Logitech Harmony 785 Manual de usuario

785 Harmony Remote

User Manual, version 1.2

User Manual Harmony 785

Table of Contents

INTRODUCTION....................................................................................................................................................1

GETTING TO KNOW YOUR HARMONY REMOTE..................................................................................2

BEGINNING THE SETUP PROCESS.......................................................................................................3

USING YOUR HARMONY REMOTE............................................................................................................4

RECHARGING THE BATTERY...............................................................................................................4

USING THE TILT SENSOR...................................................................................................................4

SELECTING AN ACTIVITY...................................................................................................................4

USING THE TELETEXT BUTTONS........................................................................................................4

VIEWING THE STATUS AND NAVIGATION BARS...................................................................................5

DISPLAYING HELP ON YOUR HARMONY REMOTE................................................................................5

Types of Help Available.........................................................................................................6

Using the Remote Assistant..................................................................................................6

CONTROLLING INDIVIDUAL DEVICES.................................................................................................6

Device Mode.......................................................................................................................6

USING THE SMART BUTTONS............................................................................................................7

USING SYSTEM OPTIONS..................................................................................................................7

CUSTOMIZING YOUR HARMONY REMOTE......................................................................................................8

CUSTOMIZING THE DISPLAY ON THE HARMONY REMOTE..................................................................8

Adding your Favorite Channel Icons......................................................................................9

Changing the Behavior of Buttons Within an Activity............................................................9

Adding Custom-Labeled Buttons..........................................................................................9

CHANGING THE SETTINGS FOR YOUR HARMONY REMOTE................................................................10

LEARNING INFRARED (IR) COMMANDS.............................................................................................10

Using the Infrared Sensor....................................................................................................10

Naming an Infrared Command............................................................................................11

GETTING ADDITIONAL HELP..............................................................................................................................12

Finding Answers to Your Questions......................................................................................12

Troubleshooting Your Harmony Remote...............................................................................12

Version 1.2 Page i

User Manual Harmony 785

Introduction

Congratulations on the purchase of your Harmony remote! This User Manual will introduce you to the basic online

setup process, customizations and main features of your Harmony remote.

If in doubt about how to set up your Harmony remote, follow the information and instructions using the

Logitech Harmony Remote Software (also referred to as Harmony Remote Software).

The Harmony remote is an Internet-powered universal remote control. Your Harmony remote can control most devices

that understand infrared (IR) signals.

The configuration of your Harmony remote is simple:

• You will be prompted to answer questions about your entertainment devices to create your own

personal Harmony remote configuration.

• Your answers will provide us with a description of the entertainment devices you want to control,

how they are set up, and your preferences for controlling them.

• If one of your devices is not in the Harmony remote’s database, the Harmony Remote Software will

learn about your device and add it to your configuration.

• Once you have told us about your devices, you will then be guided through setting up Activities.

Creating Activities is simple: you will be prompted to indicate the devices you use within an Activity and

how you want to control specific features, such as the volume, within that Activity.

• An Activity is a set of commands the Harmony remote sends to your entertainment system to

turn on the necessary devices.

• Once you have selected an Activity, you are in Activity mode, and the functionality of each

button on your Harmony remote is automatically configured for that Activity.

• Additionally, the display buttons will give you access to other commands for that Activity,

which cannot be set to the standard buttons.

Example

For the Watch Television Activity, the Harmony remote sends commands to your entertainment

system to turn on the necessary devices so you can watch television. The remote will auto-

matically be configured for the Activity based on the answers you selected during the online

setup process for the Activity.

At the end of the setup process, you will have your own configuration loaded in your Harmony remote.

Use your Harmony Remote Software to:

• Customize any of your Harmony remote’s features.

• Add more entertainment devices.

• Add more Activities.

Version 1.2 Page 1

User Manual Harmony 785

Version 1.2 Page 3

Beginning the Setup Process

Once you have installed the Logitech Harmony Remote Software, connect your remote and you will be guided

through a series of question-and-answer steps to complete each of the five main steps of the

online setup process:

Check Connection: Ensures your computer and your Harmony remote are communicating properly.

Set Up Devices: Helps you provide us with information about the devices in your personal home theater system.

