INSTRUCTION MANUAL

l-awp1015_inst_issue1

Model L-AWP1015

AIR / WATER RETRACTABLE HOSE REEL

INSTRUCTION MANUAL

lubemate by macnaught / instruction manual

CAUTION

GENERAL SAFETY

AIR / WATER RETRACTABLE HOSE REEL

DESCRIPTION

Thank you for purchasing a Lubemate hose reel. Each reel is a quality UV Stabilised reel, supplied

complete with a delivery hose, feeder hose and mounting bracket.

1. The hose reel is UV stabilised.

2. The reel is easy to use positive latch and a built in hose layering mechanism to prevent hose bunching.

3. Durable construction, made from high quality impact resistant polypropylene, light in weight and more

compact.

4. A powerful spring winds the hose back into the drum. 

FEATURES AND BENIFITS

* To prevent injury or damage do not let go of the hose during rewinding.

* Hold the hose stop ball when retracting hose.

* Do not disassemble hose reel.

* Ensure the reel or hose is not in contact with any sharp objects or exposed to high temperatures.

* Do not drop this reel or damage will occur.

* Do Not use this product with any chemicals or liquid other than water.

* Turn off air/water supply after use or at the end of the day.

Please read these operating instructions carefully and note the information given. Use these operating

instructions to familiarize yourself with the product, the proper use and the safety

instructions.

Installation:

1. Take out the unit and accessories from the box，

2. Choose a suitable place near source of air/water.

3. Take the mounting bracket as a template to mark the position for screws and drill four holes on the

wall( Fig.2)

4. Fix the bracket by four self-taping screws accordingly, (Fig.1)

Fig.1 Fig.2

1Hose reel 1

2Mounting bracket 1

3Self-tapping bolts 4

INSTRUCTION MANUAL

macnaught.com

AIR / WATER RETRACTABLE HOSE REEL

5.Connect the reel to the mounting bracket.

Operation

1.Connect feeder hose and turn on supply

2. Pull out hose to desired length and stop.

Retract hose

1. Always hold hose when rectracting back into reel

2. Turn off the air/water supply.

Storage

Cleaning

This Reel is maintenance-free and must not be cleaned internally with water.

Maintenance

When not in use, turn off supply, and release the line pressure

The reel must not be used to transmit any chemical and substance

When not in use for an extended period of time it is recommended to be stored in a cool dry place.

Fig.3

Note:

1. The reel should be installed horizontally

to a wall or post.

2. It is recommended to mount the reel

approximately 1 meter above the ground.

Item Description Material nooff

29 Synchronousbelt PU 1

28 RightCover PP 1

27 Leadhose Hybrid 1

26 SmallSpring SpringSteel 1

25 Inlet Brass 1

24 RightCasing PP 1

23 ToothWheel PA 1

22 Slowreturnmechanism PA6+GF30 1

21 O‐Ring NBR 2

20 Outlet Aluminium 1

19 LockSystem PA 1

18 FixPiece PP 1

17 Sleeve ABS 1

16 InnerHexagonScrew Q235 1

15 Drum PP+GF30 1

14 MountingBracket PP+GF30 1

13 Spring SpringSteel 1

12 MountingPin PA66+GF30 1

11 LockPlate PP+GF30 1

10 Hoseguidesystem PA+POM 1

9HoseStop PP 1

8Pre‐loadingCap PA6+GF30 1

7 OutputHose Hybrid 1

6 Handle PP 1

5Pre‐loadingWheel PA66+GF30 1

4 GuidePole StainlessSteel 1

3LockPiece POM 1

2LeftCasing PP 1

1LeftCover PP 1

Note: no spare parts available

EXPLODED DIAGRAM

INSTRUCTION MANUAL

lubemate by macnaught / instruction manual

AIR / WATER RETRACTABLE HOSE REEL

Fig.4

Forwarrantytermsandcondionsreferto

www.macnaught.com.au

SPECIFICATIONS - L-AWP1015

Maximum Pressure 300psi/20bar

Maximum Temperature + 55 deg C

Hose type Hybrid Polymer

Hose Size and Length 3/8" (10mm) x 15m (50ft)

Inlet / Outlet 1/4" BSPT (M)

Dimensions 42.5 x 20.4 x 39.5cm

Weight 5.5kg

TROUBLESHOOTING

FAULT DESCRIPTIONSOLUTION

Thehosedoesnot

retract

Hosehasbeenpulledouttoo

farandlocked

Accessthedrumthroughthewindowandcarefullyrotate

thedrumhalfaturninthedirectionofthehosebeing

pulledouttoreleaselatch.

Notenoughspringtension

Add 1-2 turns extra turns:

1. Remove the small cover,

2. Use spanner to clamp the groove of preload wheel,

3. Unscrew four bolts on the wheel, then rotate it for 1-2

turns in counterclockwise, then fasten the bolts, and

replace the cover.Fig.4
