Lux Products PSDS11b Manual de usuario

Thank you for your confidence in our product. To obtain the best results from your investment, please read these

instructions and acquaint yourself with your purchase. Follow the installation procedures carefully, and save these

instructions for future reference. This will save you time and minimize the chance of damaging either the thermostat or

the systems that it controls.

This thermostat can be used with most single-stage 24 volt: gas, oil or electric heating and cooling systems, single-stage

heat pumps, or gas Millivolt heating systems.

It cannot be used with: 3-wire zone valves, 120/240 volt heating elements, or multi-stage heat pumps. Ask your dealer

for other UXPRO thermostats to control those systems.

WA NING: Use Energizer®or DU ACELL®Alkaline Batteries Only.

Energizer®is a registered trademark of Eveready Battery Company, Inc.

DURACE ®is a registered trademark of The Procter & Gamble Company

UX Products Corporation - Mt. aurel, New Jersey 08054 - http://www.luxproproducts.com

SYSTEM COMPATIBILITY:

• 1-Stage Heat / 1-Stage Cool

• Electronic Accuracy

• Innovative SAVE Feature

• Gas / Elec Fan Option

• Battery Powered Only

• Set Temperature Range 45°F (7°C) degrees to 90°F

(32°C) degrees

• Clean, Attractive Design

• ux ight®Illuminated Display Screen

• Easy to Install

• arge, Easy to Read Display

• F/C Selectable Temperature Display

• Adjustable Temperature Differential / Cycle Rate

• User Temperature Display Calibration

• 5/2 Minute Selectable Minimum Run/Off Time

• On-Screen ow Battery Indicator

• 3-Year Warranty

• No eveling Required

THE MOSTAT FEATU ES:

I N S TA L L AT I O N A N D

O P E R AT I N G I N S T R U C T I O N S

PSDS11b Lighted

Non-Programmable Thermostat

52157

Screwdrivers, wire stripper / cutter, and possibly a drill with assorted bits (new installations only).

1. Turn OFF the electricity to all heating and cooling components. Do not turn the electricity back on

until all work is completed.

2. Remove the front portion of your old thermostat to expose the wiring connections.

3. Write down the letters printed near each wire terminal that is used, and also the color of each wire

that is connected to it. Self-adhesive wire labels are also enclosed.

4. Carefully remove the wires one at a time, and bend them in a manner so that they do not fall back

inside the wall. Do not allow bare wire ends to touch each other.

5. oosen the mounting screws for the old thermostat and carefully remove it from the wall.

On replacement installations, mount the new thermostat in place of the old one unless the conditions listed below

suggest otherwise. On new installations, please follow these general guidelines:

1. Mount the thermostat on an inside wall, about 5 ft. (1.5m) above the floor.

2. Do not locate the thermostat where air circulation is poor such as in a corner, alcove, or behind a door that is normally

left open.

3. Do not locate the thermostat where unusual heating or cooling conditions may be present, such as: direct sunlight,

above a lamp, television, or radiator, or on a wall next to an exterior door or window.

4. Do not locate in a damp environment, as this can lead to corrosion that may shorten thermostat life.

5. If painting or construction work is still ongoing, cover the thermostat completely or wait until this work is complete

before installation.

1. Strip wire insulation leaving only 3/8 in. (9.5mm) bare wire ends, and clean off any corrosion present.

2. Fill the wall opening with non-combustible insulation to prevent drafts from affecting the thermostat’s normal

operation.

3. Route the wires through the opening in the new thermostat base plate, and hold the base against the wall. Try to line

up the screw holes from the prior thermostat, and install the mounting screws.

4. If the previous holes cannot be used, hold the thermostat base against the wall so that it appears straight and level

(position the base for best appearance) and mark for the new screw holes. Attach the base to the wall using the

screws provided (use the supplied plastic anchors if needed when mounting to a soft material such as drywall).

OFF

EMOVAL OF OLD THE MOSTAT:

THE MOSTAT MOUNTING LOCATION:

INSTALLATION OF NEW THE MOSTAT:

TOOLS YOU MAY NEED:

1. When attaching the wires to the thermostat, please ensure that the bare wire ends are held A the way into the

terminal block while the screw is being tightened.

2. Securely tighten all of the electrical terminal screws, including any unused ones. Be careful not to over tighten the

screws, they only need to be snug.

** Complete heating and/or cooling system wiring can be found in the WI E IDENTIFICATION AND WI ING

SCHEMATICS section of this instruction sheet. The schematics shown provide component information for brand

new installations or for unreferenced wires.

