Martin M2GO and M2PCSafety and Installation Guide

Dimensions

All dimensions are in millimeters

Martin M2GO and M2PCSafety and Installation Guide

Introduction

Thank you for purchasing the Martin M2GO - M2PC Lighting Control System.

The system offers a powerful lighting controller with all the features of the M-Series of Martin controller

in a small and compact housing.

The M2GO is a complete lighting desk with an integrated processor, while the M2PC is a USB control

surface that requires an external PC system. Both consoles are identical with the exception of the

processor and the associated connections on the back of the M2GO.

Please read this Safety and Installation Guide carefully. Visit the Martin website www.martin.com for

further documentation including the user manual for the software and access to our user forums.

Martin M2GO and M2PCSafety and Installation Guide

Technical Support

For a complete list of Technical Support phone numbers, see the Martin website at

www.martin.com/service/hotline.asp

Most information regarding the controller systems of Martin Professional can be found at

www.martin.com/controllersupport

Fixture Profiles

The software offers a fixture profile editor to create custom profiles. It is also possible to have Martin

Professional add a new profile to the standard library.

Profile requests can be made on our website

http://www.martin.com/controllersupport/fixture_libraries.html

Please check whether the profile is already available before filling out a request.

Support Email

For specific questions please contact us directly at controllersupport@martin.dk

Training Videos

A large number of training videos showing the operation of the software can be found on our youtube

channel.

http://www.youtube.com/martincontroller

Martin M2GO and M2PCSafety and Installation Guide

Safety Information

This product is for professional use only. It is not for household use. It presents risks of lethal or

severe injury due to electric shock. Read this user manual before powering or installing the console ,

follow the safety precautions listed below and observe all warnings in this manual and printed on the

product.

If you have questions about how to operate the product safely, please contact your Martin supplier or

call the Martin 24-hour service hotline on +45 8740 0000, or in the USA on 1888-TECH-180.

This product is for indoor use ONLY.

Ensure that the power supply is electrically grounded (earthed) . Do not use ground lift

adapters.

In Finland: "Laite on liitettava suojamaadoituskoskettimilla varustettuun pistorasiaan"

In Norway: "Apparatet ma tilkoples jordet stikkontakt"

In Sweden: "Apparaten skall anslutas till jordat uttag"

Use only a source of AC power that complies with local building and electrical codes and has

both overload and ground-fault protection.

Use only the provided AC power supply and power cords and use the correct connector for the

country of operation. Use of the factory provided power cable is mandatory for operation in the

US and Canada.

Disconnect the product from power immediately if the power supply or cable or any cover or

component is wet or not in perfect condition. Do not reconnect to power until the damaged item

has been repaired or replaced.

Do not expose the product to rain or moisture.

Allow free unobstructed airflow to the bottom and back of the product. Do not block the

ventilation slots.

Operate the console only on a stable and solid surface.

Do not use the product if the ambient temperature exceeds 40°C (104° F)

Refer any service operation not described in this manual to a qualified technician.

Do not modify the product or install other than genuine Martin parts.

Transport the product only in suitable packaging or a custom fitted road case. Transportation

damage is not covered under warranty.

Protect the internal touch screen from sharp objects and operate the screen using a finger only.

Caution: Risk of fire and flectrical Shock. Use only in dry locations.

Caution: Risk of explosion if CMOS battery is replaced by an incorrect type. Dispose of used

batteries according to local environmental regulations

Caution: Do not expose CMOS battery to excessive heat such as sunshine or fire.

Martin M2GO and M2PCSafety and Installation Guide

Included Items

Each package contains the following items:

M2GO or M2PC Controller

Protective cover

External power supply unit with locking 4pin XLR connector

LED desklamp

1.5 m (4.9 ft.) power cable, 3-pin IEC P/N 11501012 (for use outside the USA and Canada)

1.5 m (4.9 ft.) power cable, 3-pin IEC P/N 11501502 (with NEMA 15-5P plug for use within

the USA and Canada)

USB cable

Safety and Installation Manual

Martin M2GO and M2PCSafety and Installation Guide

Software

The software for the M2GO and M2PC is available from the support website www.martin.com/

controllersupport

Please check periodically for new releases that may add new functionality or resolve a bug.

It is recommended to update to the latest release software before using the controller for the

first time.

Martin M2GO and M2PC Safety and Installation Guide

Recommended Touch Screen for M2GO

The M2GO is designed to be operated with an external touchscreen with a minimum screen

resolution of 800x600 pixels.

We strongly recommend that you do not use the M2GO without a touchscreen because the

controller software is designed around a touch interface.

Without the touchscreen the system will provide a poor user experience and is difficult to use.

The M2GO can be operated with the following touchscreen types:

Generic Windows 7 Touch compatible screens that do not require custom drivers

ELO Touch Systems iTouch, Accutouch and IntelliTouch compatible screens.

VGA, HDMI or DVI

USB 1.1 or 2.0

Martin recommends a 16:9 ELO touchscreen with iTouch technology.

A recommended screen is the ELO 2201L (part number E382790) which is available worldwide

through ELO retail partners.

http://www.elotouch.com/Products/LCDs/2201L/

Other screens may be verified, please check www.martin.com for further recommendations.

Recommended PC system for M2PC

The M2PC is designed to be operated with an external PC system that utilizes a touch screen.

We strongly recommend that you do not use the M2GO without a touchscreen because the

controller software is designed around a touch interface.

Without the touchscreen the system will provide a poor user experience and is difficult to use.

The PC should meet these minimum recommendations:

Windows 7 Operating System

Intel Core i5 processor

USB 2.0 connection

4GB RAM

1280x800 resolution touchscreen

Martin recommends a 16:9 ELO touchscreen with iTouch technology.

A recommended screen is the ELO 2201L (part number E382790) which is available worldwide

through ELO retail partners.

http://www.elotouch.com/Products/LCDs/2201L/

Other screens may be verified, please check www.martin.com for further recommendations.
