Manhattan 174244 Manual de usuario

MULTIMEDIA

ACCESS

HUB

USER

MANUAL

Model 174244

MAN-174244-UM-0707-01

Thank you for purchasing the MANHATTAN

®

Multimedia Accessl Hub,

Model 174244.

By replicating USB, PS/2 and audio ports with a single USB connection,

this device helps to quickly install digital cameras, keyboards, mice and

headsets with a convenient all-in-one solution. It’s an ideal accessory for

traveling notebook computer users to quickly reconnect to home/ofce-

based peripherals and devices and to help reduce tangled cables for

a neater workspace. USB 1.1 compatibility supports older devices and

provides Hi-Speed USB 2.0 data transfer speeds up to 480 Mbps.

A durable case, compact size and bus power make it easily transportable

to add multiple connectivity almost anywhere. Installation is simple with

Plug and Play and hot-swappable capabilities plus a USB cable that

quickly connects the hub to any USB port.

System Requirements

• USB-enabled PC or Mac system

• Windows 98SE/Me/2000/XP/Vista or Mac OS 9 or above

• Available USB port, PS/2 ports, stereo jack and microphone jack

Package Contents

• Multimedia Access Hub

• User manual

NOTE: If, after connecting the multimedia access hub to one or more

peripheral devices, any of the ports fail to work normally, disconnect the

device(s), as the failure may be momentary due to excessive current.

Reconnect the device(s) to allow the hub to recover and operate

normally.

SPECIFICATIONS

Standards and Certications

• USB 2.0, USB 1.1, USB 1.0

• FCC

• CE

• RoHS

• WEEE

General

• Transfer speeds: 1.5/12/480 Mbps

• Driverless design

• Up to 500 mA through USB and

PS/2 connections

• Bus powered

Ports

• 2 upstream ports, B-type

• 4 downstream ports, A-type

• 2 PS/2 ports

• Microphone and stereo headset

ports

Physical

• Dimensions: 83 x 52.5 x 18 mm

(3.25 x 2.1 x 0.75 in.)

• Weight: 157.4 g (5.6 oz.)

• Cable length: 1.1 m (3.6 ft.)

• Housing: ABS plastic

Are you completely satised with this product?

Please contact your MANHATTAN®dealer

with comments or questions.

Copyright © MANHATTAN

All products mentioned are trademarks or registered trademarks of their respective owners.

www.manhattan-products.com
