LOXONE Touch Tree Manual de usuario

Technical Specifications

Ambient temperature -20 ... 70°C / -4 ... 158°F

Dimensions 80x80x10mm /

3.15x3.15x0.4” (LxWxH)

Maintenance & Cleaning This device is free of main-

tenance and may only be

cleaned with a dry cloth.

Power supply 9 ... 28VDC

Power consumption typ. 115mW

Power loss max. 115mW

Safety rating IP40

Touch points 5 touch points, capacitive

touch detection

Loxone Electronics GmbH

Smart Home 1

4154 Kollerschlag

Austria

loxone.com

Need Help?

loxone.com/support

Part No: 100221 (White)

Part No: 100222 (Anthracite)

Touch

Tree

V150720

Humidity max. 95% r.H. (non condensing)

Click feedback Yes

Temperature detection range -40 ... 125°C / -40 ... 257°F

+/- 0.5°C / 0.9°F

Humidity detection range 0 ... 100% r.H. +/- 2%

(non condensing)

Interfaces Loxone Tree: connection with

Miniserver / Tree Extension

About the product

The Loxone Touch has five touch zones, which can be configu-

red according to your needs. The large central touch zone is

ideal for controlling lighting, whilst the corner zones are handy

for controlling music and blinds, for example.

Features

• 5 touch buttons

• Temperature & humidity sensor

• Optional click feedback

Installation

Install the mounting frame on the desired installation place.

Power up the device and pair it with your Miniserver in Loxone

Config. To finish the installation attach the Loxone Touch on

the mounting frame.

For additional information, declaration of confirmity,

visit www.loxone.com/help/touch-tree

Touch

buttons

Cable

This folder is a part of the product!

Connection

Wire cross-section

0.25 ... 0.8mm² / AWG23 ... 18

Stripping length 5mm / 0.2”

Temperature resistance

-40 … 105°C / -40 … 221°F
