MadgeTech RFPulse2000A Manual de usuario

RFPulse2000A

Wireless Pulse Data Logger

Product User Guide

Distributor: LoggerShop Technologies | Dorset

Tel: +44 (0)845 520 0202 Fax: +44 (0)845 520 0203 | Email: [email protected] | www.loggershop.co.uk

Product User Guide

RFPulse2000A Data Logger

Quick Start Steps ........................................... 1

Product Overview .......................................... 2

Additional Features & Operation .................... 3

Mounting Instructions ................................... 4

Product Maintenance ..................................... 5

General Speciﬁcations.................................. 6-7

RFC1000 Transceiver

Product Overview .......................................... 9

Installation Guide ........................................... 9

Mounting Instruction ................................... 10

Channel Programming ................................. 11

Deployment & Activation .............................. 12

General Speciﬁcations................................... 12

Compliance Information................................ 13

Troubleshooting Tips ............ Back Cover

Table of Contents

Distributor: LoggerShop Technologies | Dorset

Tel: +44 (0)845 520 0202 Fax: +44 (0)845 520 0203 | Email: [email protected] | www.loggershop.co.uk

1. Install the MadgeTech 4 Software and USB Drivers onto a Windows PC.

2. The RFC1000 interface device comes with a USB cable. Plug one end of the cable into

an available USB port on the PC and plug the opposite end of the cable into the

communication port on the RFC1000.

3. Push and hold the wireless button on the RFPulse2000A for 5 seconds to activate

wireless communication. The display will conﬁrm “Wireless: ON” and the blue LED

will blink every 15 seconds.

4. Launch the MadgeTech 4 Software. All active MadgeTech Data Loggers that are within

range will automatically appear in the connected devices window. Each data logger in

the list can be identiﬁed by serial number (printed on the exterior of the logger).

5. To claim a device, select the desired data logger in the list and click the Claim icon.

6. Select the start method, reading rate and any other parameters appropriate for the

desired data logging application. Once conﬁgured, deploy the data logger by clicking

the Start icon.

7. To download data, select the device in the list, click the Stop icon, and then click the

Download icon. A graph will automatically display the data.

Quick Start Steps

1. Install the MadgeTech 4 Software and USB Drivers onto a Windows PC.

2. Before plugging the data logger in the computer, make sure the wireless setting on

the device is set to “Wireless: OFF”. If wireless mode is on, press and hold the Wireless

button on the device for 5 seconds.

3. The RFPulse2000A comes with a USB cable. Plug one end of the cable into an available

USB port on the PC and plug the opposite end of the cable into the communication

port on the RFPulse2000A.

4. Launch the MadgeTech 4 Software. The RFPulse2000A will appear in the connected

devices window indicating the device has been recognized.

5. Select the start method, reading rate and any other parameters appropriate for the

desired data logging application. Once conﬁgured, deploy the data logger by clicking

the Start icon.

6. To download data, select the device in the list, click the Stop icon, and then click the

Download icon. A graph will automatically display the data.

Product Operation (Plugged In)

Product Operation (Wireless)

Distributor: LoggerShop Technologies | Dorset

Tel: +44 (0)845 520 0202 Fax: +44 (0)845 520 0203 | Email: [email protected] | www.loggershop.co.uk

Product User Guide

Product Overview

The RFPulse2000A is a wireless data logger that records pulse output signals from various

sensors such as ﬂow meters and anemometers. When started, the data logger samples at

100Hz and at the user speciﬁed reading rate.

The RFPulse2000A features a display screen which provides instant access to the current

reading, minimum, maximum and average statistics. Through the software the device

can be programmed to convert the pulse output into a different unit of measure such as

gallons per minute or miles per hour. This information is available on the LCD screen of the

data logger as well as in the software.

The RFPulse2000A is unique in that it not only calculates pulse count, but it also calculates

pulse rate. Engineering units can be programmed into the device as a rate, which allows

the device to calculate the measurement unit in rates per second, minute, hour or per

day. This provides more useful statistics to the user when data logging over long periods

of time.

Selection Buttons

The logger is designed with 3 direct selection buttons: Scroll, Units and Wireless.

