PRODUCT DATA

SPA3102

Voice Gateway with Router

Model No.

Intelligent Call Routing

Gateway Solution for VoIP

Toll Quality Voice and

Carrier-Grade Feature

Support

The SPA3102 delivers clear,

high-quality voice

communication in diverse

network conditions. Excellent

voice quality in a demanding IP

network is consistently

achieved via our advanced

implementation of standard

voice coding algorithms. The

SPA3102 is interoperable with

common telephony equipment

like voicemail, Fax, PBX, and

interactive voice response

systems.

Large-Scale Deployment and

Management

The SPA3102 offers all the key

features and capabilities which

service providers can provide

customized VoIP services to

their subscribers. The SPA3102

can be remotely provisioned

and supports dynamic, in-

service software upgrades. A

secure profile upload saves

providers the time, expense,

and hassle of managing and

pre-configuring or re-

configuring customer premise

equipment (CPE) for

deployment.

Ironclad Security

Linksys understands that

security for end users and

service providers is a

fundamental requirement for a

solid, carrier-grade telephony

service. The SPA3102 supports

secure, standard

encryption-based methods for

communication, provisioning

and servicing.

PRODUCT DATA

SPA3102

Model No.

Telephony

• Service Authentication via PIN, Digest, Caller ID (Bellcore Type 1)

• Per Call Authentication and Associated Routing

• Least Cost Routing Support

• Impedance Agnostics - 8 Settings

• Call Waiting, Cancel Call Waiting, Call Waiting Caller ID Detection (Bellcore Type 1)

• Caller ID with Name/Number (Multi-national Variants)

• Caller ID Blocking

• Call Forwarding to PSTN or VoIP Service: No answer, Busy, All

•DoNotDisturb

• Call Transfer

• Three-way Conference Calling with Local Mixing

• Message Waiting Indication - Visual and Tone Based

• Call Return

• Call Back on Busy

• Call Blocking with Toll Restriction

• Delayed Disconnect

• Distinctive Ringing - Calling and Called Number

• Off-hook Warning Tone

• Selective/Anonymous Call Rejection

• Hot line and Warm Line Calling

• Speed Dialing of 8 Numbers/Addresses

• Music on Hold

• Fax: G.711 Pass Through or Real Time Fax over IP via T.38

Product Specific (SPA3102)

• VoIP to PSTN (USA) Service Call Origination and Termination

• PSTN (USA) to VoIP Service Call Origination and Termination

• Single Stage and Two Stage Dialing

• Forward Calls to VoIP service - Selective, Authenticated, All

• Forward Calls to PSTN service - Selective, Authenticated, All

• PSTN Line Sharing with Multiple Extensions

• Automatic PSTN Fallback (Loss of Power or IP Service to Unit - with Quiescence to Normal Operations)

• Advanced Inbound and Outbound Call Routing

• Independent Configurable Dial Plans - Up to 8

•ForcePSTNDisconnection

• Sequential Dialing Support

VoIP to PSTN Authentication and Routing Features

• VoIP to PSTN Gateway Enable/Disable

• VoIP Caller Auth Method (None, PIN, HTTP Digest)

• VoIP PIN Max Retry Setting

• One Stage Dialing Enable/Disable

• VoIP Caller ID Pattern Matching

• VoIP Access Allowed Caller List (No Further Authentication)

• VoIP Caller PIN and Associated Dial Plan

Features

PRODUCT DATA

SPA3102

Model No.

