Lucent Technologies ED83134-30 Manual de usuario

Product Manual

ED83134-30

026-369-100

Comcode 107300584

Issue 2

June 1996

Lucent Technologies

600-2000 Ampere

Switch and Fuse

Notice:

Every effort was made to ensure that the information in this

document was complete and accurate at the time of printing.

However, information is subject to change.

Printed in U.S.A.

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)

Issue 2 June 1996 Table of Contents - 1

Table of Contents

1 Introduction

General 1 - 1

Documentation References 1 - 1

Technical Support 1 - 2

USA, Canada, Puerto Rico, and the US Virgin Islands 1 - 2

Central and South America 1 - 2

Europe, Middle East, and Africa 1 - 2

Asia Pacific Region 1 - 2

Product Repair and Return 1 - 2

USA, Canada, Puerto Rico, and the US Virgin Islands 1 - 2

Central and South America 1 - 3

Europe, Middle East, and Africa 1 - 3

Asia Pacific Region 1 - 3

Customer Service 1 - 3

2 Product Description

General Description 2 - 1

Features 2 - 1

3 Installation and Operation

4 Product Warranty

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)

Issue 2 June 1996 List of Figures - 1

List of Figures

Figure 1-1: ED83134-30 Switch and Fuse Panel

Installed in H569-418 Bay 1 - 4

Figure 1-2: Rear View of ED83134-30

Switch and Fuse Panel 1 - 5

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)

Issue 2 June 1996 Introduction 1 - 1

1 Introduction

General This Product Manual describes the 600-2000 Ampere Switch

and Fuse panel (ED83134-30). The ED83134-30, shown

installed in the H569-418 equipment frame in Figure 1-1, serves

as a multi-purpose switch and fuse. It can be used in three ways:

• as a high capacity distribution with “ON” and “OFF”

positions.

• as a battery disconnect switch which allows for the safe

removal of blown fuses.

• for off line equalize charging capability, switching from

floating operation to equalize charging.

The ED83134-30 panel may be ordered with a switch rated at

either 1200 or 2000 amperes. As many as six panels may be

installed in a single H569-418 equipment frame.

This manual includes a general product description, basic

features, and installation information.

Documentation

References This Lucent Technologies document (Select Code

026-369-100) is part of a set of documentation developed to

assistengineering and installationpersonnel.Additionalproduct

information includes the following:

• ED83134-30 Switch and Fuse Assembly Drawings

• H569-418 Bay Drawings

• T-8320730 Wiring Drawings

• SD-8320701 Schematic Drawings

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)

1 - 2 Introduction Issue 2 June 1996

Technical

Support Technical support for Lucent Technologies equipment is

available to customers around the world.

USA, Canada,

Puerto Rico, and

the US Virgin

Islands

Onapost-salebasis,duringtheProductWarrantyperiod,our

Technical Support telephone number 1-800-CAL RTAC (1-800-

225-7822) provides coverage during normal business hours.

Product Specialists are available to answer your technical

questions and assist in troubleshooting problems. For out-of-

hours EMERGENCIES, the 800 number will put you in touch

with a Regional Technical Assistance Center Engineer via our

24 hour a day, 7 day per week Help Desk.

When Technical Support is required in the Post-Warranty

Period, the service may be billable unless you hold an extended

warranty or contractual agreement.

Central and

South America If you need product technical support, contact your local Field

Support/Regional Technical Assistance Center or contact your

sales representative who will be happy to discuss your specific

needs.

Europe, Middle

East, and Africa If you need product technical support, contact your local Field

Support/Regional Technical Assistance Center or contact your

sales representative who will be happy to discuss your specific

needs.

Asia Pacific

Region If you need product technical support, contact your local Field

Support/Regional Technical Assistance Center or contact your

sales representative who will be happy to discuss your specific

needs.

Product Repair

and Return Repair and return service for Lucent Technologies equipment is

available to customers around the world.

USA, Canada,

Puerto Rico, and

the US Virgin

Islands

For information on returning of products for repair, customers

may call 1-800-255-1402 for assistance.

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)

Issue 2 June 1996 Introduction 1 - 3

Central and

South America If you need to return a product for repair, your sales

representative will be happy to discuss your individual situation.

Europe, Middle

East, and Africa If you need to return a product for repair, your sales

representative will be happy to discuss your individual situation.

Asia Pacific

Region If you need to return a product for repair, your sales

representative will be happy to discuss your individual situation.

Customer

Service For customer service, any other product or service information,

or for additional copies of this manual or other Lucent

Technologies documents, call 1-800-THE-1PWR

(1-800-843-1797). Specify the select code number for manuals,

or drawing number for drawings. Contact your regional

customer service organization or sales representative for

information regarding spare parts.

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)

1 - 4 Introduction Issue 2 June 1996

Figure 1-1: ED83134-30 Switch and Fuse Panel Installed in H569-418 Bay

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)

Issue 2 June 1996 Introduction 1 - 5

Figure 1-2: Rear View of ED83134-30 Switch and Fuse Panel

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)

1 - 6 Introduction Issue 2 June 1996

Lucent Technologies 600-2000 Ampere Switch and Fuse (ED83134-30)

Issue 2 June 1996 Product Description 2 - 1

2 Product Description

General

Description The H569-418 Battery Switch Bay can come equipped with up

to six ED83134-30 panels(600-2000 Ampere SwitchandFuse).

These switch and fuse panels have the capacity to carry and

switch up to 2000 amperes at up to 65 volts dc.

Each switch and fuse unit comes mounted in a 12-inch panel. A

protective clear cover protects users from electrical contact.

Rear access busbars allow cable connections.

You may order the ED83134-30 switch and fuse panel as either

Group 1 or Group 2. Group 1 panels use fuses ranging from 600

to 1200 amperes, while Group 2 panels uses fuses ranging from

1000 to 2000 amperes. Group 1 comes equipped with a 1200

ampere shunt and Group 2 comes equipped with a 2000 ampere

shunt for current monitoring.

Features The following features are provided with this product:

• Distributes or switches ± 24VDC and ± 48VDC

• Single pole, double throw switch

• Compact size allows six units to be mounted in one H569-

418 bay

• Accommodates fuses ranging from 600 to 2000 amps

• Fuse operation generates visual alarm within the unit

• Remote access for monitoring alarm conditions through

controller

• 1200 or 2000 ampere monitoring shunts

• Rear access for cabling

• Cable entry from top or bottom of cabinet

• Allows connection of cable sizes from 4/0 to 750MCM

• Protective front and rear clear covers

• Front access for fuse replacement
