MacroMedics DSPS Manual de usuario

DSPS ®Double Shell Positioning System

SSPS ®Single Shell Positioning System

MacroMedics BV

Oostbaan 670

2841ML Moordrecht

The Netherlands

+31(0)182 389 777

[email protected]

www.macromedics.com

DSPS

SSPS

MANUAL 112100

Instructions for use

English Instructions

Manual

Instructions for use DSPS & SSPS

02082021V19IFU112100 MacroMedics ®

[ This page is intentionally left blank ]

Manual

Instructions for use DSPS & SSPS

02082021V19IFU112100 MacroMedics ®

Table of Contents

1. Warnings

2. MRI Safety Information

3. Intended Use

4. Positioning Options

5. Cradle Set-Up

6. Mask Set-Up

7. Patient Set-Up

8. Supine Treatment

9. Prone Treatment

10. Using shims

11. Cleaning, Storage and Disposal

12. Warranty

13. Notices

14. Glossary of Symbols

Manual

Instructions for use DSPS & SSPS

02082021V19IFU112100 MacroMedics ®

1. Warnings

• Inspect the device thoroughly before use. Do not use the device if damaged.

• Check individual components on MR-safety when used together in a patient positioning system.

• Do not use MR unsafe items in an MR environment.

• Do not use the thermoplastic mask after its expiry date.

• The thermoplastic masks are for single patient use.

• Ensure that the mask is not too hot for skin contact before placing it on the patient.

• Do not remove the mask from the patient until the material cools completely. Removing the

thermoplastic mask before it has set may result in the mask’s deformation.

• If using more than one shim, do not exceed a thickness of 1.5 mm.

• In the USA, federal law restricts this device to sale by or on the order of a licensed healthcare

practitioner.

2. MRI Safety Information

2.1 MR SAFE:

The following devices are MR safe:

• 111220 SSPS™ Cradle RE MR

• 111530 SSPS™ Cradle S-Type, MR

• 111610 SSPS™ Cradle Type-O, MR

• 111650 SSPS™ Cradle ExaFix™ MR

• 112910 DSPS® Cradle-MEXF H MR

• 112920 DSPS® Cradle-O H MR

• 112930 DSPS® Cradle-S H MR

• 171250 DSPS® Cradle-M H RE MR

Released

Position

Locked

Position

Incorrect

Position

(locked)

Manual

Instructions for use DSPS & SSPS

02082021V19IFU112100 MacroMedics ®

• 112640 DSPS® Shim set

• 113390 DSPS® GLX Shim Set

• 113490 DSPS® SARY Shim Set

• 114500M Mask SSPS™-FN

• 114530M Mask UMCN

• 114550M MMask DSPS®-OS

• 115620M Mask SSPS™-FSO

• 115670M Mask SSPS™-FSOL

• 115560M Mask SSPS™-FL

2.2 MR UNSAFE:

The following devices are MR unsafe:

• 111110 SSPS Cradle Type ITV

• 111120 SSPS™ Cradle RE

• 111520 SSPS™ Cradle S-Type

• 111600 SSPS™ Cradle Type-O

• 111620 SSPS™ Cradle ExaFix™

• 111630 SSPS™ Cradle U

• 112710 DSPS® Cradle-MEXF H

• 112720 DSPS® Cradle-O H

3. Intended Use

Positioning of the patient during radiotherapy and radio diagnostics, including MR where indicated.

• 115510M Mask SSPS™-F

• 115520M Mask SSPS™-FS

• 115570M Mask SSPS™-FSL

• 115720M Mask SSPS™-FSS

• 115770M Mask SSPS™-FSSL

• 115810M Mask SSPS™-FVR

• 115820M Mask SSPS™-FSVRS

• 115860M Mask SSPS™-FVRL

• 115870M Mask SSPS™-FSVRSL

• 112730 DSPS® Cradle-S H

• 112740 DSPS® Cradle-VRT H

• 112750 DSPS® Cradle-B H

• 112760 DSPS® Cradle-I H

• 112770 DSPS® Cradle-U H

• 112780 DSPS® Cradle-V H

• 112790 DSPS® Cradle-QA H

• 171210 DSPS® Cradle-MEXF H RE

Manual

Instructions for use DSPS & SSPS

02082021V19IFU112100 MacroMedics ®

4. Positioning Options

• Double Shell Positioning System (DSPS) uses two thermoplastic masks and a cradle to support the

patient’s head.

