Logitech C920e Instrucciones de montaje
User Manual of Product 1:
Logitech C920e HD 1080p Mic-Enabled Webcam, certified for
Zoom, Microsoft Teams compatible, TAA Compliant + Litra
Glow Premium LED Streaming Light with TrueSoft, adjustable
monitor mount
User Manual of Product 2:
Logitech for Creators Litra Glow Premium LED Streaming Light
with TrueSoft, adjustable monitor mount, brightness & color
temp settings, desktop app control for PC/Mac - Graphite 3.6" x
3.6" x 1.1"
C920eHD WEBCAM
Complete Setup Guide
Guide d'installation complet
CONTENTS
English . . . . . . . . . . . . . . . . .3
Deutsch . . . . . . . . . . . . . . . .7
Français . . . . . . . . . . . . . . . 11
Italiano . . . . . . . . . . . . . . . . 15
Español . . . . . . . . . . . . . . . . 19
Português . . . . . . . . . . . . . . 23
Nederlands . . . . . . . . . . . . . . 27
Svenska. . . . . . . . . . . . . . . . 31
Dansk. . . . . . . . . . . . . . . . .35
Norsk . . . . . . . . . . . . . . . . .39
Suomi. . . . . . . . . . . . . . . . .43
Ελληνικά. . . . . . . . . . . . . . . . 47
По-русски . . . . . . . . . . . . . . . 51
Po polsku . . . . . . . . . . . . . . . 55
Magyar . . . . . . . . . . . . . . . .59
Česká verze. . . . . . . . . . . . . .63
Slovenčina . . . . . . . . . . . . . . 67
Українська. . . . . . . . . . . . . . . 71
Eesti . . . . . . . . . . . . . . . . . 75
Latviski . . . . . . . . . . . . . . . . 79
Lietuvių . . . . . . . . . . . . . . . .83
Български . . . . . . . . . . . . . . . 87
Hrvatski . . . . . . . . . . . . . . . 91
Srpski . . . . . . . . . . . . . . . . .95
Slovenščina. . . . . . . . . . . . . .99
Română . . . . . . . . . . . . . . 103
Türkçe . . . . . . . . . . . . . . . .107
111 . . . . . . . . . . . . . . . . . ةيبرعلا
115 . . . . . . . . . . . . . . . . תירבע
繁體中文. . . . . . . . . . . . . . . 119
한국어 . . . . . . . . . . . . . . . .123
Indonesia . . . . . . . . . . . . . . .127
Autofocus
HD 1080p lens
Universal
mounting clip
Tripod thread*
Attachable
privacy shutter
USB-A cable
KNOW YOUR PRODUCT
Dual microphone
LED activity light
* Tripod not included
3English
ATTACH THE PRIVACY SHUTTER
1 Attach external privacy shutter by locating
thelens on the webcam.
WHAT’S IN THE BOX
1 Webcam with 5 ft (1.5 m) attached USB-A cable
2 Privacy shutter
3 User documentation
USB-A
2 Snap it onto the front of the webcam,
directlyover the center.
3 Manually adjust the privacy shutter to open
orclose as desired.
4English
SETTING UP THE WEBCAM
For placement on a monitor
1 Place your webcam on a computer,
laptopormonitor at a position or angle
youdesire.
For placement on a tripod*
1 Locate the ¼ inch tripod thread on the bottom
of the universal mounting clip.
2 Adjust the webcam to make sure the foot
onthe universal mounting clip is ush with
theback of your device.
3 Manually adjust the webcam up/down
tothebest position to frame yourself.
2 Secure the webcam on your tripod by twisting it
into the ¼ inch thread.
3 Place your webcam with the tripod in the best
position to frame yourself.
* Tripod not included
5English
CONNECTING THE WEBCAM VIA USB-A
Plug the USB-A connector into the USB-A port
onyourcomputer.
SUCCESSFUL CONNECTION
LED activity light will light up when the webcam
isinuseby an application.
INCLUDING FIXED MOUNTING CLIP:
Height x Width x Depth:
1.70 in (43.3 mm) x 3.70 in (94 mm) x 2.80 in (71 mm)
Cable Length: 5 ft (1.5 m)
Weight: 5.71 oz (162 g)
DIMENSIONS
www.logitech.com/support/C920e
© 2020 Logitech, Logi and the Logitech Logo are trademarks or registered trademarks of Logitech
Europe S.A. and/or its aliates in the U.S. and other countries. Logitech assumes noresponsibility
for any errors that may appear in thismanual. Information contained herein issubject to change
without notice.
21LITRA GLOW
3
logitech.com/ghub
USB 3.0
LITRA GLOW
© 2021 Logitech. Logitech, Logi, Logitech
for Creators, Litra Glow and their logos are
trademarks or registered trademarks of
Logitech Europe S.A. or its aliates in the U.S.
and/or other countries. Information contained
herein is subject to change without notice.
© 2021 Logitech. Logitech, Logi, Logitech
for Creators, Litra Glow et leurs logos sont
des marques commerciales ou déposées
de Logitech Europe S.A. ou de ses sociétés
aliées aux États-Unis et dans d'autres pays.
Les informations énoncées dans ce document
peuvent faire l'objet de modications
sans préavis.
620-011016 003
4 5
