Lorex VANTAGE LBC5451 Manual de usuario

INSTRUCTION MANUAL

ENGLISH VERSION 1.0

www.lorextechnology.com

LBC5451

SECURITY CAMERA

Contents

• 1x Camera and mounting stand

• 1x Power adapter

• 1x Mounting kit

• 1x Allen key

• 1x Screw cap

• 1x 60 ft. (18m) BNC / power extension cable

• 1x BNC Female / RCA Male adapter

• 1x Instruction Manual

Features

• High resolution Sony Super HAD™ image sensor delivers

540TV lines of resolution.

• Dual infrared / white-light LEDs provide full-color night

vision in complete darkness for long-range monitoring and

close-up recognition.

• Capable of capturing images up to 60 ft. (18m) away in total

darkness in B/W and 30 ft. (9m) in color*.

• 4.3mm wide-angle lens for wide area coverage (80° FOV)†.

• IP67 rated housing for indoor / outdoor installations‡.

* Illumination range under ideal conditions. Objects at or beyond this range may

be partially or completely obscured, depending on the camera application. Color

night vision only available once motion triggers white light LEDs to turn on.

† Field of view, diagonal.

‡ Not intended for submersion in water. Installation in a sheltered location recom-

mended.

CHECK YOUR PACKAGE TO CONFIRM THAT YOU HAVE

RECEIVED ALL THE COMPONENTS SHOWN ABOVE.

Safety Instructions

• Read this guide carefully and keep it for future reference.

• Follow all instructions for safe use of the product and handle

with care.

• Use the camera within given temperature, humidity, and

voltage levels noted in the Technical Specifications.

• Do not disassemble the camera.

• Do not point the camera directly towards the sun or a source

of intense light.

• Use only the supplied regulated power supply. Use of a

non-regulated, non-conforming power supply can damage

this product and voids the warranty.

• Periodic cleaning may be required. Use a damp cloth only.

Do not use harsh cleaners or aerosol cleaners.

• The supplied extension cable is rated for surface mounting

only. Cables for in-wall / floor-to-floor installations are sold

separately.

iii

TABLE OF CONTENTS

1. Camera Overview . . . . . . . . . . . . . . . . . . . . . . 1

2. Night Vision Features . . . . . . . . . . . . . . . . . . 2

2.1 Night Vision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2.2 Motion Detection / White Light LEDs . . . . . . . . . . . . . . . . . . .2

3. Installation Tips . . . . . . . . . . . . . . . . . . . . . . . 4

3.1 Suggested Install Locations . . . . . . . . . . . . . . . . . . . . . . . . . .5

4. Installing the Camera . . . . . . . . . . . . . . . . . . 6

4.1 Before Installing the Camera . . . . . . . . . . . . . . . . . . . . . . . . .6

4.2 To Install the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

5. Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . 10

6. Connecting the Camera . . . . . . . . . . . . . . . . 12

6.1 BNC to RCA Adapter (Optional) . . . . . . . . . . . . . . . . . . . . . .13

6.2 Setup Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

7. Technical Specifications . . . . . . . . . . . . . . . 14

7.1 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

8. Cable Extension Options . . . . . . . . . . . . . . . 16

9. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . 17

1. CAMERA OVERVIEW

1Camera Module

2Camera Holder

3Camera Mount

4Mounting Base

5DC Power / BNC Video

Connectors: See

“Connecting the Camera”

on page 12 for details.

6Infrared LEDs: Enable the

camera to see at night.

7White Light LEDs:

Automatically turn on

when motion is detected

(during night vision only)

to deter criminals and

allow camera to view color

images at night

8Camera Lens

9Sensor: Detects light to

control night vision and

trigger White Light LEDs.

Night Vision Features

2. NIGHT VISION FEATURES

This camera is equipped with special features that make it

more effective at deterring and identifying nighttime

intruders.

2.1 Night Vision

This camera is equipped with IR (Infrared) LEDs, which

allow it to see at night up to a range of 60 ft. (18m). It has a

built-in light sensor that activates night vision when it is

dark. The camera sees in black and white when night

vision is on.

2.2 Motion Detection / White Light LEDs

This camera is also equipped with White Light LEDs. At

night, the White Light LEDs are set to turn on

automatically when the camera detects motion within a

range of 9 ft.

How it Works: During nighttime, the camera’s night vision sees up to 60 ft. in black and white. When

an object comes within a 9 ft. range, the White Light LEDs turn on, and the Infrared LEDs turn off. White

light projects up to 30 ft., allowing the camera to view close by objects in color (depending on lighting

conditions). After 15 seconds, the White Light LEDs turn off, and the Infrared LEDs turn back on.

(3m).

Night Vision Features

This helps deter / identify intruders by:

• Alerting them to the presence of the camera, after they

have already been spotted.

• Providing a better view of the intruder’s face. The white

lightsonthecameraturnoninstantlytosurpriseintruders,

drawing their eyes to the camera.

• Providing color images at night. When the white lights are

activated, the camera can view close by objects in color.

Color images help identify the intruder’s face and clothing.

NOTE: White Light LEDs remain on for 15 seconds after

the camera detects motion.

The camera detects motion using a built-in

light sensor. Avoid installing the camera in

areas where the lighting conditions are likely

to change frequently, as lighting changes may

trigger the sensor even if there is no motion.

IMPORTANT:

Typical night-vision cameras

maybeoverlooked by intruders White Light LEDs draw

attention to help identify faces

Installation Tips

3. INSTALLATION TIPS

• Test the camera before installing to ensure that there are

no problems with the camera.

• To maximize the range of the motion sensor and White

Light LEDs, mount the camera around 7 ft. (2.2m) off the

ground.

• Avoid installing the camera in locations overlooking a

publicroadorsidewalk, as motion or lightingchangesfrom

these locations will trigger the camera’s White Light LEDs.

• Mount the camera where the lenses are away from direct

and intense sunlight.

• Plan your cable wiring so that it does not interfere with

power lines or telephone lines.

• Ensure that the camera wiring is not exposed or easily cut.
