Map 410 GPS FAQs

1 Question:

How many batteries does my Map 410 GPS use?

Answer:

Map 410 GPS uses four AA batteries.

2 Question:

How long will the batteries operate for my Map 410 GPS?

Answer:

Using four AA batteries, your Map 410 GPS will operate

continuously for up to 12 hours.

3 Question:

How long will my Map 410 GPS keep memory active without a

battery?

Answer:

The internal lithium backup battery will keep your receiver’s

memory active for up to 10 years.

4 Question:

How do I install the batteries in my Map 410 GPS?

Answer:

The Map 410 GPS uses four AA alkaline batteries that are

installed from the bottom of the receiver. Use the rings to

unscrew the water seal battery caps. Insert the batteries into

the battery tubes, with the positive end first, two batteries in

each side, and screw the battery caps until securely closed.

Although it is recommended that four AA batteries be used, in

case of an emergency the receiver will operate with only two

batteries if both are inserted into one of the battery tubes.

5 Question:

How do I turn on my Map 410 GPS?

Answer:

To turn your Map 410 GPS “on”, press the power/light key and

then press the enter key when prompted. If the enter key is not

pressed within 10 seconds of being prompted, the receiver will

turn “off”. Wait for the unit to scroll through the start-up

screens.

6 Question:

How do I turn off my Map 410 GPS?

Answer:

To turn your Map 410 GPS “off”, press and hold the same

power/light key. This will start a shutdown sequence that

counts down the seconds until the receiver actually turns

“off”. To immediately turn the receiver “off”, release and press

the power/light key again. To cancel the shutdown sequence,

press any other key.

7 Question:

How do I initialize my MAP 410 GPS for the first time use?

Answer:

Turn your receiver on by pressing the power/ light key and the

enter key, when prompted. Because this is the first time you

have used your receiver, a screen will be displayed prompting

you to initialize your receiver. Press the enter key. When the

region screen appears, Use up/down arrow keys to highlight

the region where you are located. Enter mark. Use up/down

arrow keys to highlight country, province or state where you

are located. Enter mark. The elevation screen appears. Use the

arrow keys to enter your present elevation. Enter mark. From

the time field on the elevation screen. Use the arrow keys to

enter the local time and toggle between AM and PM. Enter

mark. From the date field on the elevation screen. Use the

arrow keys to input the date. Enter mark. During Initialization

at the Preference screen. Use the arrow keys to toggle

between marine and land. Enter mark. When you have chosen

the primary usage for your receiver, the status screen will be

displayed. At this point, you should go outside in an area

where you can get a clear view of the sky. Your Map 410 will

begin receiving data from the satellites in view and will display

the progress on the status screen. When your receiver has

computed a position fix, the map screen will be displayed. If

the map screen has been turned off then the position screen

will be displayed.

8 Question:

How do I save my position as a waypoint or landmark?

Answer:

From any screen (press and hold) enter mark you will then see

a screen with you latitude/longitude readings and also a

default name LMK00X, press and hold the mark key again to

save.

9 Question:

How do I create a GOTO route to my saved waypoint or

landmark?

Answer:

Press the GOTO key once then use up/down arrow keys to

highlight the user category and press enter mark. Use

up/down arrow keys to highlight the waypoint you just saved.

Enter mark.

10 Question:

How do I select the temp units in my Map 410 GPS?

Answer:

From the Sat Status screen press menu. Use up/down arrow

keys to highlight temp units and press enter mark. Use

up/down arrow keys to select either Fahrenheit or Celsius

11 Question:

How do I set a temperature calibration?

Answer:

From the sat status screen press menu. Use up/down arrow

keys to highlight temp calib and press enter mark. Use the

arrow keys to change the temperature. Enter mark. Use

up/down arrow keys to highlight save edits. Enter mark.

12 Question:

How do I view the secondary coordinate system from the

position screen in my Map 410 GPS?

Answer:

From the position screen, press the left/right arrows and the

lower half of the screen changes to display your present

position in the secondary coordinate system. The datums that

were selected under setup for each coordinate system are also

displayed.

13 Question:

How do I customize the NAV screens in my Map 410 GPS?

