M-system 73VR3100 Guía del usuario

– 1 –

73VR3100 PAPERLESS RECORDER

STARTUP GUIDE

– Read Before Installation –

Contents

1. POINTS OF CAUTION ...................................................................... 2

2. PACKAGE INCLUDES....................................................................... 5

3. ITEMS TO PREPARE........................................................................ 6

4. COMPONENT IDENTIFICATION ........................................................... 7

5. EXTERNAL DIMENSIONS.................................................................. 9

6. INSTALLING THE UNIT.................................................................... 10

7. WIRING TO THE UNIT..................................................................... 12

8. SETTING UP THE RECORDER............................................................ 13

9. LET’S START RECORDING ............................................................... 20

10. MORE ABOUT THE 73VR3100 ........................................................... 23

EM-7397-A Rev.9

– 2 –

1. POINTS OF CAUTION

Thank you for choosing M-System. Before use, please read this manual carefully. If

you have any problems or questions with the product, please contact M-System’s Sales

Office or representatives.

This product is for use in general industrial environments, therefore may not be suitable

for applications which require higher level of safety (e.g. safety or accident prevention

systems) or of reliability (e.g. vehicle control or combustion control systems).

For safety, installation and maintenance of this product must be conducted by qualied

personnel.

nPOWER INPUT

•Power input rating & operational range: Check the power rating for the unit on the

specication label.

 Rating100–240VAC: 85–264V,47–66Hz,

     approx.27VAat100V,approx.46VAat240V

 Rating24VDC: 24V±10%,approx.24W

•Supplyinganylevelofpowerotherthanspeciedabovecandamagethe73VR3100or

the power source.

•ThepowercablesandthesignalI/Ocablesforthe73VR3100mustbelocatedsepa-

rately.

•Themaincircuitcables(highvoltageandhighcurrent),thesignalI/Ocables,andthe

power cables should not be bundled together or placed near each other.

•Toincreasenoiseresistanceofthepowerinputwires,twistthestrandsbeforeconnect-

ing.

nSAFETY PRECAUTION

•Beforeyouremovetheunit,turnoffthepowersupplyandinputsignalforsafety.

•Donotusethe73VR3100inanenvironmentwhereammablegasesarepresent.This

may result in an explosion.

•Donotdisassembleormodifythe73VR3100inanyway.Doingsomayresultinare

or an electrical shock.

•Donotstrikethepanelofthe73VR3100withahard,heavyorpointedobject,orpress

thepanelwithexcessiveforce.Doingsomayresultinpaneldamageorinjury.

•Donotblockthe73VR3100’sventilationopeningsoruseitinareaswhereheataccu-

mulates. Additionally, do not store or use it under high-temperature conditions.

•Donotstoreorusethe73VR3100inlocationssubjecttodirectsunlight,orwhereex-

cessive dust or dirt is present.

•The73VR3100isaprecisioninstrument.Donotstoreoruseitwherelargeshocksor

excessive vibration can occur.

– 3 –

•Do not store or use the 73VR3100 in environments subject to chemical evaporation

(suchasthatoforganicsolvents),orwheretherearechemicalsand/oracidspresentin

the air.

•Donotusepaintthinnerororganicsolventstocleanthe73VR3100.

•Observetheenvironmentalconditionswhenusingthe73VR3100.

•Waitatleastfor5secondsbeforeturningonthepowersupplyafterithasbeenturned

off.The73VR3100maynotstartupifthetimeintervalislessthan5seconds.

nENVIRONMENT

•Indooruse

•The73VR3100isdesignedtobemountedonaverticalpanel.Itisnotsuitablefora

slantedorahorizontalpanelsurface.

•Environmentaltemperaturemustbewithin0to50°C(32to122°F)withrelativehumidity

within30to85%RHinordertoensureadequatelifespanandoperation.

•Desktoptypecannotbemountedonapanelsurface.

•Thehandleandrubberfeetcannotbedetachedfromdesktoptypeunit.

nGROUNDING

•Besuretodetermineinadvancethemoststablegroundingpointintheenvironment

andearththe73VR3100’sFGterminalandthatofconnecteddevices(PC)toitinor-

der to prevent electric shock to the operator and to protect the devices from dielectric

breakdown.

•Groundingisalsoeffectivetoeliminatenoisethatcouldcauseerrorsinthe73VR3100’s

operation.

nCF CARD

•Donotturnoffthepowersupplytothe73VR3100orresetitduringrecording.TheCF

Cardmaybedestroyed.

•ObservethedescribedprocedurewhenyouneedtoreplacetheCFCardduringre-

cording.

•ConrmthesidesandtheconnectorpositionoftheCFCardwheninsertingonetothe

card slot.

– 4 –

nLCD PANEL

•TheLCDpanel’sliquidcontainsanirritant.Ifthepanelisdamagedandtheliquidcon-

tactsyourskin,rinseimmediatelythecontactareawithrunningwaterforatleast15

minutes. If the liquid gets in your eyes, rinse immediately your eyes with running water

foratleast15minutesandconsultadoctor.

•ThefollowingphenomenaareLCDcharacteristics,andNOTaproductdefect:

-LCDscreenmayshowunevenbrightnessdependingupondisplayedimagesorcon-

trast settings.

