Free Your Life With Innovative Technology
PPORO User’s Guide
Please read this manual before using the product.
Please keep this manual in your sight.
Please visit www.mamirobot.com for more information.
This product specially designed for the US home use.
Please check if the machine works properly several times before you clean the floor.
Please check the status of the machine when you use it for the first time.
Please stop operating the machine if you see any scratches. We are not responsible for the
problems if you did not check the circumstance listed above.
Please check if there is any problem especially when you use the machine on the wooden
floor and Korean heating floor.
※This is user manual. Some images in this manual can be slightly different with the actual product.
1. Mamirobot is designed for efficient cleaning the regular floor and carpet(less than
1cm). Mamirobot can clean powerfully the normal floor and carpet by installing of
vacuum suction guidance.
2. With installed Front Sensor and Side Sensor, Mamirobot follows the wall smoothly.
3. Mamirobot has the auto-recharge function similar method with Ground Controlled
Approach of airplane. It guides Mamirobot to the charging station quickly and ac-
curately.
4. Battery of Mamirobot is high-speed rechargeable and working time is long,
efficient cleaning is possible.
5. With the charging station, Mamirobot and Hand Held Cleaner Zaaloo can be
charged at the same time. You can clean narrow area such as edges, window
frames with Zaaloo.
6. Dust cloth can be attached easily by plate for dust cloth. Plate for dust cloth located
in a body of machine.
Thank you for purchase Mamirobot.
Mamirobot vacuum cleaner which is made by patents of Mamirobot leads you to new world. The
Mamirobot of remarkable cleaning ability is ...
Contents
Before using
Preparing
Cleaning
Guidance
Zaaloo
Product
Information
Important Safety Information
Check List Before Operation
Know-how for Using
Components
Name of Part
Characteristic of Battery
Battery Installation
Station Installation (K5, K7)
Recharging Battery using Station (K5, K7)
Recharging Battery using Adapter (K5,K7)
Empty Dust Bin and Replace Filter
Install Dust Cloth
Side Brush Maintenance
Main Brush Maintenance
Cover and Main Brush Tips
Composition of Display Panel
Remote Controller
Operating Mamirobot
Normal Mode
SSW Mode
Auto Recharging (K5, K7)
Voice Guidance
Station Guide
Troubleshooting Error Code
Hand Cleaner Zaaloo
Important Tips
Part Name
Recharging Battery
Operating
Empty Dust Bin and Maintenance
Replace Filter
Troubleshooting
Check List Before Service Request
Specification
Warranty
6
7
7
8
9
10
10
11
11
11
12
13
13
14
14
15
16
17
18
18
19
20
20
21
22
22
23
24
24
24
25
25
26
26
27
5
Before using Preparing Cleaning Guidance Zaaloo Product Information
Safety Information
Before using Mamirobot, read all safety precautions and keep these in mind to reduce the risk of
accident or damage.
Mamirobot is for indoor use only. Do not use outdoors or on wet surfaces. It may cause failure.
Before using, put away any obstacles which interrupt Mamirobot movement on the floor. Obstacles could
be clothes, papers, power cords, etc.
Product is design for the best vacuuming performance. Make sure if there is any small object on the
bottom panel before use.
Children and pets should be supervised to ensure that they do not sit or stand on Mamirobot.
Do not use Mamirobot to pick up anything that is burning or cigarette.
Do not use Mamirobot to pick up inflammables (combustible liquids, gasoline). It can cause fire.
During operating, close any doors to prevent it from exiting the room.
Make sure that the air circular hole is not clogged.
Do not use on the table, furniture or other electronic product. Mamirobot can be damaged by falling
down.
Do not use on the outdoor surface such as concrete or asphalt. It can cause failure.
Use only the charger and battery supplied by the manufacturer. Do not charge Mamirobot around any
electronic product which generates heat such as a refrigerator. Make sure that Mamirobot is off the
ground except the wheels while charging because it can cause fire.
Do not disassemble or repair Mamirobot except by authorized technicians. Disassembling or repairing by
unauthorized person will void the warranty.
6
Before usingPreparingCleaningGuidanceZaalooProduct Information
Before Use
Prepare for Cleaning
Before using, put away any obstacles which interrupt Mamirobot movement on the floor. Obstacles could be clothes, papers, power
cord, etc..
Make sure if there is any small object on the bottom panel before use.
Anti-Falling Sensor
Sensors of Mamirobot can recognize the depth between current area and next area. That function prevents to fall the machine down.
If the depth is more than 5 cm, the machine does not go further and arrange cleaning scope again.