• Scroll: Allows user to scroll through current readings, average stats and device status

information displayed on the LCD Screen.

•Units: Allows user to change displayed units of measure to pulses per sec/min/hour/day/

total number of pulses.

•Wireless: Push and hold this button for 5 seconds to activate or deactivate wireless

communication.

•Manual Reset Option: Allows user to manually reset the statistics within the device to 0

without needing to use the MadgeTech software. Any data recorded up to that point is

recorded and saved.

LED Indicators

• Status: Green LED blinks every 5 seconds to indicate unit is logging.

• Wireless: Blue LED blinks every 15 seconds to indicate unit is operating in wireless mode.

• Alarm: Red LED blinks every 1 second to indicate an alarm condition.

Connecting Information

Port Information

The RFPulse2000A data logger terminal ports are located on the bottom of the device, one

positive and one negative. RFPulse2000A provides an internal pull up 2.88V@ 250uA.

Note about polarity: If the input signal has an external power supply, (I.E. a 9V Logic) connect

the (+) to the 9V and the (-) to the ground connection. Maximum input Voltage is 30V. If the

internal pull-up is sufﬁcient, connect the (+) to the internal positive and the (-) to the ground. If

a connection to a switch is desired, either port can be used.

Distributor: LoggerShop Technologies | Dorset

Tel: +44 (0)845 520 0202 Fax: +44 (0)845 520 0203 | Email: [email protected] | www.loggershop.co.uk

RFPulse2000A

Additional Features and Operation

Alarm Settings/Rules

In MadgeTech 4, alarms can be created

on two levels; in the software itself, and

programmed speciﬁcally to the data logger.

Creating alarm rules in the software allows

the user to utilize alarms while real time

recording, and have the added beneﬁt of

features such as e-mail and SMS notiﬁcation.

An alarm that is programmed on the data

logger will only alert the user from the

device itself, whether that is by a ﬂashing

LED, audible alarm, or local LCD notiﬁcation.

Creating a Real time Alarm Rule

1. Within the Device tab in MadgeTech 4, in the Alarms group, click Manage Rules,

then select New.

2. Enter a name in the Rule name box, and select whether notiﬁcations will occur when

All conditions are met or Any condition is met.

3. Select the desired conditions to have met before notiﬁcations occur, and select which

notiﬁcations will occur from the drop down menus.

4. If selecting to receive notiﬁcations by email or text message, click Email settings and

make sure the correct info has been entered. Email and text message notiﬁcations will

not be received if settings are incorrect.

5. Click OK. The OK button will be disabled if the Rule name box is empty.

Changing the Alarm Settings of a Device

1. In the Connected devices panel, select the RFPulse2000A device.

2. Click the Properties button under the device tab at the top of the software, and select

the Alarm tab in the Properties window.

3. The High and Low settings indicate reading thresholds at which the alarm becomes active.

4. The Delay setting indicates how long to wait before the alarm becomes active after

passing an alarm threshold.

5. The Use cumulative alarm delay checkbox indicates whether the alarm delay should

reset when reading values fall back within the alarm threshold.

6. Once the alarm is conﬁgured appropriately, click Apply to save the settings.

**Please refer to the Help ﬁle in the MadgeTech software for more information regarding alarm settings**

Distributor: LoggerShop Technologies | Dorset

Tel: +44 (0)845 520 0202 Fax: +44 (0)845 520 0203 | Email: [email protected] | www.loggershop.co.uk

Product User Guide

The base provided with the RFPulse2000A can be used in two ways.

• The bottom of the logger snaps in place to use and mount the unit on a table top or

horizontal surface.

• The base can also securely snap to the backside of the logger for wall mounting if desired

(as shown below).

• There are two holes in the base to allow for screws for mounting.

Mounting Instructions

Still need help? For more troubleshooting tips and information, refer to the built in help

section of the MadgeTech 4 software, visit our Knowledge Base online at

www.madgetech.com/kbase or contact us for customer support at 603-456-2011.

Distributor: LoggerShop Technologies | Dorset

Tel: +44 (0)845 520 0202 Fax: +44 (0)845 520 0203 | Email: [email protected] | www.loggershop.co.uk

RFPulse2000A

Product Maintenance

Battery Replacement

Materials: U9VL-J Battery

1. On the bottom of the enclosure, open the battery compartment by pulling in on the

cover tab.

