Magellan GPS 315 Manual de usuario

GPS 315/320

User Manual

WARNINGS

USE GOOD JUDGEMENT

This product is an excellent navigation aid, but does not replace the need for

careful orienteering and good judgement. Never rely solely on one device for

navigating.

USE CARE

The Global Positioning System (GPS) is operated by the U.S. Government, which is

solely responsible for the accuracy and maintenance of GPS.

The accuracy of position fixes can be affected by the periodic adjustments to GPS

satellites made by the U.S. Government and is subject to change in accordance

with the Department of Defense civil GPS user policy and the Federal

Radionavigation Plan. Accuracy can also be affected by poor satellite geometry.

USE PROPER ACCESSORIES

Use only Magellan cables and antennas; the use of non-Magellan cables and

antennas may severely degrade performance or damage the receiver, and will void

the warranty.

LICENSE AGREEMENT

Magellan grants you, the purchaser, the right to use the software supplied in and

with MAGELLAN GPS products (the "SOFTWARE") in the normal operation of the

equipment. You may make copies only for your own personal use and for use

within your organization.

The SOFTWARE is the property of MAGELLAN and/or its suppliers and is protected

by United States copyright laws and international treaty provisions; therefore, you

must treat this SOFTWARE like any other copyright material.

You may not use, copy, modify, reverse engineer or transfer this SOFTWARE

except as expressly provided in this license. All rights not expressly granted are

reserved by MAGELLAN and/or its suppliers.

* * *

No part of this handbook may be reproduced or transmitted in any form or by any

means, electronic or mechanical, including photocopying and recording, for any

purpose other than the purchaser's personal use without the prior written

permission of Magellan Corporation.

Magellan™, GPS 315™, GPS 320™ and DataSend™ are trademarks of Magellan

Corporation.

630321 C

Table of Contents

Introduction ............................... 1

Conventions Used in this Manual ..............1

GPS 315/320 Receiver ...........................2

Getting Started .......................... 3

Receiver Accuracy...................................3

Installing the Batteries ..............................3

Proper Handling - Signal Reception ...........4

Power On ..............................................4

Initialize .................................................4

Initialize for First Time Use .................4

Selecting Primary Usage ..........................5

Getting a Fixed Position ...........................6

Saving Your Waypoint .............................6

Basic Operation ......................... 7

Entering Information ................................7

Navigation Screens .................................7

Using the Status Screen ............................8

Using the Position Screen .........................9

Viewing the Secondary Coordinate Screen 9

Using the NAV 1 Screen ........................10

Customizing the NAV 1 Screen ...............10

Using the Compass Screen .....................11

Customizing the Compass Screen............11

Using the NAV 2 Screen ........................12

Customizing the NAV 2 Screen ...............12

Using the Plot Screen .............................13

Selecting PAN-N-SCAN .........................14

Setting Track History .............................. 14

Clearing Track History ........................... 14

Setting Up the Plotter ............................. 15

Setting Hide Data/Show Data ................16

Using the Road Screen...........................17

Customizing the Road Screen .................17

Using the Speed Screen .........................18

Resetting the Odometer ..........................18

Resetting the Trip Odometer....................19

Setting the Speed Average .....................19

Using the Time Screen ...........................20

Selecting Time Format ............................ 20

Resetting Elapsed Time........................... 21

Reference ................................ 22

Working with Waypoints........................23

Creating a User Waypoint .....................24

Editing a User Waypoint ........................ 24

Creating/Editing/Deleting a Message in a

User Waypoint .....................................25

Saving Changes to a Selected Waypoint .25

Deleting a User Waypoint ......................25

Finding a Non-UserWaypoint .................26

Sorting a Waypoint ............................... 26

Projecting a Waypoint ...........................26

DataSend™ CD (optional) ......................27

iii

Using DataSend™ ..........................27

Working with Routes ..............................28

Creating/Clearing a GOTO ................... 28

Creating a GOTO on the Plotter Screen ...28

Creating a Man Over Board Route .......... 29

Creating a Backtrack Route ....................29

Creating a Multi-Leg Route ..................... 30

Viewing/Editing a Route .................31

Inserting a Leg ............................... 31

Changing a Waypoint in a Route .....31

Adding a Waypoint at the End of

a Route .........................................32

Deleting a Waypoint in a Route........32

Saving a Route ............................... 32

Activating/Deactivating a Route .......32

Reversing a Route ........................... 33

Using Plot View in a Route ...............33

Deleting a Route .............................33

Working with TrackRoute........................34

Auxiliary Functions .................. 35

Working with Sun/Moon and Fish/Hunt ..35

Selecting the Simulate Mode...................36

Selecting Contrast .................................36

Selecting Alarm/Message ......................37

Accessing the Alarm/Message Menu ...... 37

Selecting Anchor Alarm .........................37

Selecting Arrival Alarm ..........................38

Selecting XTE Alarm ..............................38

Selecting Proximity Alarm .......................39

Selecting GPS Fix Alarm ........................ 40

Viewing the Alarm/MSG Menu ..............40

Selecting Alarm Defaults ........................ 40

Clearing Alarm Defaults .........................40

Customizing ............................. 41

Selecting Setup .....................................41

Selecting Initialize .................................41

Disabling NAV Screens ..........................41

Selecting a Coordinate System ...............42

Selecting Map Datum ............................43

Selecting Elevation Mode ....................... 43

Selecting Time Format ............................ 44

Selecting NAV Units ..............................44

Selecting North Reference ......................44

Selecting Light Timer ..............................45

Selecting the Beeper ..............................45

Selecting Personalize .............................45

Selecting Clear Memory ........................46

Selecting NMEA ................................... 46

Selecting Baud Rate...............................47

Connecting to DGPS..............................48

Troubleshooting ....................... 49

Commonly Asked Questions ................... 50

Contacting Magellan .............................51

Shipping Your Receiver .......................... 51

NMEA Data Messages .............. 52

Available Datums .................... 58

Specifications ........................... 59

Attaching the Wrist Lanyard..... 60

Accessories .............................. 61

Glossary .................................. 62

Index....................................... 66

Magellan GPS 315/GPS 320 1

Introduction

Congratulations on your purchase of the Magellan GPS 315/GPS 320

receiver. Since introducing the world’s first commercial, hand-held GPS

receiver in 1989, Magellan has led the way with innovative GPS

products to meet a wide range of positioning and navigation needs.

