IMPORTANT:

Please read this manual carefully before using this

mitre saw and save it for reference

model no. 055-6768-8

INSTRUCTION

MANUAL

Dual-beveling Sliding Compound Mitre Saw

with Laser Line

model no. 055-6768-8 | contact us 1-800-689-9928

TABLE OF CONTENTS

NOTE: If any parts are missing or damaged, or if you have any

questions, please call our toll-free helpline at 1-800-689-9928

SAVE THESE INSTRUCTIONS

This manual contains important safety and

operating instructions. Read all instructions and

follow them with use of this products

TABLE OF CONTENTS

QUICK START GUIDE 2

SYMBOLS 4

SPECIFICATIONS 5

SAFETY GUIDELINES 6

TOOLS NEEDED FOR ASSEMBLY 13

KNOW YOUR SLIDING MITRE SAW 14

GLOSSARY OF TERMS 16

CARTON CONTENTS 18

ASSEMBLY 19

ADJUSTMENTS 28

OPERATION 38

MAINTENANCE 55

TROUBLESHOOTING GUIDE 58

REPLACEMENT PARTS 60

WARRANTY 65

model no. 055-6768-8 | contact us 1-800-689-9928

QUICK START GUIDE

Fig. A

Make sure all accessories and the blade

are installed correctly and are tight before

operating the saw.

NOTE: The blade has been installed in the

mitre saw at the factory. Rechecking the

blade before cutting is necessary.

Use the hold-down clamp to hold the

workpiece firmly against the fence to

prevent movement towards the blade. It is

safer than using your hand and it frees both

hands to operate the mitre saw.

With the power switch OFF, bring

the saw blade down to the workpiece to see

the cutting path of the blade. Then, squeeze

trigger switch to start saw and lower blade

into workpiece with a firm downward

motion.

Hold the cutting arm in the down position.

Release trigger switch and wait for all

moving parts to stop before moving your

hands and raising the cutting arm.

A bowed workpiece (1) must be positioned

against the fence and secured with a hold-

down clamp (2) as shown before cutting.

Fig. B

Fig. C

QUICK START GUIDE

Turn the laser guide on for pre-alignment of your

cut. Use the laser adjustment knobs to adjust the

laser beam if necessary.

Place hands at least 22 cm (8 3/4") away from the

path of the blade – out of the “no-hands zone."

Fig. E

22 cm (8 3/4") 22 cm (8 3/4")

No Hands Zone

Fig. D

Laser ON/OFF switch

Laser assembly

model no. 055-6768-8 | contact us 1-800-689-9928

SYMBOLS

DANGER: indicates an imminently hazardous situation that will

result in death or serious injury if it is not avoided.

WARNING: indicates a potentially hazardous situation that could

result in death or serious injury if it is not avoided.

CAUTION: indicates a potentially hazardous situation that may

result in minor or moderate injury if it is not avoided.

CAUTION: used without the safety alert symbol, indicates a

potentially hazardous situation that may result in property damage

if it is not avoided.

WARNING



WARNING ICONS

Your power tool and its Owner’s Manual may contain “WARNING ICONS” (a picture

symbol intended to alert you to and/or instruct you how to avoid a potentially

hazardous condition). Understanding and heeding these symbols will help you operate

your tool better and safer. Shown below are some of the symbols you may see.

SAFETY ALERT: Precautions that involve your safety.

PROHIBITION

WEAR EYE PROTECTION: Always wear safety goggles or safety glasses

with side shields.

READ AND UNDERSTAND INSTRUCTION MANUAL: To reduce the risk

of injury, user and all bystanders must read and understand instruction

manual before using this product.

SUPPORT AND CLAMP WORK

KEEP HANDS AWAY FROM BLADE: Failure to keep your hands away from

the blade will result in serious personal injury.

WEAR RESPIRATORY AND HEARING PROTECTION: Always wear

respiratory and hearing protection.

DANGER



CAUTION



CAUTION

SPECIFICATIONS

MOTOR

POWER SOURCE 120V AC, 60 Hz, 15A

SPEED 3200 RPM (No load)

BRAKE ELECTRIC

DOUBLE INSULATED Yes

ARBOUR SHAFT SIZE 5/8" (15.9 mm)

BLADE

DIAMETER 12" (30.5 cm), 60-tooth carbide-tipped

ARBOUR SIZE 1" (25.4 mm) with a 5/8" (15.9 mm) reducer

ROTATING TABLE

MITRE ANGLE RANGE 0°–50° Right & Left

POSITIVE MITRE STOPS 0°, 15°, 22.5°, 31.6°, 45° Right & Left

BEVEL ANGLE RANGE 0°–47° Right & Left

BEVEL POSITIVE STOPS 0°, 33.9°, 45° Right & Left

CUTTING CAPACITY

CROSSCUT (MAXIMUM HEIGHT) 4" (10.2 cm)

