Marcy CL103 Manual de usuario
12-04-2010-1
Magnetic Cycle
Product Code: CL103
2
Contents
Important Safety Information 3
Weight Limit Capacities
Hardware Parts List 4
Pre Assembly Check List 5
Assembly Instructions 6 - 12
User Guide 13
Computer Instructions 15
Exercise Instructions 16
Fault Finding Chart 17
Exploded Diagram 18
Parts List 19
Additional Information 20
Care Maintenance
Limited Warranty 21
Supplied by
Escalade International Ltd
Pleasant Road
Penllergaer
Swansea
SA4 9GE
Tel: 00 44 1792 222550
Fax: 00 44 1792 895781
www.escaladesports.co.uk
3
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING
1. This cycle is intended for class H (H=Domestic) use only. It is not designed for
commercial use.
2. This machine has been tested to BS EN 957.
3. Read the OWNER’S OPERATION MANUAL and all accompanying literature and follow
it carefully before using your cycle.
4. Keep children and pets away from the Cycle at all times. Do not leave children
unattended in the same room with the Cycle. The Cycle is not a toy and therefore
parents and guardians should be aware of the natural tendency for children to play,
leading to situations and behaviour for which the Cycle is not intended.
5. If children are allowed to use the Cycle their physical/mental development and above all,
temperament should be taken into account. Constant supervision is therefore needed.
6. Position the Cycle on a clear levelled surface which is clear of all obstacles as not to
restrict movement whilst exercising. DO NOT use the Cycle near water or outdoors.
7. Exercise equipment has moving parts. In the interest of safety, keep others, especially
children, at a safe distance while exercising.
8. Never hold your breath while exercising. Breathing should remain at a normal rate in
conjunction with the level of exercise being performed.
9. Rest adequately between workouts. Muscle tone develops during these rest periods.
Beginners should work out twice a week and increase gradually to 4 to 5 times per
week.
10. Remove all jewellery, including rings, chains and pins before commencing exercise.
11. Always wear suitable clothing and footwear during exercise. Do not wear loose fitting
clothing that could become entangled with the moving parts of your exercise machine.
IMPORTANT!!! THE MAXIMUM RECOMMENDED WEIGHT CAPACITY FOR YOUR
CYCLE IS 120KGS.
THIS OWNER’S MANUAL CONTAINS ASSEMBLY, OPERATION, MAINTENANCE
AND SAFETY INFORMATION. IN THE INTEREST OF SAFETY, PLEASE MAKE
CERTAIN THAT YOU READ AND UNDERSTAND ALL THE INFORMATION
BELOW.
4
HARDWARE PARTS LIST
S13-15
6mm
S13-14-15
#10 M7 1PCS
#011
8*
12
*
25
1PCS
#07 M8 1PCS
#08
M8
1PCS
#33 M8*16 4PCS
#35 M8 4PCS
#30 M8*63L 4PCS
5
PRE-ASSEMBLY CHECK LIST
Part No. Description Qty
1 Handlebar Post 1
3 Handlebar 1
13 Computer 1
23 Pedal (L & R) 2
24 Saddle 1
27 Seat Post 1
31 Rear Stabilizer 1
37 Main Frame 1
42 Front Stabilizer 1
Above described parts are all the parts you need to assemble this machine. Before
you start to assemble, please check the hardware packing to make sure they are
included.
NO. 3 7
NO. 0 1
NO. 2 3
NO. 0 3
NO. 1 3
NO. 2 4
NO. 4 2
NO. 3 1
NO. 2 7
6
ASSEMBLY INSTRUCTION
STEP 1
Assemble the front and rear stabilizers (42 & 31) to the main frame using 4 carriage bolts (30),
curved washers (33) and acorn nut (35).
#33 M8 4PCS
#35 M8 4PCS
#30 M8* 63L 4PCS
7
STEP 2
The left and right pedal (23R & 23L) are marked "L" and "R". Assemble the left and right pedals to
their appropriate crank arm. The right pedal is on the right hand side of the cycle as you sit on it.
Note that the right pedal should be threaded on clockwise and the left pedal
counter-clockwise.
Please note, the
left pedal uses a
left hand thread.
8
STEP 3
Ensure the Tension Control Knob is set to number 1. Connect the tension cable upper (55) to
the tension cable lower (52). Please see the next page for a detailed description of this part of the
assembly. Connect the upper sensor wire (54) to the lower sensor wire (53). Assemble the
handlebar post (1) to the main frame and secure into position using 4 allan head bolts and curved
washer (33).
#33 M8* 16 4PCS
#36 M8* 16 4PCS
9
HOW TO CONNECT TENSION CONNECTOR
Slide the Cable wire from the
Upper Tension Connector in
between the opening on the wire
holder on the Lower Tension
Connector.
Pull the Upper Tension Connector
backward and slide the wire
through the slot on the bracket.
Drop the Connector down so the
fitting sits firmly on top of the
bracket.
10
STEP 4
Assemble the Handlebar (3) onto the bracket at the top of the Handlebar Post using plastic cover
(9), flat washer (8), spring washer (7), steel tube (11) and T Knob (10).
#10 M8 1PCS
#07 M8 1PCS
#08 M8 1 PCS
#11 8* 12*25 1 PCS