PSTN to VoIP Authentication and Features

• PSTN to VoIP Gateway Enable/Disable

• VoIP Caller Auth Method (None, PIN, HTTP Digest)

• Ring Through to FXS Enable/Disable

• Ring Through Tone - Configurable

• Caller ID (Bellcore Type 1) for VoIP Service Access

• Caller ID Enable/Disable

• PIN Max Retry Settings

• Access Allowed Caller List (No Further Authentication)

• Caller PIN and Associated Dial Plan

• Least Cost Routing (via Outbound VoIP - Line1 Dial Plan)

FXO Behavior Features

• VoIP Answer Delay Timer

• PSTN Answer Delay Timer

• VoIP PIN Digit Time-Out Timer

• PSTN PIN Digit Time-Out Timer

• PSTN-to-VoIP Call Max Dur Timer

• VoIP-to PSTN Call Max Dur Timer

• PSTN Ring Through Delay Timer

• PSTN Dialing Delay Timer

•VoIPDIGRefreshIntervalTimer

• PSTN Ring Time-out Timer

PSTN Disconnection Detection Features

• CPC (Removal of Tip/Ring Voltage Momentarily)

• PolarityReversal

• Long Silence (Configurable Time Setting)

• Disconnect Tone (e.g. Reorder Tone)

• Silence Threshold

International Control Features

• FXO Port Impedance - Configurable to 16 settings

• Ring Frequency - Configurable

• SPA to PSTN and PSTN to SPA Gain Settings

• Ring Frequency - Maximum Setting

• Ring Validation Time Setting

• Tip/Ring Voltage Adjustment Setting

• Ring Indication Delay Setting

• Operational Loop Current Minimum Value

• RingTime-outSetting

• On-Hook Speed Setting

• Ringer Impedance Setting

• Line-in-Use Voltage Setting

• 1 - SPA3102 Phone Adapter Unit

•1-PowerAdapter

•1-RJ-45EthernetCable

• 1 - RJ-11 Telephone Cable

• 1- Quick Installation Guide

Package Contents

PRODUCT DATA

SPA3102

Model No.

Model

Data Networking

Voice Gateway

Voice Algorithms

Fax Capability

SPA3102

* Many specifications are programmable within a defined range or list of options. Please

see the SPA Administration Guide for details. The configuration profile is uploaded to

the SPA3102 at the time of provisioning.

MAC Address (IEEE 802.3)

IPv4 - Internet Protocol v4 (RFC 791) upgradeable to v6 (RFC 1883)

ARP - Address Resolution Protocol

DNS - A Record (RFC 1706), SRV Record (RFC 2782)

DHCP Client - Dynamic Host Configuration Protocol (RFC 2131)

DHCP Server - Dynamic Host Configuration Protocol (RFC 2131)

PPoE Client - Point to Point Protocol over Ethernet (RFC 2516)

ICMP - Internet Control Message Protocol (RFC792)

TCP - Transmission Control Protocol (RFC793)

UDP - User Datagram Protocol (RFC768)

RTP - Real Time Protocol (RFC 1889) (RFC 1890)

RTCP - Real Time Control Protocol (RFC 1889)

DiffServ (RFC 2475), Type of Service - TOS (RFC 791/1349)

VLAN Tagging - 802.1p

SNTP - Simple Network Time Protocol (RFC 2030)

Upload Data Rate Limiting - Static and Automatic

QoS - Voice Packet Prioritization over Other Packet Types

Router or Bridge Mode of Operation

MAC Address Cloning

Port Forwarding

SIPv2: Session Initiation Protocol v2 (RFC 3261, 3262, 3263, 3264)

SIP Proxy Redundancy - Dynamic via DNS SRV, A Records

Re-registration with Primary SIP Proxy Server

SIP Support in Network Address Translation Networks - NAT (incl. STUN)

Secure (Encrypted) Calling via Pre-Standard Implementation of Secure RTP

Codec Name Assignment

G.711 (A-law and µ-law)

G.726 (16/24/32/40 kbps)

G.729 A

G.723.1 (6.3 kbps, 5.3 kbps)

Dynamic Payload

Adjustable Audio Frames per Packet

Fax Tone Detection and Pass-Through (Using G.711)

Fax Pass-Though - Using G.711

DTMF: In-band & Out-of-band (RFC 2833) (SIP Info)

Flexible Dial Plan Support with Interdigit Timers and IP Dialing

Call Progress Tone Generation

Jitter Buffer - Adaptive

Frame Loss Concealment

Full Duplex Audio

Echo Cancellation (G.165/G.168)

VAD - Voice Activity Detection with Silence Suppression

Attenuation / Gain Adjustments

Flash Hook Timer

MWI - Message Waiting Indicator Tones

VMWI - Visual Message Waiting Indicator via FSK

Polarity Control

Hook Flash Event Signaling

Caller ID Generation (Name & Number) - Bellcore, DTMF, ETSI

Music on Hold Client

Streaming Audio Server - up to 10 sessions

Specifications

PRODUCT DATA

SPA3102

Model No.

