DC145 - Firmware(FW) Upgrade Instruction

DC145 - Firmware(FW) Upgrade Instruction

*Note: upgrade to DMG109 may cause the files and custom logo saved in the internal

memory be erased. Please save the files before upgrade if necessary

1. Unzip the FW file ”DMGXXX.zip”and put the two files “DMGXXXB.BRN”and

“FW_DMG.BRN”into SD Card.

Put the “unzipped”file into SD card.

Put the FW files in the Root directory, not subdirectory.

If two more firmware files coexist in the USB flash drive, the unit will always detect

the latest version.

2. Plug in the power cord and connect unit with a monitor/projector.

3. Insert SD card into the SD card slot.

DC145 - Firmware(FW) Upgrade Instruction

4. Power on the unit and access the service menu

Please use Keypad to call the “Service Menu”.

Press “Enter”(do not release), then press”Zoom+”, hold both buttons in a second,

then the “Service menu” will be shown on screen as following picture.

5. Go [ISP] menu, select [Firmware Upgrade] and press [Enter].

Service Menu：Press “Enter”+”Zoom+ ”in sequence

1

.

2.

DC145 - Firmware(FW) Upgrade Instruction

6. FW start upgrading. (around 30sec taken)

*Note: Please do not stop the upgrading process which may cause the unit shut down.

7. Power reset the unit when the process finish.

(Unplug and re-plug the power cord to take effect.)

DC145 - Firmware(FW) Upgrade Instruction

8. After re-plug the power cord, the unit will power on automatically and continue the

FW upgrade. (around 1min taken)

*Note: Please do not stop the upgrade process which may cause the unit shut down.

9. Restart the unit after upgrading successfully.

(Unplug and re-plug the power cord to take effect.)

DC145 - Firmware(FW) Upgrade Instruction

10. Check FW version on OSD.

([Menu][Setting][Advanced])

11. Finished

Master FW version
