eBEAM SMARTMARKER Manual de usuario
Userguide
www.e-beam.com
1
Components
Bluetooth
status
Power status
Smartmarker
Sensor
Digital
Marker
Sleeve
power
status
marker
release
Digital
Marker
color ring
2
single charger
USB cable
eraser
magnetic plate
for sensor
USB dongle
magnetic plate
for eraser
eraser felt
manual
www.e-beam.com
ALuidiatechnology
www.e-beam.com
3
Main Key Features
memory mode
Bluetooth mode
power on/off
new page or
duplicate page
4
Download and Install
eBeam Note
About the USB Dongle
The USB dongle is for Windows users only.
In order to connect to the eBeam
Smartmarker, plug the USB dongle in to your
Windows PC. Make sure you install eBeam
Note from www.e-beam.com
eBeam Note platform available on
iOS the App Store
Android™ Google Play™
Mac OS X® the Mac App Store
Windows e-beam.com
Phone
Tablet
Computer
5
Installing the
eBeam Smartmarker
1
2
3
Attach the magnetic
mounting bracket
to the back of the
sensor by lining
up the bump on
the bracket with
the indent on the
back of the sensor.
Remove the protective backing
on the tape and place the sensor
firmly onto the surface. Press firmly
for best adhesion.
* When you attach it to the surface, make sure you
leave a 2in (5cm) margin between the capture area
and the side of the sensor.
Complete the installation by making
sure your devices are charged.
Sensor
• 3 hours of charging
• 8 hours of
continuous usage
Digital Marker
• 3 hours of charging
• 15 hours of
continuous usage
capture area
2in
6
4
5Power on the sensor.
Windows users
should connect the
USB dongle to their
computer at this time.
Download the app.
www.e-beam.com/smgo
iPhone & iPad
iPhone & iPad
Android
Windows
power on/off
7
6
7
8
Start the eBeam Note application.
eBeam Note will search for your sensor.
Once the sensor is found, select the sensor
name on the list.
If the sensor is not found, check the scenarios listed
in the message box to help you find a solution.
1) Check if the sensor is powered on
2) Check if the sensor is on Bluetooth mode
3) Check if the sensor is already connected with other users
4) Check if the sensor and device are located within 5m
8
9The application will notify you when your
sensor is connected.
TIP: No matter where you are in the mobile application, when
you start writing, you will automatically be navigated to a new
page screen where everything you write is captured.
Main Menu Screen
Previews Screen
Page Screen
9
Memory Mode
Memory mode lets you write and save notes to the
sensor without connecting a device.
Press the Bluetooth button once on the bottom
left side of the sensor. When the LED light beside
memory mode is on, everything you write will be
saved to memory.
Sensor memory can save up to 20,000 pages.
TIP: Notes saved on the sensor can only be
downloaded by connecting the USB cable to your
PC (Windows/Mac).
For more details, navigate to the ‘help’ menu in the
eBeam Note desktop application.
Bluetooth mode
or
Memory mode
