Marshall Amplification MIDDLETON Guía de configuración

MIDDLETON – PORTABLE LOUDSPEAKER

FULL ONLINE MANUAL

ENGLISH

CONTENTS

INDEX

Device layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 003

Getting started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 006

Connecting an AUX device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 006

Cleaning the speaker. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 006

Battery care guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 007

Performing a factory reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 007

Attaching the carry strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 008

Stack mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 009

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .010

003

MIDDLETON – FULL ONLINE MANUAL

BACK TO INDEX

DEVICE LAYOUT ENGLISH

004

MIDDLETON – FULL ONLINE MANUAL

BACK TO INDEX

DEVICE LAYOUT

1 BATTERY STATUS BUTTON

Push the Battery status button to see the battery charge.

2 BLUETOOTH BUTTON

Push and hold the Bluetooth®button until the LED

turns to a slow red pulse to start pairing mode.

3 BATTERY INDICATOR

The 10 segment battery indicator shows battery status or audio control

levels. Pushing the Battery status button will show the battery charge.

Adjusting the volume, bass, or treble will show the level for

the adjusted control. A rising animation indicates that the battery

is charging.

4 CONTROL KNOB

I. Push and hold for 2 seconds to turn on/o

II. Push once to play/pause

III. Push right/left to skip forward/back

IV. Hold right/left to fast forward/rewind

V. Push upwards/downwards to adjust the volume

5 BASS AND TREBLE CONTROLS

Use the bass and treble controls to adjust the audio balance. The 10

segment indicator shows the bass or treble level while adjusting.

6 CARRY STRAP HINGE

Attach the included carry strap to the hinge, see Attaching

the carry strap.

ENGLISH

005

MIDDLETON – FULL ONLINE MANUAL

BACK TO INDEX

7 AUX - 3.5 MM AUDIO INPUT

Plug in an audio device with an analogue

output and a 3.5 mm stereo jack.

8 USB C - POWER INPUT/OUTPUT

Charge the speaker by plugging it into a USB power source or

plug in a USB-C device and use the speaker as a powerbank.

DEVICE LAYOUT ENGLISHENGLISH

006

MIDDLETON – FULL ONLINE MANUAL

BACK TO INDEX

INSTRUCTIONS

GETTING STARTED

I. Push and hold the control knob until the speaker turns on.

II. Push the Bluetooth®button until the LED turns to a slow red pulse.

III. Select MIDDLETON from your audio device’s Bluetooth list.

CONNECTING AN AUX DEVICE

I. Connect a lead with a 3.5 mm stereo jack to the

AUX input on the back of the speaker.

II. Connect the other end of the lead to the audio output on your audio source.

III. Make sure all connected Bluetooth audio devices are paused.

Note: Audio leads are not included.

CLEANING THE SPEAKER

Clean your speaker regularly to keep it fresh and last longer.

Unplug any leads before cleaning the speaker and make sure everything

is completely dry before plugging in any audio or USB leads.

The silicone sleeve and strap can be removed and cleaned separately.

Use a disinfectant wipe or a lint-free cloth, slightly damp with 70%

isopropyl alcohol or 75% ethyl alcohol to gently clean silicon parts. Dry

them with a towel before putting them back on the speaker.

Carefully clean the speaker mesh and openings with

a dry and soft brush, or a cotton swab.

• Do not use any sharp or metal objects.

• Do not use compressed air.

• Do not use products containing bleach or hydrogen peroxide.

• Do not submerge the speaker in any cleaning agents.

ENGLISH

007

BACK TO INDEX

MIDDLETON – FULL ONLINE MANUAL

INSTRUCTIONS

BATTERY CARE GUIDE

Your speaker comes equipped with a high-performance lithium-ion battery

and the life span is aected by charging and usage. Follow the guidelines

below to keep your battery in great condition for as long as possible.

• Avoid using fast chargers if possible. Fast charging

causes stress on the battery and will degrade it.

• Avoid charging the battery when it is already full or letting it drain

completely. Try keeping the charge between 30% and 80%.

• If the speaker is stored for a long time, do so with a half-

charged battery and in a cool, dark, and dry place.

• Do not use or charge the speaker in hot and unventilated places, 45°C/113°F

and above, such as in a parked car or by a window in direct sunlight.

• Avoid charging the battery at low temperatures, below

10°C/50°F and using the speaker below 0°C/32°F.

• Avoid strong mechanical shocks such as dropping the speaker

on hard surfaces as it might damage the battery.

PERFORMING A FACTORY RESET

A factory reset will return the speaker to its original

settings, excluding any ﬁrmware updates.

Note: This will delete all user settings meaning the speaker will need to be

set up again.

I. Ensure that the speaker is on.

II. Push and hold the Bluetooth button for 7 seconds. All indicators turn

o and the speaker restarts.

III. Remove Middleton from your audio device’s Bluetooth list before

pairing again.

MARSHALL BLUETOOTH APP

Download the Marshall Bluetooth app to get the most out of your

speaker and keep it up to date with the latest software.

ENGLISH

008

MIDDLETON – FULL ONLINE MANUAL

BACK TO INDEX

ATTACHING THE CARRY STRAP

I. Remove the screw from the carry strap.

II. Thread the end of the strap through the top of the hinge on the speaker.

III. Join the end of the strap with the screw and tighten it.

Make sure the carry strap is secured to the speaker before use.

ENGLISH

1 2

009

MIDDLETON – FULL ONLINE MANUAL

BACK TO INDEX

STACK MODE

Connect two or more Middleton speakers in a Stack session for a bigger

sound. Play anything on the main speaker and all speakers in the session

will play in sync. You can adjust the volume on any individual speaker for the

perfect balance.

1 MAIN SPEAKER

Triple press the Bluetooth button to start or end a Stack session.

The LED starts to blink until another speaker joins the session.

2 ADDITIONAL SPEAKER

Double press the Bluetooth button on any speaker

you want to add to the session. The LED starts to

blink until the speaker has joined the session.

While in a session, the speaker will disconnect from any previously

connected audio device and will try to reconnect after leaving

the session.

To remove a speaker from the session, double

press the Bluetooth button on that speaker.

ENGLISH

010

MIDDLETON – FULL ONLINE MANUAL

BACK TO INDEX

PROBLEM CAUSE ACTION

The speaker does

not turn on

The battery has

no charge.

Plug the speaker

into a USB power

source to charge it.

Push and hold the

control knob for 2

seconds until the

speaker turns on.

Cannot connect

or pair with a

Bluetooth device

Bluetooth is not

enabled on your

device (smartphone,

tablet, computer).

Activate Bluetooth on

your playback device.

The speaker is

not turned on.

Push and hold the

control knob for 2

seconds to turn on the

speaker before setting

it in pairing mode.

The speaker is not

in pairing mode.

Push the Bluetooth

button until the

Bluetooth LED

pulses red.

Cannot play in

Stack mode

The playback device

is not connected to

the main speaker.

Make sure that your

playback device (phone

or computer) is paired

with the main speaker.

TROUBLESHOOTING ENGLISH
