SEQUENCERS FOR LEDS
CCT DIMMER CONTROLLER FOR 6 ZONES
Ref: 41.018 Controller
Features
• Compact size with simple and easy-to-use interface.
• Accurate and smooth colour temperature and brightness adjustment for
warm white and cold white.
• 256 level brightness adjustments for each white to archive millions of colour
temperatures.
• Smooth dimming without any flickering from 0.1% to 100% enables the
dimmer controller to archive millions colours.
• Control 6 different zones separately or synchronously with endless receivers
in each zone.
• Save kelvins / scenes for each zone.
• Control distance around 20-30m.
• To work with power repeater to expand output unlimitedly.
Compatible with controller:
• 41.019
Voltage (V) 3V (1 units of CR2025
not included)
Frequency 868/915/434MHz
Control 6 zones
Signal distance 20 - 30m
Waterproofing IP20
Working temperature 0°C / 40°C
Measurements 136.3x38.9x10.7mm
Packaging 1 unit
Guarantee 2 years
