Lutron Electronics CD-4317SD Manual de usuario

SD card real time data logger

TDS ( Total dissolved solids ), Salt

CONDUCTIVITY METER

Model : CD-4317SD

Your purchase of this

CONDUCTIVITY METE

with SD CARD

DATA LOGGER marks a

step forward for you

into the field of

precision measurement.

Althou

h this meter a

complex and delicate

instrument, its durable

structure will allow

many years of use if

proper operatin

techniques are

developed. Please read

the followin

instructions carefully

and always keep this

manual within easy

reach.

OPERATION MANUAL

TABLE OF CONTENTS

1. FEATURES................................................................ 1

2. SPECIFICATIONS......................................................

2-1 General Specifications.......................................... 2

2-2 Electrical Specifications........................................

3. FRONT PANEL DESCRIPTION.....................................6

4. MODE SELECTION.....................................................8

5. CONDUCTIVITY/TDS MEASURING and

CALIBRATION PROCEDURE....................................... 8

5-1 Conductivity measurement...................................

5-2 TDS ( PPM ) measurement................................... 10

5-3 Calibration...........................................................11

6. SALT MEASURING and calibration PROCEDURE...........13

6-1 Salt measurement................................................13

6-2 Calibration...........................................................14

7. OTHER FUNCTION....................................................

7-1 Data Hold............................................................14

7-2 Record ( Max./ Min. reading )...............................14

7-3 LCD Backlight ON/OFF.........................................

8. DATALOGGER...........................................................15

8-1 Preparation before execute datalo

er function..................15

8-2 Auto Datalo

er ( Set samplin

time 1 second )............≧16

8-3 Manual Datalo

er ( Set samplin

time = 0 second ).........17

8-4 Check time information....................................................

8-5 Check samplin

time information.......................................18

8-6 SD Card Data structure.....................................................18

9. Saving data from the SD card to the computer............20

10. ADVANCED SETTING...............................................22

11. POWER SUPPLY from DC ADAPTER..........................

12. BATTERY REPLACEMENT.........................................

13. SYSTEM RESET.......................................................

14. RS232 PC SERIAL INTERFACE..................................29

15. OPTIONAL ACCESSORIES........................................

16. PATENT..................................................................32

1. FEATURES

* One meter for multi purpose operation :

Conductivity, TDS ( Total dissolved solids ),

Salt measurement.

* Pt glass electrode, high performance for the low

conductivity ( pure water ) measurement.

* Conductivity : 200 uS/2 mS/20 mS/200 mS.

* Salt : 0 to 12 % salt ( % weight ).

* Conductivity measurement can select Temp. Coefficient

of measurement solution.

* ATC for the conductivity measurement.

* Separate probe, easy for operation of different

measurement environment.

* Real time SD memory card Datalogger, built-in Clock

and Calendar, sampling time can set from 1 sec to 8

hour 59 min. 59 sec.

* Manual datalogger is available, during execute the

manual datalogger function, it can set the different

location no. ( position 1 to position 99 ).

* Innovation and easy operation, computer is not need to

setup extra software, after execute datalogger, just take

away the SD card from the meter and plug in the SD card

into the computer, it can down load the all the measured

value with the time information ( year/month/date/

hour/minute/second ) to the Excel directly, thenuser can

make the further data or graphic analysis by themselves.

* SD card capacity : 1 GB to 16 GB.

* LCD with green light backlight, easy reading.

* Data hold, record max. and min. reading.

* Power by UM3/AA ( 1.5 V ) x 6 batteries or DC 9V adapter.

* RS232/USB PC COMPUTER interface.

* Wide applications: water conditioning, aquariums,

beverage, fish hatcheries, food processing, photography,

laboratory, paper industry, plating industry, quality

control, school & college, water conditioning.

2. SPECIFICATIONS

2-1 General Specifications

Circuit Custom one-chip of microprocessor LSI

circuit.

Display LCD size : 52 mm x 38 mm

LCD with green backlight ( ON/OFF ).

