USER’S GUIDE

LW1740 / LW2740

SERIES

English / Français / Español

USER’S GUIDE

LW1740 / LW2740 SERIES

#LX400030; r. 2.0/22135/22135; en-US iii

Thank you for purchasing this product. Lorex is committed to providing our

customers with a high quality, reliable security solution.

This manual refers to the following models:

• LW1741

• LW1742

• LW1744

• LW2742

For the latest online manual, downloads and product updates, and to learn

about our complete line of accessory products, please visit our website at:

www.lorextechnology.com

WARNING

• Risk of electric shock. Do not open.

• To reduce the risk of electric shock, do not remove cover. No user serviceable parts

inside. Refer servicing to qualified service personnel.

• To prevent fire or shock hazard, do not expose this unit to rain or moisture.

• To prevent electric shock, match wide blade of the plug to the wide slot and fully insert.

CAUTION

• Test the video monitor before use. Become familiar with its functions.

• If you do not plan to use the unit for a prolonged period of time, disconnect the battery

or ensure you charge it at least once every 3 months.

• Never use extension cords with power adapters.

• Only use the chargers and power adapters provided. Do not use other chargers or

power adapters as this may damage the device and battery pack.

• Only insert batteries / battery pack of the same type.

• Do not cover the video monitor with a towel or blanket.

• Do not use this product in humid or wet places.

• Do not install the video monitor near a heat source.

• Do not touch the plug contacts with sharp or metal objects.

• It is highly recommended to connect the product to a surge protector to protect from

damage caused by electrical surges. It is also recommended to connect the product to

an uninterruptible power supply (UPS), which has an internal battery that will keep the

product running in the event of a power outage.

• Keep this user’s guide for future reference.

