IAD SERIES USERS MANUAL
1
LVswitch IAD Series Users Manual
Guangdong Shanglu Information Technology company
All rights reserved
www.lvswitches.inc
IAD SERIES USERS MANUAL
2
Catalogue
1.Product Introduction ................................................................................................................................................. 5
1.1 Product Overview .......................................................................................................................................... 5
1.2 Functions and features...................................................................................................................................5
1.3 Product Seris .................................................................................................................................................. 6
1.4 LVswitch-4S ........................................................................................................................................6
1.5 LVswitch-8S .............................................................................................................................................7
1.5 Product specifications: ................................................................................................................................. 11
1.5.1 Hardware specifications: ...................................................................................................................11
1.5.2 Software specifications ............................................................................................................................. 12
2.Preparation before installation ................................................................................................................................ 14
2.1 Safety precautions ........................................................................................................................................ 14
2.2 Basic connection configuration ....................................................................................................................15
2.2.1 System application environment .......................................................................................................15
2.2.2 First time use and basic connection and configuration ..................................................................... 16
2.2.3 1 Set up wire connection .............................................................................................................16
2.2.4 2 Turn on the power .................................................................................................................... 17
2.2.5 3 Check the electricity .................................................................................................................17
2.3 Preparation configuration ..........................................................................................................................17
2.3.1 Preparation before configuration ...................................................................................................... 17
2.3.2 Operation button description of the Web setting page ...................................................................... 21
3.Device Summary .....................................................................................................................................................21
3.1 System status ................................................................................................................................................22
3.1.1 Device ............................................................................................................................................... 22
3.1.2 Interface Status ..................................................................................................................................22
3.2 Info Statistics ................................................................................................................................................23
3.2.1 DHCP client ...................................................................................................................................... 23
3.2.3 ON LINE USERS ............................................................................................................................. 24
4.Network configuration ............................................................................................................................................ 25
4.1 Basic Setup...................................................................................................................................................25
4.1.1 Uplink mode setup ............................................................................................................................ 26
4.1.2 LAN SETUP ..................................................................................................................................... 26
4.1.3 WAN setting...................................................................................................................................... 26
4.1.4 DHCP Configuration .........................................................................................................................36
4.2 Advanced options .........................................................................................................................................37
4.2.1 DDNS Settings .................................................................................................................................. 37
4.2.2 Static Route ....................................................................................................................................... 38
4.2.3 Dynamic Route .............................................................................................................................. 39
4.2.4 NAT setting.................................................................................................................................... 40
4.2.5 Port Mapping ................................................................................................................................. 41
4.2.6 Host name setting ..............................................................................................................................42
4.2.7 ALG setting ....................................................................................................................................... 43
IAD SERIES USERS MANUAL
3
4.2.8 Network U disk ................................................................................................................................. 43
Figure 4-21 Network USB configuration ...................................................................................................................44
4.2.9 Local subinterface ............................................................................................................................. 45
Figure 4-22 Network USB configuration ...................................................................................................................45
4.2.10 IGMP PROXY ................................................................................................................................ 45
5.Voice Configuration ................................................................................................................................................ 46
5.1 Operate mode setting................................................................................................................................... 46
5.2 SIP USER SET .............................................................................................................................................46
5.3 SIP server set ................................................................................................................................................49
5.4 H248 parameter setting ................................................................................................................................ 50
5.5 Configuration sample ................................................................................................................................... 53
5.6 Codec setting ................................................................................................................................................54
5.7 IAD GLOBAL SET..................................................................................................................................... 55
5.8 Digitmap .......................................................................................................................................................59
5.9 Suppservice .................................................................................................................................................. 60
6.Network security ..................................................................................................................................................... 62
6.1Basic setting .................................................................................................................................................. 63
6.2 ACL access control...................................................................................................................................... 63
6.3 ARP DEFENSE ............................................................................................................................................65
6.3.1 The IP/MAC binding........................................................................................................................ 65
6.3.2 ARP Defense ..................................................................................................................................... 66
6.4 DDOS defense ..............................................................................................................................................67
7.System management ............................................................................................................................................... 68
7.1 Basic setting ................................................................................................................................................. 68
7.3 Backup and restore configurations...............................................................................................................69
7.4 Upgrade ........................................................................................................................................................70
7.5 SNMP SETTING ......................................................................................................................................... 71
7.6 TR069 Configuration ................................................................................................................................... 73
7.7 Reboot .......................................................................................................................................................... 75
7.8 Restore Factory Default ............................................................................................................................... 76
7.9 System Debug .............................................................................................................................................. 76
7.10 Time Settings ............................................................................................................................................. 77
7.11 Log Manage ............................................................................................................................................... 78
8.Account Management ............................................................................................................................................. 81
8.1 Object Management ..................................................................................................................................... 81
9.Product problem analysis ........................................................................................................................................ 82
IAD SERIES USERS MANUAL
4
Dear Customer:
IAD series gateway is a powerful and excellent terminal product specially
customized by ShangLu information technology ltd for customers,which provides you
with a flexible, safe and complete enterprise network solution.It is simple to configure,
easy to operate, flexible to use, safe and reliable,you can also get the technical support
from Shanglu. In order to understand and use this product more effectively, we
provide you with a user manual for this product. Please read it carefully.