Set Up Activities: Helps you provide us with information about the way your devices work together to perform

Activities (e.g. Watch Television Activity).

Update Remote: Updates your remote with your personal settings.

Note: When using the Harmony Remote Software, click More Help to view specific help for the step you are on.

User Manual Harmony 785

Version 1.2 Page 6

2. Answer the questions on the remote’s display by selecting Yes or No. If you answer no to any question,

the Harmony remote will resend the necessary command and ask you the same question again.

When you are done, the Harmony remote will be “synchronized” with your devices again.

Types of Help Available

You can customize the Help button on your Harmony remote to provide one of the following types of help:

• Smart help

Asks questions about the devices that are on during a specific Activity.

• Full help

Asks questions about all the devices in your system.

Select Full help if you find devices aren’t being controlled the way you want them to and the help on the remote is not

asking you questions about these devices.

Use the Harmony Remote Software to select the type of help you want.

Using the Remote Assistant

Extra help is available from your remote by turning on the Remote Assistant.

While the Help button helps you solve device problems within an Activity, the Remote Assistant teaches you how to

use your Harmony remote. The following is an example of the type of help the Remote Assistant offers:

Example

If any devices are not set up correctly, press “Help” now.

Use the Harmony Remote Software to turn on/off this feature.

Controlling Individual Devices

This section provides you with an overview of three modes you can use to access specific features of each device.

Device Mode

Press Devices to enter device mode. Device mode gives you access to all the possible commands for each device

included in your Harmony remote configuration. To access device mode you do not need to be in an Activity. However,

you should never need to use Device mode during normal use of your Harmony remote. This mode should only be used

to send a specific command to a specific device.

You can eliminate the use of device mode by customizing your Activities.

User Manual Harmony 785

Version 1.2 Page 7

Example

You can put commands on the display or customize specific buttons for the commands.

See Customizing Your Harmony Remote.

At any time, press Devices to switch into Device mode. Once in this mode, the Harmony remote will display a list of

all the devices you have in your configuration. Select a device from the list and the Harmony remote will only control

the device features for the device.

Example

If you choose Television as the device, the number, volume and channel buttons will all control your

television.

PressDevices again to return to exit Device mode.

Using the Smart Buttons

While there is a default setting for the buttons in most Activities, you can customize these buttons to send

different commands. See Changing the Behavior of Buttons Within an Activity.

Using System Options

Press System Options on your Harmony remote to:

• Set the time and date.

• Turn the slide show on/off.

• Temporarily turn the Remote Assistant on/off. See Using the Remote Assistant.

Customizing Your Harmony Remote

All customization of your Harmony remote is done from the Harmony Remote Software:

Use the Harmony Remote Software to:

Troubleshoot

• Click Troubleshoot when your Harmony remote isn’t controlling your system correctly.

View Activities

• Click the Activities tab to add or delete Activities.

• Click Settings to change the specific settings (e.g. the name of an Activity) for an Activity.

Example

To have more than one Activity of a given type (e.g. If you have both a cable converter and a satellite receiver,

you can add a second Watch Television Activity) click Add an Activity. When you’re done, rename the

Activities to help you distinguish between them (e.g. For the Watch Television Activity you could rename one

from “Watch Television” to “Watch Cable” and the other to “Watch Satellite”.)

View Devices

• Click Devices tab to add or delete entertainment devices.

• Click Settings to change the specific settings for a device you have already set up.

View Remote Settings

• Click Remote Settings to change the remote’s settings.

Update Remote

• Click Update Remote after you have made changes your configuration and settings. This will ensure you

have the latest configuration and settings on your Harmony remote.

Customizing the Display on the Harmony Remote

This section provides information that will help you to customize the commands and options listed on the Harmony

remote’s display.

The display resolution on the Harmony Remote is 160 x 128 pixels.

The Harmony remote comes with a set of defaults, which you can change to make the display look the way you want it

to:

• Select or add your own backgrounds for the display.

• Add your icons for your favorite channels (you can upload your own icons up to a maximum of 160 KB (file

size), and 24-bit .png, .bmp, .jpg, or .gif .)

User Manual Harmony 785

Version 1.2 Page 8