#LX400030; r. 2.0/22135/22135; en-US iv

Table of contents

1 LW1740 / LW2740 Series Features.........................................1

2 Getting Started ...................................................................3

3 Installing the Camera(s).......................................................4

3.1 Installation Tips ..........................................................4

3.2 Mounting Positions......................................................4

4 Installing the Receiver .........................................................7

4.1 Setting the Time .........................................................9

5 Camera Overview.............................................................. 10

6 LCD Receiver Overview...................................................... 11

6.1 Front Panel.............................................................. 11

6.2 Side Panel .............................................................. 12

6.3 Rear Panel .............................................................. 13

7 Using the System .............................................................. 14

7.1 Understanding the On-screen Display ........................... 14

7.2 Navigating Menu Screen ............................................ 16

7.3 Viewing Modes ........................................................ 16

7.3.1 Auto Sequence Viewing Mode .......................... 16

7.3.2 Quad Mode .................................................. 17

7.4 Digital Zoom............................................................ 18

7.5 Changing Audio Volume............................................. 18

8 Recording ........................................................................20

8.1 Format Memory........................................................ 20

8.2 Recording Mode Summary ......................................... 21

8.3 Scheduled Recording ................................................ 22

8.3.1 Creating a Recording Schedule......................... 23

8.3.2 Pausing Scheduled Recording .......................... 24

8.3.3 Modifying / Disabling a Recording

Schedule ..................................................... 24

8.3.4 Deleting a Recording Schedule ......................... 25

8.4 Manual Recording .................................................... 26

8.5 Taking a Snapshot .................................................... 26

8.6 Enabling / Disabling File Overwrite ............................... 27

8.7 Configure Recording Time for Motion Events .................. 28

8.8 Motion Detection Sensitivity ........................................ 29

8.9 Motion Detection Area ............................................... 30

8.10 Enabling / Disabling Alarm for Motion Events .................. 32

#LX400030; r. 2.0/22135/22135; en-US v

Table of contents

8.11 Maximum Recording Times ........................................ 34

9 Playback ..........................................................................35

9.1 Video Playback ........................................................ 35

9.1.1 Playback Controls .......................................... 36

9.2 Viewing Snapshots ................................................... 37

9.3 Deleting Files........................................................... 38

9.4 Viewing Video Directly from the microSD Card................ 39

9.4.1 Player Overview............................................. 41

10 Settings ...........................................................................43

10.1 Camera Brightness ................................................... 43

10.2 Enabling / Disabling Date & Time Stamps ...................... 44

10.3 Changing Date & Time Format..................................... 45

10.4 Power Saving Mode .................................................. 46

10.5 Activating / De-activating Channels............................... 47

10.6 Changing Scan Interval for Auto Sequence

Viewing .................................................................. 49

10.7 Update Firmware...................................................... 50

10.8 Restore Default Settings ............................................ 51

11 Pairing Additional Cameras ................................................ 53

12 Technical Specifications .................................................... 56

12.1 General Specifications............................................... 56

12.2 Camera Specifications............................................... 56

12.3 Receiver Specifications.............................................. 57

12.4 Dimensions ............................................................. 58

12.4.1 LCD Receiver................................................ 58

12.4.2 Camera with Metal Stand................................. 58

13 Troubleshooting................................................................ 59

14 Notices ............................................................................61

14.1 FCC Notice ............................................................. 61

14.2 Industry Canada Notice ............................................. 62

14.3 Modification............................................................. 62

14.4 RoHS..................................................................... 62

#LX400030; r. 2.0/22135/22135; en-US vi

LW1740 / LW2740 Series

Features

• 7” rechargeable wireless LCD monitor.1

• Weather resistant wireless camera.2

• Manual, motion, and schedule recording.

• Listen-in audio monitoring.3

• Expandable up to 4 cameras.

• microSD memory card included; 32GB supported.

• Easy to use menu with icons.

• Simple installation. No video cables required.

• Video motion detection.

• Time and date stamped recordings for easy retrieval.

• Front panel feather touch controls.

• Motorized camera filter provides accurate color reproduction in all lighting

conditions.

• Night time viewing up to 65ft (20m) away in ambient night time lighting con-

ditions and up to 45ft (14m) away in total darkness.4

• View and record up to 4 cameras at the same time in quad screen.

• Secure wireless signal (FHSS).

• Up to 150ft (50m) indoor / 450ft (150m) outdoor wireless range.5

• Record in real time video.

• 2x Digital Zoom.

#LX400030; r. 2.0/22135/22135; en-US 1

LW1740 / LW2740 Series Features

NOTE

1. Up to 5 hours of portable wireless monitoring. For extended monitoring ensure the

wireless monitor is connected to a local power outlet.

2. Wireless cameras require a wired connection to power outlet. Not intended for direct

exposure to rain or snow. For outdoor applications, install under shelter protected from

the elements.

3. Audio recording without consent is illegal in certain jurisdictions. Lorex Corporation as-

sumes no liability for use of its products that does not conform with local laws.

4. Stated IR illumination ranges are based on ideal conditions in total darkness and typi-

cal outdoor night time ambient lighting. Actual range and image clarity depends on in-

stallation location, viewing area and light reflection / absorption.

5. Range up to 450ft (150m) outdoor and 150ft (50m) indoor based on line of sight. Ac-

tual range will vary depending on obstructions.

#LX400030; r. 2.0/22135/22135; en-US 2

Getting Started

The system includes the following components:

Indoor / outdoor

wireless camera(s)*

7” rechargeable

LCD receiver

Power adapters for

receiver and cam-

era(s)*

Rechargeable Lith-

ium polymer battery

Wireless antenna

(s)

for camera(s)

(SMA)*

microSD memory

card

(pre-inserted into

receiver)

Mounting kit(s)* Quick Start Guide

* Configuration may vary by model

NOTE

Camera configuration, memory card size, and the number of accessories may vary by

model. Please refer to your package for specific details. Check your package to confirm

that you have received the complete system.

#LX400030; r. 2.0/22135/22135; en-US 3

Installing the Camera(s)

CAUTION

Cameras are suitable for outdoor installa-

tion, but are weather resistant, not weath-

erproof. Cameras are not intended for

direct exposure to rain or snow. For

outdoor applications, install under shelter

protected from the elements, such as be-

neath roof eaves. The diagram to the right

shows an example of an ideal location for

outdoor placement.

3.1 Installation Tips

• Before you install the camera, plan where and how it will be positioned,

and where you will route the cable that connects the camera to the power

adapter.

• Before starting permanent installation, check the camera image on the re-

ceiver when camera is positioned in the same place it will be permanently

installed.

