Mainstays MS-PSBL-BLK Manual de usuario
MS-PSBL-BLK
Customer Assistance:
1-866-321-9509
Personal
Blender
2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions before use.
2.
appliance in water or other liquid.
3. Close supervision is necessary when any appliance is used by or near children.
4. Unplug from wall outlet when not in use, before putting on or taking off parts,
and before cleaning. Allow to cool before putting on or taking off parts, and
before cleaning.
5. Avoid any contact with blades or moving parts.
6. Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions or has been dropped or damaged in any manner. Call
our toll-free customer assistance number for information on examination or
adjustment.
7. The use of accessory attachments, including cup and blade unit, not
or injuries to persons.
8. Do not use outdoors or in a damp area.
9. Do not let power cord hang over edge of table or counter.
10. To disconnect, remove plug from wall outlet.
11. Do not use appliance for other than intended use.
12. Keep hands and utensils out of the cup while blending to reduce the risk of
severe injury to persons or damage to the appliance. A scraper may be used but
must be used only when the appliance is not running.
13. Blades are sharp. Handle carefully.
14. To reduce the risk of injury, never place blade unit on motor unit without the cup
properly attached.
15. The cup and blade unit must be properly tightened and in place before
operating the appliance.
16.
17. Do not blend hot liquids in the cup. Allow any hot liquids to cool to a lukewarm
temperature before pouring them into the cup.
18. Do not ONLY blend ice or nuts in the cup.
19. Do not place the appliance close to the edge of the countertop.
20. Do not attempt to defeat the interlock mechanism.
SAVE THESE INSTRUCTIONS
3
ADDITIONAL SAFEGUARDS
This appliance is for HOUSEHOLD USE ONLY.
DO NOT OPERATE APPLIANCE IF THE POWER CORD SHOWS ANY DAMAGE
OR IF APPLIANCE WORKS INTERMITTENTLY OR STOPS WORKING
ENTIRELY.
EXTENSION CORDS
•A short power-supply cord is to be provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord. Longer extension cords are
available and may be used if care is exercised in their use. If a long extension
cord is used:
-The marked electrical rating of the extension cord should be at least as great
as the electrical rating of the appliance.
-If the appliance is of the grounded type, the extension cord should be a
grounding 3-wire cord; and
-The longer cord should be arranged so that it does not drape over the
countertop or table top where it can be pulled on by children or tripped over
unintentionally.
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the other). To reduce
.
4
PRODUCT DIAGRAM
PRODUCT MAY VARY SLIGHTLY FROM ILLUSTRATION
MAX
1
2
8
3
5
6
7
4
1. Cup
2. Blade unit
3. Motor unit
4. Power cord with plug
5. Resealable lid
6. Quick seal
7. Interlock mechanism
8. Seal
5
ILLUSTRATIONS
a
MAX
b c
d e f
gh
MAX
i
MAX
jk l
MAX
MAX
6
ILLUSTRATIONS (CONTINUED)
mn
MAX
o
qp
BEFORE FIRST USE
•Remove all packaging materials, labels and/or stickers from your appliance.
•Check package contents for completeness and damage. Do not operate the
appliance if package content is incomplete or appears damaged. Return it
immediately to the Wal-Mart.
CAUTION: Danger of suffocation! Packaging materials are not toys. Always keep
plastic bags, foils and styrofoam parts away from babies and children. Packaging
material could block nose and mouth and
Clean your appliance thoroughly before using for the first time. See CLEANING
water or any other liquid (fig. a). This may result in electrical shock or damage to
prevent breathing.
•
AND MAINTENANCE section.
CAUTION: Do not immerse the motor unit (3) or the power cord with plug (4) in
the appliance.
7
ASSEMBLY
•
NOTE: Ensure the blade unit seal (8) is correctly placed during assembly and not
CAUTION: The blades on the blade unit (2) are very sharp. Always handle blade
HOW TO OPERATE YOUR APPLIANCE
Before starting any operation, always make sure the power cord with plug (4) is
unplugged.
