Lockly LATCH EDITION SECURE PGD628 Manual de usuario

INSTALLATION

MANUAL

SECURE

LATCH EDITION

INSTALLATIONOVERVIEW & PARTS LIST

Exterior

L K

Adhesive

PM5 x 25MM Screw, Door thickness 1-19/50"~1-69/100"(35~43mm)

Battery Cover

BM4 × 8MM Screw

Interior Assembly

Mounting Plate

Interior Adhesive

Strike Plate

KA4 x 20MM Screw

Locking Pin

Spindle

Slotted Barrel

Extension

Exterior Adhesive

Exterior Assembly

F1 Latchbolt F2 Latchbolt

Keys

Latch

PM5 Screw

BM4 x 32MM Screw

PM5 x 35MM Screw, Door thickness1-69/100"~1-97/100"(43~50mm)

M 1

M 2

*NOTE: You can either use the exterior adhesive (T) or slotted barrel extension (U) to stabilize the

exterior part. Slotted barrel extension (U) requires drilling an extra hole. Use provided Template

for drilling instructions if needed.

2-3/4"

(70mm)

2-3/8"

(60mm)

Measure distance between the center of the hole tothe edge of door:

Use F1 if 2-3/8"(60mm) or F2 if 2-3/4"(70mm)

Clamping Tool

For changing

handle orientation

Positioning Rod

For installing mounting

plate (LK)

Activation Card

This lock can be installed for both right swing and left swing doors. The lock ships ready for a right swing door installation.

If you wish to change the orientation of the lock for a Left Swing door, go to Step 3 for instructions.

LOCKLY.COM | HOTLINE: +1(669) 500-8835 | EMAIL: [email protected]OM

AUTHENTIC LOCKLY PRODUCT | DESIGNED IN USA | CARD IS PRINTED WITH A SPECIFIC PATTERN

SECURE ADDITIONAL DOORS AT A DISCOUNT:HTTP://WWW.LOCKLY.COM/MORE

ACC20200402

LOCK SERIAL

ACTIVATION CO DE

PGDxxxxxxxxxx

xxxxxxxx SCAN & SAVE

GETTING STARTED - YOUWILL NEED

All the parts you need to install the Lockly®Secure Latch Edition is included in your package.

You will require the following tools with some optional items for ease of installation.

Phillips Screwdriver

Flathead Screwdriver

Ruler

Pliers

Required Tools Optional

Screwdriver with drill bits

Drilling is not required to install the lock, and is optional. However if you are installing

your lock on a brand new door, a drill is required if there are no holes prepared for

lock installation.

STEP 1: PREPARING THE DOOR

1.1

If you are installing the Lockly®Secure

smart lock on an existing door, please

remove existing door hardware and latch

or bolts before installing the new lock.

You can remove most existing door locks

with a screwdriver.

If you are having problems removing

your existing door lock or unsure if what

you are doing can damage the existing

door, please contact a locksmith or the

current door hardware manufacturer for

assistance.

1.2

After removing the existing lock, make sure your door is properly prepared. If you

need to drill holes in your door, please use supplied templates to assist.

1 " - 2"

(35mm - 50mm)

2 "

54mm

25mm

Backset

2" (60mm)

or 2 " (70mm)

IMPORTANT NOTICE

Measure and confirm your door is

between

1 " - 2" (

35mm - 50mm).

Measure and confirm the hole in the

door is

2 "

(54mm).

Measure and confirm that the backset

is between

2 "

(60mm) to

2 "

(70mm).

Measure and confirm that hole in the

door edge is 1” (25mm).

1.3

1.4

1.5

1.6

* You are not required to drill an extra hole on your door. We have provided double

sided Adhesive tape for you to help stabilize the lock during installation. Only drill a hole

if you wish to have added stability. Please refer to the provided template for drilling if

needed.

STEP 2: INSTALLING THE LOCKSET

2.1 Measure the distance between center of front door hole to the edge of your door

and select the correct lockset. Select F1 if 2-3/8"(60mm) or F2 if 2-3/4"(70mm).

2-3/4"

(70mm)

2-3/8"

(60mm)

F 1 F 2

2.2 Install the lockset with the slanted side of the latch facing towards the closing direction.

Slanted side Facing Door Frame when closing Slanted side Facing Door Frame when closing

Example 1 Example 2

2.3 Secure lockset with provided screws, labelled G (Step 2.1) as shown.

STEP 3: CHANGING HANDLE ORIENTATION FOR

RIGHT OR LEFT SWING DOORS

The lock ships default for Right Swing Doors. You may skip STEP 3 if your door is a

Right Swing Door. To change your door handle orientation for a left swing door,

please continue reading.

How to determine if your door is a Right Swing or Left Swing door?

While facing the door, if the door hinges are on the right side of the door, you have a Right Swing

Door. If the hinges are on the left side of the door, you have Left Swing Door.

Changing the Exterior Handle Orientation

Insert the key and rotate to align the

two white dots as shown in the picture.

IMPORTANT:

The following steps are only possible

when these two white dots are aligned!

3.1

Use the provided Clamping tool

(R) to push in the two metal pins

at the base of the lock handle,

located at the 3 o’clock and 9

o’clock positions, and remove the

handle once the pins are

compressed.

3.2

Rotate the handle 180 degrees to

the other side of the lock.

Using your fingers, press the two

pins located on the left and right

side of the the lock to insert the

handle back onto the lock.

3.3