• It is recommended to ensure a clear line-of-sight between the camera and

receiver and to limit the amount of obstructions, such as walls and tree

branches, between the camera and receiver. Walls made of heavy building

materials such as brick or concrete will significantly reduce signal range.

• If the signal will have to pass through a wall, placing the receiver or camera

next to a window will improve the signal strength.

• Do not install the camera pointing out of a window. The nighttime picture

will be unusable due to reflection from the night vision LED’s.

• The cameras are pre-paired so they work out of the box. Each camera has

a channel number sticker indicating what channel they are paired to. If you

have purchased additional cameras, you will need to pair them to the re-

ceiver, see 11 Pairing Additional Cameras, page 53.

3.2 Mounting Positions

You may mount your cameras on a wall or counter. See the images below for

recommended configurations of the camera stand and antenna.

#LX400030; r. 2.0/22135/22135; en-US 4

Installing the Camera(s)

Wall Counter

To install the camera(s):

1. Use the included mounting screws to attach the camera stand(s) to the

mounting surface:

• Mark the positions of the screw holes on the mounting surface with the

base of the mounting stand.

• Drill holes and insert the drywall plugs (included) if installing on a dry-

wall surface.

• Firmly attach the camera(s) to the mounting surface using the included

screws.

NOTE

If you run the power cable through the mounting surface, connect power before attach-

ing the camera to the wall.

2. Attach the camera stand(s) and antenna(s) to the camera(s).

#LX400030; r. 2.0/22135/22135; en-US 5

Otros manuales para LW1741

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Sistema de seguridad de Lorex

Lorex

Lorex Vantage Edge+ CVC6996 Manual de usuario

Lorex

Lorex LW2300 SERIES Manual de usuario

Lorex

Lorex LW2750 Series Manual de usuario

Lorex

Lorex Vantage Manual de usuario

Lorex

Lorex L224V161C4 Manual de usuario

Lorex

Lorex SG19LD80 Series Instrucciones de funcionamiento

Lorex

Lorex SG19LD804-161 Guía de instalación

Lorex

Lorex SG21FD3044-161 Instrucciones de montaje

Lorex

Lorex WIRELESS HOME MONITORING SYSTEM Manual de usuario

Lorex

Lorex SG6350 Manual de usuario

Lorex

Lorex LHB800 Series Manual de usuario

Lorex

Lorex LW2201 Series Manual de instrucciones

Lorex

Lorex L204 Manual de usuario

Lorex

Lorex LW2702 series Manual de usuario

Lorex

Lorex LW2400 Series Manual de usuario

Lorex

Lorex SC21CD5444UQ-A80 Manual de instrucciones

Lorex

Lorex LW491HD Manual de usuario

Lorex

Lorex DMC2161 Manual de usuario

Lorex

Lorex mCAM DMC2030 Manual de usuario

Lorex

Lorex SG21FD3044-161 Manual del operador

Lorex

Lorex SG19LD804-161 Guía de instalación

Lorex

Lorex LW2960 SERIES Manual de usuario

Lorex

Lorex LW2101 series Manual de usuario

Lorex

Lorex LW2700 SERIES Manual de usuario

Manuales populares de Sistema de seguridad de otras marcas

Inner Range

Inner Range Concept 2000 Manual de usuario

Climax

Climax Mobile Lite R32 Instrucciones de montaje

CADDX

CADDX NX-6 Manual de usuario

FBII

FBII XL-31 Series Manual de usuario

Johnson Controls

Johnson Controls PENN Connected PC10 Manual de usuario

Aeotec

Aeotec Siren Gen5 Manual de usuario

Blaupunkt

Blaupunkt SA 2700 Manual de usuario

IDEAL

IDEAL Accenta Manual del propietario

AJAX

AJAX DoubleButton Manual de usuario

Swann

Swann SW-P-MC2 Manual de usuario

Ecolink

Ecolink Siren+Chime Manual de usuario

Digital Monitoring Products

Digital Monitoring Products XR150 Manual de usuario

EDM

EDM Solution 6+6 Wireless-AE Manual de usuario

Highway Safety Group

Highway Safety Group EA401 Manual de usuario

Siren

Siren LED GSM Manual de usuario

Detection Systems

Detection Systems 7090i Instrucciones de montaje

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manual de usuario

Siemens

Siemens FDM273 Manual de usuario
