Livescribe echo smartpen Manual de usuario
Interactive Getting Started Guide
Interaktive Einführung
Guide de démarrage interactif
Guía de introducción interactiva
Guida introduttiva interattiva
LS_Echo_EFIGS_GSG_PC1_01
There are four parts of the
EchoTM smartpen system
you will need to know:
Power button
Micro USB cable
Microphone
Built-in speaker
Turn your Echo smartpen on
Sharing Smartpen
Applications
Smartpen
and Paper
LivescribeTM
Desktop
Tip:
If your smartpen doesn’t power on, you
may need to charge it. To charge, make
sure your computer is on, and connect
your smartpen to your computer with the
included USB cable. A full charge may
take up to 2.5 hours.
English Page 1
LS_Echo_EFIGS_GSG_PC2_01
left
handed
right
handed
ENGLISH
Setting up your
EchoTM smartpen
Time and date
Tap “set date” with your1.
smartpen, then tap
numbers to set the date.
Example: tapping 041510
sets to the April 15, 2010.
Tap “set time”, then
2.
enter the time.
Example: 1218PM sets
the time to 12:18 PM.
The printed buttons in this guide really
work! Use your Echo smartpen to tap
within the orange framed areas below.
It’s important to set the time and date on your Echo
smartpen because your recorded notes are time-
stamped with the date and time they are created.
Tip:
Tap the buttons in this guide with the tip
of your smartpen to hear additional information.
Display orientation
Tap a button to set
your screen orientation.
Tap to choose your locale,
then tap a second time to
confirm. To further customize
settings, navigate to the
Settings menu with the Nav
Plus control.
English Page 2
LS_Echo_EFIGS_GSG_P2_01
Smartpen
and Paper
English Page 3
How can I record?
How can I save a Paper
Replay session?
What is Paper Replay?
Step 1
How can I share
a Paper Replay
session?
Where can I learn more about Paper Replay?
Paper Replay part 1:
Learn about Paper ReplayTM
LS_Echo_EFIGS_GSG_P3_01
Paper ReplayTM part 2:
Record a session
stoprecord
English Page 4
Smartpen
and Paper
Think of your favorite snack, and why1.
you like it.
Get ready to2. write and speak.
Tap3. the “record” button.
Write4. the name of your favorite snack on
the lines below.
As you write,5. say the name of the snack,
and describe why you like it.
Tap6. the “stop” button above.
Tap7. on your written words above.
Step 2
LS_Echo_EFIGS_GSG_P4_01
Paper ReplayTM part 3:
Audio playback
How can I play back recorded audio?
English Page 5
Smartpen
and Paper
Tap the first word of
these notes to hear
Aunt Lucy describing
her recipe.
Step 3
Lucy's cookies
1. Wet ingredients
2. Dry ingredients
Mixing
3. Bake
Gary?
LS_Echo_EFIGS_GSG_P5_01
Paper ReplayTM part 4:
Audio playback controls
How can I control audio playback?
stoppause jump
bookmark0% 100%jump to position
volumeplayback speed
English Page 6
Smartpen
and Paper
Step 4
Tap these controls
to hear how they
affect the audio of
Aunt Lucy’s recipe.
LS_Echo_EFIGS_GSG_P6_01
Download Livescribe
Desktop from
www.livescribe.com/install
and follow the installation
instructions
Livescribe Desktop allows you to:
Save and play back notes• on
your computer
Search your handwritten notes for•
keywords
Organize and manage your notes•
Export your notes and audio•
Upload notes and audio to your•
Livescribe account
Step 5 LivescribeTM
Desktop
English Page 7
LS_Echo_EFIGS_GSG_P7_01
Smartpen applications
What are smartpen applications?
Make your EchoTM smartpen even smarter.
Download the latest applications at
www.livescribe.com/store
Step 6
English Page 8
Smartpen
Applications
LS_Echo_EFIGS_GSG_P8_01
How to launch a smartpen
application: Piano
Double-tap1. (tap twice in the same spot in
less than a second) on the center (D) of
the Nav Plus below.
Tap2. the down arrow (E) repeatedly until
you see “Piano” on the smartpen screen.
Tap3. the right arrow (C) to launch Piano.
Follow the instructions in4. audio and
on the smartpen screen to draw your
piano below.
Tap5. the piano to play it.
Can I draw sharps and flats?6.
piano below.
Tap5.
the piano to play it.
Step 7
The “Nav Plus”
B
E
D
AC
English Page 9
Left arrow
Up arrow
Right arrow
Center
Down arrow
Smartpen
Applications
LS_Echo_EFIGS_GSG_P9_01