Password Protected System Reset to Factory Default

Password Protected Admin and User Access Authority

Provisioning/Configuration/Authentication:

HTTPS with Factory Installed Client Certificate

HTTP Digest - Encrypted Authentication via MD5 (RFC 1321)

Up to 256-bit AES Encryption

Web Browser Administration & Configuration via Integrated Web Server

Telephone Key Pad Configuration with Interactive Voice Prompts

Automated Provisioning & Upgrade via HTTP, TFTP

Asynchronous Notification of Upgrade Availability via SIP NOTIFY

Non-intrusive, In-Service Upgrades

Report Generation & Event Logging

Stats in BYE Message

Syslog & Debug Server Records - Per Line Configurable

Per Line and Purpose Configurable Syslog and Debug Options

2 100baseT RJ-45 Ethernet Port (IEEE 802.3) -- 1 WAN, 1 LAN

1 RJ-11 FXS Phone Ports - For Analog Circuit Telephone Device (Tip/Ring)

1 RJ-11 FXO Phone Ports - For a Telco or PBX Connection

Ring Voltage: 40-55 VRMS Configurable

Ring Frequency: 10 Hz - 40 Hz

Ring Waveform: Trapezoidal and Sinusoidal

Maximum Ringer Load: 3 REN

On-hook/off-hook Characteristics:

On-hook voltage (tip/ring): -50 V NOMINAL

Off-hook current: 25 mA min

Terminating Impedance: 8 Configurable Settings including

North America 600 ohms, European CTR21

FCC (Part 15 Class B), CE, ICES-003, A-Tick Certification, RoHS

DC Input Voltage: +5 VDC at 2.0 A Max.

Power Consumption: 5 Watts

Switching Type (100-240v) Automatic

Power Adapter: 100-240v - 50-60Hz (26-34VA) AC Input

Power, Internet, Phone 1, Phone 2

Quick Installation, User, and Configuration Guides

are downloaded from www.Linksys.com

Administration Guide - Service Providers Only

Provisioning Guide - Service Providers Only

3.98 x 3.98 x 1.10 in. (101 x 101 x 28 mm)

5.11 oz. (0.145 kg)

32ºF to 113º F (0ºC to 45º C)

-13ºF to 185º F (-25ºC to 85º C)

10 to 90% Non-condensing, operating and non-operating

Security

Provisioning,

Administration &

Maintenance:

Physical Interfaces:

FXS:

Subscriber Line

Interface Circuit

(SLIC):

Reg. Compliance:

Power Supply:

Indicator Lights/LED:

Documentation:

Dimensions

Unit Weight

Operating Temp.

Storage Temp.

Operating Humidity

Environmental

The SPA3102 features the ability to connect standard telephones and fax machines to

IP-based data networks with the additional benefit of an integrated connection for

legacy telephone network “hop-on, hop-off” applications. SPA3102 users will be able

to leverage their broadband phone service more than ever by automatically routing

local calls from mobile phones and land lines over to VoIP service providers and vice

versa. If power is lost to the unit or Internet service is down, calls can be redirected to a

traditional carrier via the FXO interface.

A user calling from a mobile phone or land line will be able to reduce and even

eliminate international and long distance telephone charges by first calling their

SPA3102 via a local telephone number. The advanced authentication and call routing

intelligence programmed into the SPA3102 will route the call via the Internet to the far

end destination. In addition, when using the SPA3102 at the far end, VoIP calls placed

to that location can be either answered or further processed and routed on as a local

call to any legacy land line or mobile phone.