2. Remove the battery by pulling it from the compartment.

3. Install the new battery, taking note of the polarity.

4. Push the cover closed until it clicks.

Distributor: LoggerShop Technologies | Dorset

Tel: +44 (0)845 520 0202 Fax: +44 (0)845 520 0203 | Email: [email protected] | www.loggershop.co.uk

Product User Guide

Reading Rate 1 reading every second up to 1 reading every 24 hours

Memory 16,128 readings

LED Functionality

• Green LED blinks every 5 seconds to indicate unit is logging

• Blue LED blinks every 15 seconds to indicate unit is in wireless mode

• Red LED blinks every 1 second to indicate alarm condition

Wrap Around Yes

Start Modes Immediate Start & Delay Start

Battery Type Ultralife 9V lithium battery included; user replaceable

Battery Life 5 years typical at 10 minute reading rate

Display Details Displays Pulse/Interval Count & Total Count

Time Accuracy ±1 minute/month

Computer Interface USB to mini USB, 250,000 baud for standalone operation or RFC1000

required for wireless operation

Software XP SP3/Vista/Windows 7/Windows 8 (MadgeTech 4 only)

Operating

Environment -20°C to +60°C (-4°F to +140°F); 0 to 95% RH non-condensing

Dimensions 3.5” x 3.0” x 0.95” (88.9mm x 76.2mm x 24.1mm) - Data logger only

Weight 4.1 oz (0.2563 lbs)

Enclosure Material ABS Plastic

Alarm

User conﬁgurable audible, on-screen, email and text (SMS) alarms.

Alarm Delay: A cumulative alarm delay may be set in which the device

will activate the alarm (via LED) only when the device has recorded a

user speciﬁed time duration of data.

Audible Alarm

Functionality 1 Beep per second for reading alarm above/below threshold

Overload Protection ±30 Volts (V) for 2 seconds

Approval US (FCC), CA (IC), CE, South Korea (KCC)

RFPulse2000A General Speciﬁcations

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may

not cause harmful interference, and (2) this device must accept any interference received, including interference that may

cause undesired operation.

To satisfy FCC RF Exposure requirements for mobile and base station transmission devices, a separation distance of 20 cm

or more should be maintained between the antenna of this device and persons during operation. To ensure compliance,

operation at closer than this distance is not recommended. The antenna(s) used for this transmitter must not be co-located

or operating in conjunction with any other antenna or transmitter.

Distributor: LoggerShop Technologies | Dorset

Tel: +44 (0)845 520 0202 Fax: +44 (0)845 520 0203 | Email: [email protected] | www.loggershop.co.uk

RFPulse2000A

Sensor Type Channel 1: Ambient; Pulse Detection Circuit

Channel 2: Mathematic; Phantom Total Channel

Response Time 10 microseconds

Input Range 0 to 4,294,967,295 Pulses

RF Frequency 2.45GHz IEEE 802.15.4 ultra-low power MadgeNET wireless

transceiver with fully bi-directional communication

Band ISM band 2.405-2.475 GHz

Operation (channels 11 through 25) @ 250 kbps

Maximum Output

Power +0dBm typical

Receiver Sensitivity

(RFC1000) -95dBm typical

Range 2000’ max. outdoors (line of sight unobstructed)

500’ max. indoors (typical urban)

Transmission Distance

(to other RFC1000’s)

• RFC1000

4,000’ max. outdoors - line of sight unobstructed

1,000’ max. indoors - typical urban environment

• RFC1000-CE

2,500’ max. outdoors - line of sight unobstructed

700’ max. indoors - typical urban environment

• RFC1000-IP69K

4,000’ max. outdoors - line of sight unobstructed

1,000’ max. indoors - typical urban environment

Transmission Distance

(to data loggers)

• RFC1000, RFC1000-CE & RFC1000-IP69K

2,000’ max. outdoors - line of sight unobstructed

500’ max. indoors - typical urban environment

Measurement

Wireless

Battery Warning

WARNING: MAY LEAK, FLAME OR EXPLODE IF DISASSEMBLED, SHORTED, CHARGED,

CONNECTED TOGETHER, MIXED WITH USED OR OTHER BATTERIES, AND/OR EXPOSED TO FIRE/

HIGH TEMPERATURE. DISCARD USED BATTERY PROMPTLY, KEEP OUT OF REACH OF CHILDREN.