Cross the Threshold
Mamirobot is designed to be able to cross the threshold when Mamirobot does not attach the dust cloth. Available height is around
1 cm and it depends on the shape of threshold. It does not cross threshold if the height is over 1 cm for safety.
Mopping Mode
For improving the efficient of damp mop cleaning, put away any obstacles which interrupt Mamirobot movement. Furthermore, with
attaching dust cloth, Mamirobot could not cross the threshold and carpet. Damp Mop mode cannot be used for carpet cleaning.
There can be some dust on the wheel cause by product test.
It is not a not a sign of refurbished product or used product..
Know-How for Using
1. If the machine is not used for more than 1~2 months, battery capacity could be down. At this case, it will improve again with
repetition about 2 times of full-recharge and full-discharge. Please separate the battery from the product when you don’t use the
machine for a long period of time.
2. Due to the properties of Ni-MH, frequent recharge may cause using time to reduce. Please use the machine after full recharge
and use until the battery is fully discharged.
3. Life time of battery is 18 ~ 24 months and 500 times recharge-dischargeable. As time goes by, using time may reduce, and if
the using time becomes remarkably short, you should replace it. You can purchase battery and consumable items on line http://
usa.mamirobot.com.
4. The warranty of battery is 6 months.
5. Using without dust filter or using defective dust filter can cause a breakdown due to dust inside the machine. Dust filter should
be replaced after 2~3 times used.
6. Please contact to 1-800-xxx-xxxx for A/S or send item to xxx,xxxx,xxxx,xxx
※Store the packaging box in case you need to send the product for the repair.
7
Before using Preparing Cleaning Guidance Zaaloo Product Information
Main Brush Cover
Hair Mode Cover
(Ni-MH)
Rechargeable Battery
Main Brush
100~240V(50/60Hz) Adapter
* 220v plug need to be changed to 110v plug
Dust Filter
2 AAA Remote
Controller Battery User Manual
Superfine Fibers Mop
※One of these covers is installed in the main body.
※Hair Mode Cover is used for hair cleaning.
Main Components
Components
Unpack the product and check that all of the following contents are included.
Parts/Small components
Remote Controller
Mamirobot cleaner
Hand Vacuum
( for K7 )
Battery Charge Station
(for K5, K7)
8
Before usingPreparingCleaningGuidanceZaalooProduct Information
Front Sensor
Bumper
Rubber Bumper
Remote Control Sensor
Display Window
Status Indicator
Operating Buttons
Dust Bin Cover Button
Dust Bin Cover
Recharging Holder for Hand Cleaner
Remote Controller Holder
Recharge Indicator Recharge Approach Window
Charging Socket
Anti Falling Sensor Recharge Plate
Front Wheels Rear Wheel
Side Brush Intake
Main Brush Cover (for hair mode)
Main Brush Mop Plate
Battery Cover
Name of Part
9
Before using Preparing Cleaning Guidance Zaaloo Product Information
About Battery
1.Mamirobot’s adapter is free voltage type (100 ~240V), so you can use it in any country without limitation of voltage. With a full-
recharge, the battery lasts maximum 2 hours. (Working time can be various by types of floor and cleaning mode.)
2.Because the first status of battery is not fully charged, you should charge it before using. For the first time use, battery working
time could be shorter than normal. At this case, it will improve again with repetition about 2 times of full-recharge and full-
discharge.
3.Life time of battery is 500 times recharge-dischargeable. As time goes by, using time may reduce, and if the using time becomes
remarkably short, you should replace it. Due to the properties of Ni-MH, frequent recharge may cause using time to reduce. Please
use the machine after full-recharge and use until the battery is fully discharged.
4.For the recharging failure, check the connection between adapter and power cord.
5.Actual battery life and working time varies by usages, setting, and operating conditions.
Battery Installation
1. Place Mamirobot upside down on a flat, padded surface such as on a
towel or blanket. Press and slide the battery cover as shown in picture.
2. Insert the battery plug into the socket as shown in the picture. Please
make sure the battery is installed properly.
3. Place the Rechargeable Battery in the battery repository and close the
battery cover after well arrangement of cords.
4. Dismounting is carried out in reverse order.
5. You do not need to separate the battery once battery is installed prop-
erly. Use the battery charging station and recharge connector when
you recharge the battery.
* When the connection is not good, the error code will be shown in Status Indicator and it wouldn’t be recharged.
* Never touch an electrical socket or appliance with wet hands.
* If you will not use the machine for a long time, remove the battery from machine and keep in a cool & dry place.
Insert plug into socket Correct Installation
O
Incorrect Installation
X
Battery plug
Click!
Battery socket
10