The SPA3102 supports one RJ-11 POTS (Plain Old Telephone Service) FXS port to

connect an existing analog phone or fax machine. The SPA3102 also supports one

PSTN FXO port to connect to a Telco or PBX circuit. The SPA3102 includes 2 100BaseT

RJ-45 Ethernet interfaces to connect to a home or office LAN, as well as an Ethernet

connection to a broadband modem or router. The SPA3102 FXS and FXO lines can be

independently configured via software controlled by the service provider or the end

user.

Installed by the end user and remotely provisioned, configured and maintained by the

service provider, each SPA3102 converts voice traffic into data packets for transmission

over an IP network. Compact in design, the SPA3102 can be used in consumer and

business VoIP service offerings including a full-featured IP Centrex environment. The

SPA3102 uses international standards for voice and data networking for reliable voice

and fax operation.

Linksys

A Division of Cisco Systems, Inc.

121 Theory

Irvine, CA 92617 USA

E-mail: [email protected]

support@linksys.com

Web:http://www.linksys.com

Linksys products are available in more than

50 countries, supported by 12 Linksys

Regional Offices throughout the world. For

a complete list of local Linksys Sales and

Technical Support contacts, visit our

Worldwide Web Site at www.linksys.com.

Specifications are subject to change

without notice. Linksys is a registered

trademark or trademark of Cisco Systems,

Inc. and/or its affiliates in the U.S. and

Other brands and product names are

trademarks or registered trademarks of

their respective holders.

PRODUCT DATA

SPA3102

Model No.

SPA3102-DS-60613A DF

SPA Model Service

Lines

Active

Calls

3-Way

Conferences

PSTN (FXO)

Connection

SPA1001 2 2 1 0

SPA2002 2 4 2 0

SPA2100/2102 2 4 2 0

SPA3000/3102 2 3 1 1

Linksys Phone Adapter Comparison Chart

Notes: The SPA2102/2100 and SPA3102 support up to 2 sessions using G.729. The SPA1001 and

SPA3000 support 1 G.729 session.

SPA3102/3000 supports 2 incoming services (proxy registrations) and an unlimited number

of outgoing VoIP services.

Otros manuales para SPA3102

Tabla de contenidos

Otros manuales de Puerta de Linksys

Linksys

Linksys WAG200G Manual de usuario

Linksys

Linksys WAG325N Manual de usuario

Linksys

Linksys WAG54GS Manual de usuario

Linksys

Linksys BEFDSR41W - ADSL Modem + Router Manual de usuario

Linksys

Linksys BEFDSR41W - ADSL Modem + Router Manual de usuario

Linksys

Linksys WAG54G - Wireless-G ADSL Gateway Wireless... Instrucciones de funcionamiento originales

Linksys

Linksys AG241 Manual de usuario

Linksys

Linksys WAG54G - Wireless-G ADSL Gateway Wireless... Manual de usuario

Linksys

Linksys WAG54G - Wireless-G ADSL Gateway Wireless... Manual de usuario

Linksys

Linksys BEFDSR41W - ADSL Modem + Router Guía

Linksys

Linksys AG241 Manual de operación

Linksys

Linksys WPG11 Instrucciones de funcionamiento originales

Linksys

Linksys Linksys WAG54GX2 Manual de usuario

Linksys

Linksys WAG54G - Wireless-G ADSL Gateway Wireless... Manual de usuario

Linksys

Linksys Mediatrix 440 series Manual de usuario

Linksys

Linksys AG241 Manual de usuario

Linksys

Linksys CG2P2WB Manual de operación

Linksys

Linksys SPA3102 Instrucciones de funcionamiento originales

Linksys

Linksys WAG54GP2 Manual de operación

Linksys

Linksys SPA400 Manual de operación

Linksys

Linksys WAG54G - Wireless-G ADSL Gateway Wireless... Manual de usuario

Linksys

Linksys AG310 Manual de usuario

Linksys

Linksys WAG354G (EU) Manual de usuario

Linksys

Linksys VGA2000 Manual de usuario

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario
