S4 SERIES PHOTOELECTRIC PROTECTOR
INSTALLATION AND USAGE MANUAL
SHANDONG LAIEN OPTIC-ELECTRONIC TECHNOLOGY CO. ,LTD.
Please read this document carefully and thoroughly before installation and operation,
because the correct and optimum use of this product is important for the personal safety.
Please give the user this document with the photoelectric protector if you are an agent, a
dealer or a machine manufacturer which forms a complete set, because this document is
important to guide the user correctly to install and operate.
Prohibitions:
It's prohibited to reproduce and reprint this installation and usage manual of some or
all of the content without permission.
On the content, it will be modied because of the improved device or other reasons in
the future. Please understand without notication in advance.
This manual is made professionally, but there is still something imperfect. If you have
found the unclear place, wrong pages or missing pages, etc, please notify our local
LNTECH ofce of the nearest distributor.
This operating instruction manual is designed to address the technical personnel of the machine
manufacturer or the machine operator in regards to safe mounting, wiring, commissioning,
operation and maintenance of the photoelectric protector.
The photoelectric protector (herein after called "protector") is electro-sensitive protective equipment
(ESPE); it is also named "safety light curtain".
It is used in a vertical or horizontal position, can be satisfied wherever hazardous points-of-
operation and danger areas require safeguarding.
The protector only protects the rectangular region of the light curtain. If it is installed not to be
correct, either operation is not according to the instruction manual and the correlation security
working rule, or the stamping equipments have faults, or other possible causes, it is unable to exert
the protective function.
Therefore, before installation and operation the protector, please read carefully and understand
fully related items in the instruction manual, in particular apprehend about the items stressed as
"Warning", "Attention" and so on.
In operating, please understand correctly and fully the operating performance about the protector,
operate strictly according to the requests proposed in the instruction manual, stipulate the relevant
security working rule.
Application is only introduced that the protector is used on the press in this instruction manual;
other applications may be consulted this instruction manual.
The contents of this instruction manual are explained by Shandong Laien Optic-electronic
Technology Limited Company, if you have any unclear items, please contact us.
Foreword
List of Contents
1 Important Information
1.1 Summarize.....................................................................................................................................1
1.2 The Makeup of This Manual...........................................................................................................1
1.3 Control Dependability ..............................................................................................................1
1.4 EU Directives Verification..................................................................................................1
1.5 EU Standards Verication..............................................................................................................2
1.6 GB Standards Verication..............................................................................................................3
2 Basic Introduction
2.1 Terminology...................................................................................................................................4
2.2 Usage.........................................................................................................................................5
2.3 Features ....................................................................................................................5
2.4 Relations between Light Axis Pitch and Detection precision...........................................................5
2.5 Technical Parameters......................................................................................................6
2.6 Specications.................................................................................................................................7
2.7 Working schematic drawing.....................................................................................................7
3 User self-service function
3.1 User self-service function introduction.................................................................................8
3.2 The function and operation of the handheld device.......................................................................9
3.3The function and operation of the self-service software.................................................................10
4 Installation
4.1 To Determine a Safety Distance...................................................................................................12
4.2 To Determine Placement Position................................................................................................14
4.3 Installation of multiple protectors.............................................................................15
4.4 Reflecting Surface Influence around the Light Curtain...................................................16
4.5 Accessories..................................................................................................................................17
4.6 Installation tools ......................................................................................................................... 19
5 S4 Series Light Curtain’s installation
5.1 S4 parts’ function description ....................................................................................................19
5.2 Specication sheet and external dimensions...............................................................................20
6 Wiring of S4 Series Sensor
6.1 Wiring of NPN Output Type Protector............................................................................................21
6.2 Wiring of PNP Output Type Protector...........................................................................................22
6.3 The signal table............................................................................................23
6.4 Cascade light cutrain............................................................................................23
6.5 Warning of wiring............................................................................................24
List of Contents
7 Debugging of S4 sensors
7.1 Debugging of emitter and receiver.............................................................................................25
7.2 Operation Test of Entire System....................................................................................................25
8 Operation, Check and Maintenance
8.1 Attention.......................................................................................................................................26
8.2 Check and Maintenance...............................................................................................................27
9 Simple Examination and Repair
9.1 Simple Troubles of System.........................................................................................................28
1
1 Important Information
Summarize
The Makeup of This Manual
Control Dependability
EU Directives Verication
1.1
1.2
1.3
1.4
This manual contains instruction ,operation,installation,wiring,maintenance and troubleshooting of
the S4 series production.
This manual don’t offer the instruction of the machine installed the S4 series.The instruction of
related machine operation may reference the instruction of machinery manufacture.
This manual contains following chapters:
Important information contains emphasis information,the makeup of this manual,control
dependability information,certicate,directive and so on.
Basic introduction contains the usage,features, working schematic drawing and
terminology,technical parameter data and specication of the S4 series photoelectric protector.
Setting and introduction of the user self-service function
Attentions for installation of the protector must be noticed contains calculating a safe distance,
determination of placement position and attentions for neighboring placement.
The function of S4 series parts and shell size.
Wiring contains wiring instruction for controller terminals,wiring for NPN/PNP output.
Ajustment
Check and maintenance
Troubleshooting
The“control dependability”is main indicated that the design ,structure,and connection of the
equipment,system and interface should be fulled with that if the single fault in any of these parts
occurs, it shuld not hinder the implementation of the normal stop action, it should be to prevent the
start up of the follow-up action before troubleshooting.
S4 series incorporate dual-channel redundancy and self-diagnosis function.
This design complys with IEC/EN 61496-1 and IEC/pr EN 61496-2 standards and meets the
requirements for a Type 4 Active Optoelectronic Protective Device, the safest level for safety
products. A single fault or an accumulation of faults in the type 4 device should not lead to the loss of
the safety function.It will keep the safety function for ever.
Directives No.
Machinery Directive 2006/42/EC
Low Voltage Directive 2006/95/EC
EMC Directive 2004/108/EC
2
The installation and usage of the S4 series must comply with applicable EU standards(not all list)
Directives No.
EN ISO 13849-1 Safety of machinery -- Safety-related parts of control systems -- Part 1:
General principles for design
EN 61496-1 Machinery safety-Electro-sensitive protective equipment-Part 1:General
requirements and tests
IEC/pr EN 61496-2 Machinery safety-Electro-sensitive protective equipment-Part 2: Active opto-
electronic protective devices
EN 60204-1 Machinery safety - Machinery electrical equipment
EN ISO 12100-1 Safety of machinery - Basic concepts, general principles for design - Part 1:
Basic terminology, methodology
EN ISO 12100-2 Safety of machinery - Basic concepts, general principles for design - Part 2:
Technical principles
EN ISO 14121-1 Safety of machinery - Risk assessment - Part 1: Principles
IEC 61508-1…-7 Functional safety of electrical/electronic/programmable electronic safety-
related systems
EN 62061 IEC 62061: Safety of machinery - Functional safety of electrical, electronic
and programmable control systems
EN 292 Safety of machinery; basic concepts, general principles for design
EN 999 Safety of machinery - The positioning of protective equipment in respect of
approach speeds of parts of the human body
EN 13857 Safety of machinery -- Safety distances to prevent hazard zones being
reached by upper and lower limbs
EN 692 Machine Security - Mechanical Press
EN 693 Machine Security - Hydraulic Press
EN 201 Injection Molding Machine
EU Standards Verication
1.5
Directives No.
EN 292 Safety of machinery; basic concepts, general principles for design
EN 60204-1 Machinery safety - Machinery electrical equipment
EN ISO 13849-1 Safety of machinery -- Safety-related parts of control systems -- Part
1: General principles for design
IEC/EN 61496-1 Machinery safety-Electro-sensitive protective equipment-Part
1:General requirements and tests
IEC/pr EN 61496-2 Machinery safety-Electro-sensitive protective equipment-Part
2:Active opto-electronic protective devices
The S4 series is designed in compliance with the following EU standards.
3
GB Standards Verication
1.6
The S4 series must comply with the following GB standards
Directives No.
GB 5226.1 Machinery safety - Machinery electrical equipment
GB/T 16855-1 Safety of machinery -- Safety-related parts of control systems -- Part 1:
General principles for design
GB/T 19436-1 Machinery safety-Electro-sensitive protective equipment-Part 1:General
requirements and tests
GB/T 19436-2 Machinery safety-Electro-sensitive protective equipment-Part 2:Active
opto-electronic protective devices
GB 4584-2007 Specication of active opto-electronic protective devices for presses
GB/T 15706-1 Safety of machinery - Basic concepts, general principles for design -
Part 1: Basic terminology, methodology
GB/T 15706-2 Safety of machinery - Basic concepts, general principles for design -
Part 2: Technical principles
GB/T 16856-1 Safety of machinery - Risk assessment - Part 1: Principles
GB/T 20438-1…-7 Functional safety of electrical/electronic/programmable electronic
safety-related systems
GB 27607-2011 Mechanical Press - Safety requirements
GB 28243-2012 Mydrolic plate bender- Safety requirements
GB 28240-2012 Shears—Safety requirements
4
Terminology
Emitter
The emitter consists of emitter units; it can emit the modulated light signal.
Sensor
The sensor consists of emitter units and (or) receiver units. It can emit and (or) accept the modulated
light and form light curtain with a reector (or through reector/mirror). Output a light passing signal
or light intercepting signal to controller. In order to be advantageous for the description, sometimes
also refers to the emitter and (or) the receiver.
Reector
The reector used to reect the modulated light from emitter units to receiver units.
Mirror
The mirror used to change the light direction of transmission from emitter units to receiver units, to
form multi-sides protection light curtain.
Signal cable
The signal cable used to connect the emitter, receiver and the controller, or connect the sensor and
controller.
Light curtain device
All the components that the sensor and the reflector of the reflection type, the emitter and the
receiver of the direct protection type and the reector, the emitter and the receiver of the multi-sides
protection type, produce the light curtain.
Light beam
The emitter unit sends out the infrared light, forms a bunch of parallel light after passing optics part.
Beam center line
It is the middle line of the light beam.
Light axis pitch
The distance of optical axis between the neighboring two bunches of light, uses to express the light
beam density of light curtain, the optical axis spacing is smaller, and the light beam is more crowded.
Detection precision
The light curtains' ability to detect the size of test piece, it means when the light curtain is shaded
anywhere, active opto-electronic protective device can have induction function and when the device
keeps off state, it needs the diameter value of the smallest test piece.
Protective range
The protector can protect length scope.
Light beam number
It is quantity of the light beams that sending out from emitter, the same as the quantity of the emitter
units in the emitter.
Light passing
It is the output state of the protector when the light curtain is not intercepted.
Light intercepting
It is the output state of the protector when the light curtain is intercepted.
2 Basic Introduction
2.1
5
Usage
The Photoelectric Protector is also named Safety Light Curtain, Safety Grating and so on. It is mainly
used for mechanical processing equipment, hazardous work areas, machinery and equipment to
prevent injury to the operator and caused injury or accident by into the dangerous region, to protect
personal safety.
The protector can achieve all trip protection for press which its slide could be stopped by brake at
any place in its slide’s trip, or can achieve protection of the trip between 30°~180° by using cam.
Using the protector in industrial manipulators, mould shapers, packaging equipments, automatic
equipments, jointing pipelining and other operating regions with danger, it can give an alarm after
entering the hazardous area or interlock with the safety system of the equipment, to protect personal
safety.
Features
2.2
2.3
2.4 Relations between Light Axis Pitch and Detection precision
Figure 2-1 Relations between light axis pitch and protection object
Specications Varieties, Application Wide
The protective height of conventional products
is from 113mm to 1493mm;
Pefect self-checking function
Ensure that the photoelectric protector don't
send the mistaken signal to the controlled
electrical equipment when it has faults.
The Self-locking Function
If preset the self-locking function, the press
slide stops moving after interception of light
curtain. But the press can not be restart, when
the light curtain is recovered to passing through
state. It shall be restart by pressing the reset
button.
Immunity
For the electromagnetism signal,the intense
lamplight,the welding and surrounding light
source has better immunity.
Durable life and High reliability
Good Anti-vibration
EDM Function
Auxiliary Focusing Function
Floating Blanking Function
Fixed Blanking Function
Wiring Indicating Function
Troubles Indicating Function
Second Trigger Function
Elective output mode(NPN or PNP)
P is light axis pitch,
R is detection precision,
D is the width of the lens(6.5mm)
R=P+D
R=14mm,protect the gure
R=21mm,protect the hand or ngure,
R=36mm,protect the arm or hand
6
Performance characteristics
Protective range 0～6000mm
Protective height H=(beams-1)×light axis pitch
Detection precision 14mm, 21mm,36mm
Light axis pitch 7.5mm,15mm,30mm
Light source Infrared light, 850nm
EAA Max 2.5°
Resistance to light interference 10000Lux (angle of incidence >=5°)
Electrical properties
Operating power DC24V±15%
Power consumption <10W(without load)
Control output Dual transistor output（PNP or NPN）、load current
100mA，residual voltage below 1.4V
Auxiliary output Single transistor output （PNP）、load current 120mA，
residual voltage below 1.4V
Response time 5～35ms
Status indicator
Emitter light passing(green),light intercepting(red),LED indicator
light;state,fault indicator(LED display)
Receiver light passing(green),light intercepting(red),LED indicator
light;state、fault indicator(LED display)
Noise immunity IEC61000-4-4：level Ⅲ/IEC61000-4-2：level Ⅲ
Insulating resistance ＞100MΩ
Dielectric strength AC1500V，60s
Physical characteristics
Ambient temperature -10℃～55℃
Humidity 20℃,RH≤85%
Vibration
Frequency range: 10 to 55 Hz
Sweep rate: 1 octave/min
Amplitude: 0.35 ± 0.05 mm.
Number of sweeps: 20 for each of three mutually
perpendicular axes
Sealing IP65
Shell material Sensor: Aluminium alloy;
Light lter: PMMA
Technical Parameters
2.5
The protector technical parameters sheet
Tabla de contenidos