CROSSCUT (MAXIMUM WIDTH) 12 1/4" (31.1 cm)

MITRE 45° RIGHT & LEFT 4" x 8 3/4" (10.2 x 22.2 cm)

BEVEL 45° RIGHT 1 3/4" x 12 1/4" (4.4 x 31.2 cm)

BEVEL 45° LEFT 2 1/2" x 12 1/4" (6.4 x 31.2 cm)

45° MITRE AND 45° BEVEL 2 1/2" x 8 3/4" (6.4 x 22.2 cm)

CROWN MOULDING NESTED 7 1/4" (184.2 mm)

BASE MOULDING AGAINST FENCE 4 1/2" (114.3 mm)

NET WEIGHT 47 lb 6 oz (21.5 kg)

LASER

CLASS IIIA

LASER WAVELENGTH 630–660 nm

MAX. LASER OUTPUT < 5 mW

SPECIFICATIONS

model no. 055-6768-8 | contact us 1-800-689-9928

WARNING!

To avoid mistakes that could cause serious injury, read this owner’s manual

carefully before plugging in the mitre saw.

SAFETY GUIDELINES

GENERAL SAFETY RULES

Safety is a combination of common sense, staying alert, and knowing how the mitre

saw works.

• READ and become familiar with this Owner’s Manual. LEARN the tool’s

applications, limitations, and possible hazards.

• AVOID DANGEROUS CONDITIONS. DO NOT use power tools in wet or damp areas,

and DO NOT expose them to rain. Keep work areas well lit.

• DO NOT use power tools in the presence of flammable liquids or gas.

• KEEP the work area clean, uncluttered, and well lit. DO NOT work on floor surfaces

that are slippery because of sawdust or wax.

• KEEP BYSTANDERS AT A SAFE DISTANCE FROM the work area, especially when

the tool is operating. DO NOT allow children near the tool.

• DO NOT FORCE THE TOOL. It will do the job better and safer at the rate for which

it was designed.

•

DRESS FOR SAFETY. DO NOT wear loose clothing, gloves, neckties, or jewellery

(rings, watches, etc.) when operating this tool. These items can get caught in

moving parts and draw the operator in. WEAR non-slip footwear, and tie back long

hair.

• WEAR A FACE MASK OR DUST MASK. Sawing operations produce dust.

• UNPLUG the power cord from the electrical outlet before making adjustments,

changing parts, cleaning, or performing maintenance on this tool.

• KEEP GUARDS IN PLACE AND IN WORKING ORDER.

• AVOID ACCIDENTAL START-UPS. VERIFY that the power switch is in the OFF

position before plugging in the power cord.

• REMOVE ADJUSTING TOOLS. VERIFY that all tools are removed from the mitre saw

before turning it on.

SAFETY GUIDELINES

• DO NOT LEAVE THE POWER SWITCH IN THE ON POSITION WHILE THE TOOL IS

UNATTENDED. Turn the power switch to the OFF position. DO NOT leave the tool

until it has come to a complete stop.

• DO NOT STAND ON THE TOOL. Serious injury could result if the tool tips or is

accidentally jarred. DO NOT store anything above or near the tool.

• DO NOT OVERREACH. Keep proper footing and balance at all times. Wear

oil-resistant rubber-soled footwear. Keep the floor clear of oil, scraps, and other

debris.

• MAINTAIN TOOLS PROPERLY. KEEP tools clean and in good working condition.

Follow instructions for lubricating and changing accessories.

• CHECK FOR DAMAGED PARTS. Inspect moving parts for alignment, jamming,

breakage, improper mounting, or any other condition that may affect the operation

of the tool. Any part that is damaged should be properly repaired or replaced

before use.

• MAKE THE WORKSHOP CHILDPROOF. Use padlocks and master switches, and

ALWAYS remove starter keys.

• DO NOT operate the tool while under the influence of drugs, alcohol, or medication

that may affect the ability to use the tool properly.

• WHEN SERVICING, USE ONLY IDENTICAL REPLACEMENT PARTS.

• DO NOT ALLOW ANYONE WHO HAS NOT CAREFULLY READ AND FULLY

UNDERSTOOD THIS OWNER’S MANUAL TO USE OR OPERATE THIS MITRE SAW.

ALWAYS WEAR EYE PROTECTION.

A mitre saw can propel foreign objects into the eyes, which

could cause permanent eye damage. ALWAYS wear safety

goggles (not glasses). Ordinary eyeglasses only have

impact-resistant lenses. They are NOT safety goggles.

WARNING:

Dust that is generated when cutting certain materials can be

hazardous to the health. Always operate the mitre saw in a

well-ventilated area, and provide for proper dust removal. Use a

dust collection system whenever possible.

model no. 055-6768-8 | contact us 1-800-689-9928

SAFETY GUIDELINES

SPECIFIC SAFETY RULES FOR DUAL-BEVEL SLIDING MITRE SAW

• USE ONLY CROSSCUTTING SAW BLADES. When using carbide-tipped blades,

make sure they have a negative hook angle. Do not use blades with deep gullets,

because they can deflect and contact the guard.

