Lorex LZV1722 Manual de usuario

Instruction

Manual

LZV1722 HD PTZ

Camera

Instruction Manual

LZV1722 HD PTZ Camera

#LX400025; r. 1.0/16122/16128; en-US iii

Thank you for purchasing this product. Lorex is committed to providing our customers with

a high quality, reliable security solution.

This manual refers to the following models:

LVZ1722

For the latest online manual, downloads and product updates, and to learn about our

complete line of accessory products, please visit our website at:

www.lorextechnology.com

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING: TO REDUCE THE RICK OF ELECTRIC SHOCK DO NOT

REMOVE COVER. NO USER SERVICABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated "dangerous voltage" within the

product’s enclosure that may be of sufficient magnitude to

constitute a risk of electric shock.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the

literature accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE

THIS UNIT TO RAIN OR MOISTURE.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF

THE PLUG TO THE WIDE SLOT AND FULLY INSERT.

#LX400025; r. 1.0/16122/16128; en-US iv

Table of contents

1 Safety Instructions ..............................................................1

2 LZV1722 Features ...............................................................2

3 Getting Started ...................................................................3

4 Connecting the Camera .......................................................4

5 Installation .........................................................................5

5.1 Installation Tips and Warnings ....................................... 5

5.2 Extension Cables ....................................................... 5

5.2.1 Connection Diagram for Extending the Cables

Beyond 100ft (30m) ......................................... 6

5.3 Installation (Indoor/Outdoor).......................................... 6

6 Controlling the PTZ Camera with your DVR........................... 15

6.1 Controlling a PTZ Camera (Local DVR) ......................... 15

6.2 Advanced PTZ Controls ............................................. 16

6.2.1 Presets ........................................................ 17

6.2.2 Tours........................................................... 18

6.2.3 Pattern......................................................... 19

6.2.4 Auto Scan .................................................... 19

7 Technical Specifications .................................................... 21

7.1 Dimensions ............................................................. 22

8 Troubleshooting................................................................ 23

#LX400025; r. 1.0/16122/16128; en-US v

Safety Instructions

• Read this guide carefully and keep it for future reference.

• Follow all instructions for safe use of the product and handle with care.

• Use the camera within given temperature, humidity, and voltage levels

noted in the Technical Specifications.

• Camera is rated for outdoor use and is weatherproof when properly in-

stalled. Camera is not intended for submersion in water. Installation under

a sheltered environment is recommended.

• Do not disassemble the camera.

• Do not point the camera directly towards the sun or a source of intense

light.

• Use only the supplied regulated power supply. Use of a non-regulated,

non-conforming power supply can damage this product and voids the

warranty.

• Make sure to install the camera in a location that can support the camera

weight. If mounting the camera on a drywall surface, you must drill at least

2 of the mounting screws through a wooden stud. See 5.3 Installation (In-

door/Outdoor), page 6 for complete installation instructions.

• Make sure there are no live electrical cables in the area where you plan to

mount the camera.

• Periodic cleaning may be required. Use a damp cloth only. Do not use any-

thing other than water to clean the dome cover, as chemicals such as ace-

tone can permanently damage the plastic.

#LX400025; r. 1.0/16122/16128; en-US 1

LZV1722 Features

• High definition 720p 1.3 MP Sony Exmor® image sensor.

• Powerful 12x optical zoom and 16x digital zoom to focus in on even the fin-

est details.

• Full 360° continuous pan rotation for complete area coverage. Fast 300°

per second panning speed.

• Zoom lens for viewing small or distant objects with enhanced definition.

• Control PTZ camera movement and transmit video over a single coaxial

cable.

• Program preset viewing points, patterns, scan cycles and tours when con-

nected to a DVR.

• Remote control of the PTZ camera using a smartphone or tablet when con-

nected to a DVR.

• Day/Night mode: picture automatically switches to B&W delivering better

clarity in low light conditions.

• ClearNight imaging for superior low light performance.2

• Infrared cut filter ensures accurate color representation.

• High definition video with outstanding detail, day or night.

• Weatherproof for outdoor & indoor installation (IP66 Rated).3

• Wall mount & 100ft extension cable included for installation flexibility.

Note

1. Compatible with Lorex LHV1000 Series only.

2. This camera features an ultra-low light sensitive image sensor and therefore does not

feature Infra-Red LEDs. The camera requires ambient lighting (for example, street/

building lighting, star or moon light) to render a night time image. In total darkness

(zero Lux), the camera will not produce a night time image and therefore the camera

should not be installed in completely dark areas.

3. Not intended for submersion in water. Installation in a sheltered location

recommended.

#LX400025; r. 1.0/16122/16128; en-US 2

Getting Started

The system comes with the following components:

PTZ Camera Wall Mount Pendant Cap

100ft BNC / Power

Extension Cable

4x Mounting Screws

& Anchors Power Adapter

4x O-Rings 4x Allen Bolts Allen Key

Mounting Template Instruction Manual

#LX400025; r. 1.0/16122/16128; en-US 3

Connecting the Camera

Note

• It is recommended to connect the camera to your DVR and test the PTZ controls be-

fore permanent installation. For instructions on how to setup PTZ controls, see 6 Con-

trolling the PTZ Camera with your DVR, page 15.

• When you first power up the camera and connect it to the DVR, it may take up to 2 mi-

nutes for the camera image to appear.

• The video signal can be extended up to 800ft (244m) with a single cable run. See 5.2

Extension Cables, page 5 for details.

1. Connect the BNC video connector on the camera cable to the included ex-

tension cable.

2. Connect the female AC 24V power connector on the camera cable to the

male power connector on the included extension cable.

3. Connect the BNC cable on the extension cable to one of the Video Input

ports on the DVR. Make note of the port number where you connect the

camera, as it will be used when configuring the DVR to communicate with

the camera.

4. Connect the power connector on the extension cable to the included

power adapter. Plug the power adapter into a power outlet.

CAUTION

• Make sure to disconnect the power adapter before installing the camera. The cam-

era will begin moving immediately when the power adapter is connected.

• Make sure to remove the foam ring inside the camera housing before powering the

camera on for the first time. See 5.3 Installation (Indoor/Outdoor), page 6 for

details.

#LX400025; r. 1.0/16122/16128; en-US 4
