PROGRAMMING
- 4 -
0
0
1
1
C
C
? ? ??0
0
1
1
0
0
#
#
#
*
(1 TO 9999)
(4TH DIGIT)
(FIRST DIGIT)
PROGRAM THE SUBSCRIBER ID
READ THE SUBSCRIBER ID
THE CURRENT SUBSCRIBER CODE WILL BE DISPLAYED ONE DIGIT AT THE TIME.
SUBSCRIBER I.D. SETTING ( REPEATER /CSID CODE)
AFTER ENTERING THE 4TH DIGIT THE NEW CODE IS AUTOMATICALLY STORED IN MEMORY
This is the CUSTOMER i.d. NUMBER sent to the BASE STATION
ON = SNIPER OPERATION
0#010
REPEATER “1”
0
2
Display the Repeater Number
*
THE CURRENT REPEATER
NUMBER WILL BE INDICATED.
0#
010
Set the Repeater Number
21
0#
PROGRAMMING THE NEXT ( OR BASE ) REPEATER NUMBER
OFF = SEND DTMF PROTOCOL
ON = SEND FTX PROTOCOL
OFF = SEND TO OPEN BLOCK BASE
ON = SEND TO WNET BASE
0FF = DISABLE ALL REPEATER FUNCTION
OFF = DO NOT REPORT ARM/DISARM
OFF = NO REPORT
OFF = NO REPORT
OFF = REPEAT INCOMING FORMAT
ON = REPORT ARM/DISARM
ON =REPORT SYSTEM BATTERY LOW
ON = REPORT SYSTEM MAINS FAILURE
ON = REPEAT FIXED FORMAT (BIT 1)
SPARE
SPARE
0 # 0 2010
OPTIONS REGISTER NO. 2
1
2
3
4
5
6
7
8
SPARE
SPARE
OFF = AUXIL. SIGNALS ON BUZZER ONLY
SPARE
SPARE
SPARE
ON = AUXIL SIGNALS ON BUZZER AND SIREN
SPARE
0 # 0 1010
OPTIONS REGISTER NO. 1
= OFF
= ON
NOTE:
1
2
3
4
5
6
7
8
FACTORY DEFAULT
FACTORY DEFAULT
SPARE SPARE
ON = ENABLE ALL REPEATER FUNCTION
SPARE SPARE
SPARE
SPARE
SPARE
SPARE
ON = SNIPER OPERATION
0#010
REPEATER “1”
1
2
Display the Repeater Number
*
THE CURRENT REPEATER
NUMBER WILL BE INDICATED.
0#
010
Set the Repeater Number
21
1#
PROGRAMMING THIS REPEATER NUMBER (From alarm panels)
NOTE: THIS OPERATION WILL ERASE
BOTH THE MEMORY IN THE KEY BOARD
AND THE CONTROL UNIT AND RESTORE
THE FACTORY-DEFAULT VALUES .
IT COMBINES THE ABOVE 2 COMMANDS
NOTE: THIS OPERATION WILL ERASE
ALL PRESENT OPTIONS AND RESTORE
THE FACTORY-DEFAULT VALUES INCLUDING
ZONE, OPTIONS, WIRELESS CODES ETC ! ! !
0 # 9010
ERASE KEYBOARD MEMORY
HOLD
TILL BEEP
NOTE: THIS OPERATION WILL ERASE
ALL PRESENT VALUES AND RESTORE
THE FACTORY-DEFAULT VALUES INCLUDING
KEYBOARD SETTINGS AND USER CODES ! ! !
0 # 0 9010
ERASE MEMORY
IN CONTOL UNIT
0 # 2 9010
ERASE BOTH CONTROL-UNIT
AND KEY-BOARD MEMORIES
After this command the unit will
reset to load the default values!
After this command the unit will
reset to load the default values!
After this command the unit will
reset to load the default values!
!
!
!
!
!
!
DEFAULTING THE SYSTEM (ERASING MEMORIES)
Summary of ALL Key-Pad entries
1000 # 0 1 = SET OPTIONS 1 OF THE SYSTEM
1000 # 0 2 = SET OPTIONS 2 OF THE SYSTEM
1000 # 0 4 = SET DET. DELAY FOR EACH ZONE.
1000 # 0 5 = SET SIREN ACTIVATION.
1000 # 0 6 = SET OPEN / CLOSE REPORTING
1000 # 0 7 = SET ALM / RESTORE REPORTING
1000 # 0 8 = MODE REGISTER
1000 # 0 9 = ERASE EEPROM IN THE CONTOLUNIT
1000 # 0 A = SET LEVEL A
1000 # 1 5 = PERMANENT ACTIVE ZONE
1000 # 1 6 = ENTRY/EXIT DELAY
1000 # 1 7 = ENTRY/EXIT DELAY VALUE
1000 # 1 8 = CHECK-IN TIME
1000 # 1 9 = SIREN DURATION
1000 # 1 C # = PROG CUSTOMER ID CODE
1000 # 1 C * = DISP CUSTOMER ID CODE
1000 # 2 0 # = PROGRAM “NEXT” REPEATER Number
1000 # 2 0 * = DISPLAY “NEXT”REPEATER Number
1000 # 2 1 # = PROGRAM the REPEATER Number
1000 # 2 1 * = DISPLAY the REPEATER Number
1000 # 2 9 = ERASE EEPROM IN BOTH KEYPAD AND THE CONTOLUNIT
0 # 18010
FACTORY DEFAULTS
For the next option you need to enter a value between 0 and 250.
EXAMPLE: - check-in interval time to 24 hours enter: 8 2 4 (hrs)
To set the : 1 0 0 0 # 1 0
N.B. - A CHECK-IN INTERVAL VALUE OF "0" WILL AUTOMATICALLY DISABLE THE OPTION ( NO CHECKING-IN TRANSMISSION ).
- THE “EXIT” DELAY IS AUTOMATICALLY SET TO DOUBLE THE “ENTRY” DELAY
CHECK-IN INTERVAL (HRS)
4
0 2
(24HRS)
New!!
NOTE: ALL PROGRAMMING IS PERFORMED THROUGH
THE STANDARD TRACER KEYPAD (S0032A3X)
PROGRAMMING THE OPTION REGISTERS (ONLY THROUGH TO THE INSTALLER PASSWORD)
NOTE: PLEASE NOTE THAT NOT ALL OF THE BELOW MENTIONED OPTIONS ARE AVAILABLE
ON THE REPEATER. PLEASE KEEP ONLY TO THE OPTIONS MENTIONED IN THE REPEATER
MANUAL TO AVOID UNDESIRED FUNCTIONS.
PROGRAMMING THE CHECK IN TIME ( SELF TEST INTERVAL)
PROGRAMMING THE GLOBAL FUNCTION REGISTERS
IDENTIFICATION REGISTERS