• Single Shell Positioning System (SSPS) uses a head support, a cradle, and one thermoplastic

mask to support the patient’s head.

The following tables provide details on the treatment positioning options possible with each mask and

cradle type.

Cradle Positioning Options

DSPS Cradle

111110 SSPS Cradle Type ITV

112710 DSPS® Cradle-MEXF H

112720 DSPS® Cradle-O H

112730 DSPS® Cradle-S H

112740 DSPS® Cradle-VRT H

112750 DSPS® Cradle-B H

112760 DSPS® Cradle-I H

112770 DSPS® Cradle-U H

Supine and Prone DSPS

Cradle Positioning Options

SSPS Cradle

111120 SSPS™ Cradle RE

111220 SSPS™ Cradle RE MR

111520 SSPS™ Cradle S-Type

111530 SSPS™ Cradle S-Type, MR

111600 SSPS™ Cradle Type-O

Supine and Prone DSPS and SSPS

112780 DSPS® Cradle-V H

112790 DSPS® Cradle-QA H

112910 DSPS® Cradle-MEXF H MR

112920 DSPS® Cradle-O H MR

112930 DSPS® Cradle-S H MR

171210 DSPS® Cradle-MEXF H RE

171250 DSPS® Cradle-M H RE MR

111610 SSPS™ Cradle Type-O, MR

111620 SSPS™ Cradle ExaFix™

111650 SSPS™ Cradle ExaFix™ MR

111630 SSPS™ Cradle U

Manual

Instructions for use DSPS & SSPS

02082021V19IFU112100 MacroMedics ®

Mask Options for Supine

Treatment

Mask options for Prone

treatment

114550M Mask DSPS®-OS

115510M Mask SSPS™-F

115520M Mask SSPS™-FS

115560M Mask SSPS™-FL

115570M Mask SSPS™-FSL

115620M Mask SSPS™-FSO

115670M Mask SSPS™-FSOL

114500M Mask SSPS™-FN

114550M Mask DSPS®-OS 114530M Mask UMCN

Note: MacroMedics offers thermoplastic masks with special cut-outs for patients with long hair and for

treatments using surface guided radiotherapy systems.

DSPS

ONLY DSPS and SSPS

115720M Mask SSPS™-FSS

115770M Mask SSPS™-FSSL

115810M Mask SSPS™-FVR

115820M Mask SSPS™-FSVRS

115860M Mask SSPS™-FVRL

115870M Mask SSPS™-FSVRSL

Manual

Instructions for use DSPS & SSPS

02082021V19IFU112100 MacroMedics ®

5. Cradle Set-Up

For optimum set-up stability, MacroMedics recommends using a baseplate which is secured to the

couchtop.

5.1 CRADLES WITH PLUNGERS AND QUICKFASTENERS

I. Ensure that the Plungers or Quickfasteners are in the released position.

II. Align and slot the cradle onto the baseplate.

III. Lock the cradle in place by pressing down on the plungers or quickfasteners.

IV. After use, the cradle can be detached by pulling on the plungers or quickfasteners and

returning them to the released position.

Cradle Plunger Cradle Quickfastener

in Released Position in Released Position

Manual

Instructions for use DSPS & SSPS

02082021V19IFU112100 MacroMedics ®

5.2 TYPE - O CRADLES

I. Ensure that the locking knobs are in the released position.

II. Align and slot the cradle onto the baseplate.

III. Lock the cradle in place by rotating the locking knobs 90 degrees so the knobs are pointing outwards.

IV. After use, the cradle can be detached by returning the locking knobs to the released position.

5.3 TYPE - B CRADLES

I. Attach the two pivots to the baseplate by screwing them into place. Align and slot the cradle

onto the baseplate.

Manual

Instructions for use DSPS & SSPS

02082021V19IFU112100 MacroMedics ®

II. Secure the cradle in place by tightening the white knobs at both side of the cradle.

Ensure that the locking knobs (circled) are in the released position to be able to place the

reference box over the cradle.

Reference Box

III. When using the reference cradle, place the reference box over the cradle, as shown below.

Secure it in place by rotating the locking knobs 90 degrees so the knob is pointing towards

the cranial end of the board.

IV. After use, the cradle and reference box can be detached by returning the locking knob to

the released position and loosening the white knobs.
