MA 25 / MA 25e

Quick User Guide

Description

The MA 25 / MA 25e is a pure tone screening audiometer. The MA 25e extends the MA 25

functionalities with Hughson Westlake automatic hearing threshold test and talk forward

function.

Function of buttons

Power on: Press Tone Switch

Attention: Power on is only possible if

headphones are plugged in!

Power off: Press the Hearing Level dB

dialer and Frequency Hz dialer.

Automatic power off after 3, 4, 5

minutes or never (settings can be

changed in the setup menu).

Alternatively unplug the headphones.

Frequency: Turn the Frequency Hz

dialer to select another frequency.

Level: Rotate the Hearing Level dB

dialer to increase or decrease the level.

Tone On/Off: Press the Tone Switch.

Function Buttons MA 25

Select right ear

Select left ear

Pulse

On/Off

Warble

On/Off

Display

Tone: A tone presentation indicator is provided in the top left corner of the

display header.

Response: When using the patient response switch, a response is indicated in

the middle of display header.

Power On or Battery status: The battery status is indicated in the top right

corner of the display header.

8012069-3_QG_MA25_e_15a

2 / 2

06/15

MA 25 / MA 25e

Quick User Guide

Setup menu

To access the MA 25/MA 25e setup menu press F1 and F4 simultaneously for 2-3 seconds.

Change setting

Browse up in the

setup menu

Browse down in the

setup menu

Save settings and exit

setup menu

Function of Buttons MA 25e

Function Buttons MA 25e

Toggle between

Right and Left

Store threshold

value

Pulse

On/Off

Warble

On/Off

Talk Forward: Hold down the Hearing Level db dialer. To adjust the talk

forward level hold down and rotate the Hearing Level db dialer.

Special Function Buttons MA 25e by pressing the frequency dialer

Delete all hearing

thresholds stored in

the internal memory

Store a Not Heard

threshold point.

Display hearing

thresholds stored in

the internal memory

Start Hughson

Westlake (HW)

automatic test

MAICO Diagnostics GmbH

Sickingenstr. 70-71

10553 Berlin

Germany

Tel.: + 49 30 / 70 71 46-50

Fax: + 49 30 / 70 71 46-99

E-mail: [email protected]z

Internet: www.maico.biz