Speciﬁcations subject to change.

See MadgeTech’s terms and conditions at www.madgetech.com

Distributor: LoggerShop Technologies | Dorset

Tel: +44 (0)845 520 0202 Fax: +44 (0)845 520 0203 | Email: [email protected] | www.loggershop.co.uk

Product User Guide

RFC1000

Wireless Transceiver

Other models available:

RFC1000-CE - Approved for

European markets

RFC1000-IP69K - Splash Proof

for harsh environments

Distributor: LoggerShop Technologies | Dorset

Tel: +44 (0)845 520 0202 Fax: +44 (0)845 520 0203 | Email: [email protected] | www.loggershop.co.uk

Tabla de contenidos

Otros manuales de Registrador de datos de MadgeTech

MadgeTech

MadgeTech RFCO2RHTemp2000A Hoja de especificaciones

MadgeTech

MadgeTech HiTemp140-FP Manual de usuario

MadgeTech

MadgeTech Level1000 Hoja de especificaciones

MadgeTech

MadgeTech TC101A Manual de usuario

MadgeTech

MadgeTech PRTemp1000IS Hoja de especificaciones

MadgeTech

MadgeTech HITEMP140-M12 Hoja de especificaciones

MadgeTech

MadgeTech CurrentX Series Hoja de especificaciones

MadgeTech

MadgeTech Temp1000S Manual de usuario

MadgeTech

MadgeTech RFPRHTemp2000A Hoja de especificaciones

MadgeTech

MadgeTech OctVolt Hoja de especificaciones

MadgeTech

MadgeTech HiTemp140-PT Series Hoja de especificaciones

MadgeTech

MadgeTech Shock101-5 Manual de usuario

MadgeTech

MadgeTech HiTemp140 Series Manual de usuario

MadgeTech

MadgeTech Shock101 Hoja de especificaciones

MadgeTech

MadgeTech RFOT Hoja de especificaciones

MadgeTech

MadgeTech Shock101-EB-5 Manual de usuario

MadgeTech

MadgeTech HiTemp140-FP-TSK Hoja de especificaciones

MadgeTech

MadgeTech RTDTempX Series Hoja de especificaciones

MadgeTech

MadgeTech VFC2000-MT Hoja de especificaciones

MadgeTech

MadgeTech TCTemp2000 Manual de usuario

MadgeTech

MadgeTech HiTemp140-FPST-36 Manual de usuario

MadgeTech

MadgeTech 902152-00 Hoja de especificaciones

MadgeTech

MadgeTech Cryo-Temp Hoja de especificaciones

MadgeTech

MadgeTech PRHTemp2000 Hoja de especificaciones

Manuales populares de Registrador de datos de otras marcas

TESTO

TESTO 176 Manual de usuario

HT Italia

HT Italia XL421 Manual de usuario

HBM

HBM SOMAT XR CX22B-R Manual de usuario

Agtrix

Agtrix 380i Manual de usuario

Hobo

Hobo H8 Pro Manual de usuario

Beijing ART Tech

Beijing ART Tech PCI2320 Manual de usuario

Athena

Athena GET SL1 Manual de usuario

Motec Systems

Motec Systems C185 Manual de usuario

Beijing ART Tech

Beijing ART Tech USB2832 Manual de usuario

Rotronic

Rotronic HygroLog HL20 Manual de usuario

MRC

MRC DW-6092 Manual de usuario

Racelogic

Racelogic VBOX LapTimer Manual de usuario

Edu-Logger

Edu-Logger 900-240 Manual de usuario

Elma

Elma DT173 Manual de usuario

Comet

Comet U0121M Manual de usuario

pico Technology

pico Technology PT-104 Manual de usuario

Soil Instruments

Soil Instruments GTecLink Manual de usuario

APLICOM

APLICOM A11 Manual de usuario