Measurement * Conductivity ( uS, mS )

Function * TDS ( Total Dissolved Solids, PPM )

* Salt ( % Weight )

* Temperature ( , )℃℉

Temperature Automatic from 0 to 60 (32 - 140 ),℃℉

Compensation with temperature compensation factor

variable between 0 to 5.0% per C.

Conductivity Pt glass electrode, high performance for

Probe the low conductivity ( pure water )

measurement.

Datalogger Auto 1 sec to 8 hour 59 min. 59 sec.

Sampling Time

@ Sampling time can set to 1 second,

Setting range

but memory data may loss.

Manual Push the data logger button

once will save data one time.

@ Set the sampling time to

0 second.

@ Manual mode, can also select the

1 to 99 position ( Location ) no.

Memory Card SD memory card. 1 GB to 16 GB.

Advanced * SD memory card Format

setting * Set clock time ( Year/Month/Date,

Hour/Minute/ Second )

* Set sampling time

* Auto power OFF management

* Set beep Sound ON/OFF

* Decimal point of SD card setting

* Set temperature unit to or℃℉

* Set CD temperature compensation factor

Data Hold Freeze the display reading.

Memory Recall Maximum & Minimum value.

Sampling Time Approx. 1 second.

of Display

Data Output RS 232/USB PC computer interface.

* Connect the optional RS232 cable

UPCB-02 will get the RS232 plug.

* Connect the optional USB cable

USB-01 will get the USB plug.

Operating Meter 0 to 50 .℃

Temperature Probe 0 to 60 .℃

Operating Less than 85% R.H.

Humidity

Power Supply

Alkaline or heavy duty DC 1.5 V battery

( UM3, AA ) x 6 PCs, or equivalent.

DC 9V adapter input. ( AC/DC power

adapter is optional ).

Power Current Normal operation ( w/o SD card save

data and LCD Backlight is OFF) :

Approx. DC 14 mA.

When SD card save the data and LCD

Backlight is OFF) :

Approx. DC 37 mA.

If LCD backlight on, the power

consumption will increase approx.

12 mA.

Weight 489 g/1.08 LB.

Dimension Meter 177 x 68 x 45 mm

(7.0 x 2.7x 1.9 inch)

Probe Round,

12 mm Dia. x 157 mm length.

Accessories * Instruction manual......................1 PC

Included * Conductivity/TDS/Salt probe,

CDPB-04.................................... 1 PC

* Hard carrying case ( CA-06 ).......

1 PC

Optional * 1.413 mS Conductivity Standard

Accessories Solution..............................

CD-14

SD memory card ( 1 GB )

SD memory card ( 2 GB )

AC to DC 9V adapter.

USB cable, USB-01.

RS232 cable, UPCB-02.

Data Acquisition software,SW-U801-WIN.

2-2 Electrical Specifications (23±5 )℃

Conductivity ( uS, mS )

Range Measurement Resolutio

Accuracy

200 uS 0 to 200.0 uS 0.1 uS

2 mS 0.2 to 2.000 mS 0.001 mS ± (2% F.S.+1d)

20 mS 2 to 20.00 mS 0.01 mS * F.S. -

200 mS 20 to 200.0 mS 0.1 mS full scale

* Temperature Compensation :

Automatic from 0 to 60 ( 32 - 140 ), with temperature℃℉

compensation factor variable between 0 to 5.0% per C.

* The accuracy is specified under measurement value 100 mS.≦

* mS - milli Simens * @ 23± 5℃

TDS ( Total Dissolved Solids )

Range Measurement Resolutio

Accuracy

200 PPM 0 to 132 PPM 0.1 PPM

2,000 PPM 132 to 1,320 PPM 1 PPM ± (2% F.S.+1d)

20,000 PPM 1,320 to 13,200 PPM 10 PPM * F.S. -

200,000 PPM 13,200 to 132,000 PPM 100 PPM full scale

* Temperature Compensation :

Automatic from 0 to 60 ( 32 - 140 ), with temperature℃℉

compensation factor variable between 0 to 5.0% per .℃

* The accuracy is specified under measurement value 66,000 PPM.≦

* PPM - parts per million * @ 23± 5℃

Temperature

Function Measuring Range Resolutio

Accuracy

℃0 to 60℃℃ 0.1 ℃±0.8℃

℉32 to 140℉℉ 0.1 ℉±1.5℉

* @ 23± 5℃

Salt

Measurement 0 to 12 % salt ( % weight ).