On the circuit board, there are hardware settings called “jumpers”. These settings can be changed from their default

values by removing its black cap and reinstalling the cap so that it is positioned

on only one (1) of the metal pins, and not both. A C OSED jumper means the

black cap is on both of the metal pins, and an OPEN jumper means the cap is on

only one (1) metal pin.

HA DWA E ESET BUTTON: A change to ANY of the jumper settings will not be

recognized by the thermostat until the white HARDWARE RESET button on the

circuit board is pressed.

JP1 (SYSTEM): [C OSED = Furnace, default] This setting is used for the majority of all heating

systems that are not heat pumps. Examples for this setting would be: natural gas furnace, hot

water baseboard heat, and oil heat. [OPEN = Heat Pump] Use this setting if you have a heat

pump unit (which looks just like an outside air conditioning unit, but is used for both cooing and

heating).

JP2 (DELAY): [C OSED = 5 Minutes, default] This setting changes the length of time that the

system must remain either on or off before it will switch to the alternate on or off state. The

main purpose of this setting is to provide equipment protection by preventing brief or undesirable

frequent on/off cycling. [OPEN = 2 Minutes] This can be used to decrease the minimum amount

of time that occurs between cycles, and may be desired for hot water radiator systems to reduce

overshoot.

JP3 (SCALE): [C OSED = Fahrenheit, default] All temperature values are displayed in F˚ degrees.

[OPEN = Celsius] This setting displays all temperature values in C˚ degrees.

JP4 (FAN): This option is located separately from the first three settings shown above.

[C OSED = Gas, default] This setting lets the heating system itself control the blower fan

automatically. Types of systems that would typically use the “Gas” fan setting would be: natural

gas furnace, propane furnace, and oil furnace.

[OPEN = Elec] This setting runs the system’s blower fan when heat is called for, and is required

for systems that do not control their own fan while in HEAT mode. Heat pump systems, and units

with an electric heating element typically require this setting.

Furnace

5 MIN

OPEN

2 MIN

JP1

JP2

JP3

WI ING TE MINAL CONNECTIONS:

SYSTEM CONFIGU ATION AND SETUP OPTIONS:

O P E N

C L O S E D

E L E C T

G A S

HEAT / OFF / COOL, SYSTEM MODE SWITCH: Set this switch to HEAT to control your heating system, and COO to control

your cooling system. The OFF position will disable both the heating and cooling units.

AUTO / ON, FAN SWITCH: When this switch is in AUTO, the blower fan (if present in your system) will automatically cycle

on and off by itself when heating or cooling is running. When in the ON position, the blower fan will run constantly with

or without a demand for heating or cooling, even in OFF mode.

UP AND DOWN BUTTONS: While in HEAT or COO mode, you can use the UP and DOWN buttons to raise or lower the set

temperature. When the thermostat is powered up for the first time, it will use the default set temperatures of 68°F

(20°C) for Heat mode and 72°F (22°C) for Cool mode. NOTE: when you adjust the temperature using UP and DOWN

buttons, the change occurs immediately and you do not have to press the SAVE button to accept the changes.

SAVE BUTTON: Reducing the amount of heating and cooling energy you use will directly save you money. The SAVE

feature allows you to use just one button press to easily decrease the current set temperature by 5F (3°C) degrees while

in Heat mode (or raise the set temperature by 5°F (3°C) degrees while in Cool mode). When you leave the house, simply

press the SAVE button one time to put the thermostat into Save mode, and the word “SAVE” will be shown on the screen.

When you return home, press the SAVE button again to cancel the Save mode and return back to the previous set

temperature that you were using originally.

After Save mode has been started, you can adjust the energy-saving set temperature by using the UP and DOWN buttons

in either direction. Just like above, one more press on the SAVE button will cancel the Save mode and return back to the

original set temperature that was used prior to starting Save mode.

LCD DISPLAY BACKLIGHT: The display screen has a light that will assist viewing at nighttime, or in low lighting areas.

When any front panel button is pressed, the screen will light up for approximately 10 seconds. Any button presses that

occur while the backlight is on, will reset the 10 second timer, causing the screen to remain illuminated for an additional

10 seconds.

STATIC NOTICE: This thermostat is protected against normal minor static electric discharges, however to minimize the

risk of damaging the unit in extremely dry weather, please touch a grounded metal object before touching your

thermostat.

OPE ATING INST UCTIONS:

TEMPE ATU E SWING: The amount of temperature variation between load-on and load-off is changed by adjusting the

swing setting. The default value for this thermostat is #4, and the adjustment range is from #1 to #9. A smaller swing

number makes the temperature control more precise and constant, and increases the number of cycles per hour. A larger

swing number will produce a greater variation between load-on and load-off events, and decreases the number of cycles

per hour.