NOTE: The appliance has a rated power of 220W. Before plugging it into the wall
outlet, ensure that the electrical circuit is not overloaded with other appliances. This
appliance should always be operated on a separate 120V, 60Hz wall outlet.
CAUTION:
•Do not use the appliance without placing food in the cup (1).
•Never leave the appliance unattended during operation.
•
(1) indicates the maximum level for liquids only, not for solid food. The maximum
•Do not use the cup (1) in a microwave.
•Do not blend HOT liquid.
•Do not blend ice cube or nuts only.
•Do not attempt to defeat the interlock mechanism at any time.
•
•
NOTE: Peel or core any fruits or vegetables and cut them into small chunks. Cut
solid food into small cubes (not larger than half inch cube).
•Carefully assemble the cup (1) and the blade unit (2).
•Secure the blade unit (2) to the cup (1) by turning the blade unit (2) clockwise.
•
•
•
•Turn the cup (1) with blade unit (2) clockwise until the locking mechanism clicks
•If necessary, remove cup (1) and shake ingredients in cup to re-distribute.
8
NOTE: It is required to fully click the locking mechanism into place for the blending
operation to commence.
CAUTION: Do not operate the appliance continuously for more than one minute
to prevent overheating. After use, let the appliance cool for at least three minutes
before resuming operation.
•Turn cup (1) counterclockwise to stop when desired consistency is reached
•
•Flip the cup (1) so that the blade unit (2) faces upwards.
•
•Carefully unscrew the blade unit (2) from the cup (1) by turning it
•Align cup (1) and resealable lid (5). Secure by turning the resealable lid (5)
CAUTION: When storing food in the cup (1) ensure the resealable lid (5) is sealed
tight and the quick seal (6) is closed securely. Place the cup (1) upright to avoid
spilling.
HINTS AND TIPS
•Store any unused portions using the cup (1) with resealable lid (5) in the
refrigerator.
•The resealable lid (5) has a quick seal (6) and can be used as a drinking cup
CLEANING AND MAINTENANCE
Proper maintenance will ensure many years of service from your appliance. Clean
the appliance after every use. The appliance contains no user serviceable parts and
CAUTION: Disconnect the power cord with plug (4) from the wall outlet. Allow all
parts of the appliance to cool down completely.
NOTE: Do not immerse the power cord with plug (4) and appliance into water or
Dry all parts thoroughly after cleaning, before using or storing the appliance. Ensure
that no water enters the appliance housing.
CAUTION: Any food residue left in the interlock mechanism (7) could cause the
appliance to malfunction or cause it to operate without being assembled correctly.
Use a small brush to remove any residue from the interlock mechanism (7).
•Clean the motor unit (3) with a clean, slightly damp cloth.
•Clean the cup (1), resealable lid (5) and blade unit (2) in hot, soapy water. The
cup (1) is dishwasher safe.
9
•
cleaning agent. For stubborn stains, leave to soak overnight.
•Clean all parts of the appliance after each use.
NOTE: Dry all parts and surfaces thoroughly before use. Make sure that all parts
and surfaces are completely dry before connecting the appliance to a wall outlet.
STORAGE
•Before storage, always make sure the appliance is completely cool, clean and
dry.
•It is recommended to store the appliance in a dry place.
•Store the appliance on a stable shelf or in a cupboard, preferably in its original
packaging. To avoid accidents, ensure that both the appliance and its power
cord (4) are beyond reach of children or pets.
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Appliance is not
working
Appliance is not
plugged in.
Wall outlet is not
energized.
Insert the power cord with plug (4)
into the wall outlet.
Check fuses and circuit breaker.
Motor rotates very
slowly or does not
rotate.
Too much food in the
cup.
Consistency is too
thick.
Motor is overloaded.
Remove some food and restart.
Add some liquid and restart.
Let the motor rest for at least three
minutes and restart with less food.
If additional assistance is needed, please contact Customer Assistance at 1-866-
321-9509.
TECHNICAL DATA
Rated voltage: 120V, 60Hz Rated power input: 220W
Capacity: Approx. 450 ml, 15 fl. oz.
