Logitech G502 HERO Manual de usuario

G502 HERO

Setup Guide

Guide d’installation

English . . . . . . . . . . . . . . . . . . . . . 3

Français . . . . . . . . . . . . . . . . . . . .13

Español . . . . . . . . . . . . . . . . . . . . 23

Português . . . . . . . . . . . . . . . . . . 33

English 3

Your G502 is ready to play games.

If you would like to customize your G502,

refer to the next section.

You can customize the three onboard

proles of the G502— button programming,

lighting color, lighting eects, and tracking

behavior—using the Logitech Gaming

Software. Download this free software

and learn how to customize the G502

at www.logitechG.com/support/g502-hero

USB

4English

4 To adjust the weight and balance of your G502,

rst open the weight door by grasping

the mouse rmly in your right hand and pulling

the tab down with your left thumb.

English 5

5 You can place up to ve 3.6 gram weights

in a number of dierent orientations.

Experiment with dierent positions

for the weights to nd an overall weight

and balance that feels right for you.

6English

6 After inserting the weights, close the weight

door by inserting the tabs on the weight door

into the slots on the left side of the mouse

and rotating the door down until the magnet

holds the weight door rmly closed.

English 7

11 fully programmable buttons

1. Left (Button 1)

2. Right (Button 2)

3. Wheel click (Button 3)

4. Back (Button 4)

5. Forward (Button 5)

6. DPI Shift (Button G6)

7. DPI Down (Button G7)

8. DPI Up (Button G8)

9. Scroll left (wheel tilt left)

10. Scroll right (wheel tilt right)

11. Prole select (Button G9)

12. Wheel mode shift (not programmable)

8English

Prole 1*

(High-DPI

gaming)

Prole 2*

(Low-DPI gaming)

Prole 3*

(Standard:

unshifted)

Prole 3*

(Standard:

G-shifted)

DPI values 1200, 2400, 3200,

6400

400, 800, 1600,

2400

2400 2400

Default DPI

value

2400 1600 2400 2400

DPI Shift value 1200 400 N/A N/A

Reports/sec 1000 1000 500 500

1Button 1

(left click)

Button 1

(left click)

Button 1

(left click)

Button 1

(left click)

2Button 2

(right click)

Button 2

(right click)

Button 2

(right click)

Button 2

(right click)

3Button 3

(middle click)

Button 3

(middle click)

Button 3

(middle click)

Ctrl-T

English 9

Prole 1*

(High-DPI

gaming)

Prole 2*

(Low-DPI gaming)

Prole 3*

(Standard:

unshifted)

Prole 3*

(Standard:

G-shifted)

4Button 4 (back) Button 4 (back) Button 4 (back) Ctrl-Shift-Tab

5Button 5

(forward)

Button 5

(forward)

Button 5

(forward)

Ctrl-Tab

6DPI Shift (sniper) DPI Shift (sniper) G-Shift (double

functions)

N/A

7DPI Down DPI Down Ctrl-C Ctrl-X

8DPI Up DPI Up Ctrl-V Ctrl-Z

9Scroll left Scroll left Scroll left Ctrl-F4

10 Scroll right Scroll right Scroll right Ctrl-Shift-T

11 Next prole Next prole Next prole Ctrl-0

10 English

Onboard proles

The G502 has three precongured proles, one

each for high sensitivity gaming, low sensitivity

gaming, and standard mouse usage. Use Button

9 (see mouse drawing) to rotate through

these default proles. When you change proles,

the DPI indicator lights will change color to

blue for three seconds and will indicate the new

mode as shown here:

DPI indicators

DPI values are shown using the three LEDs

indicated in the mouse drawing. The image

below shows which DPI value is being indicated

by the LED panel.

Prof. 1 Prof. 2 Prof. 3

DPI 1 DPI 2 DPI 3 DPI 4 DPI 5