To adjust the Swing setting: Set the thermostat to OFF mode using the System Mode switch, and hold down the SAVE

button for at least 5 seconds. When the screen changes to a single digit, this is the current Swing setting value and it

can be adjusted using the UP or DOWN buttons. The thermostat will return back to the normal Run mode screen if no

buttons are pressed for 4 seconds.

TEMPE ATU E CALIB ATION: This thermostat is accurately calibrated at the factory, and in most cases alteration to this

setting should not be required. The Calibration feature allows you to manually offset the room temperature measurement

by as much as plus or minus 5°F (3°C) degrees from its original value. 0°F (0°C) is the default setting.

To adjust the Calibration setting: Set the thermostat to OFF mode using the System Mode switch, press both the UP and

DOWN together for at least 2 seconds. When the screen changes to a single digit, this is the current Calibration setting

value and it can be adjusted using the UP or DOWN buttons. The thermostat will return back to the normal Run mode

screen if no buttons are pressed for 4 seconds.

This thermostat is powered by two “AA” Alkaline batteries. The batteries should be replaced AT EAST once per year (or

sooner, if the “ OW BAT” battery symbol appears in the display screen). When the O BAT symbol is shown, the

temperature digits will also display the word “ o”. The batteries are located on the back of the circuit board, and can be

accessed by pulling the front portion of the thermostat straight outwards and removing it from the wall. When installing

new batteries, we recommend using only brand new Energizer®or DURACE ®, “AA” size alkaline batteries. Please

observe the polarity markings shown in the battery compartment to ensure proper installation. When finished, line up the

front of the thermostat to the base, and firmly press together.

ADVANCED FEATU ES:

BATTE Y EPLACEMENT:

If you have any problems installing or using this thermostat, please carefully and thoroughly review the instruction

manual. If you require assistance, please contact our Technical Assistance department at 856-234-8803 during regular

business hours between 8:00AM and 4:30PM Eastern Standard Time, Monday through Friday. You can also receive

technical assistance online anytime day or night at http://www.luxproproducts.com. Our web site offers you answers to

the most common technical questions, and also permits you to email your questions to our technical support staff at your

convenience.

If this unit fails because of defects in materials or workmanship within three years of the date of original purchase, UX

will, at its option, repair or replace it. This warranty does not cover damage by accident, misuse, or failure to follow

installation instructions. Implied warranties are limited in duration to three years from the date of original purchase.

Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

Please return malfunctioning or defective units to the location from which the purchase was made, along with proof of

purchase. Please refer to “TECHNICA ASSISTANCE” before returning thermostat. Purchaser assumes all risks and

liability for incidental and consequential damage resulting from installation and use of this unit. Some states do not

allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you. This warranty

gives you specific legal rights and you may also have other rights, which vary from state to state. Applicable in the

U.S.A. and Canada only.

Mercury is considered to be a hazardous material. If this product is replacing a thermostat that contains mercury in a

sealed tube, contact your local waste management authority for instructions regarding recycling and proper disposal. It

may be unlawful in your state to place it in the trash.

TECHNICAL SUPPO T:

LIMITED WA ANTY:

ME CU Y WA NING AND ECYCLING NOTICE:

GYO BWRH RC

1-STAGE, COOLING ONLY

Factory RH-RC Jumper Wire Installed

FAN

24V

POWER

COMMON

AIR

CONDITIONER

3, 4 WIRES

BLACK TERMINAL LETTERS ARE TYPICAL, GRAY TERMINAL LETTERS ARE BRAND SPECIFIC

WI ING DIAG AM NOTES:

1. The BOLD lines are what you should be connecting to the terminals on this new thermostat.

2. The DASHED lines are optional depending upon your system type.

3. In many cases, the thin lines shown as “SYSTEM COMMON” will not be visible at the thermostat

location, they are located with your heating and cooling equipment.

4. For Heat Pumps, use the “B” or “O” wire, NOT BOTH. Typically neither are used in a conventional

system.

5. If “Y” and “C” wires are both present, then “C” is a common wire.

6. If you have a “B” wire in your system which is used as a common wire, connecting it to the “B”

terminal on this thermostat may damage your system and/or the thermostat.