Answer:

From the NAV screen press men. Use up/down arrow keys to

highlight customize and press the enter Mark key. Use

up/down arrow keys to highlight the field you wish to change

and press enter. A pop-up menu appears> Use up/down arrow

keys to highlight your choice. Enter mark> You are returned to

the NAV1 screen in the customize mode> You can continue

customizing using the same steps or press quit to exit this

mode.

14 Question:

How do I customize the compass screen in my Map 410 GPS?

Answer:

From the compass screen. Press menu. Use up/down arrow

keys to highlight customize and press the enter mark key. Use

up/down arrow keys to highlight the field you wish to change.

Enter mark. A pop-up menu appears. Use up/down arrow keys

to highlight your choice and press the enter mark key. Then

You are returned to the compass screen in the customize

mod> You can continue customizing using the same steps or

press quit to exit this mode.

15 Question:

How do I enter the map setup screen in my Map 410 GPS?

Answer:

From the map screen press menu. Use up/down arrow keys to

highlight map setup. Press the enter mark key to exit map

setup. Press the quit key.

16 Question:

What are all the options available in map screen orientation?

Answer:

The map screen has three types of orientation to choose from:

North up, course up and track up. North up has north located

at the top of the screen; Course up has the destination of the

current leg at the top of the screen; track up has the direction

you are moving at the top of the screen.

17 Question:

How do I change the map screen orientation in my Map 410

GPS?

Answer:

From the map screen press menu. Use up/down arrow keys to

highlight map setup and press enter on the enter mark key.

Use up/down arrow keys to highlight the orientation setting.

Enter mark. Use up/down arrow keys to highlight your choice

and press enter mark.

18 Question:

How do I turn on/off the latitude/longitude grid in my Map 410

GPS?

Answer:

From the map screen press menu. Use up/down arrow keys to

highlight map setup. Enter mark. Use up/down arrow keys to

highlight latitude/longitude grid. Enter mark. Use up/down

arrow keys to highlight on or off. Enter mark.

19 Question:

How do I enable/disable uploaded map data in my Map 410

GPS?

Answer:

From the map screen press menu. Use up/down arrow keys to

highlight map setup press the enter mark key. Use up/down

arrow keys to highlight the uploaded data. Press the enter

mark key. Use up/down arrow keys to highlight on or off. Enter

mark. A confirmation/ warning screen appears Use up/down

arrow keys to highlight yes or no. Enter mark.

20 Question:

What is hide/show data and what does it do?

Answer:

This function allows you to hide or show the data window on

the map screen. When the data window is displayed the option

on the menu will be hide data and when the data window is

hidden the option will be show data.

21 Question:

How do I enable hide/show data in my Map 410 GPS?

Answer:

From the map screen press menu. Use up/down arrow keys to

highlight hide data or show data and press enter mark.

22 Question:

What is track history?

Answer:

The track history function allows you to select the track

history interval or turn it off. Using track history records where

you have been by automatically storing locations, as

“dropping bread crumbs”, from your starting point as you

travel. This is useful when you want to return to your starting

point. The default setting is auto which, depending on your

speed and bearing, automatically leaves “bread crumbs”

displaying your track. The auto setting makes use of the

SmartTrack feature which stops leaving “bread crumbs” when

your speed is zero, leaves a lot of “bread crumbs” when you

are making a turn and leaves fewer “bread crumbs” when you

are traveling in a straight line. This keeps your track looking

more like the actual path you traveled instead of jagged lines.

Your track history will be displayed on the map using a black

dotted line.

23 Question:

How do I change the track interval settings in my Map 410

GPS?

Answer:

From the map screen press menu. Use up/down arrow keys to

highlight track hist and press the enter mark key. Use up/down

arrow keys to highlight your choice and press enter mark.

24 Question:

How do I clear my track history in Map 410 GPS?

Answer:

From the map screen press menu. Use up/down arrow keys to

highlight clr track and press the enter mark key. A

confirmation screen appears. Use up/down arrow keys to

highlight yes and press enter mark.

25 Question:

How do I pan map in my Map 410 GPS?

Answer:

While in the map screen you can use the 8-way arrow keys to

pan around the screen. This allows you to scan the map to see

what your surroundings are or where a specific waypoint is

located in relation to your current position. While panning, the

cursor will be displayed as an icon representing crosshairs.

Pressing the quit key will center the map screen on your

present position and hide the crosshairs.

26 Question:

How do I reset the odometer in my Map 410 GPS?

Answer:

From the speed screen, press menu. Use up/down arrow keys

to highlight odom reset and press enter mark .A pop-up

confirmation window appears Use up/down arrow keys to

highlight yes or no and press enter mark.

27 Question:

How do I reset the trip odometer in my Map 410 GPS?

Answer:

From the speed screen press menu. Use up/down arrow keys

to highlight trip reset and press enter mark. Use up/down

arrow keys to highlight yes or no enter mark.

28 Question:

How do I set the speed average in my Map 410 GPS?

Answer:

From the speed screen press menu. Use up/down arrow keys

to highlight speed avg press mark. A pop-up window appears.

Use up/down arrow keys to highlight trip, 5 seconds, 30

seconds, 1 minute, 5 minutes or 1 hour. Enter mark.

29 Question:

What information can I view on the time screen of my Map 410

GPS?

Answer:

The time screen displays the current time, estimated time

enrooted (ETE), time of arrival, and elapsed time in regards to

the route in which you are navigating.

30 Question:

How do I select the time format in my Map 410 GPS?

Answer:

From any screen press menu. Use up/down arrow keys to

highlight setup. Enter mark. Use up/down arrow keys to

highlight time format. Enter mark. Use up/down arrow keys to

highlight your choice. Enter mark.

31 Question:

What are user waypoints?

Answer:

User waypoints are locations that you save in your receiver’s

memory, including their coordinates and an icon you

associate with them. You can edit these waypoints and they

can be deleted when you no longer need them.

32 Question:

What are non-user waypoints?

Answer:

Non-user waypoints are uploaded into your receiver. They

display destinations of interest, including their coordinates

and their name. Non-user waypoints cannot be edited and are

permanently stored in your receiver’s memory.

They cannot be deleted unless written over by waypoints

downloaded from the MapSend™ CD.

33 Question:

How do I save a position fix with a user-created name?

Answer:

Enter mark. (Press and hold). Enter mark. Use arrow keys to

enter the alphanumeric characters of the name you choose.

Enter mark. Use arrow keys to highlight the waypoint icon of

your choice Enter mark. Use up/down arrows to highlight save

wpt. Enter mark.

34 Question:

How do I select a waypoint to edit (user only) in my Map 410

GPS?

Answer:

From any NAV screen press menu. Use up/down arrow keys to

highlight waypoints. Enter mark. Use up/down arrow keys to

highlight the user category. Enter mark. Use up/down arrow

keys to highlight the waypoint you wish to edit. Enter mark.

Press Menu. Use up/down arrow keys to highlight edit wpt.

Enter mark.

35 Question:

How do I project a waypoint or landmark in my Map 410 GPS?

Answer:

From the position screen press menu then select projection

and press enter. Highlight bearing and press enter. Enter the

bearing you want for the waypoint. Press enter on distance and

enter the distance you want the waypoint to be projected

36 Question:

How do I find waypoints or landmarks (User and non-user) in

my Map 410 GPS?

Answer:

From any screen press menu. Use up/down arrow keys to

highlight waypoints or landmarks and press enter. Highlight the

category of the waypoint. Press enter mark. Press menu. Use

up/down arrow keys to highlight find. Press enter. Use up/down

arrow keys to input the characters of the waypoint. Enter mark.

You are brought back to the waypoint menu with the chosen

waypoint highlighted. Enter mark. The information on that

waypoint is displayed.

37 Question:

How do I create a GOTO route in my Map 410 GPS?

Answer:

From your present location Press GOTO. Use up/down ARROW

KEYS to highlight the user category and press enter you wish

to goto press enter use UP and DOWN keys to highlight the

landmark or waypoint you want to goto and press enter

38 Question:

How do I clear a GOTO route?