This user manual contains:
1. Safety precautions
2. Main Product Functions
3. Panel and specification
4. First use and basic connection configuration
5. Configuration preparation
6. Quick setting
7. Network configuration
8. System Management
9. Log Management
10. Quick fault location
IAD SERIES USERS MANUAL
5
1.Product Introduction
1.1 Product Overview
LVswitch IAD product is a high-performance, multi-purpose voice access gateway designed by Shanglu
information technology limited for small and medium-sized enterprises.The products support voice, security, VPN
and other functions, to meet the needs of operators or virtual operators, enterprises through IP access to provide
users with broadband, voice and fax services.The product can be used be IPPBX equipment to set up cross
-regional IP voice exchange network to provide high effient voice communication.
The LVswitch IAD product includes a variety of interface types for connecting analog phones, fax machines, PCS,
and broadband networks. The product adopts standard SIP protocol, conforms to TISPAN/IMS standard, is
perfectly compatible with IPPBX, SIP server and operator IMS/NGN soft switch platform, and provides flexible
and diverse access methods, which is suitable for large-scale deployment of operator projects and enterprise fusion
communication. Shanglu information technology company has accumulated many years of practical experience
and abundant technology in SIP protocol, voice processing and embedded system design, and its VOIP voice
gateway has been adopted by operators and many enterprises all over the world.
1.2 Functions and features
Connect analog telephone, fax machine and POS machine to IMS core network
Cooperate with IMS business platform to support various telephone supplementary services;
Support SIP protocol based on 3GPP and its call control
Support H. 248 protocol voice
Support FXS interface, physical interface type RJ11;
Support static IP address configuration or dynamic IP address acquisition through DHCP and
PPPoE;
Support G. 711A, G. 711U, G. 729, G. 723.1, G. 722 speech codec;
Support local WEB, remote OMC near end and remote maintenance management mode;
Support ACL access control, ARP attack prevention, DDoS
Support VPN functionsc such as IPsec,PPTP,L2TP etc.
Support extensible wifi wireless.
Support for extensible GPON、EPON Uplink.
Compatible with Huawei/ZTE IMS, VOS, FreeSWITCH and Asterisk/Elastix business
platforms.
IAD SERIES USERS MANUAL
6
1.3 Product Seris
LVswitch IAD series product includes the following 4 kinds :
LVswitch IAD Series
Description
LVswitch-4S
4FXS Voice gateway
LVswitch-8S
8FXS Voice gateway
LVswitch-16S
16FXS Voice gateway
LVswitch-32S
32FXS Voice gateway
1.4 LVswitch-4S
LVswitch-4Ssupports 4 fxs interface ,the front panel is as below:
LVswitch-4SBack Panel is as following:
NO.
Instructions
1
Reset button
2
Power System indicator
3
VPN、NMS,USB indicator
4
4 Ethernet indicators
IAD SERIES USERS MANUAL
7
1.5 LVswitch-8S
LVswitch-8S support 8 fxs telephone interface,the front panel as following:
NO.
Instrutions
1
AC input
2
Power button
3
USB2.0 interface
4
10/100/1000MEthernet
interface :1WAN+3LAN，RJ45
5
Console，RJ45
6
4FXS analog interface ，RJ11
7
Ground column
IAD SERIES USERS MANUAL
8
LVswitch-8S Back panel is as below ：
NO.
Instrutions
①
AC input
②
Power button
③
USB2.0 interface
4
10/100/1000MEthernet
interface :1WAN+3LAN，RJ45
5
Console，RJ45
6
8 FXS analog interface ，RJ11
7
Ground column
NO.
Instrutions
1
Reset indicator
2
PWR,SYS indicators
3
VPN,NMS,USB indicators
4
Ethernet indicators
5
8 FXS light indicators
IAD SERIES USERS MANUAL
9
LV switch-16S panel is as below:
NO.
Instrutions
1
RESET BUTTON
2
Power and System indicator
3
VPN、network management ,USB
indicator
4
4 Ethernet indicators
NO.
Instrutions
1
AC input
2
Power button
3
USB2.0 interface
4
10/100/1000MEthernet
interface :1WAN+3LAN，RJ45
IAD SERIES USERS MANUAL
10
LVswitch-32S
LVswitch-32Ssupports 32 voice interface，The front panel as belows:
LVswitch-32S Back panel is as below ：
5
Console，RJ45
6
16 FXS analog interface ，RJ11
7
Ground column
NO.
Instrutions
1
RESET BUTTON
2
Power and System indicator
3
VPN、network management ,USB indicator
4
Ethernet indicator