Range

Resolution 0.01 % salt.

Accuracy ± 0.5 % salt value

3. FRONT PANEL DESCRIPTION

3-1 Display

3-2 Power Button ( Backlight Button )

3-3 Hold Button ( ESC Button )

3-4 REC Button ( Enter Button )

3-5 Mode Button ( Button )▲

3-6 Range Button ( Button )▼

3-7 Time Button

3-8 Logger Button ( SET Button, Sampling check )

3-9 Stand

3-10 Battery Compartment/Cover

3-11 Battery Cover Screw

3-12 Tripod Fix Nut

3-13 Probe Socket

3-14 DC 9V Power Adapter Input Socket

3-15 Reset Button

3-16 RS-232 Output Terminal

3-17 SD card socket

4. MODE SELECTION

1)Turn on the meter by pressing the " Power Button "

( 3-2, Fig. 1 ) momentarily.

*Pressing the " Power Button " ( 3-2, Fig. 1 )

continuously and > 2 seconds again will turn off the

meter.

2)The meter can select 3 kind Mode as :

a. Conductivity, TDS measurement

b.TDS measurement

c. Salt measurement

Pressing the " Mode Button " ( 3-5, Fig. 1 ) once, the

Display will show the following text in sequence :

Cd Conductivity measurement

tdS 'TDS measurement

SALt Salt measurement

Until the Display show the desired mode the meter will

execute this Mode with default.

5. CONDUCTIVITY/TDS MEASURING

and CALIBRATION PROCEDURE

The meter default function are following :

*The display unit is set to conductivity ( uS, mS ).

*The temperature unit is set to .℃

*Temp. compensation factor is set to 2.0% per C.

*Auto range.

*Auto power off.

*The sampling time of data logger function is

2 seconds.

Tabla de contenidos

Otros manuales de Instrumento de medición de Lutron Electronics

Lutron Electronics

Lutron Electronics SL-4011 Manual de instalación

Lutron Electronics

Lutron Electronics EM-9300SD Manual de usuario

Lutron Electronics

Lutron Electronics PM-9107 Manual de usuario

Lutron Electronics

Lutron Electronics DW-6063 Manual de usuario

Lutron Electronics

Lutron Electronics GC-2028 Manual de usuario

Lutron Electronics

Lutron Electronics MHT-381SD Manual de usuario

Lutron Electronics

Lutron Electronics EMF-839 Manual de usuario

Lutron Electronics

Lutron Electronics LM-8010 Manual de usuario

Lutron Electronics

Lutron Electronics VB-8206SD Manual de usuario

Lutron Electronics

Lutron Electronics MG-3OO2 Manual de usuario

Lutron Electronics

Lutron Electronics UVC-254SD Manual de usuario

Lutron Electronics

Lutron Electronics HT-315 Manual de usuario

Lutron Electronics

Lutron Electronics Radio Powr Sav LRF2-DCRB Instrucciones de instalación y funcionamiento

Lutron Electronics

Lutron Electronics PM-9112SD Manual de usuario

Lutron Electronics

Lutron Electronics UV-340A Manual de usuario

Lutron Electronics

Lutron Electronics DS-9200 Manual de usuario

Lutron Electronics

Lutron Electronics SL-4022 Manual de usuario

Lutron Electronics

Lutron Electronics FG-6020SD Manual de usuario

Lutron Electronics

Lutron Electronics LM-81LX Manual de instalación

Lutron Electronics

Lutron Electronics AM-4201 Manual de usuario

Lutron Electronics

Lutron Electronics ARW 4220 Manual de usuario

Lutron Electronics

Lutron Electronics DW-6195 Manual de usuario

Lutron Electronics

Lutron Electronics VB-8213 Manual de usuario

Lutron Electronics

Lutron Electronics CL-2006 Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