GYO BWRH RC

HEATING ONLY (INCLUDING MILLIVOLT)

(2-WIRE HEAT USE “RH” & “W”)

Factory RH-RC Jumper Wire Installed

FAN

24V

POWER

COMMON

HEATER

2, 3, 4 WIRES

BLACK TERMINAL LETTERS ARE TYPICAL, GRAY TERMINAL LETTERS ARE BRAND SPECIFIC

FAN WIRE

MAY NOT BE

PRESENT IN

ALL SYSTEMS

GYO BWRH RC

CONVENTIONAL (NON HEAT PUMP)

1-STAGE HEATING AND 1-STAGE COOLING

Factory RH-RC Jumper Wire Installed

FAN

24V

POWER

COMMON

HEATER

AIR

CONDITIONER

4, 5 WIRES

BLACK TERMINAL LETTERS ARE TYPICAL, GRAY TERMINAL LETTERS ARE BRAND SPECIFIC

GYO BWRH RC

1-STAGE HEATING AND 1-STAGE COOLING

WITH TWO SEPARATE 24V TRANSFORMERS

Factory RH-RC Jumper Wire REMOVED

FAN

COMMON

HEATER

AIR

CONDITIONER

5, 6 WIRES

BLACK TERMINAL LETTERS ARE TYPICAL, GRAY TERMINAL LETTERS ARE BRAND SPECIFIC

24V HEAT

POWER

24V COOL

POWER

FAN

** Use “O” or “B”

Terminals, Never Both

GYO BWRH RC

SINGLE-STAGE HEAT PUMP SYSTEM

WITH NO AUX OR EMERGENCY HEAT

Factory RH-RC Jumper Wire

24V

POWER

COMMON

4, 5 WIRES

BLACK TERMINAL LETTERS ARE TYPICAL, GRAY TERMINAL LETTERS ARE BRAND SPECIFIC

HEAT

PUMP

REVERSING

VALVE

ADD Y-W Jumper Wire

Tabla de contenidos

Otros manuales de Termostato de Lux Products

Lux Products

Lux Products PSP711TS Series Manual de usuario

Lux Products

Lux Products LuxPro P521U Manual de usuario

Lux Products

Lux Products PSD111 SERIES Manual de usuario

Lux Products

Lux Products PSP211 Series Manual de usuario

Lux Products

Lux Products PUREPRO DP732T Manual de usuario

Lux Products

Lux Products Luxpro PSP611 Manual de usuario

Lux Products

Lux Products SERIES DMH110 Manual de usuario

Lux Products

Lux Products Smart Temp TX9000a Series Manual de usuario

Lux Products

Lux Products LUXPRO EcoStat PSM011 Manual de usuario

Lux Products

Lux Products SMART TEMP TX500Ua Manual de usuario

Lux Products

Lux Products T20-1141SA Manual de usuario

Lux Products

Lux Products PSP511LCa Manual de usuario

Lux Products

Lux Products TradePro TP-LH121 Manual de usuario

Lux Products

Lux Products PurePro DP722Uc Manual de usuario

Lux Products

Lux Products LV1 Manual de usuario

Lux Products

Lux Products CAG111 Series Manual de usuario

Lux Products

Lux Products PSD011Ba Manual de usuario

Lux Products

Lux Products SMART TEMP TX9000 SERIES Manual de usuario

Lux Products

Lux Products LuxPro PSD011Wa Manual de usuario

Lux Products

Lux Products TX1500E Manual de usuario

Lux Products

Lux Products Smart Temp TX9100U Manual de usuario

Lux Products

Lux Products TX1500E Manual de usuario

Lux Products

Lux Products P711 Manual de usuario

Lux Products

Lux Products LP0511D Manual de usuario

Manuales populares de Termostato de otras marcas

EWELLY

EWELLY EW-181 Manual de usuario

Prolon

Prolon T1100 Instrucciones de instalación

Computherm

Computherm Q20 Manual de usuario

Heatmiser

Heatmiser neoStat Manual de usuario

Aube Technologies

Aube Technologies TH111GFCI-NP 240 VCA Manual de usuario

Mars

Mars HEAT CONTROLLER IR Wireless Thermostat Manual de usuario

Saswell

Saswell SAS920XWHB-7-S-RF Guía

Aircalo

Aircalo TFP1-ET85P2 Manual de usuario

Honeywell

Honeywell CM721 Manual de usuario

Carrier

Carrier DEBONAIR 33CS Manual de usuario

Lennox

Lennox iHarmony Zone Thermostat Instrucciones de montaje

Gemtech

Gemtech GT7000 Manual de instrucciones

Rollei

Rollei Smartes 45000 Manual de usuario

Sinope

Sinope TH1300RF Manual de usuario

Honeywell

Honeywell RLV4305 Manual de usuario

Honeywell

Honeywell Prestige 2.0 THX9421 Manual de usuario

NuTone

NuTone NTBZ48 Instrucciones de funcionamiento originales

Stelpro

Stelpro MAESTRO ASMT402AD Manual de usuario
