift off. The battery
Important:
Carefully read the “Read me first”
statement at the inside of the cover as
it contains vital information concerning
your security, the security of others
and your legal rights.
Open retail box
photo (MTHQ)
02207155_1.2 11/18/02 3:35 PM Side 5
Get started
6
Battery installation and charging
must be installed on the phone prior to
charging.
To charge the battery:
>Connect the charger to the plug at
the base of the phone with the “arrow”
symbol on the plug pointing towards the
display.
>Connect charger to mains
< an animation indicates charging in
progress. When the animation stops,
charging is completed
>Press release tabs on side of charger
plug and remove plug.
> Remove charger from mains by pulling
the charger itself (do not pull cord).
Important:
Be sure to charge the battery for four
hours prior to using it the first time.
For longest service life, prefér full
chargings to frequent small chargings
when possible.
02207155_1.2 11/18/02 3:35 PM Side 6
Get started
7
Installing SIM card
To connect to your network operator
your phone must have a SIM card
installed. The SIM card slot is located
under the battery.
>Switch off the phone and remove
charger if connected. Release the bat-
tery and remove it to access the SIM
cradle.
> Install the SIM card, gold-plated side
down and with the cut corner of the
card matching the slot profile. Never
use force. Avoid touching the gold-plat-
ed side of the SIM.
>Secure the card with the lock and
reinstall the battery.
>Turn on the phone by pressing the
key for a few seconds.
< a tune is heard and the display
becomes active. You are prompted to
enter the PIN code.
NOTE THAT UP TO THIS POINT, PRESSING SELECT
ON THE RIGHT SOFTKEY WILL DISPLAY A LIST OF
AVAILABLE PHONE LANGUAGES.
>Enter the network-supplied PIN code.
Press the OK key to accept.
02207155_1.2 11/18/02 3:35 PM Side 7
Get started
8
Set language
Settings menu. Press OK.
NOTE THAT IF YOU DID NOT SELECT LANGUAGE
BEFORE YOU ENTERED THE PIN CODE, OR IF YOU
WANT TO CHANGE THE LANGUAGE:
>Scroll to the Language submenu.
Press OK.
< a list of languages appears.
>Scroll, and select language with OK.
Exit with Back.
< the display will change to the
selected language
< your phone will search for the net-
work. When connection is established,
the the network name is displayed. You
are now able to make and receive calls
NOTE THAT ENTERING AN INCORRECT PIN CODE
THREE TIMES IN SUCCESSION WILL LOCK THE SIM
CARD AND YOU MUST ENTER THE PUK CODE TO
UNLOCK (SEE P. 9)
To set up language, time & date and to
change the default PIN code:
-Enter the menu by pressing the Menu
key. Use or to step to the
02207155_1.2 11/18/02 3:35 PM Side 8
Get started
9
Set time & date, change PIN
>Enter the time. Press OK. Enter the
date. Press OK
>Step Back to the Settings menu and:
>Scroll to highlight the Security sub-
menu. Press OK.The options are:
PIN code 1 Switch PIN on/off
Change PIN 1 Alter your primary PIN
Change PIN 2 Alter your secondary
PIN
SIM lock Only the designated SIM
can be used
>Step Back to the Settings menu and:
>Scroll to highlight the Time & date
submenu. Press OK
< the time & date submenu opens
>Scroll to Time zone to select your
present location and proceed to Date
format to change this if so desired
>Tick the Summer time box If you
wish to apply daylight saving time
>Scroll to Set time/date. Press OK
< the time & date editor opens
02207155_1.2 11/18/02 3:35 PM Side 9
Get started
10
The IMEI number
>Scroll to Change PIN1 and press OK.
Enter your old PIN code followed by the
new code. Confirm it when prompted.
Press OK.
>Exit with right softkey.
NOTE THAT IF YOU ENTER AN INCORRECT PIN
CODE THREE TIMES IN SUCCESSION, YOUR SIM
CARD WILL LOCK AND YOU MUST ENTER THE PUK
CODE TO UNLOCK. PIN AND PUK CODES ARE
EITHER SUPPLIED WITH YOUR PHONE OR MUST BE
OBTAINED FROM YOUR NETWORK PROVIDER OR
PLACE OF PURCHASE.
As a unique identification, your phone is
furnished with a code number known as
IMEI. You must retain this number in
case you need to block your account,
e.i. if your phone is lost or stolen. We
reccomend that you write it down here:
The IMEI number is printed on the label
under the battery.
IMEI No.
02207155_1.2 11/18/02 3:35 PM Side 10
