MachineryGuide SM1 Manual de usuario
User Manual
MachineryGuide GPS Guidance System
Read the whole manual before using the product
and keep it for later reference UK ENG
1
Table of Contents
Parts of the guidance system 4
GPS/GLONASS antenna 5
Bluetooth GNSS Receiver 6
Antenna Cable 7
DC-USB Cable 8
Tablet Mount 8
Software Installation 9
Installation steps 9
Software Updates 10
First Steps 11
Options menu 12
Units, Gauges to display and Overlap option menu 12
Session handling, Localization source and Display menu 13
Size and alignment menu 15
Guidance mode menu 16
Language settings 17
Font size settings 17
Starting a new job session (with Bluetooth-receiver) 18
Error messages and notifications when using the Bluetooth-antenna 20
Alarm notification in Main menu 21
2
Starting a new job session (with built-in GPS-module) 22
Loading previously saved sessions and continue former job 24
Managing former paths 26
Layout of the Navigation screen 27
Function buttons 28
Starting navigation (with A-B straight guidance mode) 30
Starting navigation (AB with surrounding guidance mode) 32
Starting navigation (AB curve guidance mode) 35
Starting navigation (AB round curve guidance mode) 36
3
Parts of the guidance system
Part name
Options
1
GPS/GLONASS antenna
SM1 or DM1 antenna
2
Bluetooth GNSS receiver
SM1 or DM1 receiver
3
Antenna cable
Only for DM1
4
DC-USB cable
Car charger, 3-points charger
and 2-wire charger
5
Tablet mount
-
6
Android device
-
7
MachineryGuide Android application
-
4
GPS/GLONASS antenna
The antenna has to be mounted to the highest part of the agricultural machinery, and
must not be obscured in order to achieve the best accuracy. There are two antenna
options available for the MachineryGuide application:
SM1 antenna
Specifications:
● Frequency: 1575MHz ~
1615MHz
● VSWR: 1.3 @ 1580MHz
● Bandwidth: 43MHz
● Polarization: RHCP
● Antenna gain: 27dB
● Size: 37.5mm x 34.5mm x
12.5mm
● Connection: SMA
● RF cable: RG174, 2.5m
● Magnetic bottom
DM1 antenna
The DM1 antenna has high gain (40 dB)
and multipath error rejection.
Specifications:
●Frequency: 1574 MHz +/- 10
MHz
●Bandwidth: 31 MHz (1dB)
●Polarization: RHCP
●Antenna gain: 40 dB
●Size: 66.5 mm x 66.5 mm x
49.8 mm
●Connector: TNC
●Manufacturer: Tallysman
5
DM1 Antenna Console
The DM1 antenna can be installed with a
magnetic console. The antenna goes to
the top of the holder.
The consol with the antenna should be
installed to the top of the agricultural
machine. It is very important to place it
on the highest part of the vehicle, and to
ensure that it is not covered, because
this is indispensable to achieve the
correct pass-to-pass accuracy.
CM1 antenna
The DM1 antenna has high gain (40 dB)
and multipath error rejection.
Specifications:
●Frequency: 1574 MHz ~ 1606
MHz
●Bandwidth: 31 MHz (1dB)
●Polarization: RHCP
●Antenna gain: 40 dB
●Size:152 mm x 152 mm x 94
mm
●Connector: TNC
●Manufacturer: Harxon
Bluetooth GNSS Receiver
The receiver unit gets the 12 V supply via DC cable. The communication with the
tablet is done via Bluetooth interface. The external GPS antenna can be connected to
the receiver via an SMA-connector. The data connection is in the form of serial NMEA
messages.Two GNSS Receiver options available for the MachineryGuide application:
6
SM1 Bluetooth GNSS Receiver
Specifications:
●GPS-, GLONASS-, SBAS-,
QZSS-signals
●10 Hz update rate
●Absolute accuracy: 2.5 m CEP
●Absolute accuracy with SBAS
correction: 2.0 m
●Absolute accuracy with SBAS +
PPP correction: < 1 m
●Pass-to-pass accuracy with
SBAS+PPP correction:10-20 cm
●Speed accuracy: 0.1m/s
●Hot start TTFF open sky: 29 mp
●Col start TTFF open sky:30 mp
●Sensitivity: -161 dBm
●Bluetooth device name:
MachineryGuide BT-REC-V2.3
DM1
When the Receiver is turned on, after two-three minutes of initialization time
(depends on the satellite coverage) the Receiver starts to provide submeter
level pass-to-pass accurate position data.
DM1 Bluetooth GNSS Receiver
Specifications:
●Uses GPS, GLONASS, SBAS,
QZSS signals
●10 Hz update rate
●Absolute position accuracy 2.5
m CEP
●Relative (pass-to-pass)
accuracy: 30-40 cm
●Velocity accuracy 0.1m/sec
●Warm start TTFF under open
sky 29 sec average
●Cold start TTFF under open sky
30 sec average
●Tracking sensitivity -165 dBm
●Bluetooth device name:
MG BT-REC-V2.3
When the Receiver is turned on, after ten minutes of initialization time
(depends on the satellite coverage) the Receiver starts to provide decimeter
level pass-to-pass accurate position data.
7
CM1 Bluetooth GNSS Receiver
Specifications:
●Uses GPS, GLONASS, SBAS,
QZSS signals
●10 Hz update rate
●Absolute position accuracy 1
cm CEP
●Relative (pass-to-pass)
accuracy: 2 cm
●Velocity accuracy 0.1m/sec
●Warm start TTFF under open
sky 29 sec average
●Cold start TTFF under open sky
30 sec average
●Tracking sensitivity -165 dBm
●Bluetooth version: 2.0
●Bluetooth device name:
● MG BT-REC-V2.3
When the Receiver is turned on, after ten minutes of initialization time
(depends on the satellite coverage) the Receiver starts to provide
centimeter level pass-to-pass accurate position data.
Antenna Cable
DM1 and CM1 antennas could be
connected to the Bluetooth GNSS
Receiver via an RF cable.
● Length: 2.5 m
8
DC-USB Cable
The DC-to-USB cable provides power to the Bluetooth GNSS Receiver. There are
three types of cables available for the Receiver:
A DC-to-USB cable with DC plug only on
one end for the Bluetooth GNSS
Receiver.
Specifications:
● Length: 2 m
● Plug type: 2.1 mm DC plug
A DC-to-USB cable with a DC plug for
the Bluetooth GNSS Receiver and a
standard car charger plug.
Specifications:
● Length: 2 m
● Plug type: 2.1 mm DC plug
A DC-to-USB cable with a DC plug for
the Bluetooth GNSS Receiver and a
3-point charger plug.
Specifications:
● Length: 2 m
● Plug type: 2.1 mm DC plug
Tablet Mount
Tube mount for tablet with display size
7”.
● Easy to install
● Stable mount
● Flexible at two spherical joint
9