-TheLCDscreenpixelsmaycontainminuteblack-and-white-coloredspots.

-ThecolordisplayedontheLCDscreenmayappeardifferentwhenseenfromoutside

the specied viewing angle.

-Whenthesameimageisdisplayedonthescreenforalongtimeperiod,anafterim-

age may appear when the image is changed. If this happens, turn off the 73VR3100

and wait 10 seconds before restarting it.

•Topreventanafterimage:

- Set the screensaver when you plan to display the same image for a long time pe-

riod.

-Plantochangethescreenimageperiodicallysothatthesameimagedoesnotremain

for the long time period.

nBACKLIGHT

•Evenwhenthebacklightisfailed,thescreendisplaycanbecontrolledbytouchingit.

•Backlightfailureisconrmedbythefollowingphenomena:

- The screen gets dark even when no screensaver setting is enabled.

- If the screensaver is activated, the screen display does not recover when the screen

is touched.

•ThebacklightcanbereplacedinM-Systemfactory.TheLCDmustbereplacedatthe

sametime.PleaseconsultM-System.

nI/O MODULES

•Pleaserefertorespectivemodules’instructionmanualsfordetailedinformationabout

them.

nAND ....

•WerecommenduseofanUPStosupplypowerbackups.

–5–

2. PACKAGE INCLUDES...

Pleaseconrmthatallitemsmentionedbelowareincludedinthepackage.

Paperless Recorder I/O module (R3-x) instruction manual

Mounting bracket (two pieces)

Software CD (73VRPAC2)

Startup guide (this booklet)

STARTUP GUIDE

Notincludedfordesktoptype.

–6–

3. ITEMS TO PREPARE

•CFcard

 Prepareoneofthefollowingmodelnumbers:

  1.Manufacturer:HagiwaraSolutions

  ModelNo.:MCF10P-xxxxS(Alternativemodel:CFI-xxxxDG)

  Capacity:128MBthrough1GB

  2.Manufacturer:ApacerTechnology

  Modelname:CFCIII

ModelNo.: AP-CFxxxxE3ER-ETNDNRKPartsNo.:256MB ...81.2A010.1H34C

           512MB ...81.2B010.1H34C

           1GB ...81.2E010.1H34C

 ModelNo.: AP-CFxxxxE3ER-ETNDNRPartsNo.: 256MB ...81.2A010.1H10C

           512MB ...81.2B010.1H10C

           1GB ...81.2E010.1H10C

  Capacity:  256MBthrough1GB

•CFcardreader

 TheCFcardreaderisrequiredtoreadthecardcontentsintoaPC.

•RefertoUsersManualsstoredinthe73VRPAC2CD-Rfordetailedoperationsofthe

73VR3100.

 (1)PaperlessRecorder(model:73VR3100)UsersManual .................No.EM-7397-B

 (2)PCConguratorSoftware(model:73VR31BLD)UsersManual.... No.EM-7397-C

– 7 –

4. COMPONENT IDENTIFICATION

 FRONT VIEW

(1) Touch Panel Screen

Trend chart and other data views and setup views are displayed.

(2) Front Cover

Access to the CF Card Slot.

(3) CF Card Slot

(4) Eject Button

Used to retrieve the CF Card.

(5) Reset Button

Used to restart the 73VR3100.

(6) CF Card Access Indicator LED

Red light turns on during the CF Card is accessed.

(7) USB Connector

Connect an USB flash-memory.

(2) Front Cover

(7) USB Connector

(3) CF Card Slot

(4) Eject Button

(1) Touch Panel Screen

(6) CF Card Access Indicator LED

(5) Reset Button

–8–

REAR VIEW

(8) PC Configurator Port

Used to program with the R3 Configurator Software.

(9) LAN Port

Connects the LAN cable (10BASE-T or 100BASE-TX)

(

) I/O Data Allocation DIP Switch

Assigns the required data area for each I/O module.

Four (4) modes (1, 4, 8 and 16) are selectable depending upon the number of I/Os.

(

) Power LED

Light turns on while the power is supplied.

(

) Power input terminal block

• Without I/O Modules• With I/O Modules

(8) PC Configurator Port

(9) LAN Port

(7) USB Connector

(

) I/O Data Allocation

DIP SW

(

) Power LED

(

) Power Input Terminal Block

• I/O Module Assignment

I/O Module 1

I/O Module 2

I/O Module 3

I/O Module 4

– 9 –

5. EXTERNAL DIMENSIONS

Unit:mm(inch)

245.1 (9.65)

136.5 (5.37)

2 – 26 (.08 –1.02)

(panel thickness)

Attach the mounting bracket either on the top/bottom or on the sides.

135.5 (5.33)

29.5

(1.16)

144 (5.67)

151.5 (5.96)

144 (5.67)

151.5 (5.96)

· Panel mount type

– 10 –

245.1 (9.65)

136.5 (5.37)

135.5 (5.33)

29.5

(1.16)

144 (5.67)

173 (6.81)

(.16)

· Desktop type

(.98)

The handle and rubber feet cannot be detached from desktop type unit.