Answer:

Press GOTO once, then press menu. Use up/ down arrow keys

to select clear GOTO. Press enter.

39 Question:

How do I create a Man Over Board (MOB) route?

Answer:

Press GOTO. Use up/down arrow keys to highlight MOB and

press enter.

40 Question:

What is a Man Over Board (MOB) route?

Answer:

Another type of route is Man Over Board (MOB). The MOB route

is useful when you want to instantly create a route. When you

press enter, your receiver will store the position and set a

GOTO route to it. MOB waypoints are titled MOB001, MOB002,

and so forth. If an MOB route already exists, the receiver will

give you the option of replacing the MOB route.

41 Question:

How do I clear a MOB route in my Map 410 GPS?

Answer:

Press GOTO, then press menu. Use up/down arrow keys to

highlight clear the MOB route, and then press enter.

42 Question:

How do I create a backtrack route?

Answer:

Press menu. Use up/down arrow keys to highlight routes and

press enter. Use up/down arrow keys to highlight backtrack

and press enter mark.

43 Question:

How do I create a multi-leg route in my Map 410 GPS?

Answer:

Press menu. Use up/down arrow keys to highlight routes. Press

enter. The route menu appears. Use up/down arrow keys to

highlight an empty route. Press menu. Use up/down arrow keys

to highlight create. Press enter. A screen will appear with the

first dotted line highlighted. Enter mark. Use up/down arrow

keys to highlight the category in which the waypoint is located.

Press enter mark. A menu of all the waypoints saved from the

selected category is displayed. Use up/down arrow keys to

highlight the first waypoint of your route. Press enter mark

Your receiver will display the waypoint you just selected in the

starting location and the second dotted line will be highlighted

Enter Mark Continue the above process until you have

completed the desired route Use UP/DOWN ARROW KEYS to

highlight SAVE ROUTE Enter Mark OR Press Menu Use

UP/DOWN ARROW KEYS to highlight SAVE ROUTE Enter Mark.

44 Question:

How do I view/edit a route in my Map 410 GPS?

Answer:

From any screen press menu. Use up/down arrow keys to

highlight routes and press enter mark. Use up/down arrow keys

to highlight the route you wish to edit. Press menu. Use

up/down arrow keys to highlight view/edit and press enter

mark.

45 Question:

How do I change a waypoint or landmark in a route?

Answer:

While viewing the route in which you wish to change a

waypoint, use up/down arrow keys to highlight the waypoint

that you want to change and press enter mark. Use up/down

arrow keys to highlight the category in which the waypoint is

located and press enter mark. Use up/down arrow keys to

highlight the waypoint you want to replace. Enter mark.

46 Question:

How do I add a waypoint at the end of a route in my Map 410

GPS?

Answer:

While viewing the route you wish to add a waypoint to the end

of use up/down arrow keys. To highlight the first available

dotted line of the route press enter mark then use up/down

arrow keys to highlight the category the waypoint is located in

and press enter mark. Use up/down arrow keys to highlight the

waypoint you want to add to the end of your route and press

enter mark.

47 Question:

How do I delete a waypoint in a route?

Answer:

While viewing the route you wish to delete a waypoint from use

up/down arrow keys to highlight the waypoint you wish to

delete. Press menu. Use up/down arrow keys to highlight delete

and press enter mark.

48 Question:

How do I save a route in my MAP 410 GPS?

Answer:

While viewing the route you wish to save Use up/down arrow

keys to highlight save route and press enter mark. Or press

menu. Use up/down arrow keys to highlight save route and

press enter mark.

49 Question:

How do I activate a route in my Map410 GPS?

Answer:

Press menu Use up/down arrow keys to highlight routes and

press enter mark. Use up/down arrow keys to highlight the

route you wish to activate. Press menu. Use up/down arrow

keys to highlight activate and press enter mark.

50 Question:

How do I deactivate a route in my Map 410 GPS?

Answer:

Press menu. Use up/down arrow keys to highlight routes and

press enter mark. Use up/down arrow keys to highlight the

route you wish to deactivate. Press menu. Use up/down arrow

keys to highlight deactivate and press enter mark.

50 Question:

How do I reverse a route in Map 410 GPS?