The receiver is designed to get you out into the “Great Outdoors”

rather than spending hours reading the user’s manual. In order to get

you outdoors quickly, the manual is designed with key sequences rather

than wordy sentences.

Before you begin, make sure that your package includes the items listed

on the box. If any of these items are missing, please contact your local

Magellan dealer or distributor.

Conventions Used in this Manual

The manual is divided into chapters: Introduction,Getting Started,Basic

Operation,Reference,Customizing,Troubleshooting and Glossary. There

are also subchapters that describe NMEA, Datums and Accessories.

It is very important that you read through the Getting Started chapter

first as it prepares your receiver for use and provides basic instruction.

The Basic Operation chapter describes the features found in your

receiver including step-by-step instructions on their use.

The Reference section contains information to help you navigate using

waypoints, routes and auxiliary functions. Following is the Customizing

chapter, that allows you to establish options you want set in the receiver.

The Troubleshooting chapter gives you a problem and answer series to

guide you. The final chapter, Glossary, defines terms that may be

unfamiliar to you.

The manual is to be used with either the GPS 315 or the GPS 320.

These differ in that the GPS 315 has a database of worldwide cities

consisting of major, large and medium cities. The GPS 320 has a

database of worldwide cities as well as lighthouses, fixed navaids, buoys,

large and medium cities for three different regions of the world (North/

Central/South America, Europe/Africa and Australia/Asia).

2Magellan GPS 315/GPS 320

Quadrifilar antenna

The ENTER

key confirms

data entries or

menu selec-

tions.

The NAV key accesses

the navigation screens.

The QUIT key cancels

the operation of the last

key press and can be

used to back through

the NAV screens.

The MARK key

creates waypoints

and stores the

current position.

The LIGHT key turns

the light on and off.

The GOTO key

creates a direct

route to any

waypoint stored in

memory.

The MENU accesses

waypoint, route and

setup functions.

The PWR key turns the

receiver on and off.

The ARROWs enter

information and scroll

through menus.

GPS 315/320 Receiver

Otros manuales para GPS 315

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de GPS de Magellan

Magellan

Magellan NAV6000 Manual de usuario

Magellan

Magellan MAP330 - MapSend CD For Meridian Manual de usuario

Magellan

Magellan SporTrak SporTrak Color Instrucciones de instalación y funcionamiento

Magellan

Magellan eXplorist GC Manual de usuario

Magellan

Magellan RoadMate 3045T Manual de usuario

Magellan

Magellan MobileMapper 6 Manual de usuario

Magellan

Magellan Meridian Series Manual de instrucciones

Magellan

Magellan GPS ColorTRAK Manual de usuario

Magellan

Magellan Magellan Car GPS Receiver Manual de usuario

Magellan

Magellan eXplorist 200 - Hiking GPS Receiver Manual de usuario

Magellan

Magellan RoadMate 1200 - Automotive GPS Receiver Manual de usuario

Magellan

Magellan smartGPS Manual de usuario

Magellan

Magellan MobileMapper MobileMapper 6 Manual de usuario

Magellan

Magellan eXplorist 500 - Hiking GPS Receiver Manual de usuario

Magellan

Magellan Triton 400 - Hiking GPS Receiver Manual de usuario

Magellan

Magellan Cyclo 500 Series Manual de usuario

Magellan

Magellan Maestro 4220 - Automotive GPS Receiver Manual de usuario

Magellan

Magellan Maestro 4200 - Automotive GPS Receiver Manual de usuario

Magellan

Magellan RoadMate 1200 - Automotive GPS Receiver Manual de instrucciones

Magellan

Magellan Meridian Series Manual de usuario

Magellan

Magellan eXplorist 400 - Wilderness Bundle Manual de usuario

Magellan

Magellan eXplorist 600 Manual rápido

Magellan

Magellan GiS explorist Pro 10 Manual de usuario

Magellan

Magellan RoadMate 6230-LM Manual de usuario

Manuales populares de GPS de otras marcas

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Manual de usuario

Garmin

Garmin SOUNDER 125 Manual de usuario

Garmin

Garmin DEZL 580 Manual de usuario

Jigabot

Jigabot EX Manual de usuario

Pointer

Pointer Cellocator CelloTrack XT LTE Guía de instalación

Queclink

Queclink GV55LITE Manual de usuario

Voxson

Voxson Voxtrack GPS500 Manual de instrucciones

Garmin

Garmin ECHOMAP PLUS Manual de usuario

Starcom Systems

Starcom Systems Kylos Compact Manual de usuario

Garmin

Garmin 15 H Series Manual de usuario

Cobra

Cobra Marine MC 600Ci Manual de usuario

Cellocator

Cellocator CelloTrack T Manual de usuario

Enfora

Enfora Mini-MT GSM2228UG001 Manual de usuario

LTE

LTE G50B Manual de usuario

Garmin

Garmin DEZL OTR500 Manual de usuario

SkyGolf

SkyGolf SkyCaddie SG1 Manual de usuario

Garmin

Garmin GPSMAP 78 series Manual de usuario