• DO NOT operate the mitre saw until it is completely assembled and installed

according to these instructions.

• IF YOU ARE NOT thoroughly familiar with the operation of mitre saws, call the toll-

free helpline (1-800-689-9928) for further assistance.

• ALWAYS hold the work firmly against the fence and table. DO NOT perform any

operation free hand.

• KEEP HANDS out of the path of the saw blade. If the workpiece you are cutting

would cause your hands to be within 8 3/4” (22 cm) of the saw blade, the

workpiece should be clamped in place before making the cut.

• BE SURE the blade is sharp, runs freely, and is free of vibration.

• ALLOW the motor to come up to full speed before starting cut.

• KEEP THE MOTOR AIR SLOTS CLEAN and free of chips or dust.

• ALWAYS MAKE SURE all handles are tight before cutting, even if the table is

positioned in one of the positive stops.

• BE SURE blade and collar are clean. Tighten arbour screw and clamps before

sawing.

• USE only blade collars specified for your saw.

• NEVER use blades larger or smaller in diameter than 12” (30.5 cm).

• NEVER apply lubricants to the blade when it is running.

• ALWAYS check the blade for cracks or damage before operation. Replace a cracked

or damaged blade immediately.

• NEVER use blades recommended for operation at less than 3200 RPM.

• USE the blade guards at all times.

• Do not operate saw without guards in place.

• NEVER reach around the saw blade.

• Wear respiratory and hearing protection.

• Keep hands out of path of saw blade.

• Secure tool properly to prevent unexpected movement.

Tabla de contenidos

Otros manuales de Sierra de MasterCraft

MasterCraft

MasterCraft Hawkeye Laser 54-8347-0 Manual de usuario

MasterCraft

MasterCraft Maximum Hawkeye Laser 055-6746-0 Manual de usuario

MasterCraft

MasterCraft 054-8326-0 Manual de usuario

MasterCraft

MasterCraft 054-8357-6 Manual de usuario

MasterCraft

MasterCraft Hawkeye Laser 054-8347-0 Manual de usuario

MasterCraft

MasterCraft 055-6748-6 Manual de usuario

MasterCraft

MasterCraft 055-6739-8 Manual de usuario

MasterCraft

MasterCraft 55-6829-4 Manual de usuario

MasterCraft

MasterCraft 054-8363-0 Manual de usuario

MasterCraft

MasterCraft 055-6740-2 Manual de usuario

MasterCraft

MasterCraft 055-4500-6 Manual de usuario

MasterCraft

MasterCraft 54-8306-8 Manual de usuario

MasterCraft

MasterCraft Maximum 054-8146-8 Manual de usuario

MasterCraft

MasterCraft 055-6755-8 Manual de usuario

MasterCraft

MasterCraft 055-6742-8 Manual de usuario

MasterCraft

MasterCraft 054-8153-0 Manual de usuario

MasterCraft

MasterCraft 055-6767-0 Manual de usuario

MasterCraft

MasterCraft 055-6751-6 Manual de usuario

MasterCraft

MasterCraft 055-6737-2 Manual de usuario

MasterCraft

MasterCraft 55-6883-2 Manual de usuario

MasterCraft

MasterCraft 055-6744-4 Manual de usuario

MasterCraft

MasterCraft 054-8161-0 Manual de usuario

MasterCraft

MasterCraft 55-6847-0 Manual de usuario

MasterCraft

MasterCraft 055-6748-6 Manual de usuario

Manuales populares de Sierra de otras marcas

RIDGID

RIDGID BS1400 Manual de usuario

ATIKA

ATIKA BWS 400-2 Manual de usuario

RGC

RGC FS20 Manual de usuario

Makita

Makita M2300 Manual de usuario

IMET Spa

IMET Spa BASIC 300 PLUS SHI Manual de usuario

IMET Spa

IMET Spa SIRIO 370 AF-E Manual de usuario

Optimum

Optimum OPTisaw CS 275 Manual de usuario

Makita

Makita BPB180 Manual de usuario

Stihl

Stihl MS 462 C-M Manual de usuario

AEG

AEG TS 250 K Manual de usuario

Meec tools

Meec tools 004665 Manual de usuario

Makita

Makita LS1018L Manual de usuario

Ryobi

Ryobi RCS1400 Manual de usuario

DeWalt

DeWalt DCS391 Manual de usuario

Sealey

Sealey SA72 Manual de usuario

skilsaw

skilsaw SPT88 Instrucciones de montaje

Urrea

Urrea SI810 Dimensiones y guía de instalación

EINHELL

EINHELL BKG 210/1 Manual de usuario