Answer:

Press menu. Use up/down arrow keys to highlight routes.

Enter Mark. Use up/down arrow keys to highlight the route you

wish to reverse. Press menu. Use up/down arrow keys to

highlight reverse. Enter Mark. The screen will display the route

menu and the waypoints in the titles will reverse.

51 Question:

How do I delete a route in my Map 410 GPS?

Answer:

Press menu. Use up/down arrow keys to highlight routes. Enter

mark. Use up/down arrow keys to highlight the route you wish

to delete. Press menu. Use up/down arrow keys to highlight

delete. Enter mark. A confirmation screen appears. Use

up/down arrow keys to highlight yes or no. Enter mark.

52 Question:

How do I adjust the contrast in my Map 410 GPS?

Answer:

From any NAV screen press menu. Use up/down arrow keys to

highlight contrast. Enter mark. Use left/right arrow keys to

adjust the contrast. Enter mark.

Otros manuales para MAP 410

Tabla de contenidos

Otros manuales de GPS de Magellan

Magellan

Magellan eXplorist 500 - Hiking GPS Receiver Manual de usuario

Magellan

Magellan eXplorist TRX7 Manual de usuario

Magellan

Magellan eXplorist 200 - Hiking GPS Receiver Manual de usuario

Magellan

Magellan Magellan GPS 310 Manual de usuario

Magellan

Magellan eXplorist 210 Manual de usuario

Magellan

Magellan RoadMate 1200 - Automotive GPS Receiver Manual de servicio

Magellan

Magellan Magellan RoadMate 1210 1200 Series Manual de usuario

Magellan

Magellan eXplorist 200 - Hiking GPS Receiver Manual de usuario

Magellan

Magellan RoadMate 3045T Manual de usuario

Magellan

Magellan Maestro 4370 - Widescreen Bluetooth Portable GPS... Instrucciones de montaje

Magellan

Magellan RoadMate 2035 Manual de usuario

Magellan

Magellan RoadMate 3000T - Automotive GPS Receiver Manual de usuario

Magellan

Magellan Maestro 3220 - Automotive GPS Receiver Manual de instrucciones

Magellan

Magellan Triton 400 - Hiking GPS Receiver Manual de usuario

Magellan

Magellan Maestro 4700 - Automotive GPS Receiver Manual de usuario

Magellan

Magellan MobileMapper MobileMapper 6 Manual de usuario

Magellan

Magellan eXplorist 310 Manual de usuario

Magellan

Magellan GiS explorist Pro 10 Manual de usuario

Magellan

Magellan eXplorist 510 Manual de usuario

Magellan

Magellan eXplorist 400 - Wilderness Bundle Manual de usuario

Magellan

Magellan Triton 200 - Hiking GPS Receiver Manual de usuario

Magellan

Magellan smartGPS Manual de usuario

Magellan

Magellan Meridian Series Manual de usuario

Magellan

Magellan RoadMate 3000T - Automotive GPS Receiver Manual de usuario

Manuales populares de GPS de otras marcas

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Manual de usuario

Garmin

Garmin SOUNDER 125 Manual de usuario

Garmin

Garmin DEZL 580 Manual de usuario

Jigabot

Jigabot EX Manual de usuario

Pointer

Pointer Cellocator CelloTrack XT LTE Guía de instalación

Queclink

Queclink GV55LITE Manual de usuario

Voxson

Voxson Voxtrack GPS500 Manual de instrucciones

Garmin

Garmin ECHOMAP PLUS Manual de usuario

Starcom Systems

Starcom Systems Kylos Compact Manual de usuario

Garmin

Garmin 15 H Series Manual de usuario

Cobra

Cobra Marine MC 600Ci Manual de usuario

Cellocator

Cellocator CelloTrack T Manual de usuario

Enfora

Enfora Mini-MT GSM2228UG001 Manual de usuario

LTE

LTE G50B Manual de usuario

Garmin

Garmin DEZL OTR500 Manual de usuario

SkyGolf

SkyGolf SkyCaddie SG1 Manual de usuario

Garmin

Garmin GPSMAP 78 series Manual de usuario
