Manhattan 100908 Manual de usuario

MULTI-CARD

READER

WITH BUILT-IN

DATA PANEL

QUICK

INSTALL

GUIDE

Model 100908

Thank you for your purchase of the

MANHATTAN®Multi-Card Reader with

Built-In Data Panel, Model 100908.

For use with many of today’s popular

ash memory card formats, this handy

device lets you copy, back up, restore or

recover data without opening your PC

case or installing additional drives! Just

connect SATA, eSATA and Hi-Speed

USB 2.0 storage devices/peripherals

through the front-mount ports. (See the

back of this sheet for basic installation,

specications and a compatibility list.)

MH-100908-miniQIG-0608-01

All products mentioned are trademarks or registered trademarks of their respective owners.

MANHATTAN®offers a complete line of PC Components, Peripherals, Cables and

Accessories. Ask your local computer dealer for more information or visit us online at

www.manhattan-products.com

• Slot-to-slot read/write/copy and

USB mass-storage capabilities

• Front-mount SATA, eSATA and

Hi-Speed USB 2.0 ports

• Compatible with Memory Stick,

SecureDigital, MultiMedia, XD

and CompactFlash

• Supports automatic card

detection and data transfer

speeds up to 480 Mbps

• Fits in 3.5” drive bay

• Windows and Mac compatible;

hot swappable, Plug and Play

• Lifetime Warranty

BASIC INSTALLATION

1. Insert the Multi-Card Reader into an available 3.5” bay and secure it in

place with the included screws.

2. Connect the two SATA cables

to the controller card; the USB

9-pin to the motherboard; and

the 4-pin pass-through.

NOTE: At right are examples of

how different computer manufacturers may label

connectors corresponding to specic cable

wires, plus a typical dual-head USB

connection found on the motherboard.

(Normally, the connectors are labeled on the

board; if not, contact the manufacturer.)

3. No driver installation is required. Four ash memory card icons

(Removable Disks) will display in the My Computer les.

SPECIFICATIONS

SUPPORTED MEMORY CARD FORMATS

C-Flash, CompactFlash Type I/II, Ultra II CF, MagicGate, MagicGate PRO,

MagicGate PRO Duo, Memory Stick, Memory Stick Duo, Memory Stick PRO,

Memory Stick PRO Duo, Memory Stick Select, Memory, Stick Extreme PRO,

Memory Stick Extreme III PRO, Memory Stick Ultra II PRO Duo, Microdrive,

DV-RS MMC, MMC / MMC II, MMC 4.0, MMCmicro, MMCmobile, MMCplus,

RS-MMC, Ultra MMC, SecureDigital (SD), Elite Pro SD, Extreme SD, Kingmax

SD, microSD / TransFlash, miniSD*, SecureDigital Ultimate, Ultra II SD and XD.

* Requires an adapter (not included)

Standards & Certications

• USB 2.0; USB 1.1; SATA; CE; FCC

General

• Internal connections: 2 SATA L-type

data (male), USB 9-pin (motherboard),

4-pin Molex pass-through

• External connections: eSATA, SATA

data, SATA power and Hi-Speed

USB 2.0 port

• Throughput: Hi-Speed USB 2.0, up

to 480 Mbps; SATA, up to 3.0 Gbps

• LED power and activity indicators

• Windows 2000/XP/Vista compatible

Physical

• Fits in 3.5-inch drive bay

• 102 x 105 x 25 mm (4 x 4.13 x 1 in.)

• Weight: 267 g (9.4 oz.)

Wire Connector Label

Red, orange POWER, VCC, SVCC, +5V

White, yellow P–, DATA–, SBD–

Green, gray P+, DATA+, SBD+

Black, blue, brown GROUND, GRND, GND
